SATO KEIRYOKI PC-9225 Bedienungsanleitung

Instruction Manual

Drip-Proof Digital Thermometer Model PC-9225

Thank you for purchasing the drip-Proof Digital Thermometer Model PC-9225.

- This product is designed to measure temperature. Do not use it for other

purposes.

- Read this manual thoroughly before using the PC-9225 and keep it in a safe

place for your future references.

Name of section

How to use

1. Press ON/OFF key. All characters light, then the temperature value (C°) is

displayed and the power is on. To turn the power off, press this key again.

* A protection sheet is put on the LCD before shipment.

2. Press MAX/MIN key while the power is ON. Minimum and Maximum

temperature values are displayed alternately.

3. Press HOLD key to hold the temperature reading. At this time, “HOLD”is

blinking in the display. Press this key again to release the hold function and

return to the measurement mode.

4. The power is turned off automatically approx. 60 min. after the power was

turned on.

NB.: This Auto Power-off function cannot be released.

For accurate measurement, insert the sensing stem into the object 50mm deep

from the tip.

How to replace the battery

Caution: Be careful the pointed end of the sensing stem

when you replace the battery.

When the display becomes dim, immediately replace the battery to new one.

①Open the battery lid with a coin or like and remove the exhausted battery.

②Load a new button cell battery (LR44) with polarity (+) upward.

Be sure to check the polarity (+) (-) of the battery.

③Close the battery lid.

* The battery life may be shorter since the battery installed is used for

monitoring

Warnings

Do not solder, short-circuit, disassemble, heat or fire a battery. Doing so may

cause an exothermic heat, a leakage of battery fluid or an explosion.

If the leaked fluid is spilt on your clothes or your skin, wash it off with water

and if it gets into your eyes, wash it off with clean water and seek a medical

attention immediately.

Do not dispose used batteries in fire.

Battery poses a danger of suffocation or poisoning if swallowed. Keep

battery out of reach of children.

When the battery is not in use, insulate the terminals with tape to prevent

contact with other metal objects or batteries. Otherwise, a short circuit may

occur and cause a fire or explosion.

For environmental conservation, dispose used batteries in compliance with

local rules and regulations.

①

②

③

Front View

Sensing stem

Display

Sheath

Power ON/OFF key

HOLD key

MIN/MAX key

Rear View

Battery lid

Cautions in use

After measurement, sheath the sensing stem with the attached case.

At sheathing, make sure to confirm that the temperature of sensing stem is

lower than 50°C.

Use the instrument in the ambient of 0 to 50°C.

Do not bend or snap the sensor. Do not drop or give a shock to it.

Be sure to insert the sensing stem into the object 50mm deep from the tip at

the measurement of water, liquid and like.

Do not clean the instrument with alcohol, thinner or any other solvents. Use

a clean cloth moistened with warm, neutral detergent water.

Never dissemble or alter the instrument.

This is not waterproof construction.

Specifications

Name Drip-proof Digital Thermometer

Model PC-9225

Cat. No. 1754-00

Measuring Range -30 to 200ºC

Accuracy ±1 ºC at (-5 to 160ºC)

±2 ºC at other range

Display functions Max. memory data(MAX), Min. memory data (MIN)

Data hold (HOLD)

Auto power-off function The power is automatically turned off approx.

60 min. after the power was on.

Operation ambient 0 to 50ºC

Materials Main Unit and sheath: ABS resin

Sensing stem: stainless steel (SUS304)

Power Requirement 1.5VDC (one LR44 button cell battery)

Battery Life about 1 year (use for one hour per day)

Dimensions Main Unit: 50mm (W) × 16mm (t) × 188 mm (L)

Sensing stem: 3.5mm dia. x 85mm (L)

Weight about 34 g (include a battery)

Accessories Sheath, one LR44 button cell battery

* Heatproof temperature for meter and sheath is -10 to 40ºC

- This product is not usable for the attestation or certificate purpose.

3-4, Kanda-kajicho, Chiyoda-ku, Tokyo 101-0045 Japan

URL: http://www.sksato.co.jp/english/
