NP320SL

OWNER’S GUIDE

WARNING:

To reduce the risk of

electric shock or injury, do not use outdoors

or on wet surfaces.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR INJURY:

GENERAL ELECTRICAL SAFETY:

1. Unplug from electrical outlet when not in use

and before servicing.

2. DO NOT use with damaged cord or plug.

3. DO NOT USE if the appliance has been

dropped, dropped into water, damaged or left

outdoors.

4. NO SERVICEABLE PARTS. Incorrect re-

assembly or repair can cause a risk of electrical

shock or injury to persons when the appliance is

used. Contact Customer Service.

5. DO NOT pull or carry the vacuum by the cord.

6. DO NOT unplug by pulling on the cord; to

unplug, grasp the plug, not the cord.

7. DO NOT handle the plug or the appliance with

wet hands.

8. DO NOT run the vacuum over the power cord.

9. DO NOT use the cord as a handle.

10. DO NOT close a door on the cord.

11. DO NOT pull the cord around sharp

corners. The use of an extension cord is not

recommended.

12. DO NOT leave the appliance plugged in when

not in use.

13. Keep the cord away from heated surfaces.

14. Turn off all controls before plugging or

unplugging the vacuum cleaner.

15. Always turn off this appliance before attaching

or removing accessories.

WHEN USING AN ELECTRICAL

APPLIANCE, BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE OBSERVED,

INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING

YOUR SHARK®LIFT-AROUND™CANISTER

VAC.

IMPORTANT:

This appliance is not intended for use by

persons with reduced physical, sensory or

mental capabilities or lack of experience

and knowledge, unless they have been

given supervision or instruction concerning

the use of the appliance by a person

responsible for their safety.

Children shall not use this appliance and

close supervision is necessary for any

appliance being used near children.

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

GENERAL USE:

1. Use only as described in this manual.

2. DO NOT put any objects into openings. DO

NOT use with any opening blocked; keep free

of dust, lint, hair, and anything that may reduce

air ﬂow.

3. Keep your work area well lit.

4. DO NOT place the vacuum on unstable

surfaces such as chairs or tables.

5. DO NOT allow young children to operate

the vacuum or use as a toy. Close attention is

necessary when used by or near children.

6. DO NOT use the vacuum cleaner if the

appliance is not working as it should, has

a damaged plug or cord, if the unit has

been dropped, damaged, left outdoors or

submerged in water.

7. DO NOT use without dust cup and/or ﬁlters

in place.

HOSE ATTACHMENTS:

1. DO NOT use if air ﬂow is restricted; if the air

paths, the hose, or the accessories become

blocked, turn the vacuum cleaner off. Remove

all obstructions before you turn on the

unit again.

2. Keep the end of the hose and accessory

openings away from face and body.

3. Keep cleaning tools and hose suction openings

away from hair, face, ﬁngers, uncovered feet,or

loose clothing.

4. Only use manufacturer’s recommended

attachments.

GENERAL CLEANING:

1. DO NOT pick up large-sized objects.

2. DO NOT pick up hard or sharp objects such as

glass, nails, screws or coins that could damage

the vacuum cleaner.

3. DO NOT pick up smoking or burning objects

such as hot coals, cigarette butts, matches or

hot ash.

4. DO NOT pick up ﬂammable or combustible

materials such as lighter ﬂuid, gasoline, or

kerosene or use vacuum in areas where they

may be present.

5. DO NOT pick up toxic solutions such as

chlorine bleach, ammonia, or drain cleaner.

6. DO NOT use in an enclosed space where

vapors are present from paint, paint thinner,

moth-prooﬁng substances, ﬂammable dust or

other explosive or toxic materials.

7. DO NOT vacuum up any liquids.

8. DO NOT immerse the vacuum cleaner in water

or other liquids.

9. DO NOT use outdoors or on wet surfaces; use

only on dry surfaces.

10. Use extra care when cleaning on stairs.

DUST CUP/FILTERS/ACCESSORIES:

Before turning on the vacuum:

1. Make sure that all ﬁlters are thoroughly dry

after routine cleaning.

2. Make sure that the dust cup and all ﬁlters are in

place after routine maintenance.

3. Make sure accessories are free of blockages.

4. Only use ﬁlters and accessories provided by the

manufacturer. [Failure to do so will void the

warranty.]

SAVE THESE

INSTRUCTIONS

This manual covers model number:

NP320SL 40

TECHNICAL SPECIFICATIONS

Voltage: 220-240V~, 50/60Hz

Watts: 550 W

This appliance complies with the WEEE-Directive 2002/96/EC on the disposal of electrical and electronic

equipment (WEEE).

This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/

EC and its revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions.

This marking indicates that this product should not be disposed with other household

wastes throughout the EU. To prevent possible harm to the environment or human health

from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of

material sources. To return your used device, please use the return and collection systems

or contact the retailer where this product was purchased. They can take this product for

environmental safe recycling.

Contents

Getting Started............................................................................5

How to Use ...................................................................................7

Maintenance ................................................................................9

Checking for Blockages...............................................................11

Storing..........................................................................................11

Resetting the Motor Thermostat ...............................................11

Troubleshooting Guide................................................................12

Thank you for

purchasing the

Shark®

Lift-Around™

Canister Vac.

Getting Started

Use the Shark®Lift-Around™Canister

Vac as a stand alone vacuum for spot-

cleaning small areas and large piles of debris,

or with the Flexible Hose and cleaning tools

for above-ﬂoor cleaning.

FIRST THING’S FIRST, YOU NEED TO KNOW

WHAT’S IN THE BOX YOU JUST OPENED:

ALift-Around™Canister Vac

BRemovable

Tool Caddy

C Canister Caddy

D Upholstery Brush

ECrevice Tool

FDusting Brush

GStraight Suction Nozzle

HFlexible Hose

Floor Kit Handle

JTelescopic Tube

Shoulder Strap

Accessory Bag (not shown)

NOTE: Always turn the power off before attaching

or detaching accessories.

REMOVABLE TOOL CADDY (B)

Specially designed to hold the crevice tool, dusting

brush and upholstery brush for quick access to

tools when vacuuming and cleaning around the

house.

CANISTER CADDY (C)

Specially designed to hold the Shark®Lift-

Around™and convert it to a canister vacuum.

UPHOLSTERY BRUSH (D)

This unique tool was engineered for fast and easy

removal of pet hair from upholstery.

CREVICE TOOL (E)

Reach deep into narrow spaces and clean between

cushions, under radiators and baseboards and in

hard to reach crevices and corners.

DUSTING BRUSH (F)

Dust shelves, lamp shades, window blinds, books,

furniture and other household items.

STRAIGHT SUCTION NOZZLE (G)

Powerful cleaning on low-pile carpets and

hardwood ﬂoors.

FLEXIBLE HOSE (H)

With the right cleaning tool in place and the Flexible

Hose, you can extend your reach into hard-to-clean

areas.

NOTE: Use the Flexible Hose without any

accessories attached for large debris cleaning.

FLOOR KIT HANDLE (I)

Designed for easy manoeuvrability and effortless

swivel.

TELESCOPIC TUBE (J)

Extend and adjust your reach farther into hard-to-

clean areas.

SHOULDER STRAP (K)

Specialised design to make carrying the Canister

Vac with ease. The removable Shoulder Strap is

ergonomic and easily distributes weight across the

shoulder.

ASSEMBLING THE LIFT-AROUND™CANISTER

VAC

1Insert the end of the ﬂexible hose into the

connector on the front of the Lift-Around™

Canister Vac. (ﬁg. 1)

2Insert the removable tool caddy onto the back

of the Canister Vac. (ﬁg. 2) To remove the tool

caddy, hold the vacuum by the handle, pull out

slightly from the right side and then remove it from

the Canister Vac. (ﬁg. 3)

3Insert the crevice tool, dusting brush and the

upholstery brush into the openings on the tool

caddy. (ﬁg. 4)

4Attach the shoulder strap onto the hooks on the

handle of the Canister Vac. (ﬁg. 5)

5Empty Dust Cup after cleaning and periodically

during cleaning when it appears full. (See

“Maintenance” section for instructions.)

How to Use

Fig. 1

Fig. 2

Fig. 4 Fig. 5

Power

Button

Align arrows to attach tool caddy

Pull out to remove tool caddy

Fig. 3

Fig. 9

FOR ADDED COMFORT OR FOR AN EXTENDED

REACH

9Attach the ﬂoor kit handle to the ﬂexible hose.

Push it in until it is secure. (ﬁg. 9)

10 Insert the telescopic tube into the end of the ﬂoor

kit handle. Push it in until it is secure. (ﬁg. 9)

NOTE: All accessories may be used with the

ﬂexible hose, the ﬂoor kit handle or the telescopic

tube.

11 Attach the desired accessory to the end of the

ﬂexible hose, ﬂoor kit handle or telescopic tube by

pushing it in until it is tightly secured. (ﬁg. 9)

12 While holding the Canister Vac by the handle,

press down on the power button to turn the

Canister Vac on and begin vacuuming. Press down

again to turn the vacuum off. (ﬁg. 5)

USE IN CANISTER MODE

6Place the hose in the hose dock. (ﬁg. 6)

7Place the unit over the caddy and press down until

it locks into place. (ﬁg. 6, ﬁg. 7)

8To release the vacuum from the caddy, press caddy

release button and lift the vacuum up. (ﬁg. 8)

Fig. 8

Fig. 6

Hose

Dock

Caddy

Release

Fig. 7

Maintenance

For best results empty the Dust Cup

after each use; empty several times

during prolonged usage or when it

reaches the MAX ﬁll line.

NEVER OVER-FILL THE DUST CUP.

CAUTION:

Unplug the vacuum;

failure to do so might

result in electric shock.

To reduce the risk of electric shock, unplug the unit before performing any cleaning, maintenance, or

troubleshooting checks.

Reassemble all parts securely before operating vacuum.

EMPTYING THE DUST CUP

The Dust Cup needs to be emptied each time you

vacuum and periodically during cleaning, when the

Dust Cup appears full.

1Press the dust cup release button and remove the

dust cup from the vacuum. (ﬁg. 10)

2Option A: for Quick Empty:

Insert the Dust Cup deep inside a trash receptacle

to contain the dust and debris.

Press the bottom door release button to release

the trap door. Tap gently to empty contents.

(ﬁg. 11)

Press the door shut again until it clicks.

3Option B: For Allergy Sufferers:

Wrap a trash bag around the Dust Cup leaving

space at the bottom for the door to swing open.

Locate the bottom door release button within the

trash bag and press to release as you shake the dust

cup to empty dust and debris. (ﬁg. 12)

Press the door shut again until it clicks.

Note: Option B can also be performed outside of

the home to further minimize releasing dust back

into the air. Carry just the dust cup and trash bag

outside.

4Check to make sure the trap door is secure before

returning it to the Vacuum.

5To clean the upper compartment of the dust cup,

press the top door release button to open.

(ﬁg. 13) Empty the contents over a trash

receptacle and push the door shut until it clicks

into place.

Fig. 10

Fig. 11

Fig. 13

Bottom Door

Release

Fig. 12

Top Door

Release

Dust Cup

Release

Inhaltsverzeichnis

Andere Shark Staubsauger Handbücher

Shark

Shark CZ350 Series Bedienungsanleitung

Shark

Shark EP664 Bedienungsanleitung

Shark

Shark Rocket Zero-M ZS352 Bedienungsanleitung

Shark

Shark NV642 Bedienungsanleitung

Shark

Shark ION ROBOT RV720 Series Bedienungsanleitung

Shark

Shark RV765 Bedienungsanleitung

Shark

Shark DUOCLEAN APEX QU922Q Bedienungsanleitung

Shark

Shark NV22 Bedienungsanleitung

Shark

Shark Navigator NV22UKL Bedienungsanleitung

Shark

Shark ION ROBOT RV700 Series Bedienungsanleitung

Shark

Shark VERTEX AZ1500WM Series Bedienungsanleitung

Shark

Shark WANDVAC WS632ANZ Series Bedienungsanleitung

Shark

Shark Rocket HV320REF Bedienungsanleitung

Shark

Shark DuoClean Powered Lift-Away AZ910UK Series Bedienungsanleitung

Shark

Shark Powered Lift-Away NV751 Bedienungsanleitung

Shark

Shark NAVIGATOR LIFT-AWAY NV392 Bedienungsanleitung

Shark

Shark NV480UKR Bedienungsanleitung

Shark

Shark NV105 Bedienungsanleitung

Shark

Shark Rotator Pet Plus NV255 Bedienungsanleitung

Shark

Shark STRATOS CLEAN SENSE IQ MultiFLEX IZ862H Bedienungsanleitung

Shark

Shark Rocket HV300UKS Bedienungsanleitung

Shark

Shark Navigator Lift-Away NV351 26 Bedienungsanleitung

Shark

Shark Navigator Lift-Away Bedienungsanleitung

Shark

Shark Navigator Lift-Away DLX UV440 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung

Nobles

Nobles 608669 Produkthandbuch
