Spectra®nTier700™Intelligent Secondary

Storage Appliance

READ THIS FIRST

Thank you for purchasing the Spectra®nTier700™Intelligent Secondary Storage appliance from

Spectra Logic.

System Information

Setting the IP Address

As part of the initial installation, make sure you connect Ethernet port 1 on the back of the

nTier700 to an Ethernet network that can be accessed from a remote host. After you power-on the

nTier700, the next step is to set the IP address for Ethernet port 1 on the nTier700 rear panel. The

IP address for Ethernet port 1 displays on the operator panel of each nTier700 blade and is used to

access the nTier700 BlueScale®web interface to perform the initial configuration steps.

Ethernet port 1

By default, Ethernet port 1 uses DHCP to obtain an IP address. To view the IP address assigned to

Ethernet port 1 or to set a static IP address, use the left arrow button (<) on the operator panel of

any blade to move to the IP Configuration tab (a globe icon) at the bottom of the screen.

If your site uses DHCP, the IP address displays on the screen.

If your site does not use DHCP, the IP address will be 0.0.0.0. Use the buttons on the

operator panel to assign a static IP address. Read “Setting the nTier700 IP Address” in the

Spectra nTier700 Intelligent Secondary Storage Appliance User Guide for instructions and

information.

PN 90990031, Revision B

Logging into the BlueScale Web Interface

Use the following steps to log into the BlueScale web interface for the first time.

1. Open a web browser on the computer connected to the nTier700 over the network.

2. Enter the IP address of the nTier700 IP address in the browser address bar using the form

https://nnn.nnn.nnn.nnn, where nnn.nnn.nnn.nnn is the IP address. You can also

enter the system name of the nTier700. The default system name for the nTier700 is

“nTier700.”

Note: The BlueScale web interface uses a secure internet connection. You must prefix the

nTier700 name or IP address with https://instead of just entering the IP address.

3. A warning about the web site’s security certificate displays. Select “Continue to this website”

to ignore the warning and continue to the BlueScale interface.

4. Enter the following default login information:

Domain: <leave blank>

User name: administrator (all lower case)

Password: spectra (all lower case)

As part of configuring the nTier700, Spectra Logic recommends changing the default

Windows administrator login and system name to strengthen nTier700 security. Use the

Windows operating system to manage user names, set passwords, and set the system name.

Data Drive Locations

The nTier700 includes one box of ten drives for each blade you purchased. Each boxed set of ten

drives is preconfigured as a single RAID 6 volume. You do not need to install the drives into the

blade in any particular order. The drive mapping for the RAID volumes in the nTier700 is dynamic.

The system determines the position of each drive during the first system boot and automatically

updates the drive locations to preserve that volume’s preconfigured RAID 6 volume.

For security, the nTier700 blades are locked, even when the power is turned off. The first time you

install the drives in a blade, you must unlock the blades without powering on the unit. See “Unlock

the Blades” in the Spectra nTier700 Intelligent Secondary Storage Appliance User Guide for

instructions.

CAUTION: Do not plug the power cords into the nTier700 or turn on the power until you finish

installing all of the drives for the first time. If you install the drives with the nTier700 powered on,

the RAID controller immediately begins rebuilding the RAID volume in the blade, which may

destroy the preconfigured RAID 6 volume.

CAUTION: Each box of drives is preconfigured as a RAID 6 for a single blade. Mixing the drives

from one box with the drives from another box may destroy the RAID volume.

CAUTION: Only install drives in one blade at a time. Extending multiple blades may cause the

nTier700 to tip forward.

Powering Down Blades in a Single-Blade Configuration

If your nTier700 has only one blade, do not use power down the blade using the power-down

option from the blades operator panel. Instead, shut down the nTier700 before removing the blade

or performing any other operations that require powering down the blade.
