Rointe Elba PRO 400 Bedienungsanleitung

Elba electric pro

Models / Modelos / Modèle / Modellen

PRO 400 | 450 | 500 | 550

MANUAL DE INSTALACIÓN Y USO

Página 14

MANUAL DE INSTALAÇÃO E UTILIZAÇÃO

Página 26

INSTRUCTIONS & INSTALLATION GUIDE

Page 02

INSTALLATIE- EN GEBRUIKERSHANDLEIDING

Bladzijde 50

MANUEL D’INSTALLATION ET D’UTILISATION

Page 38

Installation & safety precautions (EN 60335 Standards)

Before switching on the product, please read the “Installation & Safety Precautions” in detail rst to

ensure the correct operation of the product.

Installation precautions

The product is designed for household or residential use. You are advised to have the product installed

by an authorized professional installer. Make sure the product is properly connected to 230V.

ATTENTION

Children under 3 years of age should be kept out of reach of the appliance

unless continuously supervised. Children from the age of 3 years to 8

years should only switch the appliance on/off when it has been placed

or installed in its normal intended use position and when they have been

given supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children from 3 years of age to

8 years of age should not plug in, adjust or clean the appliance or carry out

maintenance operations.

This appliance can be used by children aged from 8 years and above

and persons with reduced physical sensory or mental capabilities or lack

of experience and knowledge if they are supervised or have been given

instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children should not play with the appliance. Cleaning

and user maintenance should not be carried out by children without

supervision. Children must be supervised at all times to ensure that they

do not interfere with the product.

This product is lled with a precise amount of special oil that does not

need any maintenance. Any repairs requiring the opening of the oil tank

must only be done by an ofcial Rointe installer or its after-sales service

personnel, who should also be notied should an oil leak be noticed. The

regulations on discarding oil when the heater is being disposed of must be

observed.

Do not cut the power supply cable under any circumstances in order to

avoid electrical risks and to guarantee the correct operation of the towel

rail.

Do not switch on the product if you notice any external damage when

unpacking or installing the towel rail. If the power cable is damaged, it

must be replaced by the manufacturer, its after-sales service or authorized

personnel in order to avoid any damage.

ELBA PRO EN

Do not spray or wet the product. During operation, keep the product

away from combustible materials such as curtains, furniture, etc. Do not

place anything other than clothes, towels or non-ammable fabrics on the

product.

The towel rail must be installed in such a way that the power plug is always

accessible. The power cable must never be in contact with the product

during operation.

CAUTION - Never touch the product with wet hands or any wet

body parts.

CAUTION - Some parts of this product may become very hot

and cause burns. Particular care should be taken when children

and vulnerable persons are present.

Contents

1. Technical Specications..........................................................................................................................4

2. Product Installation.................................................................................................................................8

2.1. Mounting..........................................................................................................................................8

2.2. Connecting instructions.................................................................................................................9

2.3. Specic regulations for bathrooms...............................................................................................9

3. Switch on & off (stand-by).......................................................................................................................10

4. Maintenance & Cleaning................................................................................................................,........10

5. Guarantee.................................................................................................................................................10

6. How to register your guarantee..............................................................................................................12

1. Technical speciﬁcations (Models 400, 450, 500 & 550)

MODEL - Width 400 WHITE TELO*40B077 TELO*40B112 TELO*40B150 TELO*40B172

CHROME TELO*40C077 TELO*40C112 TELO*40C150 TELO*40C172

DIMENSIONS

Width (mm) 400 400 400 400

Height with control panel (mm) 863 1,213 1,593 1,813

Depth (mm) 50 50 50 50

Installed depth (mm) 100 100 100 100

MECHANICAL CHARACTERISTICS

Stainless steel heating element 

Thermal ﬂuid 

On/Off control 

Finish

White RAL 9016

Chrome

ELECTRICAL CHARACTERISTICS

Nominal power (W)

White 300 500 700 1,000

Chrome 300 300 500 700

Voltage (V) 230 V ~ 230 V ~ 230 V ~ 230 V ~

Current (A)

White 1.3 2.2 3.3 4.4

Chrome 1.3 1.3 2.2 3.3

Class I 

SAFETY & INSTALLATION

Installation kit included 

Safety thermostat 

Protection grade IP 54 IP 54 IP 54 IP 54

ELBA PRO EN

MODEL - Width 450 WHITE TELO*45B077 TELO*45B112 TELO*45B150 TELO*45B172

CHROME TELO*45C077 TELO*45C112 TELO*45C150 TELO*45C172

DIMENSIONS

Width (mm) 450 450 450 450

Height with control panel (mm) 863 1,213 1,593 1,813

Depth (mm) 50 50 50 50

Installed depth (mm) 100 100 100 100

MECHANICAL CHARACTERISTICS

Stainless steel heating element 

Thermal ﬂuid 

On/Off control 

Finish

White RAL 9016

Chrome

ELECTRICAL CHARACTERISTICS

Nominal power (W)

White 300 500 700 1,000

Chrome 300 300 500 700

Voltage (V) 230 V ~ 230 V ~ 230 V ~ 230 V ~

Current (A)

White 1.3 2.2 3.3 4.4

Chrome 1.3 1.3 2.2 3.3

Class I 

SAFETY & INSTALLATION

Installation kit included 

Safety thermostat 

Protection grade IP 54 IP 54 IP 54 IP 54

MODEL - Width 500 WHITE TELO*50B077 TELO*50B112 TELO*50B150 TELO*50B172

CHROME TELO*50C077 TELO*50C112 TELO*50C150 TELO*50C172

DIMENSIONS

Width (mm) 500 500 500 500

Height with control panel (mm) 863 1,213 1,593 1,813

Depth (mm) 50 50 50 50

Installed depth (mm) 100 100 100 100

MECHANICAL CHARACTERISTICS

Stainless steel heating element 

Thermal ﬂuid 

On/Off control 

Finish

White RAL 9016

Chrome

ELECTRICAL CHARACTERISTICS

Nominal power (W)

White 300 500 700 1,000

Chrome 300 300 500 700

Voltage (V) 230 V ~ 230 V ~ 230 V ~ 230 V ~

Current (A)

White 1.3 2.2 3.3 4.4

Chrome 1.3 1.3 2.2 3.3

Class I 

SAFETY & INSTALLATION

Installation kit included 

Safety thermostat 

Protection grade IP 54 IP 54 IP 54 IP 54

ELBA PRO EN

MODEL - Width 550 WHITE TELO*55B077 TELO*55B112 TELO*55B155 TELO*55B172

CHROME TELO*55C077 TELO*55C112 TELO*55C155 TELO*55C172

DIMENSIONS

Width (mm) 550 550 550 550

Height with control panel (mm) 863 1,213 1,593 1,813

Depth (mm) 50 50 50 50

Installed depth (mm) 100 100 100 100

MECHANICAL CHARACTERISTICS

Stainless steel heating element 

Thermal ﬂuid 

On/Off control 

Finish

White RAL 9016

Chrome

ELECTRICAL CHARACTERISTICS

Nominal power (W)

White 300 500 700 1,000

Chrome 300 300 500 700

Voltage (V) 230 V ~ 230 V ~ 230 V ~ 230 V ~

Current (A)

White 1.3 2.2 3.3 4.4

Chrome 1.3 1.3 2.2 3.3

Class I 

SAFETY & INSTALLATION

Installation kit included 

Safety thermostat 

Protection grade IP 54 IP 54 IP 54 IP 54

2. Product installation

2.1. Mounting instructions

Inside the packaging you will nd a xing kit. Please nd the instructions below:

1. Choose the right part of the wall.

2. Place the mounting stencil on the wall, marking the places for the holes.

3. Remove the stencil and make the holes in the wall.

4. Insert the rawl plugs in the holes made.

5. Screw the plastic fastener to the wall with the 5.5 x 50 mm screw.

6. Screw the two brackets for supporting the product and the plastic fastener to the horizontal tube

of the product like in Figure 1 with the 8 x 26 mm screw.

7. Insert what you have assembled in Section 6 into the plastic piece and x well with the 5 x 12

mm screw.

8. Place the cover on the piece supporting the product.

NO. ELEMENT

110 x 40 mm Rawl Plug

2Bracket

35.5 x 50 mm Screw

45 x 12 mm Screw

5Bracket Insert

6Bracket Head

78 x 26 mm Screw

8Cap

9Product

2.2. Connecting instructions

Connection to the mains must be made observing the voltage stated on the product technical data label.

This product is designed to be permanently installed connected to xed facilities. The product power

supply circuit must have an all-pole circuit breaker switch with a separation of at least 3 mm between

the contacts.

The product must be installed, if possible, away from any source of draughts (windows, doors) or any

other thing which may affect its functioning. In this way, the temperature will not be affected. Place any

object which might prevent the air ow (furniture, armchairs) 50 cm away from the front of the product.

The product must never be installed immediately below a power point.

The lower part of the control panel must be placed at least 15 cm from the oor.

ELBA PRO EN

For any product, if the power cable is damaged, it must be replaced by a specic cable. The replacement

of the cable must be done by the maker, its after-sales service or qualied personnel. The technical

specications of your product appear on the technical data label.

IMPORTANT - This product must never be installed with its control

panel at the top. This product must not be installed horizontally. During

installation, use wedges so that the control panel will not be in contact

with the ﬂoor.

2.3. Speciﬁc Regulations for Bathrooms

This product can be safety installed in Zones 3. For installations in Zones 2 (check the scheme below),

please consider the following limitations:

•

In bathrooms, the product must never be installed in such a way that the control panel may be touched

by someone in the bathtub or having a shower. The control panel should be located at least 600 mm

distance from any wet areas. The body of the product can be placed in Zones 2 if the control panel is

located inside Zone 3.

• In a kitchen or bathroom, the body of the product must be placed at least 25 cm from the oor.

• Is mandatory to connect the product to an earthed electrical outlet.

3. Switch on & off (stand-by)

To switch the product on, please press the green button once. To switch the product off, please

press it again.

ON/OFF button

4. Maintenance & Cleaning

The product does not require any type of maintenance. We recommend that all parts of the product

are kept clean (behind, underneath, upper ns, etc.). Do not use any abrasive product on the steel

main body. Clean it with a damp cloth and a pH neutral soap, and the control panel with a dry cloth.

European Directive 2012/19/UE

Under the European Directive 2012/19/UE on waste electrical and electronic equipment (WEEE), the

product cannot be disposed in the usual council bins and containers. They must be separated to

optimize the recovery and recycling of all of the components and materials and reducing the impact

to human health and the environment. The symbol of the container crossed out over a horizontal

line is marked on all of Rointe products to remind the consumer of the obligation to separate them

on disposal. The consumer should contact the local authority or original point of sale to learn more

about the correct disposal of this product.

5. Guarantee

In this section, we hereby describe the guarantee conditions which the buyer acquires on buying a

new Rointe product. These conditions comply with all the rights construed in the national legislation

in force, as well as any additional rights and guarantees which are offered by Rointe.

5.1. Any incident that you might detect in your Rointe product can be sorted by the product seller or

quickly by the manufacturer. Please contact Rointe by telephoning (UK) 0203 321 5929 or (Ireland)

01 553 0523 for technical support. If you live in a different country, please check the correct phone

number on the back of this manual.

ELBA PRO

TELON45B077

300 W

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Rointe Heizung Handbücher

Rointe

Rointe Kyros Betriebsanleitung

Rointe

Rointe Kyros Bedienungsanleitung

Rointe

Rointe Sygma SRI0330RAD2 Bedienungsanleitung

Rointe

Rointe Giza PRO 400 Bedienungsanleitung

Rointe

Rointe SYGMA BAS SRF1100RADC2 Bedienungsanleitung

Rointe

Rointe Kyros Bedienungsanleitung

Rointe

Rointe D SERIES Bedienungsanleitung

Rointe

Rointe ecodesign BELIZE Bedienungsanleitung

Rointe

Rointe Symga Bedienungsanleitung

Rointe

Rointe ecodesign BELIZE BAS Bedienungsanleitung

Rointe

Rointe TN030SEB Bedienungsanleitung

Rointe

Rointe KYROS SHORT KRI1100RADC3 Bedienungsanleitung

Rointe

Rointe SYGMA Bedienungsanleitung

Rointe

Rointe SYGMA SHORT Bedienungsanleitung

Rointe

Rointe ecodeisgn SYGMA SRF0500RAD2 Bedienungsanleitung

Rointe

Rointe K series Bedienungsanleitung

Rointe

Rointe D SERIES Bedienungsanleitung

Rointe

Rointe Impero electric OVAL 500 Bedienungsanleitung

Rointe

Rointe KYROS KRI0330RAD3 Bedienungsanleitung

Rointe

Rointe Torino electric OVAL 500 Bedienungsanleitung

Rointe

Rointe Lyon electric pro Bedienungsanleitung

Rointe

Rointe Sygma SRI0330RAD2 Bedienungsanleitung

Rointe

Rointe Loira electric OVAL 432 Bedienungsanleitung

Rointe

Rointe Kyros Bedienungsanleitung

Beliebte Heizung Handbücher anderer Marken

oventrop

oventrop Regucor Series Bedienungsanleitung

Blaze King

Blaze King CLARITY CL2118.IPI.1 Bedienungsanleitung

ELMEKO

ELMEKO ML 150 Bedienungsanleitung

BN Thermic

BN Thermic 830T Bedienungsanleitung

KING

KING K Series Leitfaden

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Kurzanleitung

Well Straler

Well Straler RC-16B Bedienungsanleitung

EUROM

EUROM 333299 Bedienungsanleitung

Heylo

Heylo K 170 Bedienungsanleitung

Eterna

Eterna TR70W Bedienungsanleitung

Clarke

Clarke GRH15 Bedienungsanleitung

IRSAP

IRSAP The Radiator Company Ovali Bedienungsanleitung

Empire Heating Systems

Empire Heating Systems WCC65 Bedienungsanleitung

Wetekom

Wetekom 92 86 43 Bedienungsanleitung

Desa

Desa SPC170-F Bedienungsanleitung

Watlow

Watlow Watrod Electric Tubular Heaters Bedienungsanleitung

Haverland

Haverland ECO-DRY GPS Series Stücklistenhandbuch

Stelpro

Stelpro ASILVC2060 Series Bedienungsanleitung
