OPERATOR’S MANUAL
Record all information and attach sales receipt
here for future reference.
Purchase Date:
Serial Number:
Visit us at www.power-washer.us to register
your warranty, nd replacement parts, and talk
with our service representatives about your
pressure washer.
Table of Contents
Safety Guidelines / Denitions 2
Important Safety Instructions 2-7
Specications 7
Carton Contents 8
Assembly Instructions 8-9
Operating Instructions 9-13
Maintenance 13-14
Storage 14-15
Repairs 15
Accessories 15
Trouble Shooting Guide 15-17
Warranty 18-19
IMPORTANT
Please make certain that the person who is to use this equipment carefully reads and understands
these instructions before operating. REV. 0 12/10
Pressure Washer Models
MSV2700
2700
2.4
PREMIUM RESIDENTIAL
2
This manual contains information that is important for you to know and understand. This informa-
tion relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you
recognize this information, we use the symbols below. Please read the manual and pay attention to
these symbols.
SAFETY GUIDELINES - DEFINITIONS
CONSUMER SAFETY INFORMATION
This product may not be equipped with a spark arresting mufer. If the product is not
equipped and will be used around ammable materials, or on land covered with materials such as
agricultural crops, forest, brush, grass, or other similar items, then an approved spark arrester must
be installed and is legally required in the State of California. It is a violation of California statues
section 130050 and/or sections 4442 and 4443 of the California Public Resources Code, unless
the engine is equipped with a spark arrester, as dened in section 4442, and maintained in effective
working order. Spark arresters are also required on some U.S. Forest Service land and may also be
legally required under other statutes and ordinances.
This product contains chemicals, known to the State of California, to cause cancer,
and birth defects or other reproductive harm. Wash hands after handling.
IMPORTANT SAFETY INSTRUCTIONS
Do not operate this unit until you have read and understand this Operators Manual and
the Engine Owners Manual for Safety, Operation, and Maintenance Instructions.
READ AND SAVE THESE INSTRUCTIONS
Spilled gasoline and its vapors can become
ignited from cigarette sparks, electrical arcing,
exhaust gases and hot engine components
such as the mufer.
RISK OF EXPLOSION OR FIRE
WHAT CAN HAPPEN HOW TO PREVENT IT
Shut off engine and allow it to cool before add-
ing fuel to the tank.
Use care in lling tank to avoid spilling fuel.
Move pressure washer away from fueling area
before starting engine.
••
•
Indicates an imminently
hazardous situation which, if not avoided, will
result in death or serious injury.
Indicates an potentially
hazardous situation which, if not avoided, may
result in minor or moderate injury.
Indicates an potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
Indicates a practice not related to
personal injury which, if not avoided, may result
in property damage.
3
Heat will expand fuel in the tank which could
result in spillage and possible re explosion.
WHAT CAN HAPPEN HOW TO PREVENT IT
Fill tank to 1/2" (12.7mm) below bottom of ller
neck to provide space for fuel expansion.
••
Operating the pressure washer in an explosive
environment could result in a re.
Operate and fuel equipment in well-ventilated
areas free from obstructions. Equip areas with
re extinguishers suitable for gasoline res.
••
Materials placed against or near the pressure
washer can interfere with its proper ventila-
tion features causing overheating and possible
ignition of the materials.
Never operate pressure washer in an area con-
taining dry brush or weeds.
••
Mufer exhaust heat can damage painted sur-
faces, melt any material sensitive to heat (such
as siding, plastic, rubber, vinyl, or the high
pressure hose) and damage live plants.
Always keep pressure washer a minimum of
4' (1.2m) away from surfaces (such as houses,
automobiles, or live plants) that could be dam-
aged from mufer exhaust heat.
••
Improperly stored fuel could lead to accidental
ignition. Fuel improperly secured could get
into the hands of children or other unqualied
persons.
Store fuel in an OSHA-approved container, in a
secure location away from your work area.
••
Use of acids, toxic or corrosive chemicals,
poisons, insecticides, or any kind of ammable
solvent with this product could result in seri-
ous injury or death.
Do not spray ammable liquids.
••
RISK TO BREATHING (Asphyxiation)
WHAT CAN HAPPEN HOW TO PREVENT IT
Breathing exhaust fumes will cause serious in-
jury or death! Engine exhaust contains carbon
monoxide, an odorless and deadly gas.
Operate pressure washer in a well ventilated
area. Avoid enclosed areas such as garages,
basements, etc.
Never operate unit in a location occupied by
humans or animals.
••
•
Some cleaning uids contain substances
which could cause injury to skin, eyes, or
lungs.
Use only cleaning uids specically recom-
mended for high-pressure washers. Follow
manufacturers recommendations. Do not use
chlorine bleach or any other corrosive com-
pound.
••
RISK OF FLUID INJECTION AND LACERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
Your pressure washer operates at uid pres-
sures and velocities high enough to penetrate
human and animal esh, which could result
in amputation or other serious injury. Leaks
caused by loose ttings or worn or damaged
hoses can result in injection injuries. DO NOT
TREAT FLUID INJECTION AS A SIMPLE CUT!
See a physician immediately.
Inspect the high-pressure hose regularly. Re-
place the hose immediately if it is damaged,
worn, has melted from contacting the engine,
or shows any signs of cracks, bubbles, pin-
holes, or other leakage. Never grasp a high-
pressure hose that is leaking or damaged.
Never touch, grasp, or attempt to cover a
pinhole or similar water leak on the high pres-
sure hose. The stream of water IS under high
pressure and WILL penetrate skin.
Never place hands in front of nozzle.
Direct spray away from self and others.
Make sure hose and ttings are tightened and
in good condition. Never hold onto the hose
or ttings during operation.
Do not allow the high pressure hose to contact
the mufer.
Never attach or remove wand or hose ttings
while system is pressurized - squeeze trigger
gun (when engine is off) to relieve pressure in
the system.
••
•
Injuries can result if system pressure is not
reduced before attempting maintenance or
disassembly.
To relieve system pressure, shut off engine,
turn off water supply and pull gun trigger until
water stops owing.
Use only hoses and accessories rated
for pressure higher than your pressure
washer’sPSI.
••
•
•
•
•
•
•
RISK OF INJURY FROM SPRAY
WHAT CAN HAPPEN HOW TO PREVENT IT
High velocity uid spray can cause objects to
break, propelling particles at high speed.
Light or unsecured objects can become haz-
ardous projectiles.
Always wear ANSI-approved Z87.1 safety
glasses. Wear protective clothing to protect
against accidental spraying.
Never point wand at, or spray people or ani-
mals.
Always secure trigger lock when wand is not in
service to prevent accidental operation.
Never permanently secure trigger in pull-back
(open) position.
••
•
•
•
•
4
RISK OF UNSAFE OPERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
Unsafe operation of your pressure washer
could lead to serious death to you or others.
Do not use chlorine bleach or any other
corrosive compound.
Become familiar with the operation and controls
of the pressure washer.
Keep operating area clear of all persons, pets,
and obstacles.
Do not operate the product when fatigued or
under the inuence of alcohol or drugs. Stay
alert at all times.
Never defeat the safety features of this product.
Do not operate machine with missing, broken,
or unauthorized parts.
Never leave wand unattended while unit is
running.
•
•
•
•
•
•
•
If proper starting procedure is not followed,
engine can kickback causing serious hand and
arm injury.
If engine does not start after two pulls,
squeeze trigger of gun to relieve pump pres-
sure. Pull starter cord slowly until resistance is
felt. Then pull cord rapidly to avoid kickback
and prevent hand or arm injury.
••
The spray gun/wand is a powerful tool that
could look like a toy to a child
Keep children away from the pressure washer
at all times.
••
Reactive force of spray will cause gun/wand
to kickback, and could cause the operator to
slip and fall or misdirect the spray. Improper
control of gun/wand can result in injuries to
self and others.
Do not overreach or stand on an unstable sup-
port.
Do not use pressure washer while standing on
a ladder.
Grip gun/wand rmly with both hands. Expect
the gun to kickback when triggered
••
•
•
5
6
RISK OF INJURY OR PROPERTY DAMAGE WHEN
TRANSPORTING OR STORING
WHAT CAN HAPPEN HOW TO PREVENT IT
Fuel or oil can leak or spill and could result
in re or breathing hazard. Serious injury or
death can result. Fuel or oil leaks will damage
carpet, paint, or other surfaces in vehicles or
trailers.
If the pressure washer is equipped with a fuel
shut-off valve, turn the valve to the OFF posi-
tion before transporting to avoid fuel leaks. If
the pressure washer is not equipped with a
fuel shut-off valve, drain the fuel from the tank
before transporting. Only transport fuel in
an OSHA-approved container. Always place
pressure washer on a protective mat when
transporting to protect against damage to
vehicle from leaks. Remove pressure washer
from vehicle immediately upon arrival at your
destination.
••
RISK OF BURSTING
WHAT CAN HAPPEN HOW TO PREVENT IT
Over ination of tires could result in serious
injury and property damage.
Use a tire pressure gauge to check the tires
pressure before each use and while inating
tires
See the tire sidewall for the correct tire
pressure.
NOTE: Air tanks, compressors, and similar
equipment used to inate tires can ll small
tires similar to these very rapidly. Adjust pres-
sure regulator on air supply to no more than
the rating of the tire pressure. Add air in small
increments and frequently use the tire gauge
to prevent over ination.
••
RISK OF HOT SURFACES
WHAT CAN HAPPEN HOW TO PREVENT IT
Contact with hot surfaces, such as engine
exhaust components, could result in serious
injury.
During operation, touch only the control sur-
faces of the pressure washer. Keep children
away from the pressure washer at all times.
They may not be able to recognize the hazards
of this product.
••
High velocity uid spray directed at pneumatic
tire sidewalls (such as found on automobiles,
trailers, and the like) could damage the side-
wall resulting in serious injury.
On pressure washers rated above 1600 PSI
(110 Bar) use the widest fan spray (40º nozzle)
and keep spray a minimum of 8" (20cm) from
the pneumatic tire sidewall. Do not aim spray
directly at the joint between the tire and rim.
• •
•
•
7
RISK OF CHEMICAL BURN
WHAT CAN HAPPEN HOW TO PREVENT IT
Use of acids, toxic or corrosive chemicals,
poisons, insecticides, or any kind of ammable
solvent with the product could result in injury
or death.
Do not use acids, gasoline, kerosene, or any
other ammable material in this product. Use
only household detergents, cleaners, and
degreasers recommended for use in pressure
washers.
Wear protective clothing to protect eyes and
skin from contact with sprayed materials.
••
•
RISK OF ELECTRICAL SHOCK
WHAT CAN HAPPEN HOW TO PREVENT IT
Spray directed at electrical outlets or switches,
or objects connected to an electrical circuit,
could result in a fatal electrical shock.
Unplug any electrically operated product be-
fore attempting to clean it. Direct spray away
from electric outlets and switches.
••
RISK OF INJURY FROM LIFTING
WHAT CAN HAPPEN HOW TO PREVENT IT
Serious injury can result from attempting to lift
too heavy an object.
The pressure washer is too heavy to be lifted
by one person. Obtain assistance from others
before lifting.
••
READ AND SAVE THESE INSTRUCTIONS
SPECIFICATIONS
Model MSV2700
Max Pressure* 2700 PSI
Max Flow* 2.4 GPM
* Water ow and maximum pressure ratings determined in accordance with PWMA standard PW101.
NOTE: Photographs and line drawings used in this manual are for reference only and do not
represent a specic model.
8
CARTON CONTENTS
ASSEMBLY INSTRUCTIONS
1) Locate and remove all loose parts from the carton.
2) Cut the four corners of the carton from top to bottom and lay the panels at.
3) Place the handle onto the frame, depress the snap buttons, and slide the handle assembly down
on the frame until snap buttons snap into place.
Risk of Personal Injury. Avoid placing hands between the handle and frame when
assembling to prevent pinching.
4) Connect Gun to Wand. Tighten Securely.
5) Attach high pressure hose to gun. Tighten securely.
6) Remove the colored quick connect nozzled from plastic bag and insert them into grommets on the
nozzle holder.
Engine Frame
and Wheel
Assembly
High Pressure Hose Handle
Spray Gun
Spray Wand
Quick Connect
Nozzles
Nozzle
Cleaning
Tool
Engine
Manual
Operation
Manual
Bagged Parts
9
OPERATING INSTRUCTIONS
NOTE: The pump on this unit is maintenance free and requires no oil. If there is a problem with the
pump, contact our Customer Service Group on www.power-washer.us as soon as possible.
Risk of bursting. Use a tire pressure gauge to check the tire pressure before each use
and while inating tires; see the tire sidewall for the correct tire pressure.
NOTE: Air tanks, compressors, and similar equipment used to inate tires can ll small tires similar to
these very rapidly. Adjust pressure regulator on air supply to no more than the rating of the tire pres-
sure. Add air in small increments and frequently use the tire gauge to prevent over ination.
The engine is shipped without oil. Before starting engine, add the oil provided. Damage
to the engine will occur if the engine is ran without oil, this damage will not be covered under
warranty.
Compare the illustrations with your unit to familiarize yourself with the location of various controls
and adjustments. Save this manual for future reference.
BASIC ELEMENTS OF A PRESSURE WASHER
High Pressure Pump: Increases the pressure of the water supply.
Engine: Drives the high pressure pump. Refer to the engine manual for location and operation of
engine controls
High Pressure Hose: Carries the pressurized water from the pump to the gun and spray wand.
Spray Gun: Connects the spray wand to control water ow rate, direction, and pressure.
High Pressure Pump
Engine
Spray Gun
High Pressure Hose
Quick Connect Spray Wand
10
Quick Connect Spray Wand: Allows the user to quickly change the spray pattern. See next
sections for more details on your specic Spray Wand included with your machine.
Chemical Hose (not shown): Feeds cleaning agents into the pump to mix with the water. See How
to Apply Chemicals / Cleaning Solvents instructions.
BASIC ELEMENTS OF AN ENGINE
Refer to the engine manual for location and operation of engine controls.
Choke Control: Opens and closes carburetor choke valve.
Starter Grip: Pulling starter grip operates recoil starter to crank engine.
Engine Switch: Enables and disables ignition system.
PRESSURE WASHER TERMINOLOGY
PSI: Pounds per Square Inch. The unit of measure for water pressure. Also used for air pressure,
hydraulic pressure, etc. Sometimes noted as “Bar”, another unit of measure.
GPM: Gallons per Minute. The unit of measure for the ow rate of water. Sometimes noted as L/
min (Liters per Minute).
CU: Cleaning Units. GPM multiplied by PSI equals CU.
Bypass Mode: Allows water to re-circulate within the pump when the gun trigger is not pulled. This
feature allows the operator to release the trigger gun and reposition themselves without having to
turn the engine off in between cleaning actions.
Allowing the unit to run for more than two minutes without the gun trigger being pulled
could cause overheating and damage to the pump. Do not let the pressure washer run for more
than two minutes in Bypass Mode. Turn off the engine and relieve the pressure in the gun during
these extended situations.
Thermal Relief Valve (not shown): When the temperature inside the pump rises too high, this valve
will open and release a gush of water in an effort to lower the temperature inside the pump. The
valve will then close.
Chemical Injection System: Mixes cleaners or cleaning solvents with the water to improve cleaning
effectiveness. Depending on your machine, this could either be a Detergent Siphon Tube (which is
inserted into a container of detergent), or a Detergent Tank (which is lled with detergent and is an
integral part of the pressure washer frame).
Water Supply: All pressure washers must have a source of water. The minimum requirements for a
water supply are 20 PSI and 5 Gallons Per Minute.
PRESSURE WASHER OPERATING FEATURES - SPRAY WAND
The powerful spray from your pressure washer is capable of causing damage to
surfaces such as wood, glass, automobile paint, auto striping and trim, and delicate objects such
as owers and shrubs. Before spraying, check the items to be cleaned to assure yourself that it is
strong enough to resist damage from the force of the spray.
Inhaltsverzeichnis
Sprachen:
Andere Simpson Hochdruckreiniger Handbücher
Simpson
Simpson PS3835 Bedienungsanleitung
Simpson
Simpson ALH3425 Bedienungsanleitung
Simpson
Simpson PRO3800PW Bedienungsanleitung
Simpson
Simpson PS4240H Bedienungsanleitung
Simpson
Simpson SuperPro Roll-Cage SW7040KUGL 49-State Bedienungsanleitung
Simpson
Simpson MS60921 Bedienungsanleitung
Simpson
Simpson Pro Series Bedienungsanleitung
Simpson
Simpson MS60920 Bedienungsanleitung
Simpson
Simpson Water Shotgun WS5050H 49-State Bedienungsanleitung
Simpson
Simpson ALV2623 Bedienungsanleitung
Simpson
Simpson MSV2723-S Bedienungsanleitung
Simpson
Simpson ALH3425-S Bedienungsanleitung
Simpson
Simpson WBK4200 Bedienungsanleitung
Simpson
Simpson MegaShot MS60809-S Bedienungsanleitung
Simpson
Simpson 3125-S Bedienungsanleitung
Simpson
Simpson MS61222 Bedienungsanleitung
Simpson
Simpson CLEAN MACHINE CM60976 Bedienungsanleitung
Simpson
Simpson Megashot MS61049 Bedienungsanleitung
Simpson
Simpson MSH3125-S Bedienungsanleitung
Simpson
Simpson Megashot MS61039 50-State Bedienungsanleitung
