XP25iBATTERY POWERED PORTABLE

PA SYSTEM

Owner's Manual

v1.3

Samson Technologies Corp.

45 Gilpin Avenue

Hauppauge, New York 11788-8816

Phone: 1-800-3-SAMSON (1-800-372-6766)

Fax: 631-784-2201

www.samsontech.com

Important Safety Information

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This lightning ash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of non-insulated “dangerous volt-

age” within the product’s enclosure that may be of sucient magnitude to

constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance instructions

in the literature accompanying the appliance.

AVIS

RISQUE DE CHOC ÉLECTRONIQUE -

NE PAS OUVRIR

RECHARGEABLE BATTERY

CAUTION: This unit contains a rechargeable battery. There is a danger of explosion if

the battery is incorrectly replaced. Replace only with the same or equivalent type of

battery. Do not expose to excessive heat such as sunlight, re, etc. The battery used in

this product must be recycled or properly disposed of. Please dispose of used batteries

in a manner that follows any local regulations. Do not incinerate. Contact your local

recycling center for information about the proper disposal of rechargeable batteries.

If you want to dispose this product, do not mix it with general household waste. There is a

separate collection system for used electronic products in accordance with legislation that

requires proper treatment, recovery and recycling.

Private household in the 25 member states of the EU, in Switzerland and Norway may return their used

electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar

new one).

For Countries not mentioned above, please contact your local authorities for a correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and

recycling and thus prevent potential negative effects on the environment and human health.

Important Safety Information

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. This apparatus shall not be exposed

to dripping or splashing liquid and

no object lled with liquid, such as

a vase, should be placed on the ap-

paratus.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation

openings. Install in accordance with

the manufacturer's instructions.

8. Do not install near any heat sources

such as radiators, heat registers,

stoves, or other apparatus (including

ampliers) that produce heat.

9. Only use attachments/accessories

specied by the manufacturer.

10. Unplug this apparatus during light-

ning storms or when not in use for

long periods of time.

11. Do not override the intended pur-

pose of the polarized or grounding-

type plug. A polarized plug has two

blades, with one wider than the

other. A grounding-type plug has

two blades and a third grounding

prong. The wide blade or third prong

is provided for your safety. If the pro-

vided plug does not t your outlet,

consult an electrician to replace the

obsolete outlet.

12. Protect the power cord from being

walked on or pinched, particularly at

the prongs, convenience receptacles,

and the point where they exit from

the apparatus.

13. Use only with the cart

stand, tripod bracket,

or table specied by

the manufacture, or

sold with the apparatus.

When a cart is used, utilize caution

when moving the cart/apparatus

combination to avoid injury from

tip-over.

14. Refer all servicing to qualied service

personnel. Servicing is required if the

apparatus has been damaged in any

way, such as power-supply cord or

plug breakage, damage due to liquid

or objects falling onto the appara-

tus, exposure to rain or moisture, or

if the apparatus does not operate

normally, or has been dropped.

15. POWER ON/OFF SWITCH: For prod-

ucts with a power switch, the power

switch DOES NOT break the connec-

tion from the mains.

16. MAINS DISCONNECT: The plug

should remain readily operable.

For rack-mount or installation

where plug is not accessible, an

all-pole mains switch with a contact

separation of at least 3mm in each

pole shall be incorporated into the

electrical installation of the rack or

building.

17. FOR UNITS EQUIPPED WITH EXTER-

NALLY ACCESSIBLE FUSE RECEP-

TACLE: Replace fuse with same type

and rating only.

18. MULTIPLE-INPUT VOLTAGE: This

equipment may require the use of a

dierent line cord, attachment plug,

or both, depending on the available

power source at installation. Connect

this equipment only to the power

source indicated on the equipment

rear panel. To reduce the risk of re

or electric shock, refer servicing

to qualied service personnel or

equivalent.

XP25i

Owner's Manual 1

Table of Contents

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

XP25i Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Gel-Cell Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

XP25i Controls and Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

XP25i Controls and Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Connecting an iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

XP25i Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

XP25i Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANO

XP25i

Introduction

Thank you for purchasing the Samson Expedition XP25i all-in-one battery

powered portable PA system. The XP25i is a lightweight, compact, personal

sound system ideal for use in a variety of mobile presentation, tour guide and

school activity applications. The XP25i provides exceptionally clear sound;

offering 25 watts of power to a 5-inch full-range loudspeaker. Unique to

the XP25i is an integrated iPod dock for playback of pre-recorded speech,

alerts, or music. The XP25i also features an expanded mixer section with a

microphone input, line input, line output, as well as independent volume

controls for iPod, and microphone. The XP25i system includes a push-to-talk

microphone with 3' cable, shoulder strap, battery charger and microphone

stand adapter.

In these pages, you’ll find a detailed description of the features of the XP25i

portable PA, as well as a guide to its control panel, instructions for setup and

use, and full specifications. You’ll also find a warranty card enclosed. Please

don’t forget to fill it out and mail it in so that you can receive online technical

support, and so that we can send you updated information about this and

other Samson products in the future. Also, be sure to check out our website

(www.samsontech.com) for information about our full product line.

With proper care, your XP25i will operate trouble-free for many years. We

recommend you record your serial number in the space provided below for

future reference.

Serial number: ____________________________________________

Date of purchase: __________________________________________

Should your unit ever require servicing, a Return Authorization number (RA)

must be obtained before shipping your unit to Samson. Without this number,

the unit will not be accepted. Please call Samson at 1-800-3SAMSON (1-800-

372-6766) for a Return Authorization number prior to shipping your unit.

Please retain the original packing materials and if possible, return the unit

in the original carton and packing materials. If you purchased your Samson

product outside the United States, please contact your local distributor for

warranty information and service.

XP25i

Owner's Manual 3

XP25i Features

Here is a look at some of the unique features of the XP25i battery pow-

ered portable PA system:

• Compact, lightweight, ergonomic design for easy transport with carry

handle and shoulder strap.

• Built-in rechargeable battery with 8 hours of continuous use per charge.

• Battery recharges in only four hours.

• 5" full-range high efficiency loudspeaker.

• 25-watts onboard power.

• Integrated iPod dock with volume control.

• Samson PT40M push-to-talk microphone with 3' coil cable included.

• Line input and output allows use with other audio devices.

• Power and battery charge indicator LEDs.

• Rugged construction for use while carrying, placed on a table, or mount-

ed using the built-in microphone stand mount.

• Battery charger included.

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANO

XP25i

Gel-Cell Batteries

The XP25i is a battery powered portable sound system that comes with a

rechargeable gel-cell battery installed.

Before using your XP25i for the rst time, you must charge the rechargeable

battery for at least four hours. To charge, connect the included AC/DC adaptor

to the XP25i. The Battery LED will ash while the unit is charging. When the

XP25i is fully charged the Battery LED will light steady green.

With proper use and care, the battery in your XP25i should last for many years.

Follow these instructions for getting the longest life from the internal battery:

• Charge the XP25i completely after each use.

• The battery must not be exposed to extreme heat.

• Avoid completely draining the battery.

• Always store your XP25i in a full-charge condition.

• For long-term storage, you should apply a topping charge to the XP25i

every six months

Note: Extended storage below the critical voltage may result in the battery failing

to hold a charge, in which case the battery will need to be replaced. Battery life

may vary based on temperature, age, and product usage.

Gel-cell rechargeable batteries must not be disposed of with household

waste. To discard your rechargeable battery, bring to an appropriate public

collecting site, or battery retail location. To guard against possible short-

circuiting, rechargeable batteries should be completely discharged before

being disposed of, and its terminals should be covered with non-conductive

adhesive tape (for example, black electrical tape).

Note: If you have any questions regarding discharging the battery, contact a tech-

nician or your local collection center.

Caution: Under no circumstances should your battery be incinerated as this

can cause explosion.

XP25i

Owner's Manual 5

XP25i Controls and Layout

6 7

1. Loudspeaker - 5" full-range high

efficiency paper cone transducer.

2. Volume/Power Control - This

rotary knob controls the level of

the microphone input and powers

the unit on and off. Turn the control

clockwise to turn the system on.

Turn the knob counter-clockwise

until it clicks to turn the system off.

3. Power Indicator - RED

LED illuminates indicating the unit

is powered on, ready for operation.

4. iPod Level - This rotary knob

controls the level of the iPod to the

loudspeaker.

5. Charge Indicator - The Charge

Indicator flashes GREEN while the

rechargeable battery is charging,

and will light steady GREEN when

the battery is fully charged. The

Charge Indicator will flash RED

when the battery is low and the

unit is power on.

6. Line Out Jack - 1/8" (3.5mm)

auxiliary Line Output. The

Microphone, iPod and Line In

signals are present at this output.

7. Line In Jack - 1/8" (3.5mm)

auxiliary Line Input for connecting

an external sound source (CD

player, MP3 player, or audio line

output from another device).

8. DC Power Input - Connect the

supplied AC/DC adaptor to

recharge the battery or to supply

power to the unit.

9. Microphone Input - 1/4” (6.3mm)

Mic level Input jack. Plug the

supplied Samson PT40M or another

high-impedance microphone into

this input.

10. iPod Compartment - The XP25i

has a built-in iPod dock which can

be used to connect most of the

latest iPod models. The iPod signal

is controlled by the iPod Level

control (#4).

11. Microphone Stand Adaptor

- 5/8" female thread adaptor

for mounting the XP25i onto a

microphone stand.

ENGLISH

FRANÇAISDEUTSCHEESPAÑOLITALIANO

XP25i

XP25i Controls and Layout

12. Shoulder Strap Connection - Connect

the included Shoulder Strap to these two

connection points. The shoulder strap includes

a microphone clip for the Samson PT40M

microphone.

13. Carry Handle - Ergonomically designed Carry Handle allows for easy

transport.

14. Battery Compartment - The XP25i comes with a rechargeable battery

installed. If you ever need to replace the battery, open the compartment

cover, and remove the battery protection plate. Gently slide the old battery

from the compartment and disconnect the RED and BLACK battery leads.

Connect the battery leads to the new battery. Connect the RED cable to the

positive (+) terminal, and the BLACK cable to the negative (-) terminal. Slide

the battery into the compartment, replace the protection plate and slide the

compartment cover closed.

Note: If you have any questions about replacing the battery contact Samson or

your local distributor.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Samson Sprecher Handbücher

Samson

Samson Resolv 65 Bedienungsanleitung

Samson

Samson PORTABLE PA SYSTEM EXL250 Bedienungsanleitung

Samson

Samson EXPEDITION XP40i Bedienungsanleitung

Samson

Samson Resound RS12M Bedienungsanleitung

Samson

Samson STUDIODOCK 4i Bedienungsanleitung

Samson

Samson Resolv RXA5 Bedienungsanleitung

Samson

Samson Studio GT Bedienungsanleitung

Samson

Samson RS Series Bedienungsanleitung

Samson

Samson MEDIAONE BT Bedienungsanleitung

Samson

Samson 215XL Bedienungsanleitung

Samson

Samson Expedition XP800 Bedienungsanleitung

Samson

Samson Expedition Escape Bedienungsanleitung

Samson

Samson Studio Reference Monitor System Resolv 40a Bedienungsanleitung

Samson

Samson Expeditionn XP150 Bedienungsanleitung

Samson

Samson Expedition Express Bedienungsanleitung

Samson

Samson Expedition XP300 Bedienungsanleitung

Samson

Samson AURO D415 Bedienungsanleitung

Samson

Samson XP308i Bedienungsanleitung

Samson

Samson Auro D208 Bedienungsanleitung

Samson

Samson AURO D412 Bedienungsanleitung

Samson

Samson MEDIAONE BT3 Bedienungsanleitung

Samson

Samson Expedition EX10 Bedienungsanleitung

Samson

Samson Resolv 65a RESOLV65A RESOLV65A Bedienungsanleitung

Samson

Samson RESOLV SE5 Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung
