PROAIM CINEMA VCTR-TH Bedienungsanleitung

What’s In The Box

Dual Tripod Holder For Camera Cart (VCTR-TH)

Assembly Manua l

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

1 x 38mm (ID)

Clamp

1 x Pair Tripod

Holder

Tripod Holder Bar with Clamp

38mm (OD) Dia Mast Accessory Cross Bar with Clamp

5mm, 6mm Allen key

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

• Aach the clamp to the boom crossbar and

secure it properly using both the knobs.

• Remove both the knobs of the 38mm (ID)

clamp.

Tripod Holder Setup

• Image showing clamp aached to the

crossbar.

• Insert the 38mm (OD) mast into the clamp

hole on the boom crossbar.

Rod Mounng

• Loosen the side clamp knobs of the accessory

crossbar and mount the crossbar on the side

rods of the cart.

• Align the crossbar and secure it by ghtening

the side clamp knobs.

• Insert and ghten the knob to secure the

tripod holder properly.

• Slide and mount the tripod holder on the

tripod holder bar.

• Repeat the process for the other tripod

holder.

• Loosen the ratchet knob and open the clamp

on the tripod holder bar.

• Tighten the ratchet knob of the top accessory

crossbar clamp as shown in the image.

• Mount the tripod holder bar on the 38mm

mast and ghten the ratchet knob.

• Remove the knob of the tripod holder.

Tripod Holder Mounng

• Both the tripod holders are correctly aached

to the cart, as shown in the image.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.

YOUR PROAIM DUAL TRIPOD HOLDER FOR CAMERA CART

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

NOTE: Proaim Dual Tripod Holder for Camera

Cart is a perfect add-on accessory to carry or

store two full-size tripods on the cart.
