Samson SE10x Bedienungsanleitung
SE10x Earset Microphone
Owner’s Manual
Omnidirectional Earset Microphone with Miniature Condenser Capsule
2
If you want to dispose this product, do not mix it with general household waste. There is a
separate collection system for used electronic products in accordance with legislation that
requires proper treatment, recovery and recycling.
Private household in the 28 member states of the EU, in Switzerland and Norway may return their
used electronic products free of charge to designated collection facilities or to a retailer (if you pur-
chase a similar new one).
For Countries not mentioned above, please contact your local authorities for a correct method of
disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery
and recycling and thus prevent potential negative effects on the environment and human health.
Copyright 2019, Samson Technologies Corp.
v1.1
278-B Duffy Ave
Hicksville, New York 11801
Phone: 1-800-3-SAMSON (1-800-372-6766)
www.samsontech.com
Other trademarks and trade names are those of their respective owners.
3SE10x Earset Microphone
Congratulations on your purchase of the Samson SE10x Earset Microphone. The SE10x is a low
profile, miniature condenser Earset microphone with a 3mm capsule. With its omnidirectional pick
up pattern, the SE10x delivers linear off-axis frequency response, resulting in a clear and articulate
sound perfect for house-of-worship, presentation, theater and fitness applications. The microphone
has been specially treated with a water resistant coating providing extra protection from sweat and
other moisture. In addition, there is a moisture guard drip-ring to further protect the capsule and
ensure reliable performance.
The SE10x Earset Microphone is well-suited for use with Samson wireless systems, and with four
included adapter cables, the microphone can be used with most popular wireless systems. Other
accessories included in the kit are a clothing collar clip, four windscreens and a carry case that
holds the SE10x and all the accessories.
In the box, you’ll find a registration card enclosed, don’t forget to follow the instructions so that you
can receive online technical support and so we can send you updated information about this and
other Samson products in the future. We recommend you keep the following records for reference,
as well as a copy of your sales receipt.
Serial number: __________________________ Date of purchase: ___________________________
If you have any questions or comments regarding the SE10x Earset Microphone or any other
products from Samson, do no hesitate to contact us at support@samsontech.com.
With proper care and maintenance, your SE10x Earset Microphone will operate trouble-free for many
years. Should your SE10x Earset Microphone ever require servicing, a Return Authorization (RA) number
must be obtained before shipping your unit to Samson. Without this number, the unit will not be accepted.
Please visit www.samsontech.com/ra for an RA number prior to shipping your unit. Please retain the
original packing materials and, if possible, return the unit in its original carton. If your SE10x Earset
Microphone was purchased outside of the United States, contact your local distributor for warranty details
and service information.
Introduction
4
To connect the cable to the Earset:
• Choose the right cable and connector that
works with your wireless system.
• Line the cable up to the threaded terminal on
the back of the SE10x and screw the cable
into the Earset. Do not over-tighten the cable.
Connector Cables
The SE10x includes four cables with adapters for some of the most popular wireless microphone
beltpack transmitters.
3.5mm Connector
Works with Sennheiser®wireless systems
Hirose®4-Pin Connector
Works with most Audio-Technica®wireless systems
Switchcraft®TA3F Connector
Works with Samson AirLine ATX Series, Concert Series and most AKG®wireless systems
Switchcraft®TA4F Connector
Works with most Shure®wireless systems
5SE10x Earset Microphone
Mic Positioning
Position the SE10x microphone element about
0.25” –1” behind the corner of your mouth.
Since the SE10x is an omnidirectional capsule,
the end of the microphone does not need to be
facing your mouth.
To avoid breath noise and p-pops, do not place
the microphone directly in front of your mouth
or use one of the included windscreens.
If the microphone is too far away from your
mouth you will need to increase the gain and
reduce isolation.
To minimize additional noise, do not locate the
microphone tight against your cheek.
The SE10x microphone is designed to be worn on either the left or right ear. The microphone can
be re-sized to fit nearly any size ear simply by bending the wire into a new shape. Be sure to fit the
microphone’s ear band behind your ear. For optimal placement please follow the directions below:
6
Specifications
Element Back electret condenser
Polar pattern Omnidirectional
Frequency Response 20Hz-20KHz
Sensitivity -45dBV/Pa @1kHz ±3dB
Output impedance 2kΩ ±30%
Maximum SPL 130dB
Self-Noise 30dB(A)
Dynamic Range 100dB
Operating voltage 1.5–12V DC
Cable: ø1.4mm*1.2m
Weight: 0.09oz / 2.5g
Dimension: ø3mm
Included Adapter Cables 1/8” (3.5mm), Hirose®4-Pin, Switchcraft® TA 3 F,
Switchcraft®TA4F
Accessories: (4) Windscreens, Clothing Collar Clip, Carry Case
At Samson, we are continually improving our products, therefore specifications and images are
subject to change without notice.
7SE10x Earset Microphone
Specifications
Polar Pattern
Frequency Response
0°
180°
dB
-5
-10
-15
-20
-25
45°
90°90°
135°
45°
135°
20 50 100 200 500
Frequency in Hz
1000 2000 5000 10000 20000 Hz
-20
-10
10
dB
0
Samson Technologies Corp.
278-B Duffy Ave
Hicksville, New York 11801
Phone: 1-800-3-SAMSON (1-800-372-6766)
www.samsontech.com
