ENGLISH
1
PX4000
PX4000 - Head On
4 Buttons
Turbo Button
Start Button
Analog Button
Select Button
8-Way D Pad
Right Analog Stick
Left Analog Stick
Throttle Wheel
L1
L2
R1
R2
Analog Mode LED
Turbo LED
(Analog
compatible)
(Analog
compatible)
Triggers (R1, R2, L1 & L2)
(Analog compatible)
PP8X2 English 3 5/11/01 1:02 PM Page 1
Introduction
Congratulations on your purchase of the new Saitek PX4000 gamepad. The Saitek PX4000 gives you
the latest Twin Analog technology on a gamepad for the Sony PlayStation2™/PSone™/PlayStation™
and combines it with Double Shock/Double Shock 2 to produce a superior product for the discerning
gamer. Ergonomically designed with a superbly sculptured Throttle Wheel and Double Shock/Double
Shock 2, the Saitek PX4000 offers a fusion of the latest technology with top-of-the range styling.
Getting Started
Securely insert the gamepad connector into the connector port of your Sony
PlayStation2™/PSone™/PlayStation™console. Switch on your console and insert your chosen game
and follow the on-screen instructions.
EXTRA FEATURES AVAILABLE WITH THE PX4000
Switching Between Digital and Analog Modes
The Saitek PX4000 comes with two Analog Sticks for increased precision, performance and playing
power. Most of the push buttons, including the D-Pad, x, o, ∆,o, L1, L2, R1 and R2 are also proportion-
al to the pressure applied on these buttons and allow precision controls and flexibility in PlayStation 2™
(on supported games only). Simply select the Analog Mode for complete control in driving and flying
games or any game where accuracy in movement is crucial.
Switch between Digital and Analog Modes by pressing the Analog Mode Button. The Analog LED will
light up when the gamepad is in Analog Mode. In some cases, the game itself will make this change
automatically, overriding the Analog/Digital Mode. For more details, consult the game’s user manual. The
default power-up mode for the gamepad is Digital Mode.
ENGLISH
2
SAFETY FIRST
PP8X2 English 3 5/11/01 1:03 PM Page 2
Using the PX4000 in Digital Mode
In this mode, the Saitek PX4000 simulates the standard Sony PlayStation2™/PSone™/PlayStation™
gamepad. The Analog Sticks work in Digital Mode, emulating the D-Pad and buttons and if pressed,
work as the L1 and R1 buttons.
Using the PX4000 in Analog Mode
In Analog Mode, as well as the standard Digital features, the dual Analog Sticks of the Saitek PX4000
become active. Used with the Throttle Wheel, it makes the PX4000 ideal for use with those games that
require a high level of control.
To use the Analog features, look for games that display the
‘Analog Controller Compatible’label on the game’s packaging.
Lockable Axis on Analog Sticks
To improve your gaming, Saitek have added a unique feature to the
PX4000 – a lockable axis for the Analog Sticks. This is ideal for
those situations when the axes need to be separately controlled, eg,
for steering or for accelerator/brake function. Simply press down the
button to the side of the stick and rotate the dial to the direction lock
you require - either "Up/Down" or "Right/Left" depending on the type
of game you are playing. This will especially improve your control in
driving and first-person games.
3
ENGLISH
ANALOG
BUTTON
PRESS
MODE ANALOG
LED D-PAD LEFT
ANALOG
STICK
RIGHT
ANALOG
STICK
THROTTLE
WHEEL
DIGITAL OFF ON D-PAD ■
X
▲● ON / ■
X
POWER-UP
DEFAULT
1st PRESS
2nd PRESS
ANALOG ON ON ANALOG
STICK ANALOG
STICK ON / ■
X
ANALOG &
THROTTLE FLASHING
ON ANALOG
STICK OFF
ON /
ANALOG YR
3rd PRESS REVERT TO DEFAULT
PP8X2 English 3 5/11/01 1:03 PM Page 3
ENGLISH
4
Analog Sticks Work In All Modes
Unlike most other gamepads, where the Analog Sticks will not function in Digital Mode, the Analog
Sticks of the Saitek PX4000 do work in Digital Mode - emulating the D-Pad and the 4 Buttons. The ben-
efits of this are that your new gamepad will work in your old Digital games and that it will also give you
the choice of using either the Analog Sticks or D-Pad 4 Buttons – suiting your personal gaming style
exactly.
Double Shock/Double Shock 2
Double Shock/Double Shock 2 are the names we give to Saitek’s superior, ultra-responsive Shock
Technology. Games for the Sony PlayStation 2™/PSone™/PlayStation™ displaying the Dual
Shock™/Dual Shock 2™ logos will activate the twin Shock motors integrated into the Saitek PX4000
gamepad. These motors are situated both left and right on the pad and operate in varying degrees of
strength, from a slight shock to full feedback.
Throttle Wheel
The Saitek PX4000 comes with a self-centering Throttle Wheel for improved play - especially in driving
and flying games. It is situated in the optimum position for precision game play – allowing the user to
control the wheel with thumb or finger. The power-up default setting for the Throttle Wheel is ON.
Turbo Functions
Each of the buttons can be independently selected to have the Turbo function. Press and hold down the
Turbo key and the Turbo LED will be lighted steadily. Then, press the button(s) you prefer with turbo
function once, (press it a second time will turn off turbo on that button). When you are done, release the
Turbo key to exit and the Turbo LED will be off.
Pressing any of the programmed keys will now have the stream-firing effect. The Turbo LED will flash to
indicate the action.
PP8X2 English 3 5/11/01 1:03 PM Page 4
Troubleshooting
Technical Support
The Saitek Website
If you have access to an Internet connection, many of your technical queries may be answered with a
simple visit to the Saitek Website at: http://www.saitek.com
The technical support area will provide you with all the information you need to get the most out of your
gamepad and solve any problems that you might have.
The site also contains regularly updated material including information about:
•Current and forthcoming products
• Links to useful sites
• Useful information
Contacting Saitek
If you do not have access to the Internet, or if the Saitek Website cannot answer your question, you will
need to contact your local Saitek Technical Support Team.
5
ENGLISH
PP8X2 English 3 5/11/01 1:03 PM Page 5
ENGLISH
6
However, before contacting Technical Support, here are a few tips to help us to help you:
• Make sure you have followed all the steps shown in this manual
• Check that the gamepad is correctly connected to your Sony PlayStation2™/PSone™
/PlayStation™
At Saitek, we aim to offer a comprehensive and thorough technical support to all of our users. So,
before you call, make sure that you have all of the information necessary for us to help you.
•Know the problem
•Know the version of the game you are playing
• Be ready – if possible, please try and ring whilst sitting at the Sony PlayStation2™/ PSone™/
PlayStation™ with all the relevant information and hardware to hand. If you are having a problem
with a particular game, make sure that you have that game loaded
To contact your local Saitek Technical Support Center, look up the relevant address on the separate
Saitek Support Sheet that comes packaged with this product.
"Sony" is a registered trademark of Sony Corporation
"Sony PlayStation2™/PSone™/PlayStation™" are a registered trademarks of Sony Computer
Entertainment Inc.
"Dual Shock and Dual Shock 2" are a registered trademarks of Sony Computer Entertainment Inc.
