Sauber SH-100 Pro Bedienungsanleitung

PRO HAND VACUUM

SH-100

ACharger Input

BBattery Indicator

COn/Off Button

DHEPA Filter and Stainless Steel Mesh Filter

EDust Bin

Dust Bin Lid Release Button

GDusting Brush

SH-100 Pro Hand Vacuum

Features

Congratulations on the purchase of your new Sauber Pro Hand Vacuum. There

are many useful features built into your cleaner. We recommend that you carefully

read this instruction manual for the best results.

Accessories:

HCrevice Tool

ICharging Base (including two screws)

JCharger Adaptor

Speciﬁcations:

Wattage: 90W

Voltage: 11.1V D C

Battery Lithium: 2500mAh

Dust Capacity: 90ml

Run Time: Up to 22 minutes

Charging Time: 3-4 Hours

Net Weight: 0.5Kg

Model Number: SH-100

Please contact Sauber Customer Service Australia on 1800 728 237 or

New Zealand on 0800 282 288 to ﬁnd your local spare parts provider.

Before You Begin

1. Do not operate the vacuum cleaner too close to heaters, radiators

or other hot surfaces.

2. Before inserting the plug into the wall, make sure your hands are dry.

3. Before turning on the vacuum cleaner, safely remove any large

objects from the ﬂoor or cleaning surface in order to prevent

damage to the ﬁlter.

4. When you want to remove the plug from the power socket, do not

use the power cable, gently pull the plug from the power socket.

5. Do not use this vacuum cleaner to pick up water or liquids.

6. Do not use this vacuum cleaner if the battery pack housing and/or

the charger housing is damaged.

This cleaner must be operated in accordance with these instructions and

used only for domestic household cleaning to remove DRY dirt and dust from

household carpets, ﬂooring, walls and fabrics. This cleaner is not ﬁt to be

used as an industrial cleaner and will void the manufacturer’s warranty if used

inappropriately.

Please read the manual before operating cleaner

This will ensure you obtain full beneﬁt from your new cleaner. Keep this

Instruction manual in a handy place for future reference.

Important

Always switch off the appliance before cleaning, when not in use, attempting any

maintenance task, ﬁtting or removing accessories. The charger must only be

connected to an AC power supply at the voltage shown on the rating label. This

cleaner should only be charged with the charger provided. This cleaner should

only be used for its intended purpose as described in these instructions.

Precautionary measures:

IMPORTANT! Always switch off the cleaner before cleaning, when not

in use or attempting any maintenance task. The charger must only be

connected to an AC power supply at the voltage shown on the rating

label. This cleaner should only be used for its intended purpose as

described in this instruction manual. Never operate the cleaner without

ﬁlters.

When using your vacuum cleaner, basic

precautions should always be observed,

including the following;

1. This appliance is not intended for use

by persons (including children) with

reduced physical, sensory, mental

capabilities or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

2. Children should be supervised to

ensure that they do not play with the

appliance.

3. To prevent electrical shock, do not

immerse the appliance, battery

or power plug into water or other

liquids.

4. To prevent electrical shock, do not

use the vacuum cleaner outdoors or

on wet surfaces.

5. Always check the power cord

before use, the power cord and the

power adapter should be in a good

condition and must not be damaged.

If the power cord or the charger

adaptor is damaged or defective, it

must be replaced.

6. The appliance and charger are

intended for domestic indoors use

only.

7. Do not unplug the charger by pulling

on the power cord. To unplug, grasp

the power adapter, not the power

cord and gently pull the power

adapter from the power socket.

8. Do not handle or operate the

appliance with wet hands. Follow

electrical safety precautions at all

times.

9. Do not attempt to change the

attachments while the appliance

is switched on. Use only

manufacturer’s recommended

accessories.

10. Do not operate the vacuum cleaner

too close to heaters, radiators and

other hot surfaces.

11. Do not use the appliance to pick

up ﬂammable items or combustible

liquids (i.e. gasoline, hot ashes,

cigarettes, matches, explosive

materials or anything burning) or use

in areas where such substances and

items may be present.

12. Do not use the appliance to pick up

toxic materials (i.e. chlorine, bleach,

ammonia).

13. Never operate or use the appliance

without the ﬁlters in place.

14. Before vacuuming, remove any large

or sharp objects from the ﬂoor or

cleaning surface in order to prevent

damage to the ﬁlter.

Before You Begin

15. If the air inlet is blocked, switch off

the cleaner straight away. Clear the

blocked object before attempting to

start the vacuum cleaner again.

16. Before carrying out any maintenance

or cleaning the ﬁlters, always switch

off the vacuum cleaner.

17. Keep openings away from your face

and body.

18. Do not use the vacuum cleaner if it

is damaged or broken. If connection

cables are damaged, have them

replaced immediately.

19. Never clean the vacuum cleaner or

any of the electrical parts, especially

the electrical connections with water

or liquid cleaners.

20. Never attempt to make any

modiﬁcations to the vacuum cleaner

and charger.

21. Always store the appliance, battery

and charger indoors in a cool and dry

place.

22. Do not use the vacuum to pick up

water or liquids. This cleaner is for

dry household use only.

23. Damage caused by improper use or

by not observing the instructions in

this manual will void the warranty.

Battery use and care

1. The appliance is only to be used

with the charger provided with the

appliance.

2. Only charge the battery inside the

cleaner or the charging dock. Only

use the speciﬁcally designated

charger to charge the product.

3. When the appliance is not in use,

keep it away from other metal

objects, like paper clips, coins, keys,

nails, screws or other small metal

objects that can make a connection

from one terminal to another.

Shorting the appliance terminals

together may cause burns or a ﬁre.

4. Under abusive conditions, liquid may

be ejected from the battery; avoid

contact. If contact occurs, ﬂush with

water immediately. If liquid comes

into contact with your eyes, seek

medical help immediately.

5. Do not charge or store the appliance

outdoors or inside the car. Only

charge or store the battery in a dry

indoor area where the temperature

is more than 4°C but less than 40°C.

The charger is for indoor use only.

6. Never attempt to open the battery

for any reason. If the plastic housing

of the battery casing breaks or

cracks, immediately discontinue use

and do not recharge.

7. The charger is not a serviceable part.

8. Before disposal of your battery, fully

discharge your battery by running the

product until it stops.

9. The cleaner contains a Li-Ion battery.

Do not dispose the appliance with

your local garbage. Contact your

local council for instructions on how

to safely dispose of the battery.

10. Do not use the charger to charge a

non-chargeable battery.

11. This appliance contains battery cells

that are non-replaceable.

12. Do not handle battery with wet

hands.

Assembly

1. Insert the machine holder to the Charging Base.

3. Connect Charger to the Charging Base or top of

the cleaner.

2. Flip the Charging Base upside down and use

the provided screws to attach the machine

holder to the Charging Base.

Before You Begin & Assembly

Instructions for Use

1. Press the On/Off Button to start vacuum on

normal mode.

2. Press the On/Off Button again to get maximum

suction.

3. Click third time to turn off the hand vacuum.

Normal Mode

Max Mode

Off

Accessories

Crevice Tool

Allows you to eliminate dust from hard to reach

areas.

Dusting Brush

Cleaning blinds, bookshelves and lampshades is

made easy with this dusting brush.

Note:

If the hand vacuum is blocked, please switch off the vacuum cleaner at

once. Remove any object that has blocked the vacuum, and switch on

again.

Instructions for Use & Accessories

Maintenance

IMPORTANT! Always remove the power plug from the power supply

before ﬁtting or removing accessories.

Charging the Hand Vacuum

1. Insert the charging cable into the back of the

charging dock or to the top of the machine

directly.

2. When the machine has been attached to the

charger correctly, the battery indicator will

intermittently ﬂash a blue light to show it is

charging.

3. Once the machine is fully charged, the light will

become a solid blue.

Attention:

1. It is recommended to charge your product

after each use to maintain maximum

performance.

NOTE:

1. Product needs to be charged for 3-4 hours

after each use.

2. Do not try to open the battery and repair it

yourself.

3. As a safety precaution, the vacuum cannot

be switched on while the vacuum is

charging.
