SATO CX200 Bedienungsanleitung
CX200
Desktop Label Printer
®
1
Rev B
SATO SERVICE MANUAL
CX Series Printers
General Information
1-1 Overview
The SATO CX Series Printers are compact desktop printers designed especially for bar
code labeling and tagging. The CX uses SATO Command Language making it simple
to integrate with any other SATO printer models. Designed for convenience the CX
has many advanced features like larger media capacity user replaceable print head
and platen and a high lift print head carriage that makes it easy to clean and load
supplies.
This manual covers in detail:
CX200DT and CX200TT
Direct Thermal and Thermal Transfer Units
Features include:
••
••
•4.1 inch Wide Print Area
••
••
•Label Width From 2 inches to 4.65 inches
••
••
•Up To 3 inches Per Second Print Speed
••
••
•203 DPI Resolution
••
••
•512K Flash and 512K RAM Memory
••
••
•2Mb or 4Mb Expanded Memory
••
••
•12 Proportional and Mono-spaced Fonts
••
••
•14 Bar Code Symbologies, Including 2D
••
••
•Parallel and Serial Interfaces
Step-by-step maintenance instructions are described in this manual. It is
recommended that you become familiar with each section before installing
and maintaining your printer.
Section
1
2
Rev B
SATOSERVICE MANUAL
CX Series Printers
1-2 Dimensions
D
H
W
CX200DT CX200TT
Weight 3.1lb./1.41 kg 3.6 lb./1.63 kg
Depth 10 in. (254 mm)
Heigth 6.6 in (168 mm)
Width 6.9 in. (175 mm)
SECTION 1 - GENERAL INFORMATION
3
Rev B
SATO SERVICE MANUAL
CX Series Printers
1-3 Specifications
Model CX200DT/CX200TT
Print Method Direct Thermal/Thermal Transfer
Resolution 203 dpi 8 dpmm
Max. Media Width 4.65 inches 118 mm
Min Media Width 2.0 inches 51 mm
Max. Print Width 4.1 inches 104 mm
Max. Print Length 14 inches 356 mm
Max. Print Speed 3 ips 76 mm/s
Installed RAM 512 KB, non-volatile
Installed ROM 512 KB, Flash
Communications RS232C Serial and Centronics Parallel
Max. Media Roll OD 5.0 inches 127 mm
Ribbon 460 feet (140m) Wax, Wax/Resin
418 feet (127m) Resin
0.5 inch core, Coated Side Out
Label Sensing method Eye-Mark, Gap or Notch, Fixed Position
Minimum Form Length 0.375 inches 9.5 mm
Text Fonts 12 proportional and monospaced fonts up to 12X expansion
Graphics PCX and SATO Hex/Binary
Bar Codes UPC-A/E, EAN-8/13, UCC/EAN-128, Bookland, Code 39,
I 2 of 5, Code 128, Codabar, Plessey, MSI, Code 93,
Postnet, PDF417, Maxicode
Rotation Text and bar codes can be rotated in four 90oincrements
Power 20-26 VAC 50/60 Hz or 18-26 VDC
120 VAC 50/60 Hz
230 VAC 50/60 Hz
40 W power supply provided with printer
Environmental Operating: 41o to 104oF (5oto 40oC)
Storage: - 4o to 122oF (-20oto 50oC)
RH: 25 to 85% non-condensing
SECTION 1 - GENERAL INFORMATION
4
Rev B
SATOSERVICE MANUAL
CX Series Printers
1-4 Attributes
READY INDICATOR
ON-LINE/OFF LINE
BUTTON
FEED BUTTON
TOP CASE
PAPER GUIDE
PLATEN ROLLER
REMOVAL ACCESS
SLOTS
WALL
MOUNTING
SLOTS
POWER INPUT POWER CABLE
ROUTING
CHANNEL
SERIAL
PORT
PARALLEL
PORT
EXTERNAL MEDIA
FEED KNOCKOUT
SECTION 1 - GENERAL INFORMATION
BOTTOM CASE
FRONT CASE
5
Rev B
SATO SERVICE MANUAL
CX Series Printers
1-4 Attributes
RELEASE LEVERS FOR
PRINT HEAD/RIBBON
MECHANISM
PAPER GUIDE (SHOWN
WITH LABELS)
PAPER GUIDE (SHOWN
WITHOUT LABELS)
SECTION 1 - GENERAL INFORMATION
6
Rev B
SATOSERVICE MANUAL
CX Series Printers
1-5 Controls, Indicators and Connections
The following table summarizes the functions of the various printer controls
indicators and connections.
PRESS - to advance media
PRESS while pressing READY
indicator-to print test label
PRESS to pause printing during
batch mode operation
GREEN - Printer ready for data
OFF - Printer busy, or Off-Line
RED - Printer needs attention
PRESS to switch to/from Off-Line
or to reset the printer
Connect to power supply pro-
vided with printer
DB9 female connector for connec-
tion to host controller, RS232
interface
Centronics compatible connector
for connection to host controller
Push both releases toward rear of
printer to release print head
Lift to open
Push outward at hinge to remove
FEED button Advances print media
READY indicator Shows print status
ON-OFF line Places printer in On-
Line or Off-Line mode
Power input Connects to power
supply
Serial port Data input
Parallel port Data input
Print head Unlocks print head
release
Media cover Protects print media
mechanism
DEVICE NAME PRIMARY FUNCTION USE
SECTION 1 - GENERAL INFORMATION
7
Rev B
SATO SERVICE MANUAL
CX Series Printers
1-5 Controls, Indicators and Connections
PIN # DESCRIPTION
2 RXD (printer data input)
3 TXD (printer data output)
5 Ground
7 RTS (printer busy)
8 CTS
1,9 +5 VDC, 200 mA max
PIN # DESCRIPTION
1 Strobe
2-9 Data bits 0-7
10 Acknowledge
11 Busy
12 Out of paper
13 +5 VDC
14-15 No connection
17 Chassis ground
18 +5 VDC
31 Reset
32 Error
16,33 Signal Ground
19-30
34-36 No connection
PARALLEL INPUT
CONNECTOR
CENTRONICS 36 PIN
SERIAL INPUT
CONNECTOR DB9S
1
18
5
1
6
9
1936
BACK END OF
PRINTER
SECTION 1 - GENERAL INFORMATION
8
Rev B
SATOSERVICE MANUAL
CX Series Printers
POWER INPUT
READY INDICATOR
ON-LINE/OFF LINE
BUTTON
FEED BUTTON
UNDERSIDE OF PRINTER POWER
SUPPLY
AC OUTLET
1. Plug the output of the AC power supply provided with the printer
into the connector on the underside of the printer.
2. Plug the supply into an AC outlet having the correct voltage.
Important!
The required AC voltage is marked on the power supply.
Confirm that your AC voltage matches the power supply
requirements. Do not use any power supply other
then the one provided with the printer.
Note:
CX200 printers consume very little power when idle so are not equipped
with a power switch. Press the READY indicator ON-OFF (a combined
control) to reset the printer and switch from OFF-Line to On-Line mode.
SECTION 1 - GENERAL INFORMATION
1-5 Controls, Indicators and Connections
Printer Power Connection
9
Rev B
SATO SERVICE MANUAL
CX Series Printers
1-5 Controls, Indicators and Connections
Connecting the Interface Cable
AVAILABLE DB9S
SERIAL PORT PARALLEL PORT
CONNECT THIS END OF THE
CENTRONICS 36 PIN CABLE
TO THE PARALLEL PORT ON
THE PRINTER
CONNECT THIS END OF THE
PARALLEL CABLE TO THE
PORT ON THE COMPUTER
SECTION 1 - GENERAL INFORMATION
