fas ening. Fix he Smar Bracke wi h he se ’s assembling uni s only! O her fi xing
sys em use, for example, self- apping screws of big diame er, can damage fas ening
clip. Toge her wi h self- apping screws, here is a double s ick ape in he se . I can be
used for emporary sensor fi xing only. I is recommended no o use he ape for he
permanen fi xing, as he ape is drying up over a ime and he sensor may fall down
which can in erfere wi h i s func ions or even cause a breakdown.
Be careful while SmartBracket installing. Overexertion while installing can cause
deformation and, as a result, impossibility to install the sensor or to its unreliable fastening.
Fix the SmartBracket with the set’s assembling units only! Other fi xing system use, for
example, self-tapping screws of big diameter, can damage fastening clip. Together with
selftapping screws, there is a double stick tape in the set. It can be used for temporary sensor
fi xing only. It is recommended not to use the tape for the permanent fi xing, as the tape is
drying up over a time and the sensor may fall down which can interfere with its functions or
even cause a breakdown.
5.3 Install the fastening clip SmartBracket on the wall with a help of the expansion bolts and
self-tapping screws included in the set (PICTURE 2). The sensor is not to be fastened directly
to the glass!
5.4 Put the sensor on the SmartBracket. Once the sensor is fi xed on the SmartBracket, its
light must blink. It means that the tamper on the sensor is shut. In case the sensor does not
blink, the tamper status must be checked at the receiver confi guration software!
5.5 The sensor is installed!
5.6 Make sure that curtains, house plants, furniture and other objects do not cover the
sensor’s microphone. Its small opening is on the front panel. In case there are curtains of
dense texture on windows, the sensor is to be installed between the curtains and the
window, for example on window jamb. Otherwise, the curtains might silence the sound of
glass crash sound.
5.7 With a help of receiver’s confi guration software, select the necessary level of the
sensor’s sensitivity. It is necessary that the sensor will not react to the background noise in
the room. To perform a check, the device imitating the high-frequency glass breaking sound
is necessary. In case there is no such device, a light metal object can be used, such as a
spoon. With confi guration application, choose detection zone test to put the sensor to the
detection zone test mode (the receiver’s manual explains how to accomplish it). In the
detection zone test mode, the sensor’s light is on permanently, switching off when the
alarming sound is registered – it is very easy to observe. In order to check the sensor, fi st a
solid surface (preferably a glass one, without breaking it). The sensor must react to a low-
frequency sound by switching off the light for 0.2 seconds. When it happens, during 1.5
seconds throw a metal object (such as a spoon) to the solid surface or tap the glass with a
spoon. The sensor will switch off the light for one second. It means that in security mode
the sensor will react to the glass breaking. Reduce the sensor’s sensitivity and repeat the
check until the sensor stops reacting to alarming sounds. Then, get back to the previous
sensitivity level when the sensor was reacting normally. Thus, the sensor’s false triggering
probability is reduced and the reliable protection is guaranteed. For the maximum
protection from the false triggering, switch on all devices which normally function in the
room – generator units, air-conditioning, etc. In a case, these devices’ turning on from time
to time provokes the sensor’s triggering, the location for its installation should be chosen
more carefully.
5.8 In order to connect an additional wire opening sensor, plug in its wire to the socket “4”
(PICTURE 3) and pass the wire through the opening of the main unit having broken out the
cover 5 on the body frame (PICTURE 3).
5.9 In “security” mode if the glassbreak is detected, the sensor sends the alarm signal not
more frequently than once in 5 seconds switching on the light simultaneously.
