Roborock Dyad Pro Bedienungsanleitung
Read this manual carefully before using this product and
store it properly for future reference.
Roborock Dyad Pro
Wet and Dry Vacuum Cleaner User Manual
03
English 03
Français 22
Español 41
Contents
04 Safety Information
06 International Symbols Explanation
07 FCC Statement
09 Product Introduction
10 Product Installation
11 Connecting to the App
12 Instructions for Use
17 Routine Maintenance
20 Basic Parameters
20 Holiday Energy Saving Function
21 Common Issues
English
04
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Safety Information
When using an electrical appliance, basic precautions should always be followed, including the following:
•READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE).
•Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
•Do not use outdoors or on wet surfaces when charging. Store indoors. Use indoor only.
•Do not allow to be used as a toy. Close attention is necessary when used by or near children, pets or plants.
•Use only as described in this manual. Use only manufacturer’s recommended attachments.
•Use the maintenance brush carefully to avoid injury. Keep out of reach of children.
•Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into
water, return it to a service center.
•Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run appliance
over cord. Keep cord away from heated surfaces.
•Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
•Do not handle Power Supply, including Power Supply plug, and Power Supply terminals with wet hands.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce air flow.
•Do not immerse. Use only on carpet moistened by cleaning process.
•Brush may start unexpectedly. To reduce the risk of injury from moving parts, keep the power off before cleaning or servicing.
•Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
•Use extra care when cleaning on stairs.
•Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
•Prevent unintentional starting. Ensure the switch is in the off-position before picking up or carrying the appliance. Carrying the appliance
with your finger on the switch or energizing appliance that have the switch on invites accidents.
•Recharge only with the Power Supply specified by the manufacturer. A Power Supply that is suitable for one type of battery pack may create
a risk of fire when used with another battery pack.
To reduce the risk of fire, electric shock or injury:
05
Safety Information
SAVE THESE INSTRUCTIONS
Household use only.
•Use appliances only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
•When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal
objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
•Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
•Do not use a battery pack or appliance that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
•Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to fire or temperature above 130°C (266 °F) may
cause explosion.
•Follow all charging instructions and do not charge the battery pack or appliance outside of the temperature range specified in the
instructions. Charging improperly or at temperatures outside of the specified range may damage the battery and increase the risk of fire.
•Have servicing performed by a qualified repair person using only identical replacement parts. This will ensure that the safety of the product
is maintained.
•Do not modify or attempt to repair the appliance or the battery pack except as indicated in the instructions for use and care.
•Always turn off this appliance before connecting or disconnecting motorized nozzle.
•Do not use without filters in place.
•Do not use a flammable or combustible liquid to clean a floor.
06
Safety Information
Battery and Charging
•Please keep the power supply and docking station away from heat (such as heating plates).
•For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper configuration for the power outlet, if needed.
•The battery must be removed from the appliance before it is scrapped.
•The appliance must be disconnected from the supply mains when removing the battery.
•The battery is to be disposed of safely. Please do not discard waste batteries. Leave them to a professional recycling organization.
•Do not wipe or clean the power supply or docking station shrapnel with a piece of wet cloth or wet hands.
•Please make sure the cleaner is powered off in shipment and original packaging is advised.
•If left unused for a long period, please store the cleaner in a cool and dry place afer having it fully charged and switched off, charge it at
least every three months to avoid the battery being over discharged.
•Please do not use the product when the temperature is higher than 40°C (104°F) or lower than 4°C (39°F) , or there is any liquid or sticky
substance on the floor.
Battery pack charging temperature
Battery pack using temperature
Battery pack storage temperature
Storage(within 3 months)
Long Storage(3months)
4°C ~ 40°C (39 ~ 104°F)
4°C ~ 40°C (39 ~ 104°F)
-20°C ~ 45°C (-4 ~ 113 °F)@Less than 75% RH
25+/- 3°C (77 °F +/- 37.4 °F)@Less than 75% RH
International Symbols Explanation
– ON-OFF (push-push) symbol [symbol IEC 60417-5010 (2009-02)]
– ALTERNATING CURRENT symbol [symbol IEC 60417-5032 (2009-02)]
– DIRECT CURRENT symbol [symbol IEC 60417-5031 (2009-02)]
07
FCC Statement
Compliance Information
Product Name
Product Model
Compliance Statement
Company
Address
Email
Correspondence of the responsible party in USA
Wet and Dry Vacuum Cleaner and Accessories
Wet and Dry Vacuum Cleaner Model: WD2H1A
Power Supply Model: YJS060P-3001900U, E060-1P300190VU
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including inter-ference that may
cause undesired operation.
Roborock Technology Co.
16192 COASTAL HWY LEWES, DE 19958 US
support@roborock.com
08
FCC Statement
Warning
Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
IC Statement
MPE Requirements
This device contains licence-exempt transmitter(s)/receiver(s) that comply with innovation, Science and Economic Development Canada’s
licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired
operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement
économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1)L’appareil ne doit pas produire de brouillage;
(2)L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
To satisfy FCC / IC RF exposure requirements, a separation distance of 20 cm or more should be maintained between the antenna of this
device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended.
CAN ICES-3 (B)/NMB-3(B)
09
Vacuum Cleaner
Product Introduction
Self-Clean
Power
Press: Start/Pause
Press and hold for 2s: Switch off
Press while charging: Start/Stop drying
Press: Switch to AUTO/MAX/
Floor Drying/ECO mode
Press: Standard mode
Press and hold for 2s: DEEP mode
Change Mode
Clean Tank Release
LED Display
Detergent Cartridge
Cleaning Head
Clean Tank
Dirty Tank Release
Dirty Tank
Splash Guard Lift Toggle
Rear Roller
Front Rollers
Handle
Accessories
Drying & Charging Dock Maintenance Brush
FilterPower Supply
Charging
Battery Level
Self-Cleaning
Clean Tank Empty
Dirty Tank Full
ECO Mode
AUTO Mode
Dirt Level
Body
Tray
Floor Drying Mode
MAX Mode
Drying
Error
WiFi
Screen Functions
10
Charging Dock Installation
1. Align the charging dock tray with the charging dock body, press
down, making sure they are firmly secured.
2. Connect the power supply into the bottom of the charging dock
and plug it in. Power cable can exit from the side.
3. To disassemble the charging dock, grasp the side handles of
the tray and pull upward.
Product Installation
Setting Up the Vacuum Cleaner
1. Insert the handle into the vacuum body until it clicks in place.
The power button should face forwards.
2. To remove the handle, remove the clean tank and then gently
pull the handle while pressing the release button on the
vacuum body.
Click
PressPress
Insert
Remove
11
If the mobile phone fails to connect to the vacuum cleaner because your router
configuration has changed or you forget your password or for any other reasons, reset WiFi
and add your device again.
1. Download the App.
Search "Roborock" in the App Store or Google Play or scan the
QR code below to download and install the app.
a. Keep the machine upright and press to light up the screen
and enter standby mode.
b. Press and hold and until you hear the "Resetting WiFi"
voice alert. The reset is complete when the WiFi indicator
flashes slowly. The vacuum cleaner will then wait for a
connection.
On the Roborock App, tap “+” on the home page, and add the
device as instructed in the app.
2. Reset WiFi. 3. Add the Device.
Connecting to the App
Note:
Notes:
•The actual process may vary due to ongoing app updates. Follow the instructions provided
in the app.
•Only 2.4 GHz WiFi is supported.
•If the vacuum cleaner waits more than half an hour for a connection, WiFi will be
automatically disabled. If you want to reconnect, reset the WiFi before proceeding.
WiFi Indicator
•Off: WiFi disabled
•Flashing slowly: Waiting for connection
•Flashing quickly: Connecting
•Steady on: WiFi connected
Press and hold the
buttons simultaneously
