SmarTrax™ Installation Manual
Hagie STS 10/12
While every effort has been made to ensure the accuracy of this document,
Raven Industries assumes no responsibility for omissions and errors. Nor is any
liability assumed for damages resulting from the use of information contained
herein.
Raven Industries shall not be responsible or liable for incidental or consequential
damages or a loss of anticipated benefits or profits, work stoppage or loss, or
impairment of data arising out of the use, or inability to use, this system or any of
its components. Raven Industries shall not be held responsible for any
modifications or repairs made outside our facilities, nor damages resulting from
inadequate maintenance of this system.
As with all wireless and satellite signals, several factors may affect the availability
and accuracy of wireless and satellite navigation and correction services (e.g.
GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the
accuracy, integrity, continuity, or availability of these services and cannot
guarantee the ability to use Raven systems, or products used as components of
systems, which rely upon the reception of these signals or availability of these
services. Raven Industries accepts no responsibility for the use of any of these
signals or services for other than the stated purpose.
Disclaimer
Manual #016-0190-029
1
CHAPTER
I
NTRODUCTION
Congratulations on your purchase of the Raven SmarTrax system! This
system is designed to provide cutting-edge, hands-free steering of your
machine via GPS coordinates.
Hagie STS 10/12 SmarTrax Installation Manual
2
Basic Kit
Contents
Below you will see the kit contents that you should have received with this
SmarTrax Kit.
Hagie STS 10/12 SmarTrax Kit Contents
Quantity Item Description Part Number
1 SENSOR, YAW 063-0172-684
1 CABLE, HYDRAULIC SOLENOID / OVERRIDE 115-0171-775
1 WELDMENT, BRKT., UNIVERSAL HYD. MOUNTING, PART "A" 116-0159-527
1 KIT, HYD., SMARTRAX, HAGIE STS 10/12 117-0194-029
1 SWITCH, PRES., MICRO, H.D., 15-100 BAR ADJ., W/90° FITTING 422-0000-074
4 BOLT, 5/16-18 x 7/8" HEX 311-0052-104
4 BOLT, HEX HEAD, 3/8"-16 x 1" 311-0054-180
4 NUT, 3/8"-16 ZINC-PLATED HEX 312-1001-037
4 WASHER, LOCK, 5/16" 313-1000-019
4 WASHER, 3/8" LOCK, SPLIT, ZINC 313-1000-022
8 WASHER, FLAT 3/8" 313-2300-013
1 VALVE, HYD., O.C., PWM 334-0003-064
1 MANUAL, INSTALLATION 016-0190-029
1 MANUAL, INSTALLATION, SMARTRAX 016-9001-008
3 FTG., ADAPTER, SWIVEL RUN TEE, -8 JIC M/M/F 333-0012-039
3 FTG., ELBOW, 90° SWIVEL, -6 JIC M/F 333-0012-042
3 FTG., ELBOW, 90° SWIVEL, -8 JIC M/F 333-0012-064
2 HOSE, HYD., -8 JIC, (F) TO -6 JIC (F), 40” 214-1000-244
1 HOSE, HYD., -8 JIC, (F) TO -8 JIC (F), 29” 214-1000-245
1 HOSE, HYD., -8 JIC, (F) TO -6 JIC (F) 45°, 28” 214-1000-246
Manual #016-0190-029
3
CHAPTER
S
AFETY
Hydraulic
Safety
Requirements
When disconnecting the hydraulic hoses or when purging is required, be
aware that the hydraulic oil within the machine system may be extremely
hot and under high pressure. Caution must be exercised. Any work carried
out on the hydraulic system must be performed in accordance with the
machine manufacturers’s approved maintenance instructions. Raven
Industries recommends that appropriate protective equipment be worn
when working on the hydraulic system. Objects or materials that are able to
bypass the machine’s hydraulic filtration system will adversely reduce
performance and possibly damage the hydraulic valves.
Electrical Safety
Requirements
Do not reverse the power leads. Doing so will cause severe damage to the
equipment. Always check to make sure that the power leads are connected
to the right polarity as marked. Ensure that the power cable is the last cable
to be connected.
Important: Hydraulics are under pressure. Never attempt
to open or work on a hydraulic system with the
equipment running.Care should always be taken when
first opening a system that was previously pressurized.
Hagie STS 10/12 SmarTrax Installation Manual
4
Contacting
Raven
Industries
We welcome your feedback about this manual. If you have any comments
or suggestions for improvement, please let us know by contacting our
Customer Support Center by any of the following methods:
•Via phone: 1-800-243-5435
•Via mail:
Raven Industries
Flow Control Division
205 E. 6th St.
Sioux Falls, SD 57104
•Via email: [email protected]
Manual #016-0190-029
5
CHAPTER
M
OUNTING
THE
UNIVERSAL
B
RACKET
AND
V
ALVE
1. Using the supplied 3/8” bolts, washers, lock washers, and nuts, mount
the valve to front right corner of the cab floor.
Important: Ensure there is clearance for pressure switch
and swing down tank fill arm before holes are drilled for
mounting bracket.
Pressure
Switch
Front of
Machine
Hydraulic
Valve
Drill Mounting
Holes in
Cab Floor.
Hagie STS 10/12 SmarTrax Installation Manual
6
Notes:
Manual #016-0190-029
7
CHAPTER
H
YDRAULICS
Installing the
Pressure Hose
1. Attach the supplied 3/4” 90° fittings to ‘P’ and ‘EF’ ports on valve.
2. Remove original pressure hose from steering orbital and connect
directly to ‘P’ port on SmarTrax Valve.
3. Attach supplied excess flow hose (P/N 214-1000-245) to ‘EF’ port on
valve.
Note: Remove the valve from bracket to tighten fittings.
Tank Left Steer
Right Steer
Pressure
Hagie STS 10/12 SmarTrax Installation Manual
8
Installing Left,
Right and Tank
Hoses
1. Remove original right steer hose (fitting in orbital may need to be
removed for clearance to left steer port).
2. Remove left steer hose. Attach 3/4” run tee to original 90° fitting.
Reattach left steer hose to tee.
3. Attach supplied left steer to ‘A’ port hose (P/N 214-1000-244) to
branch fitting of tee. Tighten all couplings on left steer line.
4. Install 3/4” run tee onto right steer port and reinstall original right steer
hose.
5. Attach supplied right steer to ‘B’ port hose (P/N 214-1000-244) to
branch fitting of run tee.
6. Remove original tank line and attach 3/4” run tee to original 90° fitting.
7. Attach supplied 90° 3/4” fitting to run tee branch fitting.
8. Attach original tank hose to run tee.
9. Attach supplied tank hose (P/N 214-1000-246) to branch of run tee
fitting. Tighten all fittings.
Installing Left, Right, and Tank Hoses on Hydraulic Valve
1. Attach tank hose to ‘T’ port on valve using supplied 9/16” 90° fitting, if
needed.
2. Attach left steer hose to ‘A’ port on valve. Tighten fittings.
3. Attach right steer hose to “B” port on valve using supplied 9/16” 90°
fitting, if needed.
Supplied
Left Steer
Hose
Original Left
Steer Hose
Temporarily Disconnect for Access
Supplied
Tank Hose
Supplied
Excess
Flow Hose
Right Steer
Supplied
Hose
