RS PRO RM-804 Bedienungsanleitung

Instruction Manual

RM-804 & RM-805

D.C. Milli-Ohm Meter

EN FR DE IT SP

Table of Contents

13/10/2016 Version No. 001 1

Table of Contents

SAFETY INSTRUCTIONS ...............................................................3

GETTING STARTED.......................................................................8

RM-804/805 Characteristics ............................................. 10

Key Features ................................................................... 13

Model Lineup................................................................... 14

Front Panel Overview.......................................................15

Rear Panel Overview ....................................................... 20

TFT-LCD Overview .......................................................... 22

Set Up............................................................................. 24

MEASUREMENT.......................................................................... 29

Resistance Measurement ................................................. 31

Compare Function............................................................45

Binning Function.............................................................. 51

Temperature Measurement ............................................... 57

Temperature Compensation.............................................. 59

Temperature Conversion .................................................. 63

Measurement Settings ..................................................... 68

System Settings...............................................................78

HANDLER/SCAN INTERFACE ...................................................... 89

Handler Overview ............................................................ 90

Scan Overview ................................................................94

Configure Interface ........................................................ 105

SAVE/RECALL............................................................................117

COMMAND OVERVIEW.............................................................. 122

RM-804 & RM-805 Instruction Manual/English

2 13/10/2016 Version No. 001

Command Syntax ...........................................................123

Command List................................................................126

BINNing Commands .......................................................130

Calculate Commands......................................................139

Memory Commands........................................................151

Sense Commands ..........................................................153

Source Commands .........................................................158

Status Commands ..........................................................160

System Commands ........................................................162

Temperature Commands.................................................170

Trigger Commands.........................................................177

Userdefine Commands ...................................................181

IEEE 488.2 Common Commands ....................................184

Status system ................................................................189

FAQ...........................................................................................190

APPENDIX.................................................................................191

Function Selection Combinations ....................................192

Temperature Measurement .............................................193

Specifications.................................................................197

Dimensions....................................................................202

Declaration of Conformity ...............................................203

SAFETY INSTRUCTIONS

13/10/2016 Version No. 001 3

SAFETY INSTRUCTIONS

This chapter contains important safety instructions that you must

follow when operating the RM-804/805 or when keeping it in

storage. Read the following before any operation to insure your

safety and to keep the RM-804/805 in the best possible condition.

Safety Symbols

These safety symbols may appear in this manual or on the RM-804/805.

WARNING

Warning: Identifies conditions or practices that could result in

injury or loss of life.

CAUTION

Caution: Identifies conditions or practices that could result in

damage to the instrument or to other properties.

DANGER High Voltage

Attention Refer to the Manual

Protective Conductor Terminal

RM-804 & RM-805 Instruction Manual/English

4 13/10/2016 Version No. 001

Earth (ground) Terminal

Do not dispose electronic equipment as unsorted municipal

waste. Please use a separate collection facility or contact the

supplier from which this instrument was purchased.

Safety Guidelines

General

Guidelines

CAUTION

Do not place any heavy objects on the instrument.

Avoid severe impact or rough handling that leads to damaging

the instrument.

Do not discharge static electricity to the instrument.

Use only mating connectors, not bare wires, for the terminals.

Do not disassemble the instrument unless you are qualified as

service personnel.

(Measurement categories) EN 61010-1:2010 specifies the measurement

categories and their requirements as follows. The RM-804/805 doesn’t fall under

category II, III or IV.

Measurement category IV is for measurement performed at the source of low-

voltage installation.

Measurement category III is for measurement performed in the building

installation.

Measurement category II is for measurement performed on the circuits directly

connected to the low voltage installation.

Measurement category I is for measurements performed on circuits not directly

SAFETY INSTRUCTIONS

13/10/2016 Version No. 001 5

connected to Mains.

Power Supply

WARNING

AC Input voltage: 100 - 240 V AC, 50 - 60Hz, 25VA

The power supply voltage should not fluctuate more than 10%.

Connect the protective grounding conductor of the AC power

cord to an earth ground, to avoid electrical shock.

Cleaning the

RM-804/805

Disconnect the power cord before cleaning.

Use a soft cloth dampened in a solution of mild detergent and

water. Do not spray any liquid into the instrument.

Do not use chemicals or cleaners containing harsh products

such as benzene, toluene, xylene, and acetone.

Operation

Environment

Location: Indoor, no direct sunlight, dust free, almost non-

conductive pollution (Note below)

Temperature Range: 0~35°C, Relative Humidity: <80%RH;

>35°C, Relative Humidity: <70%RH

Altitude: < 2000m

Operating Environment: 0°C to 40°C (operation)

Pollution Degree 2

RM-804 & RM-805 Instruction Manual/English

6 13/10/2016 Version No. 001

(Note) EN 61010-1:2010 specifies the pollution degrees and their requirements as

follows. The RM-804/805 falls under degree 2.

Pollution refers to “addition of foreign matter, solid, liquid, or gaseous (ionized

gases), that may produce a reduction of dielectric strength or surface resistivity”.

Pollution degree 1: No pollution or only dry, non-conductive pollution occurs.

The pollution has no influence.

Pollution degree 2: Normally only non-conductive pollution occurs.

Occasionally, however, a temporary conductivity caused by condensation must

be expected.

Pollution degree 3: Conductive pollution occurs, or dry, non-conductive

pollution occurs which becomes conductive due to condensation which is

expected. In such conditions, equipment is normally protected against

exposure to direct sunlight, precipitation, and full wind pressure, but neither

temperature nor humidity is controlled.

Storage

environment

Location: Indoor

Storage Conditions: −10°C to 70°C

Temperature Range: 0~35°C, Relative Humidity: <90%RH;

>35°C, Relative Humidity: < 80%RH

Disposal

Do not dispose this instrument as unsorted municipal waste.

Please use a separate collection facility or contact the supplier

from which this instrument was purchased. Please make sure

discarded electrical waste is properly recycled to reduce

environmental impact.

SAFETY INSTRUCTIONS

13/10/2016 Version No. 001 7

Power cord for the United Kingdom

When using the oscilloscope in the United Kingdom, make sure the power cord

meets the following safety instructions.

NOTE: This lead/appliance must only be wired by competent persons

WARNING: THIS APPLIANCE MUST BE EARTHED

IMPORTANT: The wires in this lead are coloured in accordance with the following code:

Green/ Yellow:

Earth

Blue:

Neutral

Brown:

Live (Phase)

As the colours of the wires in main leads may not correspond with the coloured

marking identified in your plug/appliance, proceed as follows:

The wire which is coloured Green & Yellow must be connected to the Earth terminal

marked with either the letter E, the earth symbol or coloured Green/Green &

Yellow.

The wire which is coloured Blue must be connected to the terminal which is marked

with the letter N or coloured Blue or Black.

The wire which is coloured Brown must be connected to the terminal marked with

the letter L or P or coloured Brown or Red.

If in doubt, consult the instructions provided with the equipment or contact the

supplier.

This cable/appliance should be protected by a suitably rated and approved HBC

mains fuse: refer to the rating information on the equipment and/or user instructions

for details. As a guide, a cable of 0.75mm2should be protected by a 3A or 5A fuse.

Larger conductors would normally require 13A types, depending on the connection

method used.

Any exposed wiring from a cable, plug or connection that is engaged in a live socket

is extremely hazardous. If a cable or plug is deemed hazardous, turn off the mains

power and remove the cable, any fuses and fuse assemblies. All hazardous wiring

must be immediately destroyed and replaced in accordance to the above standard.

RM-804 & RM-805 Instruction Manual/English

8 13/10/2016 Version No. 001

GETTING STARTED

This chapter describes the RM-804/805 in a nutshell, including its

main features as well as its front and rear panels. After going

through the panel overview, follow the Power-up sequence before

attempting to use the instrument.

Please note the information in this manual was correct at the time

of printing. However as RS PRO continues to improve its

products, changes can occur at any time without notice. Please

see the RS PRO website for the latest information and content.

RM-804/805 Characteristics......................................... 10

Key Features .............................................................. 13

Model Lineup .............................................................. 14

Front Panel Overview .................................................. 15
