Shark V2940C N Bedienungsanleitung

V2940C_N

OWNER’S GUIDE

MANUEL DU PROPRIÉTAIRE

sharkclean.com

2TOLL FREE: 1-800-798-7398

1Read and follow all label, operational and

marking instructions.

2Use ONLY as described in this manual.

Use only manufacturer’s recommended

attachments.

3DO NOT allow the appliance to be used

by children. Close supervision is necessary

when used near children. This is not a toy.

4DO NOT use for any purpose other than

described in this user’s guide.

5DO NOT use with damaged cord or plug.

Do not use the cordless ﬂoor and carpet

sweeper if it has been dropped, damaged,

left outdoors, or dropped in water. Return it

to SharkNinja Operating LLC for examination,

repair or adjustment.

6DO NOT abuse the charger cord. Never carry

the charger or base by the cord or yank to

disconnect from an outlet; instead grasp the

charger and pull to disconnect.

7Keep the charger cord away from heated

surfaces.

8DO NOT use the charger with an extension

cord. Plug the charger directly into an

electrical outlet. Use charger only in a

standard electrical outlet.

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

9DO NOT attempt to use the charger with

any other product or attempt to charge this

product with another charger. Use only the

charger model YLS0041-T110025 supplied

with this cordless ﬂoor and carpet

sweeper.

10 DO NOT charge this unit outdoors.

11 DO NOT use outdoors or on wet surfaces.

12 DO NOT handle plug or appliance with wet

hands.

13 Use only on dry, indoor surfaces.

14 DO NOT put any object into openings. Do

not use with brush roll blocked; keep free of

ﬁber, lint, hair and anything that may prevent

the brush roll from working.

15 Keep hair, loose clothing, ﬁngers and all parts

of body away from openings and moving

parts.

16 DO NOT pick up anything that is burning or

smoking, such as cigarettes, matches or hot

ashes.

17 DO NOT use to pick up ﬂammable or

combustible liquids such as gasoline or use

in areas where they may be present.

18 DO NOT attempt to change accessories while

the unit is running.

19 DO NOT use the cordless ﬂoor and carpet

sweeper without the dust container in place.

20 Use extra care when cleaning on stairs.

21 Store the cordless ﬂoor and carpet sweeper

indoors. Store after use to prevent accidents.

22 This product includes rechargeable nickel

metal hydride batteries. Batteries must

be recycled or disposed of properly and

safely. The battery must be removed from

the appliance before it is discarded. The

appliance must be disconnected from the

READ ALL INSTRUCTIONS BEFORE USING

YOUR SHARK®CORDLESS FLOOR AND CARPET

SWEEPER.

WHEN USING YOUR SHARK CORDLESS

FLOOR AND CARPET SWEEPER, BASIC

SAFETY PRECAUTIONS SHOULD ALWAYS BE

OBSERVED, INCLUDING THE FOLLOWING:

WARNING:TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK OR INJURY:

sharkclean.com

TO MAXIMIZE THE LIFE OF YOUR

NI-MH BATTERIES:

1After ﬁrst use, discharge the unit fully and then

recharge for 6 hours.

2 DO NOT store in areas of high temperature or

humidity.

3After 3 months of non-use, the product should

be fully discharged and then recharged to

maximize battery power.

4Ni-MH batteries have a long useful life but

at some time they will need to be replaced.

To purchase replacement batteries, visit

sharkaccessories.com.

NOTE: The power button must be in the “Off”

position in order to charge the unit. If the

charging indicator does not light, press the

power button once.

SAVE THESE INSTRUCTIONS

supply when removing the battery. Do not

incinerate batteries or expose to high

temperatures, as they may explode.

23 DO NOT charge the battery at temperature

below 32°F (0°C). This will degrade the

battery performance, shorten life and

cause gas leakage from venting. Optimum

charging efﬁciancy for the battery is within

temperature range of 50°F (10°C) and 86°F

(30°C).

24 DO NOT charge with the battery polarity

reversed. This will cause battery venting,

swelling or rupture.

25 Leaks from battery cells can occur under

extreme conditions. Improper use of the

battery can cause the safety vent to activate.

Small amounts of liquid (alkaline electrolyte)

will leak from the vent near the terminal. If

the liquid gets on the skin, wash immediately

with soap and water. If the liquid gets into

the eyes, ﬂush them immediately with clean

water for a minimum of 10 minutes and seek

medical attention.

26 The cordless ﬂoor and carpet sweeper must

be disconnected from the power supply when

removing the battery.

27 To reduce the risk of electrical shock, do not

put the charger and sweeper body in water

or other liquid. Do not place or store the

appliance where it can fall or be pulled into a

tub or sink.

28 DO NOT charge the unit outdoors.

4TOLL FREE: 1-800-798-7398

Quick Start 5

Assembly 6

Charging Your Cordless Floor & Carpet Sweeper

Using Your Cordless Floor & Carpet Sweeper 7

Emptying the Dust Container 8

Maintenance 9

Troubleshooting Guide 10

Ordering Replacement Parts 10

Warranty and Registration 11

Thank you

for purchasing

the Shark®

Cordless

Floor and Carpet

Sweeper

CONTENTS

sharkclean.com

English

CLEAN

2Pull back on the handle and

press lightly on the body of the

unit with your foot to engage

the steering. (Fig. 2)

3Using your foot, press the

power button and push the unit

forward over the surface you

wish to clean. (Fig. 3)

4Press the speed button on the

right with your foot to change

the speeds. One light indicates

the speed optimized to clean

bare ﬂoors and two lights

indicate the speed optimized to

clean carpets and larger debris

on bare ﬂoors. (Fig. 4)

IMPORTANT: Before you can start using your new cordless

ﬂoor and carpet sweeper, charge it for 20 hours.

NOTE: The charging adapter will be shipped inside the

packaging.

ASSEMBLE

1Insert the lower handle

extension tube (the shortest of

the three tubes) into the lower

handle (a). Then assemble

the other two extension tubes

and insert the assembly into

the lower handle extension

tube (b). Now attach the upper

handle to the top extension

tube. (Fig. 1)

EMPTY

5When you’re ﬁnished cleaning,

pull the dust container straight

out from the side. (Fig. 5)

NOTE: Be careful not to

accidentally turn the unit on.

6Empty dust container contents.

(Fig. 6) If desired, you may

rinse with water to clean

the dust container - but dry

thoroughly before replacing.

When ﬁnished, replace the dust

container.

Fig. 1

Fig. 2

Fig. 3

Fig. 4 Fig. 6

QUICK START

Fig. 5

6TOLL FREE: 1-800-798-7398

ASSEMBLY OF YOUR FLOOR

AND CARPET SWEEPER:

NOTE: The charging adapter

and lower handle will be

shipped inside the packaging.

COMPONENTS:

AMain Unit

BSpeed Control Button

CPower Button

DDust Container

EUpper Handle

FExtension Tubes

GLower Handle Extension Tube

HCharging Adapter

Fig. 1

Model Number: V2940C _N

Voltage: 7.2 V

ASSEMBLY

1Insert the lower handle

extension tube (the shortest of

the three tubes) into the lower

handle (a). Then assemble the

other two extension tubes and

insert the assembly into the

lower handle extension tube (b).

Now attach the upper handle to

the top extension tube. (Fig. 1)

sharkclean.com

English

If the brush roll stops moving, it’s probably

due to the anti-jam feature. This feature

protects the motor from becoming overheated.

If the brush becomes overloaded, it will stop

turning and both speed indicator lights will

stay on. Turn off your unit by pressing the

power button once. See page 9 for instructions

on removing or cleaning the brush roll. Wait

for 10 seconds to let your unit cool down. Now

press the power button again and you’re ready

to resume cleaning!

1Always make sure that the unit

is turned off. (Fig. 2)

2Insert the charger plug into the

hole on the back of the unit.

Plug the charger into a wall

outlet. The light next to the

power button will illuminate

when the unit is charging. If the

unit is plugged in and the light is

not illuminated, press the power

button once. The light should

now be illuminated indicating

that the unit is charging. (Fig. 3)

CHARGING YOUR CORDLESS FLOOR AND CARPET SWEEPER

3Charge the battery for 6 hours

before initial use and 6hours

for each recharge.

4For best battery performance,

remove the charging adapter

from the unit after the charging

period has completed. Storing

the unit with the adapter

attached and plugged in will

reduce the battery life.

IMPORTANT: Although many

adaptors look similar, it’s

important to use only the

adaptor that came with the unit

(XA2950).

4Do not use the unit on concrete,

tar or other rough surfaces.

5Do not use the unit to pick

up pieces of string or fabrics.

Do not use the unit to clean

tasseled or frayed carpets.

1Press the power button to

start the unit. When ﬁnished

cleaning, press the power

button again to turn the unit off.

(Fig. 4)

2You can adjust the speed of

the brush roll to suit the ﬂoors

that you are cleaning. Press the

button on the right (opposite

USING YOUR CORDLESS FLOOR AND CARPET SWEEPER

the power button) to switch

between speeds. One light

indicates the speed optimized to

clean bare ﬂoors and two lights

indicate the speed optimized to

clean carpets and larger debris

on bare ﬂoors. (Fig. 5)

3Do not use the unit to pick up

liquids or clean wet ﬂoors.

Fig. 4 Fig. 5

FLOOR CARPET

Fig. 2

Fig. 3

OFF

8TOLL FREE: 1-800-798-7398

1To achieve the best

performance, empty the dust

container after each use. Pull

the dust container straight out

from the side. (Fig. 6)

NOTE: Be careful not to

accidentally turn the unit on.

2Empty dust container contents.

(Fig. 7) If desired, you may rinse

with water to clean the dust

container - but dry thoroughly

before replacing.

3Re-insert the dust container into

the unit. (Fig. 8)

EMPTYING THE DUST CONTAINER

Fig. 6 Fig. 7 Fig. 8

sharkclean.com

English

CAUTION: Do not clean the unit

while it is charging.

1Once a month, wipe down the

unit with a dry cloth, including

the area under the dust

container. Wipe away any hair,

ﬁber or other dirt that may have

built up in the chamber and on

the rotating brush. Do not use

any harsh cleaner or chemicals.

2Do not immerse the unit in

water.

CLEANING THE ROTATING BRUSH

1Pull the dust container straight

out from the side. (Fig. 6)

2Turn the unit upside down. Be

careful not to accidently turn

the unit on!

3Remove all hair, string or ﬁbers

wrapped around the brush

bar. Using a pair of scissors,

carefully cut along the raised

guide to remove anything

wound around the brush bar.

Avoid damaging or cutting the

bristles. (Fig. 9)

4Use a coin to remove the trap

door if you need to remove the

brush roll to either clean it or

replace it. (Fig. 10)

MAINTENANCE

5Carefully lift and remove the

brushbar from the belt. (Fig. 11)

To reinsert the brushbar, slide

the brush bar into the bushing

and then place the belt over

the ridges of the brushbar cap.

Replace the trap door and lock

in place.

REMOVING AND REPLACING THE

BATTERY

NOTE: If uncertain as to how

to remove your battery pack,

we suggest you take the unit

to a reputable small appliance

service technician to have this

service performed.

1Pull the dust container straight

out from the side. (Fig. 6)

2Turn the unit upside down. Be

careful not to accidently turn

the unit on!

3Push in the locking tab and lift

off the battery compartment

cover. (Fig. 12)

4Carefully lift out the battery

pack and disconnect the wire

terminals by pressing on the

latch and pulling apart the wire

terminal connectors. Remove

the battery pack. (Fig. 13)

5Connect the wire terminal from

the unit to the wire terminal

connector of the new battery

pack and replace the battery

pack into the unit.

6Tuck the wiring inside the

battery compartment and

replace the cover.

7Follow the instructions on page

7 to charge your new battery

pack. Please call customer

service at 1-800-798-7398

if you have any problems

removing the battery pack.

IMPORTANT This appliance

contains Ni-MH batteries. The

batteries must be recycled

or disposed of in accordance

with local regulations. Please

consult your Yellow Pages or

local recycling center for more

information.

WARNING: Never use ordinary

batteries for replacement as

these may leak and cause

damage. Use only battery pack

XB2950 for replacement.

Fig. 9

Fig. 12 Fig. 13

Ni-MH BATTERY

MUST BE RECYCLED

OR DISPOSED OF

PROPERLY

Fig. 10

Fig. 11

10 TOLL FREE: 1-800-798-7398

PROBLEM

The unit will not operate

The unit will not pick up

Dust is escaping from the

unit

The rotating brush will not

pick up

The unit will not charge

POSSIBLE REASONS AND SUGGESTED SOLUTION

Batteries need to be recharged.

Batteries are dead and need to be replaced.

There is no power in the electrical outlet supplying the charging adapter. Try to

charge using a different outlet.

Ensure the wire terminal connectors on the battery pack are securely attached.

Clear any obstruction from the rotating brush. Turn unit off for 10 seconds, and

then restart.

If the unit still doesn’t work, call Customer Service at 1-800-798-7398.

Empty the dust container.

Recharge the battery.

Empty the dust container.

Ensure that the dust container is properly in place.

Check for and remove any excessive material on the brush roll or in the bottom

of the unit.

Empty the dust container.

Press the power button once to turn the unit “OFF”.

There is no power in the electrical outlet supplying the charging adapter.

Try to charge using a different outlet.

Ensure the wire terminal connectors on the battery pack are securely attached.

Charging adapter may not be working. Call Customer Service at

1-800-798-7398.

REPLACEMENT PARTS

AXB2950 Battery Pack

BXA2950 AC Adapter

C1121FK-2940 Brush Bar Replacement Kit

To order any of the above replacement parts, go to sharkaccessories.com or call 1-800-798-7398.

ORDERING REPLACEMENT PARTS

TROUBLESHOOTING GUIDE

Inhaltsverzeichnis

Sprachen:

Andere Shark Staubsauger Handbücher

Shark

Shark duoclean Shark.ION FLEX 2X Bedienungsanleitung

Shark

Shark NV360 Bedienungsanleitung

Shark

Shark Rocket HV345 Bedienungsanleitung

Shark

Shark STRATOS Cordless Pet Pro Vacuum with Clean Sense... Bedienungsanleitung

Shark

Shark HV324Q Bedienungsanleitung

Shark

Shark NAVIGATOR LIFT-AWAY PRO Bedienungsanleitung

Shark

Shark Rocket AH450ANZ Bedienungsanleitung

Shark

Shark Rocket HV322Q Series Bedienungsanleitung

Shark

Shark LIFT-AWAY NV590UK Series Bedienungsanleitung

Shark

Shark SONIC DUO KD450UKL Bedienungsanleitung

Shark

Shark Rotator PetPro Lift-Away LA555 Series Bedienungsanleitung

Shark

Shark FLEX DuoClean HV394Q Series Bedienungsanleitung

Shark

Shark NV602ANZ Series Bedienungsanleitung

Shark

Shark LV800 Series Bedienungsanleitung

Shark

Shark HYDROVAC WD200 Series Bedienungsanleitung

Shark

Shark Navigator Lift-Away NV380 Series Bedienungsanleitung

Shark

Shark DuoClean PZ1000UK Series Bedienungsanleitung

Shark

Shark Powered Lift-Away NV620UKT Bedienungsanleitung

Shark

Shark APEX QS360Q Bedienungsanleitung

Shark

Shark ICZ160EU Series Bedienungsanleitung

Shark

Shark IQRobot Self-Empty XL AV1002AE Series Bedienungsanleitung

Shark

Shark Rocket UV425CCO Bedienungsanleitung

Shark

Shark NV702UK Series Bedienungsanleitung

Shark

Shark duoclean ROCKET HV382ANZ Series Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung

Nobles

Nobles 608669 Produkthandbuch
