SATO TXPEX6 Bedienungsanleitung

Quick Start Guide

TXPEX6

TXPEX6

Read this Quick Start manual before beginning.

For the best prinng results, we recommend the use of SATO genuine labels

and ribbons.

Contact your SATO authorized reseller for further details.

More informaon can be found at www.satoamerica.com

Important Informaon

This quick start guide provides important informaon on how to setup your

new SATO product. Be sure to read this quick start guide thoroughly before

using this printer. It is an integral part of the product and should be kept in

the immediate vicinity of the device and available to the operang sta.

Limitaon of Liability

The manufacturer will not be held liable for damage resulng from:

• Disregarding these instrucons

• Unintended use of the printer

• Unauthorized technical modicaons

• Use of unapproved consumables

i

ii

TXPEX6

Table of Contents

Table of Contents

iii

1 Unpacking the Printer 1

2 Inial Setup 2

3 Loading Ribbon 5

4 Loading Media 6

5 Connecng Cables and the Power Cord 8

6 Turning the Printer ON/OFF 9

TXPEX6

1Unpacking the Printer

1. Open the carton.

2. Remove the accessories.

a. Power cord

b. Tear-o Blade

3. Remove the foam inserts and printer.

Note: Keep the carton and packaging materials for future transportaon of

the printer.

Unpacking the Printer

1

TXPEX6

2Inial Setup

1. Open the top cover.

2. Remove the twist e securing the print head block.

3. From the accessories; locate the tear-o blade.

4. Aach the tear-o blade to the printer with the provided pan screws.

Slide the blade tabs into the notches and securely aach with the pan

screws.

5. Move the head lever to free posion.

Inial Setup

2

TXPEX6

6. Swing open the guide bracket.

7. Li the print head block.

8. Remove the bubble wrap.

Note: Keep the twist e and bubble wrap for future transportaon of the

printer.

9. Close the print head block (do not lock the guide bracket and head

lever).

10. Gently push the media sensor (green bar) all the way inward toward

the interior printer wall.

11. Li the print head block completely up and then back down.

This acon will set the default media sensor posion for SATO notched tags.

3

Inial Setup

TXPEX6

Note: The media sensor may need to be reposioned for other media

types. (Gap sensor is round and Black Mark sensor is square).

12. Loosen the thumb screw and remove the media supply Hub

assembly.

13. Loosen the Label Holder thumb screw.

14. Slide the label holder all the way inside toward the interior printer

wall and ghten the thumb screw.

This is the default posion for SATO notched tags.

Black Mark Gap

4

Inial Setup

TXPEX6

3Loading Ribbon

1. Grasp the tabs on the top and boom of the Ribbon Stoppers and

move the Ribbon Stoppers back to the end of the Ribbon Sha (inside

of the printer).

2. Li open the print head block.

3. Leaving slack between the ribbon spools, place the ribbon onto the

ribbon shas as shown below:

4. Lower the print head block and remove any slack in the ribbon.

5. Secure guide bracket and head lever to lock posion.

Note: All Ribbon must be wound coated side out (CSO)/Ink outside.

The ribbon roung guide is located on the inside of the Top Cover

Loading Ribbon

5
