INSTRUCTIONS FOR MODELS
92-SE-4300-R4
NEED HELP?
TOOLS AND SUPPLIES IMPORTANT
REQUIRED
HELPFUL
SAFETY TIPS
MAINTENANCE
Be sure to wear proper eye protection.
WARRANTY
3 year limited warranty
Additional warranty information can be found at:
www.speakmancompany.com
For additional assistance or service please contact:
SPEAKMAN®Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
www.speakmancompany.com
Using a screwdriver, remove the lower
portion of the Wall Bracket from the
recess on the Tank. Remove the Tank from
the Wall Bracket completely.
Select a suitable location for the
SE-4300. The location should protect the
unit from freezing and potential scalding
conditions. After confirming the Spray
Head height, refer to the rough-in
diagram for Wall Bracket height
measurements to determine mounting
hole locations for the bracket. Making
sure the bracket is level, mark and drill
holes in the mounting structure.
Portable Eyewash
SE-4300
GRAVITYFLO®
Note: Mounting
hardware not
included. Ensure the
mounting surface
(wall, etc.) and
mounting hardware
can safely hold a
minimum vertical load
of 300 lbs.
Ocassional cleaning and disinfection is reccomended.
To clean the inside of the unit, add 1/2 cup (4 fluid
oz.) of Clorox (liquid bleach) to a full tank of potable
water. Allow the mixture to penetrate for 15 minutes.
Drain tank, and rinse thoroughly several times with
potable water. For further information about Clorox,
call toll-free at 1-800-292-2200. Follow refilling
instructions in this manual and place the tank back in
service. Should any repair part be required, use only
genuine SPEAKMAN parts for repair or replacement.
See available replacement parts on Page 3, to order
parts call 1-800-537-2107.
ANSI Z358.1 requires that all self-contained
eyewash shall be visually inspected weekly, unless
the product is placed in environments with extreme
conditions that may affect the form, fit, or function of
the unit (temperature, dirt, etc.). If this is the case,
then the inspection should be conducted more often
as the end user deems necessary. Speakman
Company furnishes a testing record tag (91-0635)
with each unit. On this tag, the date of inspection
and the inspectors’ initials should be noted. ANSI
Z358.1 specifies that the height of the spray heads is
to be between 33” - 45” from the floor. The SE-4300
unit weighs approximately 185 lbs filled. Ensure the
mounting surface (wall, etc.) and mounting hardware
can safely hold a minimum vertical load of 300 lbs.
Be sure to read instructions thoroughly before
beginning installation. Do not overtighten any
connections or damage may occur. The unit should
be full at all times, to achieve the minimum 15 minute
run time as stated by ANSI, in case of an emergency.
Refill the tank to a full level after each activation.
Before refilling tank dry and clean outside of spray
heads, and inside of pull strap to remove debris, and
to assure proper sealing.
Level DrillPencil
Flat Tip
Screwdriver
Adjustable
Wrench
Slip Joint
Wrench
Socket
Wrench
Measuring
Tape
Safety
Glasses
