StarTech.com USB32DPES2 Bedienungsanleitung

Manual Revision: 09/22/2017

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the most up-to-date information, please visit: www.startech.com/USB32DPES2

*actualproduct may vary from photos

USB 3.0 to DisplayPort Video Adapter

Please ensure that the latest

driversfrom the StarTech.com

website are installed before

plugging in the USB 3.0 Video

Adapter

USB32DPES2

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction......................................................................................................... 1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation............................................................................................................ 2

Driver Installation Windows .................................................................................................................. 2

Multiple USB Video Adapter Installation .......................................................................................... 3

Verifying Installation................................................................................................................................ 3

Supported Resolutions..................................................................................... 4

Technical Support .............................................................................................. 5

Warranty Information ....................................................................................... 5

Instruction Manual

Package contents

• 1 x USB video adapter

• 1 x quick-start guide

Requirements

• A DisplayPort monitor with cabling

• A computer system with:

• A USB port

• Microsoft Windows® 10, 8/8.1, 7 (32 and 64-bit)

For 1 ~ 2 video adapters

• CPU: Intel® Core™ i3 2.8 GHz or equivalent (Core i5 recommended for HD

video)

• RAM: 2 GB or more (4 GB recommended for HD video)

For 3 ~ 4 video adapters

• CPU: Intel Core i5 Quad Core 2.8 GHz or equivalent

• RAM: 4 GB or more

For 5 video adapters

• CPU: Intel Core i7 Quad Core 3.0 GHz or equivalent

• RAM: 8 GB or more

Note: USB 3.0 is recommended for maximum performance. However, this adapter

is backward compatible with USB 2.0.

Requirements are subject to change. For the latest requirements, please visit:

www.StarTech.com/USB32DPES2

Instruction Manual

Product diagram

USB 3.0 input

cable

DisplayPort

output port

Instruction Manual

Installation

Please ensure that the driver installation is complete prior to the physical

installation (plugging in) of the USB 3.0 Video Adapter

Note: You may need to restart your computer during the installation process. Be

sure to save any unsaved material before you install the software.

1. Download the latest software from the StarTech.com website:

www.StarTech.com/USB32DPES2

2. The software is compressed in a .zip folder. Extract the contents of the folder

to a location on your computer that’s easy to access, such as your Desktop or

Downloads folder.

Note: Ensure the USB video adapter is not connected to your computer.

3. Launch the Setup(.exe) le.

4. Follow the on-screen prompts to complete the installation, and if instructed to do

so, restart your computer.

5. Connect a DisplayPort cable (sold separately) to the adapter’s DisplayPort output

port and to the DisplayPort monitor’s input port.

6. Connect the built-in USB 3.0 input cable to a USB port on your computer.

Important installation notes:

• This USB video adapter uses a Trigger family chipset. If you’re connecting

this device to a computer along with additional USB video adapters or

docking stations, avoid using devices with dierent family chipsets, such as

DisplayLink® or Fresco Logic®.

• To connect multiple USB display adapters to the same computer, you don’t

need to install any additional drivers. Repeat steps 3 through 4 for each video

adapter.

• You may be prompted to restart your computer during the installation of each

USB video adapter.

Instruction Manual

Verifying installation

From the desktop, right-click on Computer or My Computer, then select Manage. In

the Computer Management window, select Device Manager from the left window

panel.

Double-click the Universal Serial Bus Controllers category and the USB adapter

should be visible.

An audio device will also be listed under the Sound, Video and Game Controllers

category in Device Manager.

Conguring the adapter

Video conguration

1. Right-click on the USB video adapter icon ( ) on your Windows System Tray (next

to clock).

2. Click on Screen Resolution.

3. Select the monitor you want to change the settings on.

4. Adjust the screen resolution and orientation as needed.

Audio conguration

This device becomes the default audio playback device when it’s initially connected

to your computer. To playback audio from another audio device instead, such as your

computer speakers, you must manually change the default audio device from the

Hardware and Sound settings in the Control Panel.

1. Browse to the Windows Control Panel.

2. Click on Hardware and Sound.

3. Click on Manage audio devices.

4. Select your desired audio device from the list and click the Set Default button.

Instruction Manual

Supported resolutions

Resolution Color Depth

3840×2160 @ 30Hz 16, 32-bit

2048 x 1152 @ 60Hz 16, 32-bit

1920 x 1200 @ 60Hz 16, 32-bit

1920 x 1080 @ 60Hz 16, 32-bit

1680 x 1050 @ 60Hz 16, 32-bit

1600 x 900 @ 60Hz 16, 32-bit

1440 x 900 @ 60Hz 16, 32-bit

1360 x 768 @ 60Hz 16, 32-bit

1280 x 800 @ 60Hz 16, 32-bit

1280 x 768 @ 60Hz 16, 32-bit

1280 x 720 @ 60Hz 16, 32-bit

Note: Lower refresh rates are supported at specied resolutions.

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
