Samson Go Mic Bedienungsanleitung

Quick Start Guide

Samson Technologies

45 Gilpin Avenue

Hauppauge, New York 11788-8816

Phone: 1-800-3-SAMSON (1-800-372-6766)

Fax: 631-784-2201

www.samsontech.com

If you want to dispose this product, do not mix it with general household waste. There is a

separate collection system for used electronic products in accordance with legislation that

requires proper treatment, recovery and recycling.

Private household in the 28 member states of the EU, in Switzerland and Norway may return

their used electronic products free of charge to designated collection facilities or to a retailer (if you

purchase a similar new one).

For Countries not mentioned above, please contact your local authorities for a correct method of

disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery

and recycling and thus prevent potential negative effects on the environment and human health.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions:

(1) This device must not cause harmful interference, and

(2) This device must accept any interference received including interference that may cause

undesired operation.

Suitable for home or ofﬁce use.

EN FR DE ES IT

Introduction

Samson’s Go Mic Connect Portable Stereo USB Microphone is the next step in advanced audio

solutions for digital communication, including VoIP, digital broadcasting and speech-to-text dictation

software. At the root of the design are two matched high-quality microphones and advanced audio

converters, which provide vastly improved audio performance over standard computer microphones.

The microphone features a unique, compact design that mounts to the top of your laptop or comput-

er monitor, as well as a headphone output for zero-latency monitoring.

Additionally the Go Mic Connect features state-of-the-art digital processing which provides Focused

Pattern Technology and Active Noise Cancellation. Focused Pattern Technology creates a concen-

trated pickup pattern that blocks sounds beyond the focal area. This is perfect for noisy ofﬁce

environments, such as call centers, where conversations are going on all around you and you need

to ensure that only your voice is captured. Active Noise Cancellation on the input and output signals

improves intelligibility of the audio heard through VoIP communication. Powering the advanced

features of the Go Mic Connect is the Samson Sound Deck software (available as a free download from

www.samsontech.com).

The Samson Go Mic Connect combines studio-quality sound for ex-

ceptional audio via Skype™, FaceTime®, Google Hangouts™ and

more. Whether you are leading a webinar, recording a podcast, or

staying in touch with your family, the Go Mic Connect is the most

comprehensive solution for high-quality recording. Just plug it in

and start communicating!

Focus Pattern Technology

Microphone Features

Mini USB Connector

Multi-hinge Mounting Clip

Mute/Peak Status Indicator

8” (3.5mm) Stereo

Headphone Jack

Microphone Mute Button

Two Studio Quality Microphone Capsules

EN FR DE ES IT

Quick Start

1. Afﬁx the Go Mic Connect to a monitor or arrange it on a ﬂat service.

2. Position the microphone so that it is facing the sound source.

3. Connect the included USB cable from the microphone into an avail-

able USB port on your computer.

4. If you are using headphones, connect your headphones or speakers

to the headphone output located on the rear of the Go Mic Connect.

5. Launch your audio software and select the Go Mic Connect as the

audio input and output devices.

6. Set the level of the Go Mic Connect by slowly raising the level of

the microphone while talking or singing into the microphone at the

performance level. If you see the peak indicator illuminate red, your

signal will be distorted. Turn the microphone level control down

until it no longer ﬂashes red.

7. The headphones will provide a mix of the direct signal that the

microphone is picking up and the return audio from your software.

If you want to only hear the audio back from your software you will

need to turn off the direct monitoring.

8. If you ﬁnd that there is a lot of background noise in your audio,

turn on the Active Noise Canceling function in the Sound Deck

Software.

9. When using the microphone in a busy environment, try turning on

the Focus Pattern Technology in the Sound Deck Software to en-

sure you only pick up the sound of your voice.

10. Press RECORD and start capturing your performance!

Installing the Go Mic Connect is a simple procedure that takes just a few minutes. Simply connect

the included USB cable and begin recording. The following sections of this manual provide detailed

instructions on setting up your Go Mic Connect in Windows or MAC OS.

Windows

1. The ﬁrst time you plug the Go Mic Connect into a USB port, Windows will install the universal

USB drivers for that port.

2. To set the Go Mic Connect as your default input/recording device, or to change its settings,

open the Control Panel’s Hardware & Sound settings, then click SOUND. Under the Recording

tab, you can select the Samson Go Mic Connect from the list of devices and press the Set

Default button to set the microphone as the default audio input and output device.

3. To set the gain of the microphone, click the Properties button, and then select the Levels tab.

If the Microphone Level setting is displayed by percentage, right-click the slider and change

the setting to decibels. Slide the control until the desired level is reached. A good starting

point is to set the slider to 0dB. If you ﬁnd that the microphone’s red clip LED is lighting

frequently, turn this control down until the LED no longer ﬂashes red.

4. Download and install the Samson Sound Deck software from www.samsontech.com

5. Launch the Sound Deck software (found in the Windows task bar) and listen to the effect of

each algorithm.

Apple MAC OSX

1. To start using the Samson Go Mic Connect, simply plug it in. The LED will illuminate to indicate

it is receiving USB power. The MAC will recognize the USB audio device and automatically

install a universal driver.

2. To select the Go Mic Connect as the computer’s audio input, open System Preferences from

the dock or the main Apple Menu.

3. Next, open the Sound preferences, choose the Input tab and select Go Mic Connect. To set

the gain of the microphone, adjust the Input volume slider at the bottom of the Sound dialog

box. The Input Level meter will show the recording level.

4. Download and install the Samson Sound Deck software from www.samsontech.com

5. In Synstem Preference, click on the Samson Sound Deck icon to launch the software and turn

on the available algorithms.

Computer Setup

EN FR DE ES IT

Samson’s Sound Deck computer software expands the operation of the Go Mic Connect by providing

Focused Pattern Technology™ and Active Noise Reduction algorithms. Sound Deck software works

with Windows and Mac OSX operating systems and can be downloaded at Samson’s website

www.samsontech.com/gomicconnect.

Focused Pattern Technology increases the directionality of the microphone’s

pickup pattern. When activated, all sound that originates outside the

focus area is signiﬁcantly reduced, making the Go Mic Connect ideal for

communications in a noisy environment. .

The Active Noise Reduction algorithm enhances speech applications by

reducing ambient noise in your environment such as computer fans and air

conditioners. Continuous and repetitive noise is effectively removed from

the microphone input, providing cleaner audio for speech recognition,

videoconferencing, gaming, and voice over internet communication.

Sound Deck for Windows operating systems includes Echo Erase which is an

acoustic echo cancellation algorithm. This allows for two-way conversation

with the Go Mic Connect while minimizing any echo or feedback caused by

monitoring audio with speakers.

Samson Sound Deck Software

Polar Pattern. . . . . . . . .Omni-directional

Capsules. . . . . . . . . . .Two, 10mm condenser capsule

Frequency Response . . . . . 20Hz - 20kHz

Software Filter Algorithm . . . Digital Noise Reduction, Focus Pattern Technology,

Echo Stop (Windows only)

Sample Rate . . . . . . . . .44.1/48kHz

Bit Rate . . . . . . . . . . . 16 Bit

Power Requirements . . . . . 5V 50mA

Max SPL . . . . . . . . . .130 dB

Dimensions . . . . . . . . . 4.3” x 0.6” x 3.2” / 110mm x 16mm x 82mm

Weight. . . . . . . . . . . .0.3lb / 139g

Specications

At Samson, we are continually improving our products, therefore specifications and images are subject to change without notice.

Minimum System Requirements

Windows (PC)

• Windows XP / Vista / Win 7 / Win 8 / Win 10

• 800MHz or higher, 256MB RAM or larger, USB port

Mac OS

• Mac OS X 10.4.9 or higher

• 733MHz or higher, 512MB RAM or larger, USB port

EN FR DE ES IT

A u cas où vous souhaiteriez éliminer ce produit, ne le mélangez pas aux ordures ménagères.

En conformité à la législation, pour les produits électroniques usagés, il y a un système

séparé de collecte exigeant traitement, récupération et recyclage corrects.

Les résidences privées dans les 28 états membres de l’UE et en Suisse et Norvège peuvent

gratuitement renvoyer leur produit électronique usagé à certains services de collecte désignés ou à

un détaillant (si vous rachetez un produit neuf similaire).

Pour ce qui est des pays autres que ceux mentionnés ci-dessus, pour obtenir la méthode correcte de

mise au rebut, veuillez contacter vos autorités locales.

Vous vous assurerez ainsi que le produit que vous éliminez, subit le traitement, la récupération et

le recyclage nécessaires et donc que vous évitez ses effets potentiels négatifs sur l’environnement

et sur la santé humaine.

Le présent dispositif est conforme à la partie 15 des règles FCC (Interférences des

radiofréquences). Le fonctionnement est soumis aux deux conditions suivantes:

(1) Ce dispositif ne doit pas causer d’interférences nocives, et

(2) Ce dispositif doit accepter toute interférence reçue y compris des interférences qui peuvent

provoquer un fonctionnement inopportun.

Etre adapté à un usage domestique ou professionnel.

Introduction

Le microphone USB portable stéréo Go Mic Connect de Samson est une étape successive parmi

les solutions avancées de communication numérique pour le son, y compris la VoIP [voix sur IP],

la radiodiffusion numérique et le logiciel de dictée pour la saisie de la voix en texte. A la base de

cette conception, il y a deux microphones ajustés de grande qualité et des convertisseurs audio

perfectionnés produisant une prestation sonore très améliorée, comparée à celle des microphones

standards d’ordinateurs. Le microphone présente une conception unique, compacte; se met en

place dans la partie supérieure de votre écran d’ordinateur portable ou d’ordinateur ﬁxe et possède

également une sortie casque pour un contrôle sans aucune latence.

De plus, le Go Mic Connect présente un traitement numérique de technologie de pointe qui prévoit

une technologie à directivité concentrée et une suppression active du bruit. La technologie à direc-

tivité concentrée crée un type concentré de captage qui bloque les sons au-delà de la zone focale.

Ce qui est parfait pour les environnements bruyants de bureaux tels que les centres d’appel où

les conversations se poursuivent tout autour de vous et où vous devez garantir que seule votre voix

est capturée. La suppression active du bruit sur les signaux d’entrée et de sortie améliore l’intel-

ligibilité du son entendu à travers une communication VoIP. Les

caractéristiques perfectionnées du Go Mic Connect (disponible en

téléchargement gratuit sur www.samsontech.com) fonctionnent

grâce au logiciel Sound Deck de Samson.

Le Go Mic Connect de Samson coordonne un son de qualité studio

pour une écoute audio exceptionnelle via Skype™, FaceTime®,

Google Hangouts™ et plus. Que vous conduisiez un webinaire,

enregistriez un podcast, ou restiez simplement en contact avec

votre famille, le Go Mic Connect est la solution la plus exhaustive

pour des enregistrements de grande qualité. Il vous sufﬁt de le

brancher et vous pouvez commencer à communiquer!

Focus Pattern Technology

Andere Handbücher für Go Mic

Inhaltsverzeichnis

Sprachen:

Andere Samson Mikrofon Handbücher

Samson

Samson SE10 Bedienungsanleitung

Samson

Samson LM10 Bedienungsanleitung

Samson

Samson SADK5 Bedienungsanleitung

Samson

Samson CL8 Bedienungsanleitung

Samson

Samson 5Kit Bedienungsanleitung

Samson

Samson C01U Bedienungsanleitung

Samson

Samson CS Series Bedienungsanleitung

Samson

Samson CM12C Montageanleitung

Samson

Samson QKICJ Bedienungsanleitung

Samson

Samson CM15P Bedienungsanleitung

Samson

Samson DE50 Series Bedienungsanleitung

Samson

Samson C05 Bedienungsanleitung

Samson

Samson 7KIT Bedienungsanleitung

Samson

Samson R11 Bedienungsanleitung

Samson

Samson S-Monitor Bedienungsanleitung

Samson

Samson G Track Bedienungsanleitung

Samson

Samson SE60x Bedienungsanleitung

Samson

Samson QKICK Bedienungsanleitung

Samson

Samson CM15P Bedienungsanleitung

Samson

Samson MTR231 Bedienungsanleitung

Samson

Samson UB1 Bedienungsanleitung

Samson

Samson Go Mic Bedienungsanleitung

Samson

Samson Go Mic Bedienungsanleitung

Samson

Samson CL7 Bedienungsanleitung

Beliebte Mikrofon Handbücher anderer Marken

IK Multimedia

IK Multimedia iRig Stream MIC PRO Bedienungsanleitung

DAPAudio

DAPAudio RM-101 Bedienungsanleitung

AKG

AKG CHM 21 Bedienungsanleitung

Sennheiser

Sennheiser evolution wireless series EM 100 Bedienungsanleitung

Sony

Sony C-48 Bedienungsanleitung

GIGAMEDIA

GIGAMEDIA GGM PAMICUHFG Bedienungsanleitung

Shure

Shure WH30TQG Bedienungsanleitung

auna PRO

auna PRO MIC-900 Bedienungsanleitung

AKG

AKG D 3800 Bedienungsanleitung

Shure

Shure KSM141 Bedienungsanleitung

MAIIN SOUND

MAIIN SOUND IIN style Bedienungsanleitung

Earthworks

Earthworks TC25 Bedienungsanleitung

Sennheiser

Sennheiser evolution D1 Bedienungsanleitung

Alesis

Alesis MicLink Wireless Bedienungsanleitung

DSPPA

DSPPA D6234 Bedienungsanleitung

Monacor

Monacor IMG STAGELINE ECM-300B Bedienungsanleitung

Ansr Audio

Ansr Audio Scan16 Bedienungsanleitung

Shure

Shure MXA710 Series Bedienungsanleitung
