SHARKCLEAN.COM

NV85

OWNER’S GUIDE

NV85_IB_170427.indd 1 2017-04-27 11:34 AM

1-800-79 8-7398

TECHNICAL SPECIFICATIONS:

Voltage: 120V.

Watts: 1200W

Amps: 10A

Hertz: 60Hz

NV85_IB_170427.indd 2 2017-04-27 11:34 AM

sharkclean.com

Contents

Important Safety Instructions �� 2

Getting Started�� 4

Using the Vacuum�� 6

Cleaning with the Vacuum Accessories �� 7

Emptying the Dust Cup Assembly�� 8

Proper Care of Your Vacuum �� 9

Troubleshooting �� 10

Checking for Blockages �� 11

Maintenance �� 12

Warranty and Registration �� 13

Thank you for

purchasing the

Shark Navigator®

Professional.

NV85_IB_170427.indd 3 2017-04-27 11:34 AM

1-800-79 8-7398

WARNING:

TO REDUCE THE RISK OF ELECTRIC SHOCK OR

INJURY DO NOT USE OUTDOORS OR ON WET

SURFACES�

WHEN USING YOUR SHARK NAVIGATOR®

PROFESSIONAL VACUUM, BASIC SAFETY

PRECAUTIONS SHOULD ALWAYS BE

FOLLOWED, INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE

USING YOUR SHARK NAVIGATOR®

PROFESSIONAL VACUUM�

POLARIZED PLUG:

This appliance has a polarized plug (one blade

is wider than the other). As a safety feature,

this plug will ﬁt into a polarized outlet only one

way. Do not force into the outlet or try to

modify the plug to ﬁt�

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR INJURY:

GENERAL ELECTRICAL SAFETY:

1 Unplug from electrical outlet when not in use

and before servicing.

2 DO NOT use vacuum with a damaged cord

or plug. If appliance is not working as it

should, has been dropped, damaged, left

outdoors, or dropped into water, return it to

SharkNinja Operating LLC for examination,

repair, or adjustment.

3 DO NOT pull or carry vacuum by the cord.

4 DO NOT unplug by pulling on cord; to unplug,

grasp the plug, not the cord.

5 DO NOT handle plug or appliance with

wet hands.

6 DO NOT run the vacuum over the power cord.

7 DO NOT use the cord as a handle.

8 DO NOT close a door on the cord.

9 DO NOT pull cord around sharp corners. The

use of an extension cord is not recommended.

10 DO NOT leave appliance when plugged in.

11 Keep cord away from heated surfaces.

12 Turn off all controls before plugging or

unplugging vacuum cleaner.

13 ALWAYS turn off this appliance before

connecting or disconnecting motorized nozzle.

14 Store your appliance with the power cord

secured around the two cord holders-as

shown in the storage instructions.

NV85_IB_170427.indd 4 2017-04-27 11:34 AM

sharkclean.com

HOSE ATTACHMENTS:

1 DO NOT use if air ﬂow is restricted; if the air

paths, the hose, or the accessories become

blocked, turn the vacuum cleaner off. Remove

all obstructions before you turn on the

unit again.

2 Keep the end of the hose and accessory

openings away from face and body.

3 Keep cleaning tools and hose suction openings

away from hair, face, ﬁngers, uncovered feet,or

loose clothing.

4 Only use manufacturer’s recommended

attachments.

GENERAL USE:

1 Use only as described in this manual.

2 DO NOT put any objects into openings. DO NOT

use with any opening blocked; keep free of

dust, lint, hair, and anything that may reduce air

ﬂow.

3 Keep your work area well lit.

4 Keep the vacuum moving over the carpet

surface at all times to avoid damaging the

carpet ﬁbers.

5 DO NOT place vacuum on unstable surfaces

such as chairs or tables.

6 DO NOT allow young children to operate the

vacuum or use as a toy. Close attention is

necessary when used by or near children.

7 DO NOT use vacuum cleaner if it has been

dropped, damaged, left outdoors, or submerged

in water. Return to SharkNinja Operating LLC

for examination, repair, or adjustment.

8 DO NOT use without dust cup and/or ﬁlters in

place.

DUST CUP/FILTERS/ACCESSORIES:

Before turning on the vacuum:

1 Make sure that all ﬁlters are thoroughly dry

after routine cleaning.

2 Make sure that dust cup and all ﬁlters are in

place after routine maintenance.

3 Make sure accessories are free of blockages.

4 Only use ﬁlters and accessories provided by

SharkNinja Operating LLC. [Failure to do so will

void the warranty.]

GENERAL CLEANING:

1 DO NOT pick up large-sized objects.

2 DO NOT pick up hard or sharp objects such as

glass, nails, screws or coins that could damage

the vacuum cleaner.

3 DO NOT pick up smoking or burning objects

such as hot coals, cigarette butts, ﬁreplace ash,

or matches.

4 DO NOT use to pick up drywall dust.

5 DO NOT pick up ﬂammable or combustible

materials such as lighter ﬂuid, gasoline, or

kerosene or use vacuum in areas where they

may be present.

6 DO NOT pick up toxic solutions such as chlorine

bleach, ammonia, or drain cleaner.

7 DO NOT use in an enclosed space where

vapors are present from paint, paint thinner,

moth-prooﬁng substances, ﬂammable dust or

other explosive or toxic materials.

8 DO NOT vacuum up any liquids.

9 DO NOT immerse vacuum cleaner in water or

other liquids.

10 DO NOT use outdoors or on wet surfaces; use

only on dry surfaces.

11 Use extra care when cleaning on stairs.

SAVE THESE INSTRUCTIONS

NV85_IB_170427.indd 5 2017-04-27 11:34 AM

1-800-79 8-7398

WHAT’S IN THE BOX YOU

JUST OPENED:

AVacuum Body

BFloor Power Nozzle

CHandle Assembly

DSuper Stretch Hose

ECleaning Wand with Handle

FCleaning Wand

GAir-Driven Pet Brush

HCleaning Attachments

NOTE: The crevice tool may be stored

in the Cleaning Wand.

Getting Started

YOUR SHARK NAVIGATOR®

PROFESSIONAL IS EASY TO

ASSEMBLE:

1Lay your vacuum body on a level

surface.

2Slide the electrical connection

from the power nozzle into the

main body to click into place.

3Connect the hose from the main

body to the power nozzle; push

with a slight turning motion to

create a snug ﬁt.

4Slide the handle assembly into

the upright unit aligning the hose

hook on the handle assembly

with the power cord hooks on the

back of the unit.

5Secure the handle assembly in

place with included bolt.

6Place the vacuum in the upright

position.

7Insert the Cleaning Wand with

the Handle into the center post

on the tool caddy.

8Store the Crevice Tool, Dusting

Brush on the back of the unit.

Store the Cleaning Wand onto

the back post of the tool caddy.

NV85_IB_170427.indd 6 2017-04-27 11:34 AM

sharkclean.com

11 To carry the vacuum:

With the unit in the standing

position, lift by the Dust Cup

Assembly Handle (carry handle).

CAUTION: When lifting or

carrying, DO NOT press Dust

Cup Assembly release button�

Attach the Super Stretch Hose:

aSnap hose into swivel

connector

bRoute under anti-tip hook to

prevent vacuum from tipping

cRoute over upper hose holder

dPress securely onto cleaning

wand with handle

IMPORTANT: Insert the hose

into the wand with the handle.

This completes the air path and

enables suction to reach the

Floor Power Nozzle.

10 To store the vacuum:

When storing your vacuum, wind

the cord around the two cord

holders and secure with cord clip:

• Quick Cord release at the

top of the unit – place in the

upright position.

• Cord holder near the base –

turn it until it is pointing down.

To release the cord, turn the Quick

Cord release to the left or right.

Store the Pet Hair Power Brush,

in the accessory bag when not

inuse.

c10

NV85_IB_170427.indd 7 2017-04-27 11:34 AM

1-800-79 8-7398

Using the Vacuum

Your Shark Navigator®Professional

Vacuum can be used to clean bare

ﬂoors or carpets – with the click of

a switch.

Stand the vacuum into the upright

position.

Plug in the vacuum.

1Start with the Power Switch in the

“O" - Off position.

2Place your foot on the Floor

Power Nozzle and pull handle

towards you.

3Set the Power Switch to desired

cleaning setting.

4Push the power cord into the

groove on the handle and then

secure the power cord into the

cord clip.

5Press the On/Off switch to the“I"

position to vacuum bare ﬂoors or

cleaning with the hose (straight

suction only) or to the "II" position

to engage the motorized ﬂoor

brush (for vacuuming carpets

andrugs).

6Due to the huge suction power

of this vacuum, it may become

necessary to adjust the suction

release on the hose. If the

vacuum is difﬁcult to push or

pull or if it is lifting up area rugs,

adjust the suction release by

opening the valve at the top end

of the hose. Close the suction

release valve for maximum

suction when vacuuming ﬂoors.

IMPORTANT: Your Brushroll

Indicator Light will illuminate solid

green when the brushroll is on,

or solid red if there is a blockage.

This feature is designed to protect

your Lifetime Belt that powers

your brushroll. See Checking for

Blockages on page 11.

NOTE: The height of your power

nozzle has been optimized for

easy pushing and superior

cleaning on all ﬂoor types, so

there is no need to make any

height adjustments as you

transition to different ﬂoor &

carpet types.

IMPORTANT: To protect your carpets, the

brushroll will only turn on when you have

pulled the handle back towards you and

released the Floor Power Nozzle.

OFF

Bare Floors / Tools

Carpets

Power Switch

Settings

Suction Release

Release suction for easier

push and pull on high pile

carpets and area rugs.

NV85_IB_170427.indd 8 2017-04-27 11:34 AM

sharkclean.com

Cleaning with the Vacuum Accessories

Before cleaning with your

accessories:

Stand vacuum into upright position.

Secure Super Stretch

Hose in the anti-tip

hose hook to prevent

tipping.

Select the “I" - On

position for suction only cleaning.

DO NOT pull vacuum cleaner

around by the hose.

DO NOT overextend the hose.

Vacuum Accessories

Your vacuum comes with a Super

Stretch Hose and Cleaning Wand with

handle. Use one or the other to attach

your cleaning accessories.

1Using the Super Stretch Hose:

Stand the vacuum into upright

position.

Remove the hose from the

Cleaning Wand with handle.

Push the selected tool into the

hose connector.

2Using the Cleaning Wand:

Stand the vacuum into upright

position.

Remove the Cleaning Wand with

handle (with hose attached) from

the unit.

Push the selected tool into the

end of the Cleaning Wand.

For a longer reach, add the extra

Cleaning Wand (7) and then

attach the various accessories.

3Air-Driven Pet Brush

4Dusting Brush

5Crevice Tool

NOTE: Remove the crevice tool from

the Cleaning Wand to use.

6Extra Cleaning Wand

To order additional parts and

accessories, go to sharkclean.com or

call 1-800-798-7398.

NV85_IB_170427.indd 9 2017-04-27 11:34 AM

1-800-79 8-7398

Maintenance

For best results empty the Dust Cup Assembly after each use, as needed during prolonged usage or when it reaches the

MAX ﬁll line. DO NOT OVERFILL� Turn vacuum off before emptying.

CAUTION: Unplug the vacuum;

failure to do so might result in

electric shock�

To empty the Dust Cup:

1 Grip carry handle and press

the Dust Cup release button to

remove.

2 Option A: For Quick Empty:

Insert Dust Cup deep inside trash

receptacle to contain dust and

debris.

Press the bottom Dust Cup re-

lease button; tap container gently

to dislodge and release dust and

debris.

Snap door in place.

IMPORTANT: If the Dust Cup

Door does not swing open after

pressing the release button, push

the door open using the bottom

door tabs.

3 Option B: For Allergy Sufferers:

Wrap a trash bag around the Dust

Cup leaving space at the bottom

for the door to swing open.

Locate the Dust Cup Door release

button within the trash bag and

press to release as you shake the

dust cup to empty dust and debris.

Snap the bottom door in place.

NOTE: Option B can also be

performed outside of the home to

further minimize releasing dust

back into the air. Carry just the

Dust Cup and trash bag outside.

NOTE: Some dust and debris

may remain in the top of your

dust cup on or near the metal

screen. It is not necessary to

completely remove this material

before continuing to vacuum;

Shark®advanced cyclonic action

will sweep the metal screen clean

once you begin to reﬁll your dust

cup.

NV85_IB_170427.indd 10 2017-04-27 11:34 AM

Inhaltsverzeichnis

Andere Shark Staubsauger Handbücher

Shark

Shark NV105 Bedienungsanleitung

Shark

Shark Rocket HV384Q Series Bedienungsanleitung

Shark

Shark AI Ultra RV2600WDEU Bedienungsanleitung

Shark

Shark Lift-Around NP318 Bedienungsanleitung

Shark

Shark Rocket NV480 Series Bedienungsanleitung

Shark

Shark Shark ION RV700_N series Bedienungsanleitung

Shark

Shark Rotator NV90 series Bedienungsanleitung

Shark

Shark Vertex CZ2000 Series Bedienungsanleitung

Shark

Shark Rocket POWERHEAD AH450UKP Bedienungsanleitung

Shark

Shark Navigator Pet Plus NV251 Series Bedienungsanleitung

Shark

Shark IQRobot Self-Empty XL AV1002AE Series Bedienungsanleitung

Shark

Shark HV300UK Bedienungsanleitung

Shark

Shark HYDROVAC WD100 Series Bedienungsanleitung

Shark

Shark DuoClean Powered Lift-Away NZ801UK Series Bedienungsanleitung

Shark

Shark NV642 Bedienungsanleitung

Shark

Shark Rocket Deluxe Pro UV330 Series Bedienungsanleitung

Shark

Shark ZERO-M Navigator Pet Pro Bedienungsanleitung

Shark

Shark LIFT-AWAY ZU782 Bedienungsanleitung

Shark

Shark DuoClean Powered Lift-Away NZ801UK Series Bedienungsanleitung

Shark

Shark SV726 Bedienungsanleitung

Shark

Shark UV700 Bedienungsanleitung

Shark

Shark Rocket DeluxePro Bedienungsanleitung

Shark

Shark ION RV870 Series Bedienungsanleitung

Shark

Shark Rotator Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung

Nobles

Nobles 608669 Produkthandbuch
