Shark NV35 Series Bedienungsanleitung

NV35* NZ Series

Owner’s guide

1CUSTOMER CARE - NZ: 0800 002 999

WARNING: To reduce the risk

of electric shock or injury, do not use

outdoors or on wet surfaces.

CAUTION: Power nozzle contains

electrical connections and the Power

nozzle is not a serviceable part.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR INJURY:

GENERAL ELECTRICAL SAFETY:

1Unplug from electrical outlet when not in use and

before cleaning or servicing.

2 DO NOT use with damaged cord or plug. Contact

Customer Service or Service Center for the repair or

replacement of the line cord.

3 DO NOT use if the appliance is not working, has

been dropped, dropped into water, damaged or left

outdoors.

4 NO SERVICEABLE PARTS. Incorrect re-assembly

or repair can cause a risk of electrical shock or injury

to persons when the appliance is used. Contact

Customer Service.

5 DO NOT pull or carry vacuum by the cord.

6 DO NOT unplug by pulling on cord; to unplug, grasp

the plug, not the cord.

7 DO NOT handle plug or appliance with wet hands.

8 DO NOT run the vacuum over the power cord.

9 DO NOT use the cord as a handle.

10 DO NOT close a door on the cord.

11 DO NOT pull cord around sharp corners. The use of

an extension cord is not recommended.

12 DO NOT leave appliance when plugged in.

13 Keep cord away from heated surfaces.

14 Turn off all controls before plugging or unplugging

vacuum cleaner.

15 Always turn off this appliance before connecting or

disconnecting motorised nozzle.

16 Store your appliance with the power cord secured

around the two cord holders-as shown in the storage

instructions.

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

WHEN USING AN ELECTRICAL APPLIANCE,

BASIC SAFETY PRECAUTIONS SHOULD

ALWAYS BE OBSERVED, INCLUDING THE

FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING

YOUR SHARK®NAVIGATOR™LIFT-AWAY®PRO.

IMPORTANT:

This appliance is not intended for use by persons with

reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of

the appliance by a person responsible for their safety.

Children shall not use or play with this appliance.

Close supervision is necessary to keep appliance out of

reach of children during use.

CUSTOMER CARE - AU: 1800 890 840

HOSE ATTACHMENTS:

1 DO NOT use if air ﬂow is restricted; if the air paths,

the hose, or the accessories become blocked, turn

the vacuum cleaner off. Remove all obstructions

before you turn on the unit again.

2Keep the end of the hose and accessory openings

away from face and body.

3Keep cleaning tools and hose suction openings away

from hair, face, ﬁngers, uncovered feet, or loose

clothing.

4Only use manufacturer’s recommended attachments.

GENERAL USE:

1 Use only as described in this manual.

2 DO NOT put any objects into openings. DO NOT use

with any opening blocked; keep free of dust, lint, hair,

and anything that may reduce air ﬂow.

3 Keep your work area well lit.

4 Keep the vacuum moving over the carpet surface at

all times to avoid damaging the carpet ﬁbers.

5 DO NOT place vacuum on unstable surfaces such as

chairs or tables.

6 DO NOT allow young children to operate the vacuum

or use as a toy. Close attention is necessary when

used near children.

7 DO NOT use without dust cup and/or ﬁlters

in place.

DUST CUP/FILTERS/ACCESSORIES:

Before turning on the vacuum:

1Make sure that all ﬁlters are thoroughly dry after

routine cleaning.

2Make sure that dust cup and all ﬁlters are in place

after routine maintenance.

3Make sure accessories are free of blockages.

4Use only manufacturer’s recommended accessories

and replacement parts

GENERAL CLEANING:

1 DO NOT pick up large-sized objects.

2 DO NOT pick up hard or sharp objects such as glass,

nails, screws or coins that could damage the vacuum

cleaner.

3 DO NOT pick up smoking or burning objects such as

hot coals, cigarette butts, or matches.

4 DO NOT pick up ﬂammable or combustible materials

such as lighter ﬂuid, gasoline, or kerosene or use

vacuum in areas where they may be present.

5 DO NOT pick up toxic solutions such as chlorine

bleach, ammonia, or drain cleaner.

6 DO NOT use in an enclosed space where vapors

are present from paint, paint thinner, moth-prooﬁng

substances, ﬂammable dust or other explosive or

toxic materials.

7 DO NOT vacuum up any liquids.

8 DO NOT immerse vacuum cleaner in water or other

liquids.

9 DO NOT use outdoors or on wet surfaces; use only

on dry surfaces.

10 Use extra care when cleaning on stairs.

SAVE THESE

INSTRUCTIONS

3CUSTOMER CARE - NZ: 0800 002 999

This manual covers model number:

NV35* NZ Series

TECHNICAL SPECIFICATIONS

Voltage: 220-240V~

Hertz: 50/60Hz

Watts: 1200W

Power Nozzle: 80W

SGSEA/110659

CUSTOMER CARE - AU: 1800 890 840

Getting Started 5

Mode 1: Upright Vac 7

Mode 2: Portable Lift-Away®9

Above-Floor Cleaning 10

Lift-Away®with Floor Nozzles 11

Dust-Away™Hard Floor Attachment Use & Care 12

Storage 13

Maintenance 14

Emptying the Dust Cup 14

Cleaning the Pre-Motor Filters 14

Cleaning the Post-Motor HEPA Filter 15

Cleaning the Pet Power Brushes 15

Cleaning the Motorised Floor Brush 16

Checking for Blockages 16

Ordering Parts 17

Troubleshooting Guide 18

Warranty 20

Contents

Thank you for

purchasing

the Shark®

Navigator™

Lift-Away®

Pro

5CUSTOMER CARE - NZ: 0800 002 999

FIRST THING’S FIRST, YOU NEED TO KNOW

WHAT’S IN THE BOX YOU JUST OPENED:

a Handle with Stretch Hose

bAccessory Holder

cExtension Wand

dPortable Lift-Away®

eMotorised Floor Brush*

f14 cm Crevice Tool

g28 cm Crevice Tool

h60 cm Crevice Tool

iDusting Brush

jLarge Pet Power Brush

k Small Pet Power Brush

lDust-Away™Hard Floor Attachment

mDusting Pad

n Bare Floor Nozzle

oAccessory Bag (not shown)

*NOTE: Motorised ﬂoor brush may differ from what is

shown in the illustration above.

f g

ACCESSORIES:

DUST-AWAY™HARD FLOOR ATTACHMENT

Specialized hard ﬂoor attachment vacuums up large

particles, then re-usable micro-ﬁbre pad traps extra

ﬁne dirt and dust for a superior bare ﬂoor clean.

(Fig. 1) Use only in Portable Lift-Away®mode.

CREVICE TOOLS

Reach deep into narrow spaces and clean between

cushions, under radiators and baseboards and in

hard to reach crevices and corners. (Fig. 2)

DUSTING BRUSH

Dust shelves, lamp shades, window blinds, books,

furniture and other upholstered household items.

(Fig. 3)

ACCESSORY HOLDER

Designed to hold the crevice tool and dusting brush.

For quick access to tools when vacuuming and

cleaning around the house. (Fig. 4)

PET POWER BRUSHES

This unique tool was engineered for fast and easy

removal of pet hair and ground in dirt from carpeted

stairs and upholstery. (Fig. 5)

BARE FLOOR NOZZLE

Ideal for bare ﬂoor cleaning and large and small

particle pick up. Low proﬁle for easy access to any

area. (Fig. 6)

Fig. 1

Fig. 4

Fig. 2

Fig. 3

Getting Started

Fig. 5

Fig. 6

CUSTOMER CARE - AU: 1800 890 840

Your new Shark®Navigator™Lift-Away®Pro vacuum cleaner can easily be conﬁgured into different

cleaning modes to meet all your cleaning needs: upright vacuum and portable Lift-Away®- both with

constant suction power.

MODES:

1UPRIGHT VAC

Upright vacuuming - ﬂoors and carpets. (Fig. 6)

Fig. 6 Fig. 7

2PORTABLE LIFT-AWAY®

Take the Lift-Away®with you around the house to

clean hard to reach places. (Fig. 7)

7CUSTOMER CARE - NZ: 0800 002 999

Upper Cord

Storage Wrap

To reduce the risk of electric shock, unplug the unit before assembling, adding or removing attachments or

converting modes.

WARNING: The On/Off switch is on the top of the Lift-Away®canister. Always ensure the power is OFF

(“O” position) before plugging and unplugging.

TO ASSEMBLE:

1Place the ﬂoor nozzle on a level surface.

2Align the tube of the ﬂoor nozzle with the tube on

the Lift-Away®canister and lower until you hear the

two pieces click into place. (Fig. 8)

When attaching the motorised ﬂoor brush, ensure

that the latching mechanism is fully locked in place

to ensure electrical connection has been made.

3Attach the end of the extension wand to the tube on

the back of the Lift-Away®canister until it clicks into

place. (Fig. 9)

4Slide the accessory holder (a) positioned opposite

the upper cord wrap, over the extension wand. Align

the tab with the groove and push down. (Fig. 10)

5Push the handle (b) onto the top of the extension

wand until you hear it click into place. (Fig. 10)

6Insert the end of the stretch hose (c) into the

connector on the back of the Lift-Away®canister.

(Fig. 10)

7Store the dusting brush (d) and the crevice tool (e)

on the mounts of the accessory holder. (Fig. 10)

Fig. 8 Fig. 9

Fig. 10

Mode 1: Upright Vac

CUSTOMER CARE - AU: 1800 890 840

TO USE:

1Rotate the cord release to quickly release the power

cord.

2Secure the power cord in the cord hook.

= Brush Roll ON

= Bare Floor

= OFF

WARNING: When vacuuming ﬁne dust, e.g. sawdust,

sand, ﬂour, talcum powder etc electrostatic charges

build up naturally. Under certain conditions these

charges will be released. To avoid the unpleasant

effects of these discharges, a metal strip has been

incorporated into the underside of the handle. Please

make sure that you keep your hand in constant

contact with this metal strip during vacuuming.

3Press the On/Off switch (a) to the “I” position to

vacuum bare ﬂoors (straight suction only) or to the

“II” position to engage the motorised ﬂoor brush (for

vacuuming carpets and rugs). (Fig. 11)

IMPORTANT: The motorised brush indicator light

(b) will illuminate green when motorised ﬂoor brush

is on, or red if there is a blockage or jam. (Fig. 11)

This feature is designed to protect your Lifetime

Belt that powers your motorised ﬂoor brush. See

Checking for Blockages on page 16.

4Gently press the ﬂoor nozzle down with your foot

while you grasp the handle and tilt it back towards

you. (Fig. 12)

NOTE: The rotating brush on the motorised ﬂoor

brush will not spin unless the nozzle is ﬂat against

the ﬂoor and the handle is tilted back.

5Due to the huge suction power of this vacuum,

it may become necessary at times to adjust the

suction release (c) on the handle. (Fig. 11) If the

vacuum seems difﬁcult to push or pull or if it is

lifting up area rugs, adjust the suction release

by rotating the collar 90° counterclockwise to

open the valve. Rotate the collar clockwise to

close the valve when you need high suction and

for vacuuming ﬂoors.

6Empty dust cup after vacuuming and periodically

during use when it appears full. (See “Maintenance”

section for instructions.)

7When you are ﬁnished vacuuming, turn the

vacuumoff.

Fig. 12

Fig. 11

Suction

Release Collar

Release suction

for easier push &

pull on high pile

carpets and

area rugs.

9CUSTOMER CARE - NZ: 0800 002 999

You can carry your vacuum cleaner

in both modes by the carry handle

located on top of the dust cup.

Fig. 15

Fig. 14

Fig. 13

Mode 2: Portable Lift-Away®

PORTABLE LIFT-AWAY®

1Separate the portable Lift-Away®canister from the

ﬂoor nozzle by pressing the red release button (a) on

the side of the canister. Gently hold the nozzle to the

ﬂoor with your foot and pull the canister up. (Fig. 13)

2Press the handle release button (a) and pull the

handle up or press the extension wand release

button (b) and pull the extension wand up. (Fig. 14)

3Attach desired accessory onto the end of either the

extension wand or the handle.

4Press the On/Off switch to the “I” position to turn

the vacuum on for above-ﬂoor cleaning and hold

the handle in one hand while you carry the portable

Lift-Away®around the house with the other hand.

(Fig. 15)

Andere Handbücher für NV35 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Shark Staubsauger Handbücher

Shark

Shark EP724 Bedienungsanleitung

Shark

Shark WANDVAC SYSTEM WS640 Bedienungsanleitung

Shark

Shark ION RV850C Bedienungsanleitung

Shark

Shark Rocket ZS351Q Series Bedienungsanleitung

Shark

Shark SV1100 Bedienungsanleitung

Shark

Shark Rotator Powered Lift-Away NV750 Series Bedienungsanleitung

Shark

Shark SV736K Bedienungsanleitung

Shark

Shark RV1001AE XL Bedienungsanleitung

Shark

Shark NV340UKT Bedienungsanleitung

Shark

Shark APEX ZS360 Bedienungsanleitung

Shark

Shark HV300 Bedienungsanleitung

Shark

Shark ROTATOR Powered Lift-Away Speed NV683 Series Bedienungsanleitung

Shark

Shark HV380ANZ Series Bedienungsanleitung

Shark

Shark Rocket HV301Q Series Bedienungsanleitung

Shark

Shark NV105 Bedienungsanleitung

Shark

Shark NV801UK SERIES Bedienungsanleitung

Shark

Shark V1510C Bedienungsanleitung

Shark

Shark AI ULTRA 2600WD Series Bedienungsanleitung

Shark

Shark ROTATOR MOBILE NV680UKCO Bedienungsanleitung

Shark

Shark ROCKET PowerFins UZ360 Series Bedienungsanleitung

Shark

Shark LIFT-AWAY XL UV550 Bedienungsanleitung

Shark

Shark Rocket HV301Q Series Bedienungsanleitung

Shark

Shark Navigator Lift-Away Pro NV390 Series Bedienungsanleitung

Shark

Shark Rocket Deluxe Pro UV330 Series Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung

Nobles

Nobles 608669 Produkthandbuch
