STANDARD FEATURES
CABINET
The PAC series cabinet is constructed of 18 gauge steel with a gray polyester
powder coated finish that will compliment any decor. The entire cabinet is insulated
with sound- absorbing insulation for cool, quiet comfort. All units come equipped
with handles and swivel casters for portability and convenient set-up.
ELECTRONIC THERMOSTAT
All PAC units are equipped with a non-programmable electronic thermostat. When
power is connected to the unit, the thermostat will control the unit to cool a space to
the desired temperature. The thermostat is also capable of controlling the fan to
operate automatically when needed, or continuously. To protect the compressor
from short-cycling, there is a built-in time delay.
FAN SPEED CONTROL
A two position rocker switch, located next to the thermostat, provides the user with
the option of running the evaporator fan at high-speed or low-speed.
CONDENSATE TANK/PUMP
PAC series units come equipped with a means for handling the condensate gener-
ated during the cooling process. All units, except the PAC60 models, come
equipped with a condensate tank. The tank can be easily removed from the unit
and emptied as needed.
The PAC60 models come equipped with an Automatic Condensate Pump that re-
moves the condensate. The pump comes with a 20 foot long vinyl hose that allows
for the removal of the condensate water to a drain. The automatic pump is capable
of a 20ft vertical lift, to handle various installation requirements.
CONDENSATE ALARM LIGHT
On the front of all PAC models, there is a Condensate Alarm Light (RED) located
near the thermostat. For models other than PAC60, the light indicates that the con-
densate tank is full, and needs to be emptied. PAC60 units, the light indicates a
condensate pump over-flow condition where the pump is either disabled or restrict-
ed, and cannot remove the condensate water, and must be serviced.
FILTERS
All PAC series units are equipped with washable filters at the air intakes. Electro-
static mesh air filter located behind the evaporator return air grille serves to filter
the air before it is cooled. A 1/2” aluminum mesh filter serves to protect the con-
denser coil from dust build-up. Both filters can be easily removed and cleaned.
HIGH PRESSURE SAFETY SWITCH
Located on the back of the PAC unit is a manual re-set high pressure switch, used
for the protection of the compressor. If the condensing pressure exceeds the limit
setting, the switch will cycle the compressor off, while the evaporator fan remains
running. The compressor can be re-started, once the condensing pressure has
equalized, by depressing the “RESET” button.
POWER CORDS
All PAC units come standard with a power cord for a convenient connection. All
models, except for the 3-phase units and 5-ton units, are equipped with a LCDI for
added safety features.
