920i Single Kiosk Truck In/Out

Software Application

Version 1.02

Operation Manual

February 26, 2019 PN 159487 Rev B

An ISO 9001 registered company

Rice Lake Weighing Systems® is a registered trademark of

Rice Lake Weighing Systems.

All other brand or product names within this publication are trademarks or

registered trademarks of their respective companies.

All information contained within this publication is, to the best of our knowledge, complete and

accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make

changes to the technology, features, specifications and design of the equipment without notice.

The most current version of this publication, software, firmware and all other product

updates can be found on our website:

www.ricelake.com

Contents

Technical training seminars are available through Rice Lake Weighing Systems.

Course descriptions and dates can be viewed at www.ricelake.com/training

or obtained by calling 715-234-9171 and asking for the training department.

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2.1 Weigh In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2.2 Weigh Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2.3 Truck Register. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

3.0 Serial Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3.1 Weigh In Ticket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3.2 Weigh Out Ticket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3.3 Transaction Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

4.0 Modifying the Database Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4.1 Application Setup & Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4.2 Database Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4.2.1 Built In Truck Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

5.0 Hardware Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

920i Single Kiosk Truck In/Out Operation Manual

2 Visit our website www.RiceLake.com

Rice Lake continually offers web-based video training on a growing selection

of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction

1.0 Introduction

This 920i® Single Kiosk Truck In/Out program (PN SZ99999) allows a truck to weigh in and out (saves inbound weight after

weighing out and has value swapping) and store the transaction after each weigh out with Truck ID, Gross, Tare and Net.

Transactions may be printed or cleared at any time through the setup menu. An HID scanner, numeric keypad and an American

custom VK80II kiosk printer are available options.

This program is for use on a single direction truck platform with a single kiosk. Weights can be streamed to a remote display.

Manuals are available for viewing and/or downloading from the Rice Lake Weighing Systems website at

www.ricelake.com/manuals

Warranty information can be found on the website at www.ricelake.com/warranties

After a successful download, the 920i needs to be power cycled.

Note

920i Single Kiosk Truck In/Out Operation Manual

2 Visit our website www.RiceLake.com

2.0 Operation

System displays the Weigh In, Weigh Out, Truck Regs, Setup Menu softkeys when it powers up or when it exits the

configuration or setup menus.

2.1 Weigh In

1. Press the Weigh In softkey. The 920i prompts Enter ID Inbound.

2. Enter the truck ID and press the enter key, or scan an HID card (ID must not be weighed yet). The system prints a

Weigh In Ticket and displays Weigh In Complete – Exit Scale.

2.2 Weigh Out

1. Press the Weigh Out softkey. The 920i prompts Enter ID Outbound.

2. Enter the truck ID and press the enter key, or scan an HID card (must have a stored tare from a previous inbound

weighment).

3. System displays the following:

A. ID FOUND

i. Prints a Weigh Out Ticket .

ii. Displays Weigh Out Complete – Exit Scale.

iii. Stores a Transaction.

iv. Removes the inbound weighment if Store Tares is NO.

When the transaction database reaches its 1,000 record capacity it automatically deletes the oldest 25% of data.

B. ID NOT FOUND.

i. System displays ID Not Found.

2.3 Truck Register

Pressing the Truck Regs softkey shows all the stored inbound tare weights, truck IDs and time/dates. Use softkeys to page up,

page down, delete an individual Inbound record, delete all Inbound records or exit back to the starting keys.

Note

Serial Communications

3.0 Serial Communications

3.1 Weigh In Ticket

The program uses the Auxiliary Print Format #1 for weigh in tickets. The dealer may modify this print format through the 920i

front panel or by using iRev™ PC software.

Figure 3-1. Weigh In Ticket Sample

3.2 Weigh Out Ticket

The program uses the Auxiliary Print Format #2 for weight out tickets. The dealer may modify this print format through the 920i

front panel or by using iRev PC software.

Figure 3-2. Weigh Out Ticket Sample

3.3 Transaction Report

The program prints all the stored transactions. This is not configurable without a program modification.

Figure 3-3. Transaction Report Sample

ID: 88

Inbound: 126560 lb

05/07/2018 11:22PM

ID: 88

Gross:

Tare: 81560 lb

Net:

05/07/2018 11:29PM

45000 lb

126560 lb

Transactions as of 11:30PM 05/07/2018

ID: 88

Gross: 126560 lb

Tare: 81560 lb

Net: 45000 lb

05/07/2018 11:29PM

ID: 22

Gross: 126560 lb

Tare: 4000 lb

Net: 122560 lb

05/07/2018 11:19PM

920i Single Kiosk Truck In/Out Operation Manual

4 Visit our website www.RiceLake.com

4.0 Modifying the Database Tables

A program, Interchange, can be used by the end-user to upload, export and clear the database tables. The exported file may be

saved as a delimited text file, an Excel spreadsheet or as a XML document. iRev may also be used to perform database

maintenance.

4.1 Application Setup & Configuration

The Setup Menu softkey is password-protected and offers access to the following:

• Display Program Name & Version

• Display a weight widget

4.2 Database Table

4.2.1 Built In Truck Database

Parameter Default Softkey Description

System Time and Date Current Time/Date Time and date of 920i

Setup Password “” Setup Password Changing the password that is required for entry into the Setup menu; setting the pass-

word to nothing causes the system to not prompt for a password when the Setup Menu

softkey is pressed

Clear Transactions - Transactions Clear transaction database with a YES/NO option

Print Transaction - Transaction Prints transaction report

USB Upload/ Download - USB Options 920i standard USB softkey; reference the 920i Installation manual for more details (920i

USB required)

Contrast Key - USB Options 920i standard Contrast softkey; reference the 920i Installation manual for more details

(920i USB required)

Stored Tare Option YES Store Tare

YES/NO

NO - deletes the inbound weighment after a weigh out;

YES - retains the inbound weighment after a weigh out

Table 4-1. Setup Menu Parameters

Field Type Description

ID String Truck Id – 16 alphanumeric

Gross Real Gross Weight

Tare Real Tare Weight

Net Real Net Weight

DT DateTime Date and Time of Transaction

Table 4-2. Transactions Database (1,000 Records)

Field Type Description

ID String Alphanumeric truck identifier – 16 characters

Pri_Wgt Real Inbound weight in primary units

Sec_Wgt Real Inbound weight in secondary units (Currently Not Used)

Ter_Wgt Real Inbound weight in tertiary units (Currently Not Used)

TimeDate DateTime Time and date of inbound weighment (Currently Not Used)

Scale Byte Scale number (Currently Not Used)

Keyed Byte Keyed Tare (Currently Not Used)

Table 4-3. Truck Database (1,000 Records)

Hardware Setup

5.0 Hardware Setup

This section provides information regarding the setup of option card locations, digital I/O and serial ports.

Slot Type

1 Dual Channel Serial Card

2 1 MB Memory Card

3 Single A/D Card

4 Dual Channel Serial Card

Table 5-1. Option Card Locations

Slot Bit Type Function

0 1-6 Off Currently Not Used

Table 5-2. Digital I/O

Port Type Description Setup

1 Programmability HID RF tag reader 9600,8,N,2

2 CMD iRev, Qwerty keyboard or ethernet 115200,8,N,2

3 Programmability Numeric Keypad 9600,8,N,2

4 CMD Left blank for iQube2 (RS-485)

By default not configured

9600,8,N,2

5 CMD American Custom VK80II Printer 19200,8,N,2

6 CMD N/A 9600,8,N,2

Table 5-3. Serial Port

920i Single Kiosk Truck In/Out Operation Manual

6 Visit our website www.RiceLake.com
