PROAIM ATLS-HAP Bedienungsanleitung

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Height Adjustable Telescopic Poles for Atlas

carts (ATLS-HAP)

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

4 x Height Adjustable Telescopic Poles

Assembly Manual

 Now, remove the top shelf by liing it

upwards.

NOTE: Two people are required to detach the

top shelf from the foldable rods.

 Aer removing the top shelf, loosen and

remove the bolts of the rod from the

boom shelf using 3mm Allen key.

 Now, loosen the bolts of the lock using

4mm Allen key, as shown in the image.

 Remove the lock from the cart.

Telescopic Poles Setup

 Open the lock at all corners of the top shelf

of the Atlas cart (Not Included).

 Similarly, remove the remaining three locks.

 Thus, repeat the same process for other

corners as well.

 Slide the wheel to backward.

 Then, turn the cart to one side.

 Now, open the lock near the wheel, under

the shelf.

 Similarly, follow the same steps to remove

the rods from all corners.

 Loosen and remove the bolts on the boom

shelf using 4mm Allen key.

 Now, loosen and remove the bolts from the

shelf.

 Follow the same steps to remove the

remaining bolts at other corners as well.

 Fix the wheel by locking it.

 Remove the sank from the Adaptor.

 Push the sank from the Adaptor using any

Allen key .

 Now, remove the rod from the Rod Adaptor.

 Loosen the knob of the Adaptor and open its

lock.

 Loosen bolts using 5mm Allen key from the

Rod Adaptor.

Removal of Rod from Adaptor

 Now remove the bolts from the Rod

Adaptor.

 Insert the other washer on the right side of

the pole.

 Insert the sank from the same side of the

washer.

 Tighten the bolt using 5mm Allen key.

 Push the sank to the inner side of the

Adaptor and insert the bolt on the other

side.

 Insert Rod Telescopic Pole to the Rod

Adaptor.

 Insert one washer on the le side of the

pole.

Telescopic Pole Assembly

 Aer inserng the bolt, ghten it using the

3mm Allen key.

 Aach the Adjustable Telescopic Pole to the

boom shelf of the Atlas cart.

 Aer aaching the Pole, insert the bolt, as

shown in the image.

 Now, insert the bolt of the lock, ghten it

using the 4mm Allen key.

 Insert all 4 bolts on the back side of the

shelf, ghten it using the 4mm Allen key.

 Close the lock and the knob to secure the

pole in the Adaptor.

 Repeat the process for other poles as well.

 Aer turning the cart again to the previous

posion, remove the knob xed in the

adjustable pole by loosening it.

 Insert the bolt on the boom of the shelf,

ghten it using the 4mm Allen key.

 Slide the wheel to backward.

 Then, turn the cart to one side.

 Now, open the lock near the wheel, under

the shelf.

 Aer that, adjust the height of the

telescopic pole according to the

requirement.

 Insert the knob in the provided hole at the

desired height, as shown in the image.

 Tighten the knob to secure the aachment.

 Fix the wheel using lock.

 Now, lock the shelf at all corners to secure

the aachment.

 Your cart is fully assembled with adjustable

telescopic poles.

 Mount the top shelf of the Atlas cart on the

rod.

 Similarly, follow the same steps to aach

the remaining poles.

Features: The height of the top shelf can be

adjusted from 2.46 feet / 29.5" to 1.67 feet /

20"

Height Range- 2.46 / 29.5” To 1.67 / 20”

YOUR PROAIM HEIGHT ADJUSTABLE TELESCOPIC POLES FOR ATLAS CARTS

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
