Pro-Aqua PA 03 Bedienungsanleitung
English
3
PA 03 basic device
TECHNICAL DATA
Type PA 03
Voltage 120 V - 60 Hz
Power output max. 1000 Watt
continuous control
Outer dimensions approx. 34,9 x 36,5 x 46,6 cm
(L x W x H)
CONTENTS
Operating manual
PA 03
Page
5-6 Standard accessories - the integral
components
7 Preparation
7 Basic functions
8 Cleaning with standard accessories
9 Other functions
Page
10 Care and storage
10-13 Special accessories
16 Nozzle - Direct contact
18 Safety instructions
50 Your notes / point of contact
Dear Pro-Aqua Customer!
We would like to congratulate you on the purchase of your Pro-Aqua room cleaning
systems. You have acquired a product that combines technical perfection and func-
tionality with a high degree of user comfort and modern design.
Please read the tips and instructions in this operating manual carefully to ensure
that you can enjoy your Pro-Aqua room cleaning system for many years to come.
Household TypeCAUTION
To Reduce The Risk Of Injury
From Moving Parts - Unplug
before servicing.
DOUBLE
INSULATED
WARNING
To Reduce The Risk Of Electric
Shock - Do not expose to rain.
Store indoors.
5
1. Pro-Aqua ON/OFF
switch
2. Motor control
3. Socket
4. Motor head
5. Separator
6. Fixing nut
7. Water tank
8. Closure cap
9. Suction fitting
10. Chassis and
accessory holder
11. Air exhaust grid (rear)
INTEGRAL COMPONENTS
English
6
Patent number
EP 195 47722
INTEGRAL COMPONENTS
Crevice
nozzle
Pro-Aqua suction hose (two
colours, tapered) for wet and
dry vacuuming
Air regulator
Upholstery
nozzle
Dusting brush
(round)
Suction/Blast nozzle
with flexible tube
Stainless steel
telescopic wand
Natural
hair brush
Accessory
holder
Drain
adapter
English
7
PREPARATION
1. Fill the water tank with water until the suction-device is slightly covered with
water. Your Pro-Aqua cleaning system needs this water volume for all
functions.
2. Ensure that the separator is correctly secured.
3. Mount the motor head on the water tank and secure it.
4. Please ensure when using perfumed oils that these are poured directly into the
filled tank.
Use only perfumed oils from the Pro-Aqua range. The manufacturer bears no
liability for damage caused through the use of other perfumed oils.
BASIC FUNCTIONS
Air cleaning
Position the Pro-Aqua in the room and let it run for
a few minutes (time depends on the room size).
Vacuumed dust particles and odors are mixed with
the water.
The freshly-cleaned air is expelled again through
the air exhaust outlet. A few drops of perfumed oil
can be added to the water in the tank if desired.
Your rooms will be filled with a pleasant odor within
a few minutes.
Recommended position for plea-
sant air washing
English
8
Natural hair brush
The natural hair brush is particularly suitable for thorough
and careful cleaning of smooth surfaces and carpets.
Crevice nozzle
This attachment facilitates cleaning in spots which until
now have been difficult to reach.
Upholstery nozzle
The small and reliable attachment for all soft and scratch-
resistant surfaces (e.g. upholstery). It facilitates surface
vacuuming in spots that are difficult to reach, without sac-
rificing positive handling characteristics.
Dusting brush (round)
The round dusting brush is suitable for cleaning plants and
other delicate objects. Attach the dusting brush directly
to the handle and open the air control to enable particu-
larly gentle vacuuming.
Drain adapter
The Pro-Aqua blast function in this powerful standard ac-
cessory enables the removal of blockages in drains.
Suction/Blast nozzle with flexible tube
Our multifunction attachment is particularly effective for
blowing out air mattresses, paddle pools or similar. It is
ideal for cleaning heating radiators when combined with
the flexible tube.
CLEANING WITH THE STANDARD ACCESSORIES
English
Blast function
Ideal for blowing out blocked drains or drying ob-
jects. Open the air exhaust outlet and fit the suc-
tion hose to this position (Fig. 1).
Vacuuming
Place the objects to be cleaned (cushions, duvets,
cuddly toys, etc.) in the vacuum bag, attach the
dusting brush, switch on the Pro-Aqua and vacuum
the air up completely (Fig. 2). Now remove the hose
and fit it to the air exhaust outlet (blast function).
Blow fresh air into the vacuuming bag. Everything
smells fresh again!
IMPORTANT! The Pro-Aqua should not be
switched off when vacuuming.
Wet vacuuming
Commence with an empty water tank for wet vacu-
uming and vacuum the water up with the Pro-Aqua
hose (Fig. 3). Ensure that the water tank is not
overfilled! The hose should be cleaned and dried af-
ter each wet vacuuming. Vacuum clean water in for
this purpose, then fit the hose to the air exhaust
outlet and push the hand piece into the suction fit-
ting. Now let the Pro-Aqua run for approximately
2 - 3 minutes and blow the hose dry (Fig. 4). It can
then be used again for all other work.
Warning: Do not vacuum water
with the electrical nozzle or hose!
Recommended position for wet
vacuuming
9
Fig. 1
Fig. 2
Fig. 3
OTHER FUNCTIONS
English
Please follow these instructions after every use:
1. Pull out the mains power plug first.
2. Drain dirty water from the water tank and then clean and dry the water tank.
3. Clean the base of the motor head with a damp cloth and then dry it.
4. Remove the separator (see Page 5), clean it thoroughly and mount it again. Ensure that the
separator engages correctly in the guide grove during this and secure it with the nut.
5. Never switch off your Pro-Aqua room cleaning system when it is filled with water or damp.
Do not close the closure caps, but open the head slightly with their assistance to allow the
water tank to dry completely.
CARE AND STORAGE
10
SPECIAL ACCESSORIES
Switchable floor nozzle
The switchable floor nozzle is particularly suitable for thorough and
careful cleaning of smooth surfaces and carpets.
Hand turbo nozzle
For particularly gentle and thorough cleaning of upholstery, car
seats, etc.
Manual turbo nozzle (electric drive)
Even more powerful with electric drive. Ideal for particularly easy and
thorough cleaning of upholstery, car seats, etc.
Floor wiper
Ideally suitable for hard floors and tiles. Vacuuming and wet wiping
in a single operation!
English
SPECIAL ACCESSORIES
11
Polishing machine
Vacuums and polishes simultaneously, with an adjustable-
height roller; easy to clean.
Squeegee
Ideal for wet cleaning of smooth surfaces, such as tiles, PVC,
linoleum, etc.
Window cleaner
Thorough cleaning of all window surfaces without cleaning agents.
Air freshner
The Pro-Aqua air freshner neutralises unpleasant odors, bacteria
and contaminated air. Contaminated air is vacuumed and cleaned or
scented air flows back out.
Animal curry comb
The animal curry comb with its long hose is outstanding for curry-
combing horses or brushing dogs.
Floor turbo nozzle (air driven)
The floor turbo nozzle means you can clean all smooth surfaces and
carpets easily and efficiently.
English
12
Spray extension kit
This specially-developed spray extension kit
enables you to achieve a particularly high de-
gree of cleanliness when dealing with ex-
tremely dirty upholstery or carpets.
The cleaning agent is sprayed under
pressure onto the upholstery or
carpet and binds dirt together.
The large volume of air flowing
through the system now absorbs
the moisture and dirt. Most stub-
born stains and dirt can thus be dissolved and re-
moved again.
SPECIAL ACCESSORY -
SPRY EXTENSION KIT
1. Large carpet nozzle
2. Extension tube
3. Extraction hose
4. Handle
5. Small upholstery nozzle
6. Fresh water tank
TECHNICAL DATA
Water tank approx. 3,5 litres
Maximum pressure 4 bar
Pump 120 V - 60 Hz
extension kit
larly high de
-
with ex
-
ets.
der
r
ub
-
1. Large carpet nozz
le
2. Extension tube
3. Extraction hose
Maximum pressure
4
ba
r
Pump
120 V - 60 Hz
English
