Interactive Whiteboard

Installation

Guide

SMART Board

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the manufacturer's instructions, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

Trademark Notice

SMART Board, DViT, Notebook, smarttech and the SMART logo are trademarks or registered trademarks of SMART

Technologies ULC in the U.S. and/or other countries. CalliGrapher is either a registered trademark or a trademark of

Microsoft Corporation in the U.S. and other countries. CalliGrapher 6.3 is an independent product not affiliated with

Microsoft Corporation. Windows is either a registered trademark or a trademark of Microsoft Corporation in the U.S.

and/or other countries. All other third-party product and company names are mentioned for identification purposes only

and may be trademarks of their respective owners. Patent No.

transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without

the prior written consent of SMART Technologies ULC. Information in this guide is subject to change without notice and

does not represent a commitment on the part of SMART.

Portions of the software that ships with this product are copyrighted by Intel Corporation.

Portions of the software that ships with this product are copyrighted by ParaGraph, a business unit of Vadem.

Single Mounting Bracket

Printed in Canada 12/2007.

US5448263; US6141000; US6326954; US6337681;

US6741267; US6747636; US6803906; US6919880; US6947032; US6954197; US6972401; US7151533; US7184030;

US7236162; CA2058219; EP1297488; ES2279823; CN1310126; and DE60124549. Other patents pending

Product Registration

If you register your SMART product, we’ll notify you of new features and

software upgrades.

Keep the following information available in case you need to contact

Technical Support:

Serial Number

Date of Purchase

99-00667-00 B0 Important Information i

Important Information

Please read this manual carefully before setting up and using the SMART Board™ for Flat-Panel

Displays interactive whiteboard (SBFPD).

WARNING Make sure an AC socket outlet is near the SBFPD and remains easily accessible

during use.

Assurez-vous qu’une prise secteur se trouve à proximité du SBFPD et demeure

facilement accessible durant l’utilisation.

Asegúrese de que hay una toma de corriente alterna cerca del SBFPD y que es

fácilmente accesible para su uso.

Stellen Sie sicher, dass sich in der Nähe des SBFPD eine Steckdose befindet und

sie während der Verwendung auch leicht zugänglich bleibt.

SBFPD

WARNING To reduce the risk of fire or electric shock, don’t expose this product to rain or

moisture.

Pour réduire le risque d'incendie ou de choc électrique, évitez d'exposer ce produit

à la pluie ou à l'humidité.

Para reducir el riesgo de incendio o de descarga, no exponga este producto a la

lluvia o la humedad.

Um das Risiko eines Feuers oder eines Stromschlags zu reduzieren, darf das

Produkt weder Regen noch Nässe ausgesetzt werden.

WARNING

FOR EUROPEAN

CUSTOMERS

The SBFPD should be used only with European TN and TT power

distribution systems.

The SBFPD is not suitable for older, IT-type power distribution systems

found in some European countries. “This system (IT-type) is widely used

isolated from earth, in some installations in France, with impedance to earth,

at 230/400V, and in Norway, with voltage limiter, neutral not distributed, at

230V line-to-line.” (IEC 60950:1999)

Contact qualified personnel if you're uncertain of the type of power system

available where you’re installing your SBFPD.

ii Important Information 99-00667-00 B0

AVERTISSEMENT

POUR LES

CLIENTS

EUROPÉENS

Le SBFPD doit être utilisé uniquement avec les systèmes de distribution

d’alimentation européens TN et TT.

Le SBFPD ne convient pas aux systèmes de distribution d’alimentation plus

anciens de type IP utilisés dans certains pays européens. “Ce système (type

IT) est largement utilisé isolé de la terre, dans certaines installations en

France, avec une impédance à la terre, à 230/400V, et en Norvège, avec

limiteur de tension, neutre non distribué, à 230V ligne à ligne.”(IEC

60950:1999)

Si vous avez des doutes sur le type de système d’alimentation disponible

lors de l’installation de votre SBFPD, contactez un personnel qualifié.

ADVERTENCIAS

PARA LOS

CLIENTES

EUROPEOS

La SBFPD sólo se podrá utilizar con los sistemas eléctricos TN y TT

europeos.

Este modelo no está disponible para antiguos sistemas eléctricos de tipo IT

que aún se utilizan en algunos países europeos. “Este sistema (IT) tiene

una utilización muy extendida como núcleo aislado de tierra; en algunas

instalaciones en Francia, con impedancia de tierra, a 230/400 V; y en

Noruega, con limitador de tensión, a 230 V entre conductores.” (CEI

60950:1999)

Si no está seguro del tipo de sistema eléctrico que posee, póngase en

contacto con personal cualificado a la hora de instalar su modelo SBFPD.

WARNUNG FÜR

EUROPÄISCHE

KUNDEN

Das SBFPD darf nur mit europäischen TN- und TT-Netzverteilern verwendet

werden.

Das SBFPD eignet sich nicht für ältere Netzverteiler vom Typ IT, die in

manchen europäischen Ländern zu finden sind. “Dieses System (IT-Typ)

wird, von der Erdung isoliert, in einigen Installationen in Frankreich mit

Impedanz zu Erde bei 230/400 V und in Norwegen mit

Spannungsbegrenzer, neutral, nicht verteilt, bei 230 V Leitung zu Leitung

verwendet.” (IEC 60950:1999)

Wenden Sie sich an qualifiziertes Personal, wenn Sie sich nicht sicher sind,

welches Stromsystem dort zur Verfügung steht, wo Sie Ihr SBFPD

installieren.

SBFPD

99-00667-00 B0 Important Information iii

Other Precautions

For operating safety and to avoid damage to the interactive whiteboard and its parts, please read

the following information carefully.

• If you transport the interactive whiteboard, we strongly urge you to completely repackage it

using the original packaging. This packaging was designed with optimal shock and vibration

protection. If the original packaging is no longer available, pack all components with as much

padding as reasonably possible to ensure that they are not exposed to excessive vibration or

shock.

• Clean the interactive whiteboard surface regularly. Otherwise, dust can build up on the

surface, adversely affecting its operation. For further information, see page 31.

• Don’t spray glass cleaner directly onto the interactive whiteboard. Instead, spray the cleaner

lightly on a cloth and then gently wipe the glass.

• Avoid setting up and using the interactive whiteboard in an area with excessive levels of dust,

humidity or smoke.

• Avoid exposing the interactive whiteboard to extreme heat or cold. The operating temperature

range is from 41°F to 85°F (5°C to 29°C) with up to 80% humidity (non-condensing). The

shipping and storage range is from 14°F to 95°F (-10°C to 35°C) with up to 80% humidity (non-

condensing).

• If possible, unplug the unit before thunderstorms. However, don’t touch the unit or its power

plug during a thunderstorm as there is a risk of electrical shock.

• Unplug the unit if you won’t use it for an extended period.

• Use safe practices when you’re plugging in the power cable. For example, plug it in with dry

hands and don’t insert it into a dusty outlet. Unplug the interactive whiteboard before you

install or service any components.

• Your SMART product comes with a power plug that works with your country’s power outlets. If

the power plug is a three-prong, grounding-type power plug (designed to fit into a grounding-

type power outlet) and you’re unable to insert the plug into the outlet, contact an electrician to

replace the outlet. Don’t modify the power plug.

• Handle the power cord carefully and avoid bending it excessively. Route the power cord so it’s

unlikely to be walked on or pinched by items placed upon or against it. If you must run a cable

over the floor, lay it in a flat, straight line and secure it to the floor with tape or a cable

management strip of contrasting color.

• If your SMART product requires replacement parts, use parts that are specified by SMART

Technologies.

iv Important Information 99-00667-00 B0

99-00667-00 B0 Table of Contents v

Table of Contents

Important Information i

Other Precautions ........................................................................................................................... iii

Introduction 1

Interactive Whiteboard Technology ................................................................................................. 1

About This Guide ............................................................................................................................ 1

Components of the Interactive Whiteboard..................................................................................... 1

Important Information about Compatibility ...................................................................................... 4

Installing SMART Board Software 5

Installing the Interactive Whiteboard 7

Preparing the Interactive Whiteboard for Use 25

Opening SMART Board Software ................................................................................................. 25

Orienting SMART Board Software ................................................................................................ 25

Configuring the COM Port for a Serial Connection ....................................................................... 26

Setting Up the On-Screen Display Control.................................................................................... 27

Using the SMART Bulb Saver....................................................................................................... 28

Configuring the Display Control Icon Strip .................................................................................... 29

Cleaning and Troubleshooting 31

Cleaning........................................................................................................................................ 31

Troubleshooting ............................................................................................................................ 31

Calibrating the Cameras ............................................................................................................... 32

Customer Support 33

Online Support .............................................................................................................................. 33

Training ......................................................................................................................................... 33

Contacting SMART Technical Support.......................................................................................... 33

General Inquiries........................................................................................................................... 33

Warranty........................................................................................................................................ 33

Registration ................................................................................................................................... 34

Sending Feedback ........................................................................................................................ 34

Obtaining More Information on SMART Products......................................................................... 34

Index 35

vi Table of Contents 99-00667-00 B0

99-00667-00 B0 Introduction 1

Introduction

The SMART Board for Flat-Panel Displays interactive whiteboard adds touch-screen control and

writing capability to your flat-panel display while only minimally increasing its depth.

The SMART Board for Flat-Panel Displays interactive whiteboard includes an overlay, SMART

Board software and a pen tray equipped with an eraser and color pens. With these tools, you can

write over the on-screen image by simply picking up a pen and writing on the interactive

whiteboard.

NOTE: As an alternative, you can order a controller instead of the pen tray. You won’t have access

to the pen tray tools, but you’ll still have touch control, and you can use the many features of

SMART Board software to create written notes.

Interactive Whiteboard Technology

When you’ve installed the interactive whiteboard, you can view the flat-panel display’s image

through the interactive whiteboard, and you can control any displayed computer application by

touching the interactive whiteboard.

The interactive whiteboard includes DViT™ (Digital Vision Touch) technology, which uses digital

cameras to track objects that interact with the interactive whiteboard. Each camera is calibrated to

recognize the position of a pen tray tool or your finger.

About This Guide

This guide shows you how to install your interactive whiteboard. For operating instructions, refer to

the SMART Board Software User’s Guide or the Help that comes with SMART Board software.

Components of the Interactive Whiteboard

There are several configurations of the SMART Board for Flat-Panel Displays interactive

whiteboard. All configurations include an overlay and SMART Board software, but some

configurations also include components such as a pen tray and a Display Control icon strip.

Flat-Panel Display

Interactive

Whiteboard

Pen Tray

2Introduction 99-00667-00 B0

The overlay, which includes embedded digital cameras in the top-left and top-right corners, is

mounted onto your flat-panel display.

The pen tray attaches to your overlay and includes four colored pens and an eraser. To write over

the computer image, just pick up a pen and write on the interactive whiteboard as you’d write on a

standard whiteboard.

SMART Board software includes all the tools you need to write notes over any application and to

save these notes. The software features include:

• Notebook™ software – an application that you can use to organize, save and share your

notes. Notebook software also has many writing tools and is great for creating presentations

or jotting down notes during a presentation or meeting.

• SMART Recorder – an application that can record everything you do on the screen

• SMART Video Player – an application for the Windows operating system that allows you to

play video files, write over these videos, and then save or clear these notes

• SMART Keyboard – a virtual keyboard that you can use to enter text into an application and

convert your handwritten notes to typed text

The Overlay

The Pen Tray

SMART Board Software

Overlay

Cameras

Pen Tray

Buttons

Green Pen

Red Pen

Blue Pen

Black Pen

Eraser

Andere Handbücher für Smart Board

Inhaltsverzeichnis

Andere Smart Technologies Interaktives Whiteboard Handbücher

Smart Technologies

Smart Technologies HAWM-600i2 Bedienungsanleitung

Smart Technologies

Smart Technologies Smart Board Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 480i5 Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 800i5-SMP Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 4000i Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 3000i Bedienungsanleitung

Smart Technologies

Smart Technologies Smart Board Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 8070ie-SMP Bedienungsanleitung

Smart Technologies

Smart Technologies Smart Board Bedienungsanleitung

Smart Technologies

Smart Technologies SB680i2-SE240 Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 480i5 Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 600i5 Bedienungsanleitung

Smart Technologies

Smart Technologies Smart Board Betriebsanleitung

Smart Technologies

Smart Technologies SB800ix3 Bedienungsanleitung

Smart Technologies

Smart Technologies Smart Board Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 400iv Bedienungsanleitung

Smart Technologies

Smart Technologies Smart Board Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 2000i Projector replacement Stücklistenhandbuch

Smart Technologies

Smart Technologies SMART Board 800i5e-SMP Bedienungsanleitung

Smart Technologies

Smart Technologies Board 660 Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board V280 Bedienungsanleitung

Smart Technologies

Smart Technologies Hub PE Bedienungsanleitung

Smart Technologies

Smart Technologies SMART Board 600i3 Bedienungsanleitung

Smart Technologies

Smart Technologies Parts Kit for SMART Board 580 Bedienungsanleitung

Beliebte Interaktives Whiteboard Handbücher anderer Marken

SMART

SMART KAPP42 Bedienungsanleitung

HitachiSoft

HitachiSoft StarBoard FX-TRIO-88W Bedienungsanleitung

Buhl

Buhl LyteBoard Bedienungsanleitung

SMART Board

SMART Board 680 Bedienungsanleitung

SMART

SMART SBX880 Bedienungsanleitung

Legamaster

Legamaster e-SCREEN ETX Bedienungsanleitung

SMART Board

SMART Board SBM685ix2 Bedienungsanleitung

Seneca

Seneca eno Bedienungsanleitung

BenQ

BenQ RP840G Bedienungsanleitung

SMART

SMART Sympodium IC-150 Bedienungsanleitung

Olivetti

Olivetti OLIBOARD Bedienungsanleitung

Turning Technologies

Turning Technologies MOBIVIEW Bedienungsanleitung

Panasonic

Panasonic UB-5335 Bedienungsanleitung

Dukane

Dukane ITP84 Bedienungsanleitung

Bretford

Bretford EDUIMS Konfigurationshandbuch

Panasonic

Panasonic Panaboard UB-5315 Bedienungsanleitung

Plus

Plus M-11S Bedienungsanleitung

TRIUMPH BOARD

TRIUMPH BOARD ULTRA SLIM Bedienungsanleitung
