Pyle PBC5200
3G Wi-Fi Mobile Power Bank and Router Integrator
Quick Installation Guide
-1-
3G Wi-Fi mobile power bank and router integrator is a 3G network product for consumers, which
integrates 3G routing, wireless routing, ADSL dial-up Internet access, wireless network storage, mobile
power and other functions. This allows you to create a wireless network anytime and anywhere there is a
LAN connection. You can easily share contents in digital devices with others. Various functions of this
product are listed below:
3G Routing: support 3G wireless network card dialing and bandwidth sharing for WCDMA / CDMA
2000 / TD-SCDMA standard;
Wireless routing: support traditional wired broadband ADSL dial-up, dynamic and static network
access;
Wireless network storage: supports file reading and sharing on U disk, USB mobile hard disk, as
well as online video on-demand;
Mobile power bank: can charge iPhone, iPad, Android smart phones, tablet PCs and other mobile
digital devices;
Wireless relay: relay and amplify the signals and thus extend the coverage of wireless network.
1.
1. List
List of
of accessories
accessories
Thank you for buying the 3G Wi-Fi mobile power and router integrator. Please make sure your package
includes the following accessories.
1. Host
2. USB charging cable
3. Quick Installation Guide / Warranty Card
4. Certificate
-2-
2.
2. Introduction
Introduction of
of panel
panel
2.1
2.1 Description
Description of
of hardware
hardware interfaces
interfaces
Hardware
Interface Identity Detailed Description of Functions
Power switch
R Turn on the power switch to R to start the router function
CCharging, switch to C to activate the mobile power bank function to
charge devices through the USB port
Off switch
Battery indicator
button
Press this button, the battery indicator will show the current battery,
battery indicator is divided into four levels.
USB interface This interface can connect 3G USB modems, U disk, USB mobile
hard disk, flash drive, or connect smart phones, tablet PCs, PSP
and other digital terminals for charging.
DC charging
interface
DC 5V input, you can charge the unit through the Micro USB
charging cable.
Charging
indicator When the unit is being charged, the indicator is always on
RJ45 network
port
WAN port: In the mode of Dynamic IP/Static IP/PPPoE, the port is
used as a WAN port to connect a wired network, LAN broadband,
xDSL Modem/Cable Modem of hotels.
Restore factory
settings
In Routing state, long press for 5 seconds, then release the key,
the router will restore to factory settings.
USB
USB port:
port: Connect
Connect the
the network
network
card
card,
,mass
mass storage
storage device,
device, or
or
charge
charge the
the phone
phone
Charg
Charging
ing Indicator
Indicator
DC
DC char
g
in
g
charging interface
interface
RJ45
RJ45 network
network cable
cable port
port
Power
Power Switch
Switch
R:
R: Power
Power
C
C:
:Charging
Charging
0:
0: O
Off
ff
Batter
y
Battery indicato
r
indicator button
button
Batter
y
Battery indicato
r
indicator
Restore
Restore factor
y
factory settin
g
s
settings
-3-
2.2
2.2 Descriptions
Descriptions of
of Status
Status Indicators
Indicators
Action
Performed Indicator
status Details
Turn On the
power
Blue light
always on Slide the power switch to C to power on unit
Removable
storage
inserted
Equipment
Blue light
flashes slowly
(1.5 seconds
each time)
When U disk, mobile hard drives and other removable storage
devices are plugged in to the USB port, you can see the blue
light flash slowly after 8-10 seconds, indicating that the
removable storage devices are loaded normally and can be
accessed.
Blue light
always on Removable storage devices are not loaded successfully
3G card
inserted
Blue light
flashes quickly
(0.5 seconds
each time)
When 3G USB modems are inserted, you can see the blue light
flash quickly after about 30 seconds (0.5 seconds each time),
indicating the router is in the 3G dialing state;
Blue light
flashes slowly
(1.5 seconds
each time)
Blue light flashes slowly (1.5 seconds each time), indicating that
the router has dialed-up via 3G successfully, and you can
access the Internet.
Blue light
always on Dial not successful
Insert ADSL
network cable
(PPPOE Mode)
Green light
always on
With the Ethernet cable plugged in, if you can see the green
light is always on after 5 seconds, this indicates that the network
connection is normal;
Blue light
flashes slowly
(1.5 seconds
each time)
After green light is on for a while, if you see the blue light flash
slowly, this indicates that the router ADSL has dialed-up
successfully, and you can access the Internet
Network cable
plugged into
the router
(Dynamic IP
mode)
Green light
always on Indicates that the network cable is connected properly
Green light
flashes slowly
(1.5 seconds
each time)
Indicates that network cable is connected properly, also
meaning that the router has successfully retrieved IP addresses
dynamically assigned on the upper router.
Network cable
plugged into
the router
(Static IP mode)
Green light
always on Indicating that the network cable is connected properly
-4-
3. Application scenarios
The product supports the following application modes:
1) 3G to WiFi Internet Sharing mode
2) Wired to WiFi Internet Sharing mode
3G to wifi mode
Plug 3G USB data card
Gas ADSL modem / router
Wired broadband to wifi mode
-5-
4.
4. Mobile
Mobile power
power function:
function: Instructions
Instructions for
for charging
charging mobile
mobile phones,
phones,
tablet
tablet computers
computers and
and other
other digital
digital products
products
Step 1: Battery display.
Before charging mobile phones, tablet computers and other digital products, check the battery level of the
device itself, and follow these instructions:
a) Press the battery indicator button. The battery indicator light should turn on and you can see the
current battery percentage. The light will turn off automatically when idle for more than four seconds in
order to save power.
b) The corresponding relationship between battery and power indicator:
(Battery schematic diagram)
Step 2: Charge mobile phones, tablet computers and other digital products.
Set the switch to the charging function (C) position to activate mobile power function, and then connect
the charging cable of digital products to the USB port of this product. This unit can charge iPad, iPhone,
LED status Details
Battery
level
indicator
No lights No electricity, please charge this unit
first
One light is on Capacity is less than 25%
Two lights are on Capacity is between 25% - 50%
Three lights are on Capacity is between 50% - 75%
Four lights are on Capacity is between 75% - 100%
Press the "z"
button, you can
display the
current battery
charge
Battery level
indicator
(divided into
four)
-6-
Android smart phones, and other mobile digital devices.
Tip: Use original charging cable for cell phones to achieve the best results.
(Schematic
(Schematic diagram
diagram of
of charging
charging devices)
devices)
5.
5. Charge
Charge this
this product
product
When the battery has been exhausted, you can charge it in the following two ways:
Power Charging: Connect one end of the Micro USB charging cable to the DC charging port of this
product (Micro USB Interface) and connect the other end to the USB port of charging adapter.
Computer USB Charging: Connect one end of the Micro USB charging cable to the DC charging
port of this product (Micro USB Interface) and connect the other end to the computer's USB port.
(Schematic diagram of charging this 3G Wi-Fi unit)
Please connect
the smaller end
of Micro USB
charging cable
to this interface
Charge various
devices via this
USB port
-7-
Charging Precautions:
1. Please choose the charging adapter where the output is 5V (output current is between 600 to 1000mA)
Common charging adapters, such as adapters for iPhone or iPad, can be used.
2. Charging time: it will take about 5-8 hours with a charge of 5V 1000mA; 11 hours with a charge of 5V
600mA;
It will take more than 12 hours if it is directly charged using a computer USB.
3. In the process of charging this unit, do not reuse the unit to charge other equipment, in order to protect
the battery and prolong battery life.
6.
6. Features
Features and
and configurations
configurations of
of 3G
3G Wi-Fi
Wi-Fi wireless
wireless router
router
3G Wi-Fi router supports access and configuration through a web browser. You can use common
browsers, such as Microsoft's IE browser, Apple's Safari browser and the built-in browser of any Android
operating system. Login to the router, browse contents of mobile storage, and configure the router
parameters. The
The following
following is
is an
an introduction
introduction to
to the
the operation
operation of
of this
this unit.
unit.
6.1
6.1 The
The use
use your
your wireless
wireless device,
device, you
you need
need to
to connect
connect to
to the
the wireless
wireless router
router first
first (for
(for
example,
example, iPad)
iPad)
Step 1: Open the main interface of the iPad, select "Settings" "Wireless LAN", enter the Wi-Fi settings
page. Turn on the wireless network switch, iPad will automatically scan surrounding wireless networks,
and you will see the id 3G Wi-Fi xxxx, double-click to connect.
Step 2: When connecting, enter the Wi-Fi password behind the router enclosure, and make the
connection (the password can be modified yourself)
If connected successfully, a tick “ ” will appear to the left, while at the same time there will be a sign
at the upper left corner of the screen indicating a successful connection. If prompted you can not
join the network, please make sure your wireless password is entered correctly.
-8-
Step 3: View and set network parameters. Click the ">" button at the right of where it says connected, and
the setting page for wireless connection network parameters pops up (By default, DHCP server is enabled
by the router, it is recommended to use DHCP).
Set up
Flight mode
Wireless LAN
Notification Open
Location Service Open
Brightness and Wallpaper
Digital Photo Frame
General
Mail, Contacts, Calendars
Video
Memo
Applications
Wireless LAN
Select a Network…
Wireless LAN
Other…
Ask to Join Networks
The computer will be automatically added to a known network,
if the network is not known, it prompts to ask if you want to
join a new network
-9-
6.2
6.2 Enter
Enter the
the configuration
configuration interface
interface for
for 3G
3G Wi-Fi
Wi-Fi router
router
Click the Safari browser, enter: http://192.168.169.1, in the address bar. Click the "Go" button to enter the
homepage of the router configuration page. See below:
In addition, for users of iPhone and iPad ios devices, there is a more efficient way to enter the router
configuration page. You can directly enter "wd" in the Safari browser's address bar. Then, you can go in
by clicking the "Go" button.
Set up
Flight mode
Wireless LAN
Notification Open
Location Service Open
Brightness and Wallpaper
Digital Photo Frame
General
Mail, Contacts, Calendars
Video
Memo
Applications
Ignore this Network
IP address
Static IP
Subnet Mask
Router
Search Domains
Client ID
Renewal
Close Manually
HTTP Proxy
Automatically
Inhaltsverzeichnis
Andere Pyle Zubehör Handbücher
Pyle
Pyle PPBCM28 Bedienungsanleitung
Pyle
Pyle Nutrichef PKELKN16 Bedienungsanleitung
Pyle
Pyle PPBCM16 Bedienungsanleitung
Pyle
Pyle PSLBRP4 Bedienungsanleitung
Pyle
Pyle PAD20MXU Bedienungsanleitung
Pyle
Pyle PINPOINTER Bedienungsanleitung
Pyle
Pyle PPBCM22 Bedienungsanleitung
Pyle
Pyle Nutrichef PKTCEC4BL Bedienungsanleitung
Pyle
Pyle PAD15MXU Bedienungsanleitung
Pyle
Pyle PBPK42 Bedienungsanleitung
