Installation and Mounting:
1. On the mounting plane, prepare surface with
three tapped holes, H1-H3 for M4/M4.5
mounting screws. H2& H3 are 3.815”
[96.9mm] from H1. See Figure 1. NOTE that
the single hole on the side with the two slots
is not meant to be used for mounting.
2. Mount inclinometer to mounting plane using
M4/M4.5 mounting screws. Use the two slots
for fine adjustments.
Default Horizontal Mount Option: Axis
Orientation
The 0° orientation for the horizontal-mount
option H6EX-B is a desktop, level position.
•For the X-axis, looking at the unit from
the side with the connector facing to
the right (top right of Figure 2), a
clockwise rotation from the zero
position is considered positive and a
counter-clockwise rotation from the
zero position is considered negative.
•For the Y-axis, looking at the unit from
the front with the connector facing
towards you (top left of Figure 2), a
clockwise rotation from the zero
position is considered positive and a
counter-clockwise rotation from the
zero position is considered negative.
Alternate Vertical Mount Option: Axis
Orientation
The 0° orientation for the vertical-mount option of the H6EX-B is a vertical position with the connector down.
•For the X-axis, looking at the unit from the top side with the connector facing down (bottom left of
Figure 2), a clockwise rotation from the zero position is considered positive and a counter-clockwise
rotation from the zero position is considered negative.
•For the Y-axis, looking at the unit from the side with the connector facing down and the mounting
surface to the left (bottom right of Figure 2), a clockwise rotation from the zero position is considered
positive and a counter-clockwise rotation from the zero position is considered negative.
