Siqura Pd1103 Bedienungsanleitung

PD1103 Series

3 MP Intelligent IP PTZ Dome Cameras

User Manual

Note: To ensure proper operation, please read this manual thoroughly before using the

product and retain the information for future reference.

PD1103

User Manual v1 (160805-1)

AIT55

Nothing from this publication may be copied, translated, reproduced, and/or published by

means of printing, photocopying, or by any other means without the prior written permission

of Siqura.

Siqura reserves the right to modify specifications stated in this manual.

Brand names

Any brand names mentioned in this manual are registered trademarks of their respective

owners.

Liability

Siqura accepts no liability for claims from third parties arising from improper use other than

that stated in this manual.

Although considerable care has been taken to ensure a correct and suitably comprehensive

description of all relevant product components, this manual may nonetheless contain errors

and inaccuracies. We invite you to offer your suggestions and comments by email via

[email protected]. Your feedback will help us to further improve our documentation.

How to contact us

If you have any comments or queries concerning any aspect related to the product, do not

hesitate to contact:

Siqura B.V.

Zuidelijk Halfrond 4

2801 DD Gouda

The Netherlands

General : +31 182 592 333

Fax : +31 182 592 123

E-mail : [email protected]

WWW : www.siqura.com

Contents

1 About this manual ..................................................................................... 5

2 Safety and compliance .............................................................................. 6

2.1 Safety instructions ............................................................................... 6

2.2 Compliance information ........................................................................ 7

3 Functions overview ................................................................................... 9

4 Connect to network ................................................................................... 12

4.1 System requirements ........................................................................... 12

4.2 Connect the camera to a LAN ................................................................ 12

4.3 Connect the camera to a WAN ............................................................... 14

5 Get access to the camera .......................................................................... 17

5.1 Get access via web browser .................................................................. 17

5.2 Get access via Siqura Device Manager .................................................... 18

5.3 Get access via UPnP ............................................................................. 19

5.4 Log on to the camera ........................................................................... 20

5.5 Install the videoplayer plug-in ............................................................... 21

5.6 Power-up action .................................................................................. 22

6 Live View .................................................................................................. 23

7 Playback ................................................................................................... 32

8 System ...................................................................................................... 34

8.1 Basic Information ................................................................................ 34

8.2 Time Settings ...................................................................................... 35

8.3 Upgrade & Maintenance ........................................................................ 36

8.4 RS-485 .............................................................................................. 38

8.5 Log .................................................................................................... 39

8.6 Local Configuration .............................................................................. 40

9 Security ..................................................................................................... 42

9.1 User Management ................................................................................ 42

9.2 Authentication ..................................................................................... 43

9.3 IP Address Filter .................................................................................. 45

10 Network .................................................................................................... 46

10.1 TCP/IP ............................................................................................... 46

10.2 DDNS ................................................................................................. 48

10.3 PPPoE ................................................................................................ 50

10.4 SNMP ................................................................................................. 51

10.5 802.1X ............................................................................................... 52

10.6 QoS ................................................................................................... 53

10.7 NAT ................................................................................................... 54

10.8 HTTPS ................................................................................................ 55

10.9 Mail ................................................................................................... 57

10.10 FTP .................................................................................................... 58

11 Video/Audio .............................................................................................. 60

11.1 Streaming .......................................................................................... 60

11.2 Picture Adjustment .............................................................................. 62

11.3 Text Overlay ....................................................................................... 65

11.4 Privacy Mask ....................................................................................... 66

11.5 ROI ................................................................................................... 67

12 Events ....................................................................................................... 69

12.1 Motion Detection ................................................................................. 69

12.2 Video Tampering ................................................................................. 72

12.3 Alarm Input ........................................................................................ 73

12.4 Alarm Output ...................................................................................... 75

12.5 Exception ........................................................................................... 76

12.6 Audio Exception Detection .................................................................... 77

12.7 Face Detection .................................................................................... 79

12.8 Intrusion Detection .............................................................................. 81

12.9 Line Crossing Detection ........................................................................ 83

12.10 Region Entrance Detection .................................................................... 85

12.11 Region Exiting Detection ....................................................................... 87

13 Storage ..................................................................................................... 89

13.1 HDD Management ................................................................................ 89

13.2 Record Schedule .................................................................................. 90

13.3 Capture .............................................................................................. 92

13.4 Net HDD ............................................................................................. 93

14 PTZ ........................................................................................................... 95

14.1 Settings ............................................................................................. 95

14.2 Zero Position ....................................................................................... 97

14.3 Home Action ....................................................................................... 98

14.4 Limit .................................................................................................. 99

14.5 Auto Tracking ...................................................................................... 100

14.6 Clear Config ........................................................................................ 101

Index ...................................................................................................... 102

Contents

1 About this manual

What's in this manual

This is version 1 of the user assistance which is embedded in the web interface of the PD1103

series camera. The Help topics give you all the information you need for using this product

efficiently. They tell you:

● How to get access to the camera

● How to communicate with the camera

● How to operate the camera

● How to configure the settings of the camera

Where to find more information

The technical specifications of this product are given in the PD1103 datasheet. All manuals

(including this user assistance) and datasheets for Siqura products are available as PDF

download at www.siqura.com. We advise you to make sure that you have the latest version of

this manual.

Who this manual is for

These instructions are for all professionals who will configure and operate Siqura PD1103

series cameras.

What you need to know

You will have a better understanding of how the camera works if you are familiar with:

● Camera technologies

● CCTV systems and components

● Ethernet network technologies and Internet Protocol (IP)

● Windows environments

● Video, audio, data, and contact closure transmissions

● Video compression methods

Before you continue

Before you continue, read and obey all instructions and warnings in this manual. Keep this

manual with the original bill of sale for future reference and, if necessary, warranty service.

When you unpack your product, make sure there are no missing or damaged items. If any

item is missing, or if you find damage, do not install or operate this product. Ask your supplier

for assistance.

Why specifications may change

At Siqura, we are committed to delivering high-quality products and services. The information

given in this manual was current when published. As we continuously seek to improve our

products and user experience, all features and specifications are subject to change without

notice.

We like to hear from you!

Customer satisfaction is our first priority. We welcome and value your opinion about our

products and services. Should you detect errors or inaccuracies in this manual, we would be

grateful if you would inform us. We invite you to offer your suggestions and comments via

[email protected]. Your feedback helps us to further improve our documentation.

2 Safety and compliance

This section provides safety instructions and compliance information.

In This Chapter

2.1 Safety instructions.................................................................................................. 6

2.2 Compliance information........................................................................................... 7

2.1 Safety instructions

These instructions are intended to make sure that the user can use the product correctly and

avoid danger or property loss.

The precaution measure is divided into ‘Warnings’ and ‘Cautions’:

●Warnings: Serious injury or death may be caused if any of these warnings are neglected.

●Cautions: Injury or equipment damage may be caused if any of these cautions are

neglected.

Warnings Follow these safeguards to

prevent serious injury or

death.

Cautions Follow these precautions to

prevent potential injury or

material damage.

Warnings

● Use a power adapter which can meet the safety extra low voltage (SELV)

standard.The power consumption cannot be less than the required value.

● Do not connect several devices to one power adapter as an adapter overload

may cause overheating and can be a fire hazard.

● When the product is installed on a wall or ceiling, the device should be firmly

fixed.

● To reduce the risk of fire or electrical shock, do not expose this product to

rain or moisture.

● This installation should be made by a qualified service person and should

conform to all the local codes.

● Install blackout equipment into the power supply circuit for convenient

supply interruption.

● If the product does not work properly, contact your dealer or the nearest

service centre. Never attempt to disassemble the camera yourself. We shall

not assume any responsibility for problems caused by unauthorised repair or

maintenance.

Cautions

● Make sure the power supply voltage is correct before using the camera.

● Do not drop the camera or subject it to physical shock. Do not install the

product on vibratory surfaces or places.

● Do not expose the camera to a high electromagnetic radiating environment.

● Do not aim the camera lens at strong light such as the sun or an

incandescent lamp. The strong light can cause fatal damage to the camera.

● The sensor may be burned out by a laser beam, so if any laser equipment is

used, make sure that the surface of the sensor is not exposed to the laser

beam.

● Use the unit under conditions where the temperature remains within the

range given in the Technical Specifications of this product. You can

download the datasheet of the camera at www.siqura.com.

● To avoid heat accumulation, good ventilation is required to ensure a proper

operating environment.

● While shipping, the camera should be packed into its original packing.

● Use the provided glove when you open the product cover. Do not touch the

product cover directly with your fingers. The acidic sweat of the fingers may

erode the surface coating of the product cover.

● Use a soft and dry cloth when you clean the inside and outside surfaces of

the product cover. Do not use alkaline detergents.

● Improper use or replacement of the battery may result in the hazard of

explosion. Use the battery type recommended by the manufacturer.

2.2 Compliance information

FCC compliance

This equipment has been tested and found to comply with the limits for a digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1 This device may not cause harmful interference.

2 This device must accept any interference received, including interference that may cause

undesired operation.

Safety and compliance

EU Conformity Statement

This product and - if applicable - the supplied accessories too are

marked with "CE" and comply therefore with the applicable

harmonised European standards listed under the Low Voltage

Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS

Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that

cannot be disposed of as unsorted municipal waste in the European

Union. See the product documentation for specific battery

information. The battery is marked with this symbol, which may

include lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your supplier or to a

designated collection point. For more information see:

www.recyclethis.info.

Safety and compliance

3 Functions overview

This section gives an overview of the functions offered by the speed dome camera.

Note: The availability of the functions may vary depending on the model of the camera.

Limit stops

The dome can be programmed to move within limit stops (left/right, up/down).

Scan modes

The dome provides five scan modes: auto scan, tilt scan, frame scan, random scan and

panorama scan.

Presets

A preset is a predefined image position. When the preset is called, the dome automatically

moves to the defined position. Presets can be added, modified, deleted and called.

Preset freezing

This feature freezes the scene on the monitor when the dome is moving to a preset. This

allows for smooth transition from one preset scene to another. It also guarantees that a

masked area is not revealed when the dome is moving to a preset.

Patrol

A patrol is a memorised series of predefined preset function. The scanning speed between two

presets and the dwell time at the preset are programmable.

Pattern

A pattern is a memorised series of pan, tilt, zoom, and preset functions. By default, the focus

and iris are in autostatus when the pattern is being memorised.

Label display

The on-screen label of the preset title, azimuth/elevation, zoom, time and dome name can be

displayed on the monitor. The displays of time and speed dome name can be programmed.

Autoflips

In manual tracking mode, when a target object goes directly beneath the dome, the video will

automatically flips 180 degrees in horizontal direction to maintain continuity of tracking. This

function can also be realised by auto mirror image, depending on different camera models.

Privacy mask

This function allows you to block or mask certain areas of a scene to prevent the personal

privacy from being violated by recording or live viewing. A masked area will move with pan

and tilt functions and will automatically adjust in size as the lens goes to telephoto and wide

angle.

3D Positioning

In the client software, use the left mouse button to click on the desired position in the video

image and drag a rectangle area in the lower right direction. The dome system will move the

position to the centre and allow the rectangle area to zoom in. Use the left mouse button to

drag a rectangle area in the upper left direction to move the position to the centre and allow

the rectangle area to zoom out.

Proportional pan/tilt

Proportional pan/tilt automatically reduces or increases the pan and tilt speeds according to

the amount of zoom. In telephoto zoom mode, the pan and tilt speeds are slower than in wide

angle zoom mode. This keeps the image from moving too fast on the live view image when

there is a large amount of zoom.

Autofocus

The autofocus function enables the camera to focus automatically to maintain clear video

images.

Day/Night autoswitch

The speed domes deliver colour images during the day. As light diminishes at night, the speed

domes switch to night mode and deliver black and white images with high quality.

Slow shutter

In slow shutter mode, the shutter speed is automatically reduced in low illumination

conditions to maintain clear video images by extending the exposure time. The feature can be

enabled or disabled.

Backlight compensation (BLC)

If you focus on an object against strong backlight, the object will be too dark to be seen

clearly. The backlight compensation (BLC) function can compensate the light in front of the

object to make it clear, but this causes overexposure of the background where the light is

strong.

Wide dynamic range (WDR)

The wide dynamic range (WDR) function helps the camera provide clear images even under

difficult light circumstances. When there are both very bright and very dark areas

simultaneously in the field of view, WDR balances the brightness level of the whole image and

provide clear images with details.

Note: This feature varies depending on the speed dome model.

White balance (WB)

White balance can remove unrealistic colour casts. White balance is the white rendition

function of the camera to automatically adjust the colour temperature according to the

environment.

Power off memory

The dome supports the power off memory capability with the predefined resume time. It

allows the dome to resume its previous position after power is restored.

Time task

A time task is a preconfigured action that can be performed automatically at a specific date

and time. The programmable actions include: auto scan, random scan, patrol 1-8 ,pattern

1-4, preset 1-8, frame scan, panorama scan, tilt scan, day, night, reboot, PT adjust, Aux

Output, and other actions.

Park action

This feature allows the dome to start a predefined action automatically after a period of

inactivity.

Functions overview

Inhaltsverzeichnis

Andere Siqura Sicherheitskamera Handbücher

Siqura

Siqura CD820 Series Bedienungsanleitung

Siqura

Siqura PD910 Bedienungsanleitung

Siqura

Siqura 910 Series Bedienungsanleitung

Siqura

Siqura PD900 Series Bedienungsanleitung

Siqura

Siqura FD12 Betriebsanleitung

Siqura

Siqura HSD62 series Bedienungsanleitung

Siqura

Siqura BL2005M1-EI Bedienungsanleitung

Siqura

Siqura 1002 Series Bedienungsanleitung

Siqura

Siqura HSD 62 Series Bedienungsanleitung

Siqura

Siqura HD10A Bedienungsanleitung

Siqura

Siqura MSD620 Bedienungsanleitung

Siqura

Siqura HSD820 Series Bedienungsanleitung

Siqura

Siqura XCU Series Bedienungsanleitung

Siqura

Siqura sa fixed series Bedienungsanleitung

Siqura

Siqura BL2002M1-EI Bedienungsanleitung

Siqura

Siqura HD18EXP Bedienungsanleitung

Siqura

Siqura FD820MI-SFP Bedienungsanleitung

Siqura

Siqura FD820M1(IR)-SFP Bedienungsanleitung

Siqura

Siqura PD910 Bedienungsanleitung

Siqura

Siqura BL2002F4-EI Bedienungsanleitung

Siqura

Siqura PD1103Z2-E Bedienungsanleitung

Siqura

Siqura FD820M1IR Bedienungsanleitung

Siqura

Siqura XCU Fusion Bedienungsanleitung

Siqura

Siqura HSD626EXP Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung

Siqura pd1103 Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken
