SATO CX208 Bedienungsanleitung

CX208

Desktop Label Printer

USER

GUIDE

BAR CODE SATO ELECTRONICS (S) PTE LTD

438A Alexandra Road

#02-01/04 Alexandra Technopark

Tel: (65) 271 5300 Fax: (65) 273 6011

Service Hotline: (65) 273 6455

http://www.satosingapore.com

BAR CODE SATO ELECTRONICS (S) PTE LTD

Warning: This equipment has been tested and found to comply with the lim-

its for a Class B computing device pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed in accordance with

the instructions may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try and correct the interference by one or

more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment into an outlet or a circuit different from that

to which the receiver is connected.

•Consult an experienced radio/TV technician for help.

Caution: The FCC warns the users that changes or modifications of the unit

not expressly approved by the party responsible for compliance could void

the user’s authority to operate the equipment.

to third parties in any form whatsoever without the express permission of

BAR CODE SATO ELECTRONICS (S) PTE LTD. The material in this

document is provided for general information and is subject to change without

notice. BAR CODE SATO ELECTRONICS (S) PTE LTDassumes no

responsibility for any errors that might appear.

PN9001091 Rev. A

Singapore 119967

BAR CODE SATO ELECTRONICS (S) PTE LTD

438A Alexandra Road

#02-01/04 Alexandra Technopark

Singapore 119967

Table of Contents

WhatYouGet ...............................1

Controls, Indicators, and Connections ..................2

Printer Power Connection.....................2

Printer Interface Connection....................4

Setup ...................................4

Loading Labels or Tags......................4

Loading Ribbon ..........................6

Sensor Calibration.........................8

Selecting theLabel Sensor Type..................8

Using the Printer ..............................9

Printing a Self-test Label.....................9

Feeding Blank Labels.......................9

Label Reprint ...........................9

Sending Data to the Printer....................9

Printer Ready/Standby/Reset Control................9

Printing Labels ..........................10

Controlling the Printer Using Direct Commands........10

Routine Maintenance ...........................11

What To Do If... ..............................12

READY light is not lit ......................12

READY light glows red .....................12

Self-test label willnot print ...................13

Labels will not feed........................13

Host stops responding ......................13

Labels feed continuously.....................14

Poor print quality.........................14

Technical Support.............................14

Printer Specifications...........................15

Communication Ports ..........................16

Standard Printer Cables.....................16

Serial Port Parameters......................16

CX Software................................17

Label Wizard CX.........................17

Windows Drivers.........................18

Media and Supplies ............................18

Page i

CX208 User Guide

What You Get

The SATO CX208 Printers come complete and ready to install and

print labels. Your CX208 shipping carton contains the following items:

•CX208 Printer

•Parallel Printer Cable

•40 Watt Power Supply (80 Watt Supply optional)

•Stack of label

•Thermal Transfer Ribbon (not supplied with the CX208DT)

•User’s Guide

•CD-ROM Containing:

Label Wizard CX Label Design and Production Software

Label Wizard CX Manual Files

CX208 User’s Guide

CX208 Programming Reference Guide

Windows Printer Driver for CX208

Label Wizard SE Evaluation Software

SATO Product Catalog

Adobe Acrobat Reader

for viewing and printing the manuals.

Page 1

CX208 User Guide

Controls, Indicators, and Connections

Device Name Primary Function Use

FEED Button Advances print media

PRESS - to advance media

PRESS while pressing READY

indicator - to print test label

PRESS - to pause printing during

batch mode operation

READY

Indicator

ON-OFF Button

Shows printer status

Places printer in On- ine

or Off- ine mode

GREEN - Printer ready for data

OFF - Printer busy, or Off- ine

RED - Printer needs attention

PRESS to switch to/from Off- ine

or to reset the printer

Power Input Connects to power supply Connect to transformer provided

with printer

Serial Port Data input DB9 female connector for

connection to host controller,

RS232 interface

Parallel Port Data input Centronics compatible connector

for connection to host controller

Print Head

Release Unlocks print head Push both releases toward rear

of printer to release print head

Top Cover Protects print media and

mechanism ift to open

Push outward at hinge to remove

Printer Power Connection

1. Plug the output of the AC power supply

provided with the printer into the connec-

tor on the bottom panel.

2. Connect the supply into an AC outlet

having the proper voltage.

Note:

CX208/212 printers consume very little power

when idle, so are not equipped with a power

switch. Pressing the EADY indicator/ON-OFF (a

combined control) will reset the printer and switch

it from Off-Line to On-Line mode.

Important!

The required AC voltage is marked on the power supply.

Confirm that your AC voltage matches the power supply

requirements. Do not use any power supply other than

the one provided with the printer.

Page 2

CX208 User Guide

ote :

X208 printers consume very little power

hen idle, so are not equipped with a power

witch. Pressing the READY indicator ON-OFF

ombined control will reset the printer and switc

t from Off-Line to On-Line mode.

Printer Interface Connection

1. Connect the supplied interface cable to the parallel printer port on the

computer.

2. Connect the other end to the parallel input port on the printer.

Page 3

CX208 User Guide

Ready LED Indicator/

ON-OFF Button

Top Cover

FEED Button

Paper

Guide

Print Head

Release

Print Head

Release

Ribbon

Cover

Parallel

Port all Mount Slots

Power Cable

Routing Channel

External Media

Feed Knockout

Power Input

Serial

Port

Page 4

CX208 User Guide

Media Loading

Paper Guide Lock

rint Hea

ensor Ligh

Source

rive Plate

edia

oll

entre Justified

aper Guides

rint Head

elease

abel Ex

lot

abels

Setup

Loading Labels or Tags

1. Lift the top cover.

2. Press the two print head releases back to unlock the print head.

3. Unwrap the new media, and unwind a few labels from the roll. La-

bels should be wound face-in for the best results.

4. Slide the centre justified Paper Guides apart until the label roll will

drop down between them.

5. Place media roll in the paper tray such that the media unwinds from

the bottom of the roll toward the front of the printer. The label imag-

ing surface must face up as it passes under the print head.

6. Lock the Paper Guides in place by pressing down on the green lock-

ing tab.

7. Lift the print head and slip the free end of the media under the print

head and out the front paper exit

8. Lower the print head and press it down firmly until it locks closed on

both sides.

9. Close the top cover.

10. Wait until the Ready Indicator glows green and press the FEED but-

ton to feed a label or to resume printing.

Loading Ribbon

The CX208TT thermal transfer printer transfers ink from a ribbon to

the label to produce an image.

1. Lift the top cover.

2. Press the two print head releases back to unlock the print head and

open the Ribbon Cover to expose the ribbon take-up spindles.

3. Unwrap the new ribbon and unwind about 4" from the roll. The end of

the ribbon is attached to a take-up core.

4. Observe the notches on both ends of the supply core and the take-up

core. These notches must fit on the corresponding nibs on both the sup-

ply and take-up spindles.

5. Roll several turns of ribbon on the take-up core, winding to the under-

side as shown. The dull (coated) side of the ribbon must be on the out-

side of the take-up roll.

Page 5

CX208 User Guide

Page 6

CX208 User Guide

Left Take-up

Core Spindle

Spring Loaded

Take-up Spindle

Left Supply

Spindle Spring Loaded

Supply Spindle

Take-up Core

Ribbon Supply Roll

Spindle Notches

Spring Loaded

Take-up Spindle

Supply Roll Mounted

on Spindles

Supply Roll

Take-up Core

Ribbon Path

Ribbon Cover

ibbon Loading
