ROSE DISPLAYS QUICKGRIP WITH WINDOW MOUNTS Bedienungsanleitung

Parts

Instructions for Hanging

Instruction Sheet

Step 1

For use with poster paper or thinner

substrates. Score and fold or staple poster

edge and slide into the QuickGrip Holder.

When using staples, place staples 1/4” from

top and bottom edges of poster. Fig. 1

For use with thicker graphics up to 2mm.

Starting at one corner push the QuickGrip

Holder onto the graphic. Work your way

down the holder tapping it firmly down to

seat the graphic fully. Fig. 2

Step 3

Slide window mounts into the top rail of the

QuickGrip holder. Fig. 3

Place one window mount about 1/3 from each

edge of the holder.

Step 4

Push end caps into place. Fig. 5

Step 5

Suspend poster. Fig. 6

Important note:

Please save and reuse the QuickGrip Holder,

End Caps and Window Mounts for future

projects.

End Caps

06-5525

QuickGrip™

Incept-12.31.02

QuickGrip is a trademark of Rose Displays, Ltd. Neither the manufacturer

nor any sales agent may be held liable for injury, loss or damage resulting

from the use of these products. Part #02QuickGripWindowMounts

QuickGrip

12-0500

Figure 5Figure 4

Figure 3

Figure 2

Figure 1

Window

Mounts

20-0038

35 Congress Street, Salem, MA 01970

Tel# 1- 800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Instructions for Hanging

Instruction Sheet

Step 1

For use with poster paper or thinner

substrates. Score and fold or staple poster

edge and slide into the QuickGrip Holder.

When using staples, place staples 1/4” from

top and bottom edges of poster. Fig. 1

For use with thicker graphics up to 2mm.

Starting at one corner push the QuickGrip

Holder onto the graphic. Work your way

down the holder tapping it firmly down to

seat the graphic fully. Fig. 2

Step 3

Slide window mounts into the top rail of the

QuickGrip holder. Fig. 3

Place one window mount about 1/3 from each

edge of the holder.

Step 4

Push end caps into place. Fig. 5

Step 5

Suspend poster. Fig. 6

Important note:

Please save and reuse the QuickGrip Holder,

End Caps and Window Mounts for future

projects.

End Caps

06-5525

QuickGrip™

Incept-12.31.02

QuickGrip is a trademark of Rose Displays, Ltd. Neither the manufacturer

nor any sales agent may be held liable for injury, loss or damage resulting

from the use of these products. Part #02QuickGripWindowMounts

QuickGrip

12-0500

Figure 5Figure 4

Figure 3

Figure 2

Figure 1

Window

Mounts

20-0038
