Socket 7Qi Bedienungsanleitung

COMMAND BARCODES

2D IMAGER MODELS - 7Qi, 7Xi, 7XiRx

This document pertains to the following CHS Series 7:

Model P/N

7Qi Blue 8550-00081

7Qi Gray 8550-00078

7Qi Green 8550-00090

7Qi Red 8550-00080

7Qi White 8550-00082

7Qi Yellow 8550-00079

7Xi Gray 8550-00059

7XiRx White 8550-00060

The part number (P/N) is labeled inside the battery compartment for the CHS Series 7.

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

Table of Contents

General Command Barcodes

Data Editing - Prex/Sufx

Rumble/Beep Modes

Language Settings

QX Stand Modes

Apple iOS Oscreen Keyboard

Advanced Users Only

1D Symbologies

2D Symbologies

Postal Symbologies

SCANNER MODES

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

INSTRUCTIONS: Scan command barcode(s) to quickly congure the barcode scanner.

Many of the command barcodes only work with a scanner in a particular Bluetooth mode as indicated

by the header row of each table.

All Bluetooth Connection Modes OK

Scan only with CHS in SPP or iOS Mode

Scan only with CHS in HID Mode

Symbologies

Make sure the CHS is not connected to a host computer or device before scanning a

command barcode!

To use the CHS on multiple hosts, perform the unpair sequence.

1.Power on the CHS.

2.Press and hold down the trigger button.

3.Press and hold down the power button.

4.After you hear 3 beeps, release both buttons.

By default, the CHS is in HID mode as a Keyboard device.

For scanners in Bluetooth SPP or iOS mode, you can alternatively congure some settings by using

the Scanner Settings app. You can download the app from iTunes, and Google Play.

GENERAL COMMAND BARCODES

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

Scan command barcode(s) to quickly congure the CHS. By default, the CHS is in HID mode as a Keyboard

device.

IMPORTANT! Make sure the CHS is not connected to a host computer / device before scanning a command

barcode!

Bluetooth Connection Mode (General)

HID-Keyboard (default)

Congures the CHS as a Keyboard class device

(required for Apple iOS / Mac OS, Nokia E71).

#FNC HID Acceptor 000000000000#

HID-Peripheral

Congures the CHS as a Peripheral class device

(optional for Windows and Android).

#FNC COD HID 000500#

SPP Mode

Changes the CHS to Bluetooth Serial Port Prole

(SPP) mode (optional for Windows and Android).

#FNC SPP Acceptor 000000000000#

iOS Mode

Changes the CHS 7Qi, 7Xi, 7XiRx to Apple iOS mode

(equivalent to SPP mode).

#FNC IOS ACCEPTOR 000000000000#

Factory Defaults

Factory Reset

Congures the CHS to revert all settings to factory

defaults. The CHS powers off after scanning this

barcode.

#FNB41FB970001#

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

You can congure the CHS to automatically add a sufx and/or prex to each scan of data.

Note: Scanning multiple commands in a single instance will overwrite (not append) the previous

command.

Character or Command to Insert Scan to Enable

Carriage Return Sufx

(Default)

#FNB 4160C100010D#

Tab Sufx

#FNB 4160C1000109#

Carriage Return & Line Feed Sufx

#FNB 4160C100020D0A#

Data As Is – No prex or sufx

#FNB 4160C10000#

DATA EDITING – PREFIX / SUFFIX

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

Important! Make sure the CHS is not connected to a host computer before scanning a command barcode.

*Barcodes only work for 7Xi/7Qi with Rev M and above. For Rev M and below refer to page 12.

Rumble/Beep Modes

Vibrate “On”

Enables CHS to vibrate to indicate

successful scan

#FNB01310001000100FA0000#

Vibrate “Off”

Disables CHS from vibrating to

indicate successful scan

#FNB013100010000#

Beep “On”

Enables CHS to vibrate to indicate

successful scan

#FNB01190E000100030078004B#

Beep “Off”

Disables CHS from beeping to

indicate successful scans

#FNB01190E000100000078004B#

RUMBLE/BEEP MODES

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

HID Keyboard Language Settings

Scan to Enable Language

English

#FNB41FBA10000#

French

#FNB41FBA10001#

German

#FNB41FBA10002#

Spanish

#FNB41FBA10003#

LANGUAGE SETTINGS

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

QX Stand Modes

Mobile Mode - Normal (default)* Scanning this

bar code will enable the scanner to enter mobile

mode. It will always be in manual trigger mode

even when placed in the stand or cradle.

*Scanner Factory Reset returns to Mobile Mode.

#FNB 41FBA50000#

Auto Mode (Presentation Mode)

Scanning this bar code will enable the scanner

to enter auto mode. When the scanner is in auto

mode, it will switch to presentation trigger mode

when it detects power on the cradle pins. When

the scanner is removed from the cradle it will re-

main in presentation trigger mode until the users

presses the trigger. At that point it will switch to

normal manual trigger mode. Auto Mode command

barcode is also printed on the product label.

#FNB 41FBA50003#

QX STAND MODES

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

APPLE IOS OSCREEN KEYBOARD

Apple iOS Onscreen Keyboard

Apple iOS Onscreen Keyboard and Beep Enabled (Default)

Congures the CHS to activate the iOS onscreen keyboard when connected to an iOS device and the CHS

power button is double-pressed.

Scan only with CHS in HID mode

Disable both Onscreen Keyboard and Beep

#FNB 41FBDA000C000000000000000000000000#

Enable Beep

#FNB 41FBDA000C000500000000000000000000#

Disable Beep

#FNB 41FBDA000C000100000000000000000000#

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19

ADVANCED USERS ONLY

Bluetooth Connection Modes

*Barcodes only work for 7Xi/7Qi with Rev M and above. For Rev M and below refer to page 4.

HID Mode (default)

Congures the CHS to Human Interface Device

(HID) mode. The CHS will be discoverable as a

Keyboard to other Bluetooth devices.

Required for Apple iOS, Mac OS, Nokia E71.

#FNB00F40001#

HID-Keyboard (default)

Changes a CHS in HID-Peripheral mode to

HID-Keyboard mode.

Required for Mac OS and Nokia E71, optional

for Apple iOS.

#FNB0001000540#

HID-Peripheral

Changes a CHS in HID-Keyboard mode to

HID-Peripheral mode.

Optional for Windows and Android.

#FNB0001000500#

SPP Mode

Congures the CHS to Serial Port Prole (SPP)

mode.

Required for BlackBerry, optional for Windows

and Android.

#FNB00F40000#

iOS Mode

Changes a CHS 7Ci to iOS mode.

Required for Apple iOS applications developed

with SocketScan 10 SDK.

#FNB00F40002#

www.ime.de

ime mobile solutions GmbH • Borsigstraße 7-9 • D-93092 Barbing • +49 9401 9333-0 • info@ime de • www ime de

29-03-19
