Sony MDX-C800REC Bedienungsanleitung

Operating Instructions

Mode d’emploi

Manual de instrucciones

FM/AM

MiniDisc Recorder

MDX-C800REC

For installation and connections, see the supplied installation/connections manual.

Owner’s Record

The model and serial numbers are located on the bottom of the unit.

Record the serial number in the space provided below.

Refer to these numbers whenever you call upon your Sony dealer regarding this

product.

Model No. MDX-C800REC Serial No.

FM/AM MiniDisc Recorder MDX-C800REC

Warning

This equipment has been tested and found to

comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation. This

equipment generates, uses, and can radiate

radio frequency energy and, if not installed

and used in accordance with the instructions,

may cause harmful interference to radio

communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does

cause harmful interference to radio or

television reception, which can be determined

by turning the equipment off and on, the user

is encouraged to try to correct the interference

by one or more of the following measures:

— Reorient or relocate the receiving antenna.

— Increase the separation between the

equipment and receiver.

— Connect the equipment into an outlet on a

circuit different from that to which the

receiver is connected.

— Consult the dealer or an experienced radio/

TV technician for help.

You are cautioned that any changes or

modifications not expressly approved in this

manual could void your authority to operate

this equipment.

CAUTION

The use of optical instruments with this

product will increase eye hazard.

Welcome !

Thank you for purchasing the Sony MiniDisc

Recorder. This unit lets you enjoy a variety of

features using the following controller

accessories:

Optional accessories

Rotary commander RM-X4S

Card remote commander RM-X91

In addition to the MD playback and radio

operations, you can expand your system by

connecting optional CD/MD units*1.

When you play a CD TEXT disc*2on a

connected optional CD unit with the CD TEXT

function, the CD TEXT information will appear

on the display.

*1You can connect MD changers, CD changers, MD

players, or CD players.

*2A CD TEXT disc is an audio CD that includes

information such as the disc name, artist name

and track names.

This information is recorded on the disc.

Precautions

•If your car was parked in direct sunlight

resulting in a considerable rise in

temperature inside the car, allow the unit to

cool off before operating it.

•If no power is being supplied to the unit,

check the connections first. If everything is in

order, check the fuse.

•If your car is equipped with a power

antenna, it will extend automatically while

the unit is operating.

•Do not use the CUSTOM FILE feature while

driving, or perform any other function which

could divert your attention from the road.

•Do not edit the MD while driving.

•Make sure that the vehicle’s battery and

charging system are functioning properly

prior to using Timer-off recording and the

REC Continue mode function. Under certain

unusual conditions, use of the Timer-off

recording and the REC Continue mode

function could cause the vehicle’s battery to

be discharged to a degree that would prevent

the vehicle from starting. For the maximum

current drain per connection, refer to the

“connection diagram” of the supplied

installation/connections.

•Be careful if your car is equipped with an

electric current detector-type car-alarm

system: when Timer-off recording or REC

Continue mode ends, the alarm may

mistakenly go off, detecting a change in the

car’s electrical current.

•When an optional TV/video unit is

connected, the monitor stays on during

Timer-off recording or REC Continue mode.

Turn the monitor off before leaving the car to

reduce the likelihood of battery drain or

theft.

If you have any questions or problems

concerning your unit that are not covered in

this manual, please consult your nearest Sony

dealer.

Notes on recording

If you are going to make a recording that

cannot be done over, it is recommended to

make a test recording before actual recording.

IN NO EVENT SHALL SELLER BE LIABLE

FOR ANY DIRECT, INCIDENTAL, OR

CONSEQUENTIAL DAMAGE OF ANY

NATURE, OR LOSSES OR EXPENSES

RESULTING FROM ANY DEFECTIVE

PRODUCT OR THE USE OF ANY

PRODUCT.

Moisture condensation

On a rainy day or in a very damp area,

moisture may condense on the lenses inside

the unit. Should this occur, the unit will not

operate properly. In such a case, remove the

disc and wait for about an hour until the

moisture has evaporated.

To maintain high sound quality

If you have drink holders near your audio

equipment, be careful not to splash juice or

other soft drinks onto the unit and MD. Sugary

residues on the unit or MD may contaminate

the lenses inside the unit, reduce the sound

quality, or prevent sound reproduction

altogether.

Notes on MDs

Since the disc itself is housed in a cartridge,

free from accidental contact with your fingers

and dust, MDs can withstand a certain degree

of rough handling. However, dirt or dust on

the surface of the cartridge or a warped

cartridge may cause a malfunction. Observe

the following for best results.

Never touch the surface of the disc itself by

deliberately opening the shutter on the

cartridge.

When you eject the MD, the shutter may be

open. In such a case, close the shutter

immediately.

Do not expose the MD to direct sunlight or

heat sources such as hot-air ducts. Do not leave

it in a car parked in direct sunlight where there

can be a considerable rise in temperature.

Make sure the MD is not left on the dashboard

or rear tray of a car, etc. where the temperature

can also be excessive.

Notes on attaching labels

Be sure to attach labels on cartridges correctly,

as failing to do so may cause the MD to

become stuck in the unit.

•Attach the label in a suitable position.

•Remove old labels before putting new ones

on.

•Replace labels that are beginning to peel

away from the MD.

Cleaning

Wipe the surface of the cartridge from time to

time with a soft, dry cloth.

Protecting a recorded MD

To record-protect an MD, slide open the tab at

the side of the MD.

With the tab in this position, the MD cannot be

recorded on. To record on the MD, slide the

tab closed.

Slide open the tab.

Tab

Table of Contents

Location of controls ............................................. 6

Getting Started

Resetting the unit ................................................. 8

Detaching the front panel ................................... 8

Turning the unit on/off ....................................... 9

How to use the menu

— An introductive guide ............................... 9

Setting the clock ................................................... 9

MD Player

CD/MD Unit (optional)

Playing a disc ...................................................... 10

Playing tracks repeatedly

— Repeat Play ............................................... 12

Playing tracks in random order

— Shuffle Play ............................................... 13

Creating a program

— Program Memory .................................... 13

Labeling a CD

— Disc Memo*.............................................. 15

Locating a disc by name

— List-up* ..................................................... 17

*Functions available with optional CD/MD unit.

Recording on an MD

Recording from a CD or MD by the track

— Track recording ........................................ 18

Recording a whole CD or MD

— Disc recording .......................................... 19

Recording from a CD or MD in a specific track

order

— Program recording ................................... 20

Recording a radio program

— Time Machine recording ......................... 21

Editing an MD

Erasing a recording

— Erase function........................................... 22

Dividing recorded tracks

— Divide function ........................................ 24

Combining recorded tracks

— Combine function .................................... 25

Moving recorded tracks

— Move function .......................................... 26

Labeling an MD .................................................. 27

Radio

Storing stations automatically

— Best Tuning Memory (BTM)................... 29

Storing only the desired stations ..................... 29

Receiving the stored stations............................ 30

Storing station names

— Station Memo ........................................... 31

Locating a station by name

— List-up ....................................................... 32

Other Functions

Labeling the rotary commander ...................... 32

Using the rotary commander ........................... 33

Adjusting the sound characteristics ................ 34

Quickly attenuating the sound ........................ 34

Changing the sound and display settings ...... 35

Selecting the spectrum analyzer ...................... 36

TV/Video (optional)

Watching the TV ................................................. 36

Watching a video................................................ 36

Storing TV channels automatically ................. 37

Storing only the desired TV channels ............. 37

Storing the TV channel names ......................... 38

Displaying the information stored

on a disc.......................................................... 38

Watching the TV or video while listening

to a CD or MD

— Simultaneous Play ................................... 39

Additional Information

Maintenance........................................................ 40

Removing the unit ............................................. 41

System limitations of MDs................................ 41

Specifications ...................................................... 43

Troubleshooting guide ...................................... 44

Location of controls

Refer to the pages listed for details.

1Volume control dial

2MENU button 9, 11, 13, 14, 15, 16, 23,

24, 25, 26, 27, 28, 29, 30, 31, 35, 36, 37,

3DISC/PRST +/– (cursor up/down) buttons

9, 11, 13, 14, 15, 16, 17, 23, 24, 25, 26,

27, 28, 29, 30, 31, 32, 35, 36, 37, 39

During CD/MD playback:

Disc change 12, 19

During radio reception:

Preset stations select 30

Z(eject) button (located on the front side

of the unit behind the front panel) 10, 11

5DSPL (display mode change) button

11, 16, 22, 27

6LIST button 16, 31

List-up 17, 32, 38

7SOURCE (Radio/CD/MD/TV) button

7, 9, 10, 11, 13, 16, 29, 30, 36, 37, 39

8Display window

9Reset button (located on the front side of

the unit behind the front panel) 8

0OPEN button 8, 10, 11, 18, 19, 20, 21, 40

qa MD REC button 17, 18, 19, 20, 21

qs SOUND button 34

qd OFF button*6, 8, 9, 11

qf SEEK/AMS –/+ (cursor left/right) buttons

9, 11, 13, 14, 16, 23, 24, 25, 26, 27, 28,

30, 31, 34, 35, 36, 39

Automatic Music Sensor 12, 18, 19

Manual Search 12

Seek 29, 30, 37

qg ENTER button 9, 11, 13, 14, 15, 16, 17,

23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 35,

36, 37, 39

qh MODE button

During CD or MD playback:

CD/MD unit select 11, 16

During radio reception:

Band select 29, 30

During TV reception:

Unit select 36

qj Receptor for the card remote

commander

qk Number buttons

During radio reception:

Preset number select 29, 30

During CD/MD playback:

(1) REP 12, 22

(2) SHUF 13, 22

(3) PGM 14

During TV reception:

Preset number select 37

ql REC MENU button 18, 19, 20, 21, 22

w; REC STOP button 18, 20, 21

*Warning when installing in a car

without ACC (accessory) position on

the ignition switch

Be sure to press (OFF) on the unit for 2

seconds to turn off the clock display after

turning off the ignition.

When you press (OFF) only momentarily,

the clock display does not turn off and this

causes battery drain.

MDX-C800REC

–

LIST

DSPL

OFF

ENTER

SOUND

SOURCE

SEEK/AMS

OPEN

MODE

MD REC

REC STOP

REC MENU

REP

SHUF PGM

1 2 3 4 56

Location of controls

Card remote commander RM-X91 (optional)

The corresponding buttons of the card

remote commander control the same

functions as those on this unit.

1OFF button

2MENU button

3SOURCE button

4SEEK/AMS (B/b) buttons

5SOUND button

6DSPL button

7ATT button

8LIST button

9DISC/PRST (V/v) buttons

q; ENTER button

qa MODE button

qs VOL buttons

OFF

SEEK SEEK

OPEN/CLOSE

MENU LIST

SOUND

ENTER

DISC

SOURCE

DSPL MODE

VOLATT

Notes

• A unit turned off by pressing (OFF) for 2 seconds cannot be operated with the card remote commander

unless (SOURCE) on the unit is pressed, or a disc is inserted to activate the unit first.

• Do not leave the card remote commander where it can be exposed to direct sunlight such as on a

dashboard or the steering wheel, etc. The card remote commander may be deformed by the heat.

• The MiniDisc recorder may not operate properly with the card remote commander in direct sunlight. In

such a case, hold the card remote commander close to the unit’s receptor.

Getting Started

Resetting the unit

Before operating the unit for the first time or

after replacing the car battery, you must reset

the unit.

Remove the front panel and press the reset

button with a pointed object, such as a ball-

point pen.

Reset button

Note

Pressing the reset button will erase the clock

setting and some stored contents such as the

station memo.

Detaching the front panel

You can detach the front panel of this unit to

protect the unit from being stolen.

1Press (OFF).

2Press (OPEN), then slide the front panel

to the right side, and pull out the left

side of the front panel.

Notes

• Do not put anything on the inner surface of the

front panel.

• Be sure not to drop the panel when detaching it

from the unit.

•If you detach the panel while the unit is still

turned on, the power will turn off automatically

to prevent the speakers from being damaged.

•When carrying the front panel with you, use the

supplied front panel case.

Attaching the front panel

Place the hole Ain the front panel onto the

spindle Bon the unit as illustrated, then push

the left side in.

Notes

• Be careful not to attach the front panel upside

down.

•Do not press the front panel too hard against the

unit when attaching it.

•Do not press too hard or put excessive pressure

on the display window of the front panel.

•Do not expose the front panel to direct sunlight

or heat sources such as hot air ducts, and do not

leave it in a humid place. Never leave it on the

dashboard of a car parked in direct sunlight or

where there may be a considerable rise in

temperature.

Caution alarm

If you turn the ignition switch to the OFF

position without removing the front panel, the

caution alarm will beep for a few seconds.

Turning the unit on/off

Turning on the unit

Press (SOURCE) or insert an MD into the unit.

For details on operation, refer to page 10 (MD/

CD) and page 29 (radio).

Turning off the unit

Press (OFF) to stop MD/CD playback or FM/

AM reception (the key illumination and

display remain on).

Press (OFF) for 2 seconds to completely turn

off the unit.

Note

If your car has no ACC position on the ignition

switch, be sure to turn the unit off by pressing

(OFF) for 2 seconds to avoid car battery drain.

How to use the menu

— An introductive guide

One operational feature of this unit is selecting

functions/settings from a menu.

After entering Menu mode, you move the

cursor to select each item with the following

buttons:

(DISC/PRST)

(+): to select upwards

(SEEK/AMS)

(+): to select

rightwards

(SEEK/AMS)

(–): to select

leftwards

(DISC/PRST)

(–): to select downwards

SOURCE

Setting the clock

The clock uses a 12-hour digital indication.

Example: To set the clock to 10:08

1Press (MENU), then press either side of

(DISC/PRST) repeatedly until “Clock”

appears.

1Press (ENTER).

The hour indication flashes.

2Press either side of (DISC/PRST) to set

the hour.

3Press the (+) side of (SEEK/AMS).

The minute indication flashes.

4Press either side of (DISC/PRST) to set

the minute.

2Press (ENTER).

The clock starts.

After the clock setting is completed, the

display returns to normal play mode.

Note

In Menu mode the “v” in the left of the display

indicates the selectable buttons of

(DISC/PRST) and (SEEK/AMS).

MD Player

CD/MD Unit (optional)

In addition to playing an MD with this unit

alone, you can also control external CD/MD

units.

Note

If you connect an optional CD unit with the CD

TEXT function, the CD TEXT information will

appear on the display when you play a CD TEXT

disc.

Playing a disc

Playing an MD (with this unit)

1Press (OPEN) and insert the MD.

2Close the front panel.

Playback starts automatically.

If an MD is already inserted, press (SOURCE)

repeatedly until “MD” appears to start

playback.

BRadio (band indication)

MD bCD*b

*If the corresponding optional equipment is not

connected, this item will not appear.

The title of the MD*and the track title*will

appear on the display window, then the

playing time will appear.

MD indication Disc name*/track title*

*Only if these titles are prerecorded on the MD

(Some characters cannot be displayed).

Elapsed playing time

Notes

• If your car has no ACC (accessory) position on the

ignition switch, be sure to turn on the unit

before you set the clock (see page 9).

• In the initial setting, the clock indication appears

while the unit is turned off.

When D.INFO mode is set to ON, the time is

always displayed (page 35).

Track number

Labeled side up

Andere Handbücher für MDX-C800REC

Inhaltsverzeichnis

Andere Sony Autoempfänger Handbücher

Sony

Sony Xplod CDX-CA810X Bedienungsanleitung

Sony

Sony DSX-A416BT Bedienungsanleitung

Sony

Sony BluetoothH MEX-BT5100 Bedienungsanleitung

Sony

Sony CDXGT530UI - CD Receiver MP3/WMA/AAC Player Produkthandbuch

Sony

Sony HCD-H3800 Bedienungsanleitung

Sony

Sony CDX-GT730UI - Fm/am Compact Disc Player Bedienungsanleitung

Sony

Sony CDX-CA900 Bedienungsanleitung

Sony

Sony BluetoothH MEX-BT5100 Bedienungsanleitung

Sony

Sony XR-C110 Bedienungsanleitung

Sony

Sony XR-6450RDS Bedienungsanleitung

Sony

Sony RXD-700 Bedienungsanleitung

Sony

Sony CDX-GT420iP - Radio / CD Bedienungsanleitung

Sony

Sony XR-3320 Bedienungsanleitung

Sony

Sony CDX-GT730UI - Fm/am Compact Disc Player Produkthandbuch

Sony

Sony XR-C9100 Bedienungsanleitung

Sony

Sony XR-C5120R Bedienungsanleitung

Sony

Sony CDX-4480ESP - Am/fm Compact Disc Changer Produkthandbuch

Sony

Sony CDX-L300 Installation/Connection Bedienungsanleitung

Sony

Sony CDX-1200 - Fm/am Compact Disc Player Bedienungsanleitung

Sony

Sony CDX-MP30 Bedienungsanleitung

Sony

Sony HCD-DJ2i - Usb And Ipod Section Bedienungsanleitung

Sony

Sony CDX-S2000 - Fm/am Compact Disc Player Bedienungsanleitung

Sony

Sony CDX-S1000 Bedienungsanleitung

Sony

Sony XR-5880R Bedienungsanleitung

Beliebte Autoempfänger Handbücher anderer Marken

Motorola

Motorola VWA63 Bedienungsanleitung

Nextar

Nextar D3201 Bedienungsanleitung

Alpine

Alpine CDE-163BT Bedienungsanleitung

Pioneer

Pioneer DEH-P645R Bedienungsanleitung

Axxera

Axxera XDMA7600 Betriebsanleitung

XM OnyX Bedienungsanleitung

Sound Storm

Sound Storm STM93R Bedienungsanleitung

Soundstream

Soundstream VIR-5000 Bedienungsanleitung

Avson

Avson MKT Platform Bedienungsanleitung

Pioneer

Pioneer DVH-P500UB Bedienungsanleitung

JVC

JVC KD-AHD69 Bedienungsanleitung

Blaupunkt

Blaupunkt SANTIAGO CR 87 Bedienungsanleitung

XFIRE AUDIO

XFIRE AUDIO BMW42S Bedienungsanleitung

VDO

VDO CD 2253 Bedienungsanleitung

Volvo

Volvo 13 84 580 Bedienungsanleitung

ZENEC

ZENEC ZE-160DVD Bedienungsanleitung

Medion

Medion Car Audio Bedienungsanleitung

Philips

Philips CEM5000 Bedienungsanleitung
