Raidon SafeTANK GR5630-WSB3+ Bedienungsanleitung

www.RAIDON.com.tw

Your Data Security Guardian

GR5630-WSB3+

User Manual

SafeTANK

v.1.0 (Oct, 2012)

www.RAIDON.com.tw

Your Data Security Guardian

Table of Contents

Chapter 1. Package Contents and Product Views

Chapter 2. Environmental Requirements

Chapter 3. Hardware Requirements and Precautions

Chapter 4. Hardware Installation

Chapter 5. Description of Front Panel Operation and LCD Information

Chapter 6. Replacement of Malfunctioning Drive and Data Rebuild Instructions

Chapter 7. System Temperature Overheat and Fan Failure Management

Chapter 8. Visual Status Indicator Definitions

Chapter 9. Frequently Asked Questions

www.RAIDON.com.tw

Your Data Security Guardian

Chapter 1 Package Contents and Product Views

Please make sure that the contents listed above are not damaged or missing. If you should find

damages or missing contents, please contact your supplier immediately.

Open the package and you should find the following :

GR5630-WSB3+

Item Qty.

GR5630-WSB3+

(with removable drive tray enclosed)

Firewire 800 (1394b) Cable

e-SATA Cable

USB 3.0 Cable

Accessories Kit

AC Power Cable

CD(GUI)

Quick Installation Guide

USB3.0

Alarm Mute

Hard drive status Indicator

Removable drive tray

Button for Tray Clamp

LCM display

UP button

DOWN button

ENTER button

ESC button

Power indicator

Alarm indicator

USB3.0 interface connection

e-SATA interface connection

FireWire 800 (1394b) interface connection

Mute button

Power Switch

Power socket

Cooling fan

Anti-theft cord slot

Drive position(1)

Drive position(2)

Drive position(3)

Drive position(4)

Storage Mode Definition

Independent mode ( JBOD ) : Four discrete storage capacities.

Speed mode ( Raid 0 ) : One big independent data storage with without data protection.

Safe mode ( Raid 1 ) : One independent data storage with data protection.

The secondary FireWire 800 (1394b) connection on the GR5630-WSB3+ is provided to connect and

extend to another FireWire 800 (1394b) device.

Front view Rear view

Enter Esc

www.RAIDON.com.tw

Your Data Security Guardian

Chapter 2 Operating Information

Chapter 3 Hardware Requirements and Precautions

Operating Temperature : 0 ∼40 ℃(32 ~ 104 ℉)

Storage Temperature : -10 ∼70 ℃(14 ~ 158 ℉)

Line Voltage : 100 ∼240V AC

1. Only one interface connection may be used at once per computer system.

2. RAID volume formation utilizes the capacity of whichever hard drive has the smallest and then

multiply that capacity by three for RAID 5, four for RAID 0, to form a large volume, therefore,

it is recommended to only install hard drives of the same brand and specification for all drive

position prior to use. Moreover, when you need to replace with a new hard drive, please be

sure to purchase one with the same specification, capacity and brand. If these conditions can’t

be met, select one that’s at least 20 GB greater in capacity.

3. The actual storage capacity of GR5630-WSB3+ recognized by the system may differ from the

total capacity stated on the hard drives once the drives have been formatted.

4. When connected to the computer system, it’s prohibited to remove, insert or swap the hard

drive while data transfer is being performed.

5. It’s prohibited to change the positioning of the drives once the initial installation has been

completed as the changes made to the drive positions may destroy the RAID formation.

6. If you discover that hard drive failure is taking place, go to Section 6 “Replacement of

Malfunctioning Drive and Data Rebuild Instructions” and follow the steps accordingly.

7. Whenever turning off or unplugging the GR5630-WSB3+ from your computer system becomes

necessary, always remember to safely remove it from your operating system first.

8. In RAID 5 mode, the system allows one single hard drive failure. If multiple drive failures occur

at once, it’s likely that all data stored in the system have been destroyed or lost. In RAID 0

mode, if one hard drive failure occurs, then all data maybe destroyed or lost. If this happens,

we recommend you to consult with a professional hard drive data recovery specialist to see if

your data may be recoverable.

9. It is highly recommended for users to back up important data contained within the

GR5630-WSB3+ unit on a regular basis or whenever the user feels necessary to a remote or a

separate storage device. RAIDON will not be responsible for any lost of data caused during the

use of the unit or the recovery of the data lost.

www.RAIDON.com.tw

Your Data Security Guardian

Chapter 4 Hardware Installation

Step 1 Open the package and take out the product making sure that all the enclosed contents

are not damaged or missing. Should you find damages or missing contents, please contact

your supplier immediately.

Step 2 Place the system on a stable surface. Ensure that it is well ventilated without blockage to

the vent and kept away from areas near water and damage prone areas.

Step 3 Press down the button for tray clamp to eject the removable drive tray latch and extract the

removable drive tray.

Step 4 Mount your hard drives onto the removable drive tray and secure it with the screws included

in the accessory kit to avoid any damage to the hard drive due to accidental movements.

Step 5 When the hard drive installation has been completed, insert the hard drive tray into the

system horizontally and secure the latch into place.

www.RAIDON.com.tw

Your Data Security Guardian

Step 6 Connect the AC power cable to the GR5630-WSB3+, and then plug the AC power to the

wall socket. Boot-up the unit.

Step 7 Set the storage mode using the LCD and buttons on the front (please refer to section 5 for

front panel and LCD information).

Step 8 Connect the cable to the PC and the GR5630-WSB3+ port.

Step 9 After boot-up, your operating system will automatically detect the storage capacity of your

hard drives. Please follow the operating system instructions to configure and format your

drives. The formatted drives can be configured for the RAID setup.

Chapter 5 Description of Front Panel Operation

and LCD Information

Level 0

External 4BAY

HARDWARE

RAID

Quick Setup Create One RAID

Delete All RAID

Identify Disk

Show Disk Info

Identify RAID

Create RAID

Delete RAID

RAID Info

Change RAID Pwd

Rebuilding Priority

Standby Timer

System Info

Changhe Password

Logout From Menu

Alarm Control

Voltage Monitor < 3.3V / 5V / 12V >

< Temp. >

< Fan Speed /

Fan Level >

Temp. Monitor

Fan Monitor

Hardware Monitor

Select Disk

< Disk Info >

Select RAID

RAID 0 / RAID 5

Select RAID

< Password > for RAID Setup

Highest/High/Medium/Low/Lowest

< 99999min >

Firmware Version

< Password > for System Info

< Y or N >

Mute the Buzzer

Disk 1

Disk 2

Disk 3

Disk 4

Check Disk LED

RAID 0/ RAID 5 Select Disk

Disk Manager

RAID Manager

System Manager

Level 1 Level 2 Level 3 Level 4

www.RAIDON.com.tw

Your Data Security Guardian

Chapter 6 Replacement of Malfunctioning Drive

and Data Rebuild Instructions

When a front hard drive indicator has lit up red and the audio alarm sounds, this could mean the

indicated hard drive may be malfunctioning. If this occurs, you may press the mute button at the

rear of the system to shut off the audio alarm and power off the system immediately if in the

allowed operational state, and then re-power on the system to double check and see if in fact the

indicated hard drive has malfunctioned. If the problem persists, please turn off the system and

follow the directions below :

Step 1 Remove the drive tray containing the malfunctioned hard drive and disassemble the hard

drive from drive tray.

Step 2 Mount the new hard drive onto the tray and insert it back to the empty drive position of

the GR5630, then push the latch into place making sure it is secured and locked.

Step 3 In RAID 5 mode, when you turn the system on, the hard drive status indicator of the

replacement drive will interchangeably blink red and purple to inform that the data is

being rebuilt to the replacement drive. During data rebuild, you may operate the

GR5630-WSB3+ as normal. When the indicator stops, the data rebuild process has been

completed.

Chapter 7 System Temperature Overheat

and Fan Failure Management

If the alarm indicator has lit up red and the audio alarm sounds, this could mean that either a

system fan has stopped operating entirely or the system temperature has exceeded over the

default temperature of 60°C. When this occurs, you may press the mute button at the rear of

the system to shut off the audio alarm and power off the system immediately if in the allowed

operational state to let the system cool. Check and see if the overall operation environment is

well ventilated and make sure there are no blockages to the enclosed fan and then re-power on

the system to continue use. If the problem persists, please turn off the system and contact your

supplier or the RAIDON tech support for further assistance.

www.RAIDON.com.tw

Your Data Security Guardian

Chapter 8 Visual Status Indicator Definitions

Chapter 9 Frequently Asked Questions

Q1. Which drive format should I choose to format the hard drives in the GR5630-WSB3+?

A : It depends on the computer system you most often use. See the below suggestions:

1.Use NTFS format for Windows 2000/XP/Vista/Windows 7 system

2.Use HFS+ (Mac OS Extended) format for a Mac OS X system

3.Choose FAT32 format if you’ll use the GR5630 in both Windows and Mac environments

(the maximum size of one single file may not exceed 4 GB).

Q2. Why can’t my GR5630-WSB3+ reach the transfer performance speed of 200 MB/s via

e-SATA interface as stated on your website?

A : 1.Please first check if your PCI-E SATA host adapter would only support PCI-E (1X). This type

of host adapters cannot reach the transfer performance speed beyond 135MB/s.

2.The GR5630-WSB3+ will need to be set to the RAID 0 mode also.

States

Power on

No disk

Disk Fail

RAID Fail

Disk Idle

Format

Access

Fan Fail

Blue

Blue Blue

Blue

Source: Blue flash

Target: Blue and Purple

light on alternatively

1 long when

booting finished

Blue flash

Blue

Power LED Alarm LED

--------

-------- -------- --------

--------

Red

HDD LED

buzzer

4 short

Blue flash => Blue

Front LED

Blue

Over Temp.

Rebuilding
