Seagull Models SEA 334 Bedienungsanleitung
1
Specications:
Wingspan--------------- 86.0 in (218.4 cm).
Wing area--------------- 1168.7sq.ins (75.4 sq.dm).
Weight------------------- 21.6 lbs (9.8 kg).
Length------------------- 65.0 in (165.0 cm).
Engine/Motor size----- 50-60cc gasoline.
Radio--------------------- 7 channels with 8 servos.
SEA 334 : Without electric retracts landing gear.
SEA334gear: including Electric retracts landing gear.
ASSEMBLY MANUAL
Code : SEA 334
Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.
2
ank you for choosing the Giant Zero A6M Gas ARF 50-60cc, 86” ARTF by SG MOD-
ELS . e Giant Zero A6M Gas ARF 50-60cc, 86” was designed with the intermediate/
advanced sport yer in mind. It is a semi scale airplane which is easy to y and quick to as-
semble. e airframe is conventionally built using balsa, plywood to make it stronger than
the average ARTF, yet the design allows the aeroplane to be kept light. You will nd that
most of the work has been done for you already. e motor mount has been tted and the
hinges are pre-installed. Flying the RGiant Zero A6M Gas ARF 50-60cc, 86” is simply a joy.
is instruction manual is designed to help you build a great ying aeroplane. Please read
this manual throughly before starting assembly of your Giant Zero A6M Gas ARF 50-60cc,
86” Use the parts listing below to indentify all parts.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is ca-
pable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU
ASSUME ALL RISK & REPONSIBILITY.
If you are inexperienced with basic R/C ight we strongly recommend you contact your R/C
supplier and join your local R/C model Flying Club. R/C Model Flying Clubs oer a variety
of training procedures designed to help the new pilot on his way to successful R/C ight.
ey will also be able to advise on any insurance and safety regulations that may apply.
INTRODUCTION
WARNING
KIT CONTENTS
22
5
1
33
4
6
78
9
10
3
KIT CONTENTS
SEA334 Giant Zero A6M Gas ARF
50-60cc, 86”
1. Fuselage
2. Wing set (2)
3. Tail set (2)
4. Canopy
5. Cowling
6. Wing tube
7. Pilot
8. landing gear
9. Fuel tank
10. Tail wheel
ADDITIONAL ITEMS REQUIRED
TOOLS & SUPPLIES NEEDED
in cyanoacrylate glue.
Medium cyanoacrylate glue.
30 minute epoxy.
5 minute epoxy.
Hand or electric drill.
Assorted drill bits.
Modelling knife.
Straight edge ruler.
2mm ball driver.
Phillips head screwdriver.
220 grit sandpaper.
90° square or builder’s triangle.
Wire cutters.
Masking tape & T-pins.
read-lock.
Paper towels.
�50-60cc gasoline engine.
�Computer radio 7 channel with 8
servos.
�Glow plug to suit engine.
�Propeller to suit engine.
�Protective foam rubber for radio
system.
HINGING THE FLAP
.
1.
2.
3.
4.
2x10mm
Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.
4
HINGING THE AILERON
Note : e control surfaces, including the ailer-
ons, elevators, and rudder, are prehinged with
hinges installed, but the hinges are not glued in
place. It is imperative that you properly adhere
the hinges in place per the steps that follow us-
ing a high-quality thin C/A glue.
Carefully remove the aileron from one of
the wing panels. Note the position of the
hinges.
Remove each hinge from the wing panel
and aileron and place a T-pin in the center of
each hinge. Slide each hinge into the wing
panel until the T-pin is snug against the wing
panel. is will help ensure an equal amount
of hinge is on either side of the hinge line
when the aileron is mounted to the aileron.
Slide the wing panel on the aileron until
there is only a slight gap. e hinge is now
centered on the wing panel and aileron.
Remove the T-pins and snug the aileron
against the wing panel. A gap of 1/64” or
less should be maintained between the
wing panel and aileron.
NOTE : e hinge is constructed of a spe-
cial material that allows the C/A to wick
or penetrate and distribute throughout
the hinge, securely bonding it to the wood
structure of the wing panel and aileron.
Deect the aileron and completely satu-
rate each hinge with thin C/A glue. e
ailerons front surface should lightly con-
tact the wing during this procedure. Ide-
ally, when the hinges are glued in place,
a 1/64” gap or less will be maintained
throughout the lengh of the aileron to the
wing panel hinge line.
Hinge
T-pin
2.
5.
6.
1.
5
Hinge
Epoxy
Turn the wing panel over and deect the
aileron in the opposite direction from the
opposite side. Apply thin C/A glue to each
hinge, making sure that the C/A penetrates
into both the aileron and wing panel.
Using C/A remover/debonder and a paper
towel, remove any excess C/A glue that may
have accumulated on the wing or in the
aileron hinge area.
Repeat this process with the other wing
panel, securely hinging the aileron in
place.
Aer both ailerons are securely hinged,
rmly grasp the wing panel and aileron to
make sure the hinges are securely glued
and cannot be pulled out. Do this by
carefully applying medium pressure, try-
ing to separate the aileron from the wing
panel. Use caution not to crush the wing
structure.
Work the aileron up and down sev-
eral times to “work in” the hinges
and check for proper movement.
Note :
WING TIP BULBS
Please see below pictures.
2.
1.
5.3.
4.
ey are designed to operate on volt-
ages 12 volts.
Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.
6
INSTALL THE AILERONS
CONTROL HORN
Fiberglass control horn
Ailerons control horn
Epoxy
3.
4.
5.
6.
1.
2.
3.
CA glue
CA glue
7
Install the ap control horn using the
same method as same as the aileron con-
trol horns.
Fiberglass control horn
INSTALL FLAP CONTROL HORN
2.
3.
1.
2.
1.
Flap control horn
INSTALLING THE AILERON SERVOS
Because the size of servos dier, you
may need to adjust the size of the precut
opening in the mount. e notch in the
sides of the mount allow the servo lead to
pass through.
Place the servo between the mounting
blocks and space it from the hatch. Use a
pencil to mark the mounting hole loca-
tions on the blocks.
Minimum servo spec.
Torque : 194 oz-in (14 kg-cm) @ 6.0V;
236 oz-in ( 17kg-cm) @ 7.4V
Epoxy
Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.
8
Use dental oss or heatshrink tube to
secure the connection so they cannot be-
come unplugged.
Apply 2-3 drops of thin C/A to each of
the mounting holes. Allow the C/A to
cure without using accelerator.
1.5mm
6.
7.
5.8.
4.
Secure the servo to the aileron hatch
using Phillips screwdriver and the screws
provided with the servo.
Apply 1-2 drops of thin C/A to each of
the mounting tabs. Allow the C/A to cure
without using accelerator.
Remove the string from the wing at the
servo location and use the tape to attach it
to the servo extension lead. Pull the lead
through the wing and remove the string.
C/A glue
C/A glue
Use drill bit in a pin vise to drill the
mouting holes in the blocks.
3.
9
12.
13.
14.
9.
10.
11.
Set the aileron hatch in place and use a
Phillips screw driver to install it with four
wood screws.
3x10mm
INSTALLING THE FLAP SERVO
Repeat the procedure for the ap servo.
1.
Giant Zero A6M Gas ARF 50-60cc, 86” Instruction Manual.
10
AILERON PUSHROD INSTALLATION
Please see below pictures.
INSTALLING THE FLAP PUSHROD
3.
1.
1.
2.
1.
2.
INSTALLING LANDING GEAR
Locate items necessary to install Sprin
Landing Gear.
75mm
75mm
