Scooty RIde Plus Bedienungsanleitung
ELECTRIC SCOOTER
/RIDE PLUS
Please read this manual carefully before rst use
Original Instructions
03
Before using this product, carefully read the user guidelines. These will allow
you to properly understand, use and service this product, and to get to know its
performances and features.
Keep this manual for future reference.
Thank you for your purchase.
Welcome to the Scooty community!
CONTENTS
1. SAFETY GUIDELINES..................................................................................04
2. CONTENTS OF THE BOX ..........................................................................07
3. DESCRIPTION OF THE DEVICE .................................................................08
4. USER GUIDE ..............................................................................................09
5. TECHNICAL SPECIFICATIONS ...................................................................12
6. BATTERY.....................................................................................................13
7. MAINTENANCE AND CLEANING ..............................................................14
8. FAQ .............................................................................................................15
9. WARRANTY TERMS AND LIMITATIONS OF LIABILITY ............................17
04
1.SAFETY GUIDELINES
1. This device has been designed for use by teenagers and adults. It
is neither a toy nor a tness accessory. It is not intended for use in
extreme sports involving jumps or ollies o of ramps, etc., nor is it
intended for tricks or dangerous acts.
2. This device may be used by children aged 12 and up, as well as
persons with physical, sensory or mental disabilities, provided they
do so under adequate supervision or have been instructed on how
to safely operate the device and are aware of any potential risks.
Children should not be allowed to play with the device. Cleaning and
maintenance should not be performed by unsupervised children.
3. This device must never be used in a skate park for "aggressive" use
(dicult skateboard tricks, etc.).
4. This device should be used with caution on a surface that is at,
clean, dry and free of gravel and grease, as there needs to be friction
between the wheels and the ground to move forward.
If possible, stay away from other users and observe trac rules. Avoid
bumps and sewer grates that may cause accidents.
5. Caution! Please abide by local regulations and national trac laws
when riding the scooter. Follow all trac rules and signs. Stay away
from other pedestrians and road users.
6. Learn how to use the device in an open and at location without many
other road users around you, and make sure you wear a helmet.
7. Do not use this device if visibility is poor.
8. Do not use this device to carry a person or goods.
9. Do not use this device under the inuence of alcohol or other drugs.
For your safety, such use is strictly prohibited.
10. Make sure all the screws are properly tightened before each use.
05
11. DO NOT USE THE DEVICE OR CHANGE THE BATTERY UNDER THE
FOLLOWING CIRCUMSTANCES:
- The product is damaged.
- Abnormal smell and heat are released from the battery.
- Stop using and do not touch any liquids emanating from the unit in
the event of a leak. The product should be stored out of the reach of
children.
- Brake controls, other braking or safety devices (lighting) are
damaged.
Check that all these safety devices (braking, lighting) are working
properly. The folding system device must be securely locked in its
driving position.
12. The device’s battery must not be exposed to excessive heat.
13. The battery must not be replaced by the user. Please contact after-
sales service for any modication/maintenance of the device.
14. This device is designed for outdoor activity. It is your responsibility to
know and comply with the regulations in place for use in public places.
15. Do not ride in rain, snow, puddles, mud, or other wet areas that would
allow water to seep into the device. To clean your device, follow the
instructions in section 7.1
16. Inspect the device and check the battery level before riding.
17. The batteries must be disposed of appropriately. To protect the
environment, discard them in containers provided for this purpose
(ask your dealer for more information).
18. Exceeding the weight limit may cause injuries and damage the device.
That the user is within the weight limit does not mean they are tall
enough to maintain control of the device.
19. Caution: Children under 12 years of age must not use this device.
Some users may not be able to control the device, depending on their
weight, height or physical ability. Parents should not let their child use
this device unsupervised.
06
20. When travelling with the device, you should always wear sturdy
shoes and pants. Do not operate this equipment if you are barefoot
or wearing open sandals. Avoid wearing clothing that is too loose or
equipped with hanging cords or ties, scarves, etc. that could be caught
by the rotation of the wheel, which could lead to the risk of choking,
falling and/or colliding.
21. Any opening of the device or product may result in a change in safety
for which the brand is not responsible. It is also important to note
that this opening voids the warranty of the device or product. If you
nevertheless wish to carry out repairs to your device or product, the
brand declines all responsibility for the reliability of the repair and
the potential damage associated with this repair. Any accident that
may occur as a result of this repair will not be the responsibility of
the brand. In case of doubt or need for assistance, please contact an
authorized reseller or the brand’s customer support.
22. Do not leave the product within reach of any person who may
start the product without the authorization of the main user or
without prior information and knowledge of these safety measures/
instructions and use. To prevent unauthorized use, use the padlock
provided or another device to prevent the unit from being started.
07
Pictogram Meaning
Always read the user manual carefully.
An exclamation mark within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance instructions in
the device’s user manual.
This device must not come into contact with water.
Do not store the device in a damp environment.
The lightning ash with an arrowhead symbol within
an equilateral triangle is intended to alert the user to
the presence of “dangerous voltage” within the device
that may be of sucient magnitude to constitute a
risk of electric shock.
This symbol indicates that this device is equipped
with a double electrical insulation between the power
supply’s (dangerous) voltage and the parts that are
accessible by the user.
Caution! Protective equipment including wrist guards,
gloves, knee pads, helmet and elbow pads should be
worn.
Electrical and electronic equipment must be sorted
and disposed of separately. Do not dispose of
electrical and electronic equipment with normal and
unsorted household waste, bring it to a recycling
centre instead.
2.CONTENTS OF THE BOX
This pack contains:
• Scooty RIDE PLUS Electric Scooter
• Original mains charger
• User manual
• CE declaration
• Warranty card TO BE KEPT (it contains the device’s serial number and
manufacture date, essential information for warranty purposes)
08
3.DESCRIPTION OF THE DEVICE
2
4
9
11
13
8
6
12
7
1
10
3
5
14
(1). LCD monitor
(2). Accelerator
(3). Electronic brake
(4). LED lighting
(5). Charging port
(6). Front drive wheel
(7). Steering column lock
(8). Release lever
(9). Foot brake
(10).Crutch
(11).Training wheels
(12).Suspension
(13).Rear Light (optional)
(14).Bell (optional)
1
3
2
1
4
5
6
2
3
4
5
(1). Acceleration / brake gauge / errors indicator (2). Battery level indicator (3). Lights
indicator (4). Speed - and ON/OFF lights button (5). ON/OFF device button
(6). Speed +
• To activate or deactivate the LED lighting press the ON/OFF LED lighting
button (4)
• The rear light (13) is only active when the LED lighting is active.
• To turn the device on/o: Press and hold the ON/OFF button (5) for
3seconds. The device turns o automatically after 180 seconds of inactivity.
• To increase or decrease the speed level: Briey press the speed
controller (4) or (6). There are 3 levels of maximum speed: P1: 6 km/h,
P2: 15 km/h et P3: 25 km/h. The mode is displayed on (1) from P1
(lowest) to P3 (highest) when stopped.
• The brake light is switched on as soon as the electronic brake is applied.
09
4.USER GUIDE
4.1. CHARGING AND BATTERY INDICATOR
Charge the battery before rst use. To do this, use the charger provided to
charge the battery.
1. The charging port of this scooter (5) is located on the handlebars.
Remove the cap and connect the low voltage charging cable to the
charging port (5) before connecting the other end to a power source.
2. The charger indicator light will turn red while charging.
3. The charger indicator light will turn green once the battery is fully
charged.
4. Disconnect the end connected to the device and replace the cap.
Check the charge level of the battery before use with the battery level
indicator (2).
Notice:
We recommend you fully recharge the battery after each use and at least
once a month.
10
4.2. FOLDING/UNFOLDING THE DEVICE
The scooter can be folded and unfolded easily thanks to the locking lever(8).
Unfolding
1. Place the scooter horizontally in front of you.
2. Unlock the scooter by pressing the lever (8).
3. Lift the scooter frame by about 90 degrees until you hear a soft click.
4. The process is complete.
Folding
1. Place the scooter horizontally in front of you.
2. Unlock the scooter by pressing the lever (8).
3. Lower the stud of the scooter to 90°.
4. The process is complete.
Use in trolley mode
The City Ultra scooter can be used in trolley mode when folded.
When folded, lock the steering column with the silver button. The handlebar
must be properly aligned in order to lock it.
When you decide to stop using trolley mode, unlock the steering column by
pressing the red button. You can then unfold the scooter.
