PROAIM P-12-JS-JRPP Bedienungsanleitung

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

12FT Camera Crane Jib, Stand & Jr. Pan-Tilt

(P-12-JS-JRPP)

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Jib Stand

Middle Secon

Front Secon

2 x Spanner - 17

1 x Spanner - 13

End Secon

Central Post

6mm Allen Keys

Weight Shank

2 x Flower

Knob

1 x Knob

Central Pool

Adapter

Weight Closers

3 x Velcro

Tool Pouch

 Loosen the lower knob of the Jib Stand, as

shown in the image.

Jib Stand Setup

Jr. Pan-Tilt Head

12V Joysck Controller

with Safety cap

12V AC Adapter

15 mtr XLR Cable, 3 mtr Cable

4 x Wings Nuts

MS Check nut

(Size:-1/4)

3 x L-Type

Allen key

2 x Fuse

Storage Bag

Universal

Adapter

Jib Secon Storage Bag

Jib Stand Bag

Index

Sr. No Parculars Page No.

1Jib Arm Assembly 2-3

2Integrating the Section Jib Section 3-6

3Pan-Tilt Head Setup 6-7

4Joystick Controller Attachment 7-8

5Joystick Operation 8

6Final Setup 8-9

 Extend the legs along the Center Post to their

widest posion and re-ghten the lower knob

for added stability.

 Insert the Center Post of the Jib onto the

Stand, as shown in the image.

 Aer inserng the Center Post, secure it with

pins.

 Loosen the bolt from the Center post using a

spanner and remove the washers to further

remove the bolt.

 Insert the end of the 2nd secon in the

Center Post and align the holes of the secon

with the Post to screw in the shank.

 Secure the aachment with the help of the

knobs, as shown in the image.

Assembling The Jib Arm

Connect The 2nd Jib Secon To The Center Post

 Re-insert the black washers and push the

shank to ghten the aachment with the

dome nut.

 Tighten the dome nut from both sides using a

wrench and secure the Jib secon using a pin,

as shown in the image.

 The jib secon is securely aached to the

middle secon.

 Use the spanner and Allen key to remove the

bolt for seng the posion of the Central

Pool Adapter.

 Set the posion of the Central Pool Adapter

and insert the bolt to properly secure it, as

shown in the image.

 Tighten the bolt using the spanner and Allen

key.

 Remove the bolts in the front of the Middle

secon using the spanner and Allen key, as

shown in the image.

 Align the middle and end secons together to

insert the bolt and nuts.

 Tighten the bolt using the spanner and Allen

key to secure it.

 Remove the bolts of the middle secon using

the spanner and Allen key.

 Align the middle and front secons to insert

the bolts to secure them.

 Now, ghten the bolts using the spanner and

Allen key, as shown in the image.

 Remove the bolts of the Center pool Adapter

by loosening them.

 Then, align the central pool adapter in the

center of the wire puller and insert the bolt,

as shown in the image.

 Aer inserng the bolt in the Central pool

adapter, ghten it using the Allen key.

 Loosen the wing nuts and detach them.

 Aach the Jr. Pan-Tilt Head to the Front

Secon head plate and insert the screw in the

threaded hole.

 Similarly, insert the remaining screws to

securely aach the Pan-Tilt Head.

Pan Tilt Head Setup

 Jr. Pan-Tilt Head is properly Aached to the

Jib.

 Unwrap the Velcro strap around the 12V

joysck controller and safely remove the cap,

as shown in the image.

 Connect the 4-pin male connector of the

cable to the 4-pin female connector on the

head for panning and lng.

 Loosen the knob at the back of the 12V

joysck controller and insert it into the weight

rod.

 Aer properly inserng the Joysck

controller, ghten both the knobs to secure it.

 Now, aach the 4-pin Power Cable with the

Joysck Controller.

Aaching Joysck Controller

 Aach one end of the 12v adapter cable to

the adapter.

 Connect the electric plug of the 12v adapter

wire to the universal adapter.

 Aach the 4-pin Power Cable with the

Joysck Controller.

 Loosen the bolt of the Jr. Pan-Tilt Head using

the Allen key and reghten it aer properly

posioning the head.

 Speed Controller- Adjusts the speed of pan &

lt based on the requirement of the shot.

 Damping Control- Prevents the Head from

stopping with a jerk, enabling you to achieve

smooth endings.

 Pan-Tilt Direcon- You can reverse the

panning & lng direcon as & when

required.

Joysck Controlled Movement Funcons

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.

YOUR PROAIM 12FT CAMERA CRANE JIB WITH STAND

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

 Aach your camera to the Head’s camera

plate using the provided check nut.

NOTE: If the Joysck Control is opposite, undo

the connectors of motors, rotate 180° and

re-install.

 Your Camera is Properly aached with the Jr.

Pan Tilt Head.

NOTE: Proaim Jr. Pan lt oers complete

360° pan & lt inaudible movements while

keeping your camera safe and secure.
