Siqura CD820F1 Bedienungsanleitung

Installation Manual

I n s t a l l a t i o n M a n u a l

CD820 Series

Compact Network Fixed-Dome Camera

Page 2

Note: To ensure proper operation, please read this manual thoroughly before using the product and retain the

information for future reference.

CD820

Installation Manual v2 (121508-2)

AIT55MW10

Nothing from this publication may be copied, translated, reproduced, and/or published by means of printing,

photocopying, or by any other means without the prior written permission of Siqura.

Siqura reserves the right to modify specifications stated in this manual.

Brand names

Any brand names mentioned in this manual are registered trademarks of their respective owners.

Liability

Siqura accepts no liability for claims from third parties arising from improper use other than that stated in this

manual.

Although considerable care has been taken to ensure a correct and suitably comprehensive description of all

relevant product components, this manual may nonetheless contain errors and inaccuracies. We invite you to offer

your suggestions and comments by email via t.writing@tkhsecurity.com. Your feedback will help us to further

improve our documentation.

More information

If you have any comments or queries concerning any aspect related to the product, do not hesitate to contact:

Siqura B.V.

Zuidelijk Halfrond 4

2801 DD Gouda

The Netherlands

General : +31 182 592 333

Fax : +31 182 592 123

E-mail : sales.nl@tkhsecurity.com

WWW : www.siqura.com

For a full list of TKH Security Solutions sales offices, see the last page of this manual.

Page 3

Contents

1INTRODUCTION ....................................................................................................................................... 5

2SAFETY INFORMATION ............................................................................................................................ 7

2.1 CAUTIONS ..................................................................................................................................................7

2.2 REGULATIONS .............................................................................................................................................8

3PRODUCT DESCRIPTION ........................................................................................................................... 9

3.1 PRODUCT OVERVIEW ...................................................................................................................................9

3.2 PACKAGE CONTENTS ..................................................................................................................................10

4CABLE DEFINITION AND REQUIREMENTS ............................................................................................... 11

4.1 CAMERA OVERVIEW...................................................................................................................................11

4.2 INTERFACE REQUIREMENTS..........................................................................................................................12

4.3 SYSTEM COMPATIBILITY ..............................................................................................................................12

4.4 POWER OVER ETHERNET CABLE CONNECTION .................................................................................................12

4.4.1 RJ-45 connectors ..............................................................................................................................12

4.4.2 Ethernet cable connection................................................................................................................13

5INSTALLATION ....................................................................................................................................... 15

5.1 DIMENSIONS ............................................................................................................................................15

5.2 HARD-SURFACE INSTALLATION .....................................................................................................................16

5.3 CONNECTING AUDIO TO THE CD820.............................................................................................................17

6APPENDIX: TECHNICAL SPECIFICATIONS ................................................................................................ 19

Page 5

C h a p t e r 1

1Introduction

Document scope

This manual applies to Siqura's indoor and outdoor high definition (HD) mini vandal-proof

fixed-dome IP cameras, the CD820 series. It describes how to install and connect the CD820.

Operation and configuration of the CD820 is covered in the user manual.

Intended audience

This manual is aimed at installers and technicians involved in the installation of network devices,

such as the CD820.

Assumed skills and know-how

To work with the CD820 camera, an installer or technician must have adequate knowledge and

skills in the fields of:

CCTV systems and components

Electrical wiring and low-voltage electrical connections

Ethernet network technologies and Internet Protocol (IP)

Windows environments

Web browsers

Video, audio, data, and contact closure transmissions

Video compression methods

Specifications

The information given in this manual was current when published. Siqura reserves the right to

revise and improve its products. All specifications are subject to change without notice.

Important information

Before proceeding, please read and observe all instructions and warnings in this manual. Retain

this manual with the original bill of sale for future reference and, if necessary, warranty service.

When unpacking your product, check for missing or damaged items. If any item is missing, or if

damage is evident, do not install or operate this product. Contact your supplier for assistance.

We like to hear from you!

At Siqura, customer satisfaction is our first priority. We welcome and value your opinion about

our products and services. Should you detect errors or inaccuracies in this manual, we would be

grateful if you would inform us. We invite you to offer your suggestions and comments by email

via t.writing@tkhsecurity.com. Your feedback will help us to further improve our documentation.

CD820 Series

Page 6

Typographical conventions

Before you start using this guide, it is important to understand the typographical conventions

used in the documentation. The following kinds of formatting in the text identify special

information.

Formatting convention

Type of Information

Numbered list

Step-by-step procedures. You can follow these instructions to

complete a specific task.

Special Bold

Items you must select, such as menu options, command buttons, or

items in a list.

Emphasis

Used to emphasize the importance of a point or for variable

expressions such as parameters.

CAPITALS

Names of keys on the keyboard. for example, SHIFT, CTRL, or

ALT.

KEY+KEY

Key combinations for which the user must press and hold down one

key and then press another, for example, CTRL+P, or ALT+F4.

Page 7

C h a p t e r 2

2Safety Information

This chapter provides cautions on what to do and what not to do when working with or handling

your CD820 unit. It also offers information on product compliance with environmental

regulations and explains how to dispose of the product at the end of its service life.

In This Chapter

Cautions ........................................................................... 7

Regulations ....................................................................... 8

2.1 Cautions

Handle the camera carefully.

Do not abuse the camera. Avoid striking, shaking, etc. as the camera can be damaged by

improper handling or storage.

Do not disassemble the camera.

To prevent electric shock, do not remove screws or covers. There are no user serviceable parts

inside. Please consult technical support if a camera is suspected of malfunctioning.

Do not operate the camera beyond the specified temperature,

humidity, and power source ratings.

Verify that the power source is appropriate before you plug in and operate the unit. If the camera

is installed outdoors, make sure it is sheltered from direct sunlight.

Do not use strong or abrasive detergents when cleaning the

camera.

Use a dry cloth to clean the camera when it is dirty. If the dirt is hard to remove, use a mild

detergent and wipe gently. To clean the lens, use lens tissue or a cotton tipped applicator and

ethanol. DO NOT clean the lens with strong detergents.

Ensure that camera installation is performed by a specialist.

Only qualified service personnel or system installers should install and connect this product.

Never face the camera towards the sun.

Do not aim the camera at bright objects. Whether the camera is in use or not, never aim it at the

sun or other extremely bright objects, as this can damage the camera.

CD820 Series

Page 8

2.2 Regulations

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following conditions.

This device may not cause harmful interference.

This device must accept any interference received, including interference

that may cause undesired operation.

This symbol on the product or on its packaging indicates that this product shall not

be treated as household waste in accordance with Directive 2002/96/EC. Instead

it shall be handed over to the applicable collection point for the recycling of

electrical and electronic equipment. By proper waste handling of this product you

ensure that it has no negative consequences for the environment and human

health, which could otherwise be caused if this product is thrown intothe garbage

bin. The recycling of materials will help to conserve natural resources.

For more information on how to recycle this product, please contact your local city

office, your household waste disposal service or the seller of the product.

Compliance is evidenced by written declaration from our suppliers, assuring that

any potential trace contamination levels of restricted substances are below the

maximum level set by EU Directive 2002/95/EC, or are exempted due to their

application.

Page 9

C h a p t e r 3

3Product Description

The CD820 fixed-dome network camera features a 1/2.7" CMOS image sensor (1920 x 1080

pixels) that delivers unparalleled image quality and produces images of rapid moving objects

with minimum motion blurring. Dual streaming enables users to view MJPEG and H.264 video to

achieve superior image quality and conserve bandwidth. With full high-definition (HD)

resolution, users can monitor critical areas with greater detail than ever before.

In This Chapter

Product Overview ............................................................. 9

Package Contents .............................................................. 10

3.1 Product Overview

Siqura CD820F1 and CD820F2

Multiple resolutions: 1080p/720p

1/2.7” progressive scan CMOS imager

Dual-stream H.264 and MJPEG video

ONVIF-compliant

Audio - mic input

4mm fixed lens (CD820F1), 2.8 mm fixed lens (CD820F2)

Compact surface mount design

Ruggedised construction

802.3af Power-over-Ethernet/12 VDC

IP66 ingress rating

CD820 Series

Page 10

3.2 Package Contents

Before proceeding, please verify that the box contains the items listed here. If any item is

missing or has defects, do not install or operate the product. Contact your supplier for

assistance.

CD820 package contents

CD820 camera

Plastic anchors (x3)

Self-tapping screws (x3)

Rubber washer (×1, casing)

Rubber washers (×3, baseplate)

Security TORX

CD (search tool and manuals)

Quick Start Guide

The supplied self-tapping screws are mainly for softer substrate/material installations such as

wood. For other installation environments such as cement walls, pre-drill the holes and use

plastic anchors before fastening the supplied self-tapping screw to the wall.
