Shark NV355 Series Bedienungsanleitung

NV355 Series

Owner’s guide

NV355_NV356_NV356E_NV357_IB_110621_2.indd 1 11-06-21 3:40 PM

WARNING:

To reduce the risk of

electric shock or injury, do not use

outdoors or on wet surfaces.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR INJURY:

GENERAL ELECTRICAL SAFETY:

1. Unplug from electrical outlet when not in use

and before servicing.

2. DO NOT use vacuum with a damaged cord

or plug. If appliance is not working as it

should, has been dropped, damaged, left

3. DO NOT pull or carry vacuum by the cord.

4. DO NOT unplug by pulling on cord; to unplug,

grasp the plug, not the cord.

5. DO NOT handle plug or appliance with

wet hands.

6. DO NOT run the vacuum over the power cord.

7. DO NOT use the cord as a handle.

8. DO NOT close a door on the cord.

9. DO NOT pull cord around sharp corners. The

use of an extension cord is not recommended.

10. DO NOT leave appliance when plugged in.

11. Keep cord away from heated surfaces.

12. Turn off all controls before plugging or

unplugging vacuum cleaner.

13. Always turn off this appliance before connecting

or disconnecting motorized nozzle.

14. Store your appliance with the power cord

secured around the two cord holders-as

shown in the storage instructions.

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

WHEN USING AN ELECTRICAL

APPLIANCE, BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE OBSERVED,

INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING

YOUR SHARK® NAVIGATOR™

LIFT-AWAY® PRO.

POLARIZED PLUG:

To reduce the risk of electric shock, this appliance

has a polarized plug (one blade is wider than the

other). As a safety feature, this plug will ﬁt into

a polarized outlet only one way. If the plug does

not ﬁt fully into the outlet, reverse the plug. If it

still does not ﬁt, contact a qualiﬁed electrician.

DO NOT force into outlet or try to

modify to ﬁt.

NV355_NV356_NV356E_NV357_IB_110621_2.indd 2 11-06-21 3:40 PM

Soutdoors, or dropped into water.

See warranty for return instructions for

examination and repair. Incorrect

re-assembly or repair can cause a

risk of electrical shock or injury to

persons when the appliance is used.

TOLL FREE: 1-800-798-7398

HOSE ATTACHMENTS:

1. DO NOT use if air ﬂow is restricted; if the air

paths, the hose, or the accessories become

blocked, turn the vacuum cleaner off. Remove

all obstructions before you turn on the

unit again.

2. Keep the end of the hose and accessory

openings away from face and body.

3. Keep cleaning tools and hose suction openings

away from hair, face, ﬁngers, uncovered feet,

or loose clothing.

4. Only use manufacturer’s recommended

attachments.

GENERAL USE:

1. Use only as described in this manual.

2. DO NOT put any objects into openings. DO

NOT use with any opening blocked; keep free

of dust, lint, hair, and anything that may reduce

air ﬂow.

3. Keep your work area well lit.

4. Keep the vacuum moving over the carpet

surface at all times to avoid damaging the

carpet ﬁbers.

5. DO NOT place vacuum on unstable surfaces

such as chairs or tables.

6. DO NOT allow young children to operate

the vacuum or use as a toy. Close attention is

necessary when used by or near children.

7. DO NOT use vacuum cleaner if it has been

dropped, damaged, left outdoors, or submerged

8. DO NOT use without dust cup and/or ﬁlters

in place.

DUST CUP/FILTERS/ACCESSORIES:

Before turning on the vacuum:

1. Make sure that all ﬁlters are thoroughly dry

after routine cleaning.

2. Make sure that dust cup and all ﬁlters are in

place after routine maintenance.

3. Make sure accessories are free of blockages.

GENERAL CLEANING:

1. DO NOT pick up large-sized objects.

2. DO NOT pick up hard or sharp objects such as

glass, nails, screws or coins that could damage

the vacuum cleaner.

3. DO NOT pick up smoking or burning objects

such as hot coals, cigarette butts, or matches.

4. DO NOT pick up ﬂammable or combustible

materials such as lighter ﬂuid, gasoline, or

kerosene or use vacuum in areas where they

may be present.

5. DO NOT pick up toxic solutions such as

chlorine bleach, ammonia, or drain cleaner.

6. DO NOT use in an enclosed space where

vapors are present from paint, paint thinner,

moth-prooﬁng substances, ﬂammable dust or

other explosive or toxic materials.

7. DO NOT vacuum up any liquids.

8. DO NOT immerse vacuum cleaner in water or

other liquids.

9. DO NOT use outdoors or on wet surfaces; use

only on dry surfaces.

10. Use extra care when cleaning on stairs.

SAVE THESE

INSTRUCTIONS

NV355_NV356_NV356E_NV357_IB_110621_2.indd 3 11-06-21 3:40 PM

oin water. See warranty for

return instructions for examination

and repair. Incorrect re-assembly

or repair can cause a risk of electrical

shock or injury to persons when

the appliance is used.

This manual covers model numbers:

NV355

NV356

NV356E

NV357

TECHNICAL SPECIFICATIONS

Voltage: 120V., 60Hz

Watts: 1200W

Amps: 10A

NV355_NV356_NV356E_NV357_IB_110621_2.indd 4 11-06-21 3:40 PM

TOLL FREE: 1-800-798-7398

Getting Started 6

Mode 1: Upright Vac 8

Mode 2: Portable Lift-Away® 10

Above-Floor Cleaning 11

Dust-Away™ Hard Floor Attachment Use & Care 12

Storage and Maintenance 13

Maintenance 14

Emptying the Dust Cup 14

Cleaning the Pre-Motor Filters 14

Cleaning the Post-Motor HEPA Filter 15

Cleaning the Power Brush 15

Cleaning the Motorized Floor Brush 16

Checking for Blockages 16

Ordering Parts 17

Troubleshooting Guide 18

Warranty 19

Contents

Thank you for

purchasing

the Shark®

Navigator™

Lift-Away®

Pro

NV355_NV356_NV356E_NV357_IB_110621_2.indd 5 11-06-21 3:40 PM

FIRST THING’S FIRST, YOU NEED TO KNOW

WHAT’S IN THE BOX YOU JUST OPENED:

a Handle with Stretch Hose

b Accessory Holder

c Extension Wand

d Portable Lift-Away®

e Motorized Floor Brush

f Crevice Tool

g 24” Crevice Tool (

h Dusting Brush

i Pet Power Brush

j Dust-Away™ Hard Floor Attachment

k Dusting Pad

ACCESSORIES:

DUST-AWAY™ HARD FLOOR ATTACHMENT

Specialized hard ﬂoor attachment vacuums up large

particles, then re-usable micro-ﬁber pad traps extra

ﬁne dirt and dust for a superior bare ﬂoor clean.

(Fig. 1) Use only in Lift-Away® mode.

CREVICE TOOL

Reach deep into narrow spaces and clean between

cushions, under radiators and baseboards and in

hard to reach crevices and corners. (Fig. 2)

DUSTING BRUSH

Dust shelves, lamp shades, window blinds, books,

furniture and other upholstered household items.

(Fig. 3)

ACCESSORY HOLDER

Designed to hold the crevice tool and dusting brush.

For quick access to tools when vacuuming and

cleaning around the house. (Fig. 4)

PET POWER BRUSH

This unique tool was engineered for fast and

easy removal of pet hair and ground in dirt from

carpeted stairs and upholstery. (Fig. 5)

Fig. 1

Fig. 4

Fig. 5

Fig. 2

Fig. 3

Getting Started

NV355_NV356_NV356E_NV357_IB_110621_2.indd 6 11-06-21 3:40 PM

selected models only)

TOLL FREE: 1-800-798-7398

Your new Shark® Navigator™ Lift-Away® Pro vacuum cleaner can easily be conﬁgured into

different cleaning modes to meet all your cleaning needs: upright vacuum and portable Lift-

Away® - both with constant suction power.

MODES:

1 UPRIGHT VAC

Upright vacuuming - ﬂoors and carpets. (Fig. 6)

Fig. 6 Fig. 7

2 PORTABLE LIFT-AWAY®

Take the Lift-Away® with you around the house to

clean hard to reach places. (Fig. 7)

NV355_NV356_NV356E_NV357_IB_110621_2.indd 7 11-06-21 3:40 PM

Upper Cord

Storage Wrap

To reduce the risk of electric shock, unplug the unit before assembling, adding or removing attachments or

converting modes.

WARNING: The On/Off switch is on the top of the Lift-Away® canister. Always ensure the power is OFF

(“O” position) before plugging and unplugging.

TO ASSEMBLE:

1 Place the ﬂoor nozzle on a level surface.

2 Align the tube of the ﬂoor nozzle with the tube on

the Lift-Away® canister and lower until you hear

the two pieces click into place. (Fig. 8)

When attaching the motorized ﬂoor brush, ensure

that the latching mechanism is fully locked in place

to ensure electrical connection has been made.

3 Attach the end of the extension wand to the tube

on the back of the Lift-Away® canister until it

clicks into place. (Fig. 9)

4 Slide the accessory holder (a) positioned opposite

the upper cord wrap, over the extension wand.

Align the tab with the groove and push down.

(Fig. 10)

5 Push the handle (b) onto the top of the extension

wand until you hear it click into place. (Fig. 10)

6 Insert the end of the stretch hose (c) into the

connector on the back of the Lift-Away®

canister. (Fig. 10)

7 Store the dusting brush (d) and the crevice tool

(e) on the mounts of the accessory holder.

(Fig. 10)

Fig. 8 Fig. 9

Fig. 10

Mode 1: Upright Vac

NV355_NV356_NV356E_NV357_IB_110621_2.indd 8 11-06-21 3:40 PM

TOLL FREE: 1-800-798-7398

TO USE:

1 Rotate the cord release to quickly release the

power cord.

2 Secure the power cord in the cord hook.

= Brush Roll ON

= Bare Floor

= OFF

3 Press the On/Off switch (a) to the “I” position to

vacuum bare ﬂoors (straight suction only) or to the

“II” position to engage the motorized ﬂoor brush

(for vacuuming carpets and rugs). (Fig. 11)

IMPORTANT: The motorized brush indicator light

(b) will illuminate green when motorized ﬂoor

brush is on, or red if there is a blockage or jam.

(Fig. 11) This feature is designed to protect your

Lifetime Belt that powers your motorized ﬂoor

brush. See Checking for Blockages on page 15.

4 Gently press the ﬂoor nozzle down with your foot

while you grasp the handle and tilt it back towards

you. (Fig. 12)

NOTE: The rotating brush on the motorized

ﬂoor brush will not spin unless the nozzle is ﬂat

against the ﬂoor and the handle is tilted back.

5 Due to the huge suction power of this

vacuum, it may become necessary at

times to adjust the suction release (c) on

the handle. (Fig. 11) If the vacuum seems

difﬁcult to push or pull or if it is lifting

up area rugs, adjust the suction release

by rotating the collar 90° counterclockwise

to open the valve. Rotate the collar

clockwise to close the valve when you need

high suction and for vacuuming ﬂoors.

6 Empty dust cup after vacuuming and periodically

during use when it appears full. (See

“Maintenance” section for instructions.)

7 When you are ﬁnished vacuuming, turn the

vacuum off.

Fig. 12

Fig. 11

Suction

Release Collar

Release suction

for easier push &

pull on high pile

carpets and

area rugs.

NV355_NV356_NV356E_NV357_IB_110621_2.indd 9 11-06-21 3:40 PM

You can carry your vacuum cleaner

in both modes by the carry handle

located on top of the dust cup.

Fig. 15

Fig. 14

Fig. 13

Mode 2: Portable Lift-Away®

PORTABLE LIFT-AWAY®

1 Separate the portable Lift-Away® canister from

the ﬂoor nozzle by pressing the red release

button (a) on the side of the canister. Gently

hold the nozzle to the ﬂoor with your foot and

pull the canister up.(Fig. 13)

2 Press the handle release button (a) and pull the

handle up or press the extension wand release

button (b) and pull the extension wand up.

(Fig. 14)

3 Attach desired accessory onto the end of either

the extension wand or the handle.

4 Press the On/Off switch to the “I” position to

turn the vacuum on for above-ﬂoor cleaning and

hold the handle in one hand while you carry the

portable Lift-Away® around the house with the

other hand. (Fig. 15)

NV355_NV356_NV356E_NV357_IB_110621_2.indd 10 11-06-21 3:40 PM

Andere Handbücher für NV355 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Shark Staubsauger Handbücher

Shark

Shark NV801 Bedienungsanleitung

Shark

Shark HV300 Bedienungsanleitung

Shark

Shark HV320EU Bedienungsanleitung

Shark

Shark Rotator QU573Q Series Bedienungsanleitung

Shark

Shark Rotator Bedienungsanleitung

Shark

Shark NV652 Bedienungsanleitung

Shark

Shark ROTATOR NV401 Series Bedienungsanleitung

Shark

Shark Rotator NV90 series Bedienungsanleitung

Shark

Shark APEX ZS364Q Bedienungsanleitung

Shark

Shark Rocket Bedienungsanleitung

Shark

Shark NINJA NZ801EUT Bedienungsanleitung

Shark

Shark CV100UKT Bedienungsanleitung

Shark

Shark APEX R-ZS362 Bedienungsanleitung

Shark

Shark CH950EUT Bedienungsanleitung

Shark

Shark IZ500 Series Bedienungsanleitung

Shark

Shark WANDVAC WS642 Series Bedienungsanleitung

Shark

Shark ION Bedienungsanleitung

Shark

Shark IQRobot SELF-EMPTY XL AV1010AE Series Bedienungsanleitung

Shark

Shark EP709T Bedienungsanleitung

Shark

Shark NINJA STRATOS IZ400UK Series Bedienungsanleitung

Shark

Shark Rocket HV305UK Bedienungsanleitung

Shark

Shark IQrobot Bedienungsanleitung

Shark

Shark IONFlex DuoClean IF200ANZ Series Bedienungsanleitung

Shark

Shark APEX DuoClean Powered Lift-Away Bedienungs- und Wartungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung

Nobles

Nobles 608669 Produkthandbuch
