FROST-FREE REFRIGERATOR-FREEZER

Models CM405

CM411L

CM421BL

Owner's Manual

BEFORE USE, PLEASE READ AND FOLLOW

ALL SAFETY RULES AND OPERATING INSTRUCTIONS

FELIX STORCH, INC.

770 Garrison Avenue

Bronx, NY 10474

www.summitappliance.com

FF1112 series

FF1152SS series

IMPORTANT SAFEGUARDS

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance.

Always read and obey all safety messages.

This is the Safety Alert Symbol. This symbol alerts you to potential

hazards that can kill or injure you and others. All safety messages will

follow the Safety Alert Symbol and either the words ”DANGER”or

“WARNING”.

DANGER means that failure to heed this

safety statement may result in severe

personal injury or death.

WARNING means that failure to heed

this safety statement may result in

extensive product damage, serious

personal injury, or death.

Safety messages will alert you to what the potential hazard is, tell you how to reduce the chance

of injury, and let you know what can happen if the instructions are not followed.

Before the refrigerator is used, it must be properly positioned and installed

as described in this manual, so read the manual carefully. To reduce the

risk of fire, electrical shock or injury when using the refrigerator, follow

basic precautions, including the following:

Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter,

and do not use an extension cord.

It is recommended that a separate circuit, serving only your refrigerator, be provided. Use

receptacles that cannot be turned off by a switch or pull chain.

Never clean refrigerator parts with flammable fluids. These fumes can create a fire hazard or

explosion. And do not store or use gasoline or other flammable vapors and liquids in the

vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.

Do not connect or disconnect the electric plug when your hands are wet.

Unplug the refrigerator or disconnect the power before cleaning or servicing. Failure to do so

can result in electrical shock or death.

Do not attempt to repair or replace any part of your refrigerator unless it is specifically

recommended in this material. All other servicing should be referred to a qualified technician.

Use two or more people to move and install the refrigerator. Failure to do so can result in back

or other injury.

To ensure proper ventilation for your refrigerator, the front of the unit must be completely

unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below

90°F (32°C). This unit must be installed in an area protected from the elements, such as wind,

rain, water spray or drips.

The refrigerator should not be located next to ovens, grills or other sources of high heat.

The refrigerator must be installed with all electrical connections in accordance with state and

local codes. A standard electrical supply (115V AC only, 60 Hz), properly grounded in

accordance with the National Electrical Code and local codes and ordinances, is required.

Do not kink or pinch the power supply cord of the refrigerator.

The fuse (or circuit breaker) size should be 15 amperes.

It is important for the refrigerator to be leveled in order to work properly. You may need to

make several adjustments to level it.

Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may

damage or discolor the interior.

Do not use this apparatus for other than its intended purpose.

Risk of child entrapment

Child entrapment and suffocation are not problems of the past. Junked or abandoned

refrigerators are still dangerous, even if they will “just sit in the garage a few days.”

Before you throw away your old refrigerator: Take off the doors. Leave the shelves

in place so that children may not easily climb inside.

Never allow children to operate, play with, or crawl inside the refrigerator.

- SAVE THESE INSTRUCTIONS -

Table of Contents

Important Safeguards ....................................................................................................1 - 2

Location of Parts .................................................................................................................3

Technical Information .........................................................................................................4

Installation Instructions .................................................................................................4 - 7

Before Using Your Appliance .....................................................................................4

Installing the Appliance .........................................................................................4 - 5

Electrical Connection / Extension Cord ......................................................................5

Reversing the Door Swing ....................................................................................6 - 7

Operating Your Refrigerator ..........................................................................................8 - 9

Setting the Temperature Controls ..............................................................................8

Frost-Free Defrost System ....................................................................................8 - 9

Making Ice Cubes / Hot-Line ......................................................................................9

Care and Maintenance ...............................................................................................10 - 11

Cleaning Your Refrigerator / Evaporation Tray / Power Failure / Vacation Time ......10

Moving your Unit / Energy-Saving Tips ....................................................................11

Troubleshooting ................................................................................................................12

Limited Warranty ...............................................................................................................13

Location of Parts

Freezer door

with 2 racks

Refrigerator

door with 4

racks

Crisper cover

Crisper

Leveling legs

Plastic-coated

shelves

Freezer

compartment

Temperature

control

Interior light

Magnetic

door gasket

Technical Information

Models: FF1112W (white)

FF1112BL (black)

FF1152SS (black cabinet

with stainless steel door)

Capacity: 10.3 cubic feet

Electrical Input: 115V AC / 60Hz

Rated Current: 1.6A

Energy Consumption: 309 kWh/yr

Energy Star approved: Yes

Refrigerant: R134a, 5.3 oz

Installation: Free-standing

Shipping Weight: 166 lbs

Unit Dimensions: 23.63"W x 26.0"D x 58.88"H

Installation Instructions

Before Using Your Appliance:

Remove the exterior and interior packing.

Check to be sure you have all of the following parts:

2 wire shelves

1 crisper drawer with clear cover

1 ice cube tray

Before connecting the unit to the power source, let it stand for approximately 2

hours. This will reduce the possibility of a malfunction in the cooling system

from handling during transportation.

Clean the interior surface with lukewarm water using a soft cloth.

Installing the Appliance:

This appliance is designed to be free-standing only, and should not be

recessed or built in.

Place your unit on a floor that is strong enough to support it when it is fully

loaded. To level your unit, adjust the leveling legs at the bottom.

Allow 5 inches of space between the back and sides of the unit, which will

allow the proper air circulation to cool the compressor and condenser.

Locate the unit away from direct sunlight and sources of heat (stove, heater,

radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources

Improper use of the grounded plug can result in the risk of electrical shock. If the power

cord is damaged, have it replaced by an authorized service center.

may increase electrical consumption. Extremely cold ambient temperatures

may also affect the unit's performance.

Avoid locating the unit in moist areas.

Plug the unit into an exclusive, properly installed and grounded wall outlet. Do

not under any circumstances cut or remove the third (ground) prong from the

power cord. Any questions concerning power and/or grounding should be

directed toward a certified electrician or authorized service center.

After plugging the appliance into a wall outlet, allow the unit to cool down for 2

to 3 hours before placing food inside.

Electrical Connection:

This unit should be properly grounded for your safety. The power cord of this unit

is equipped with a three-prong plug which mates with a standard three-prong wall

outlet to minimize the possibility of electrical shock.

Do not under any circumstances cut or remove the third ground prong from the

power cord supplied. For personal safety, this appliance must be properly

grounded.

This unit requires a standard 115-volt AC/60Hz electrical outlet with three-prong

ground. Have the wall outlet and circuit checked by a qualified electrician to

make sure the outlet is properly grounded. When a standard 2-prong wall outlet

is encountered, it is your responsibility and obligation to have it replaced with a

properly grounded 3-prong wall outlet.

To prevent accidental injury, the cord should be secured behind the unit and not

left exposed or dangling.

The unit should always be plugged into its own individual electrical outlet which

has a voltage rating that matches the rating label on the appliance. This provides

the best performance and also prevents overloading house wiring circuits that

could cause a fire hazard from overheated wires. Never unplug the unit by pulling

on the power cord. Always grip the plug firmly and pull straight out from the

receptacle. Repair or replace immediately any power cord that has become

frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion

damage along its length or at either end. When moving the unit, be careful not to

damage the power cord.

Extension Cord:

Do not use an extension cord with this appliance. If the power cord is too short,

have a qualified electrician or service technician install an outlet near the

appliance.

Reversing the Door Swing:

The doors of the refrigerator-freezer can be hinged on either side so that the door

swing can be suited to the location of the installation.

Tools Required:

standard screwdriver

large Phillips head screwdriver

socket wrench (3/8")

In order to reverse the position of the door hinges, refer to the disassembly

diagram below and follow this procedure.

1. Remove the hinge cap by twisting it off.

2. Remove the upper hexagonal-head screws. The top hinge and the freezer

door can now be removed.

3. Remove the middle hexagonal screws. The middle hinge and the refrigerator

door can now be removed.

4. Remove the cover and screws for the middle hinge holes on the left side and

re-attach them symmetrically to the holes on the other side.

5. Tilt the refrigerator back or lay it on its back for steps 6, 7 and 8. Use a pad

or blanket to protect the floor and to avoid scratching the painted finish.

6. Remove the leveling legs by turning them counterclockwise. Remove the

lower hexagonal-head screws, two on the hinge side and one near the front

corner of the other side.

7. Attach the bottom hinge symmetrically to the other side of the cabinet with the

screws removed in Step 6. (Do not tighten screws completely.)

8. Attach the left side leg and the leg spacer to the other side hole which was

positioned symmetrically.

9. Stand the unit back in the upright position.

10. Remove the upper hinge plastic pins and insert them in the holes from which

the screws were removed in Step 2.

11. Take off the hinge collar caps from both the freezer and refrigerator doors

using a screwdriver and insert them in the hinge collars on the opposite side.

12. Attach the shaft to the hinge bottom. Attach the refrigerator door to the shaft.

13. Rotate the middle hinge 180°. Attach it to the refrigerator door and secure it

with screws. (Do not tighten screws completely.)

14. Attach the upper hinge to the freezer door. Attach the freezer door to the

middle hinge and use the screws to attach the upper hinge. (Do not tighten

screws completely.)

15. The direction in which the doors open has now been changed; however, the

following points should be checked:

a. Make sure the doors are on straight.

b. Make sure there is no space between the door gaskets and the refrigerator

and freezer units themselves when the doors are closed.

c. Make sure that the gasket on the hinge side is not caught between the door

and the unit when the door is opened or closed. (If the door is forced

closed when the gasket is caught, the gasket might be damaged.)

d. When checking the above points, if it is discovered that the doors are not

installed properly (this is apt to happen on the first try), loosen the screws

holding the upper hinge, straighten the door and tighten the screws slowly

with the socket wrench. After making sure that the doors are installed

correctly, tighten all the screws holding the hinge.

If they are not tightened, the doors may slip out of position or there may be

an opening between the doors and the unit.

Operating Your Refrigerator

Setting the Temperature Controls:

Your unit has one control for regulating the temperature in the refrigerator

compartment and a separate one for the freezer.

Refrigerator:

The refrigerator compartment's temperature control (thermostat) is a dial type

located at the top center of the compartment.

When you turn the unit on for the first time, set the control to its coldest setting,

which is

MAX

After several hours, adjust the temperature control to the setting that best suits

your needs. The setting MED should be appropriate for most uses.

Freezer:

The temperature control for the freezer is a slide switch located on the back wall

of the compartment. It has settings of WARM, MED and COLD. When first

turning on the unit, set this switch to COLD, then after a few hours, slide it back

to MED.

NOTES:

1. To completely turn off the unit, disconnect the power.

2. If the unit is unplugged, has lost power, or is turned off, you must wait 3 to 5

minutes before restarting it. If you attempt to restart before this time delay,

the unit will not start.

Frost-Free Defrost System:

It is not necessary for you to defrost either the refrigerator or the freezer

compartment of this appliance. While the compressor is operating, ice may build

up along the cold rear wall of the refrigerator compartment (the evaporator is

KNOB

BOTTOM VIEW

TURN KNOB

WARM ——————— MED ———————— COLD

FREEZER TEMP. CONTROL

behind the wall). During the compressor's off-cycle, the ice will melt, drip down,

and drain through a small hole behind the crisper into a tray above the

compressor where the compressor's heat evaporates the water.

If you notice an excessive build-up of ice on the rear wall of either the refrigerator

or the freezer compartment, try setting the thermostat to a slightly warmer

setting. Be sure the door gasket is well seated. Occasionally you should check

that there is no obstruction of the drain hole in the bottom rear of the refrigerator

cabinet.

Making Ice Cubes:

In the freezer compartment, high-quality ice cubes are formed in about 3 hours.

Once the cubes have been formed, they can be removed from the ice tray by

twisting it gently.

NOTES:

1. Since water expands when it freezes, do not fill the ice tray above the level

of the separation dividers.

2. When using a receptacle other than the supplied ice cube tray to make a

large quantity of ice, you may find that the temperature in the freezer will

rise. This can cause ice cream and other such items to soften temporarily.

3. When ice cubes are stored for an extended period of time, they may

become smaller and stick together.

4. Ice will sometimes develop an off flavor or color if kept too long. To avoid

this, empty the ice tray and make a completely new batch about once a

month.

Hot-Line:

With the refrigerator-freezer in operation, it is possible

that the housing will feel warm at the front edges.

This does not indicate trouble. It is attributable to the

hot-line design adopted for this refrigerator-freezer

which consists of piping hot gas from the motor-driven

compressor along the front edges of the housing and

the center partition to prevent moisture from

accumulating. This has nothing to do with the storage

temperature inside.

In the illustration, the dark line indicates the hot-line.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Summit Kühlschrank Handbücher

Summit

Summit FF28L Bedienungsanleitung

Summit

Summit FF71LLF2 Bedienungsanleitung

Summit

Summit FF-874 Series Bedienungsanleitung

Summit

Summit FF41 Leitfaden

Summit

Summit CP97 Bedienungsanleitung

Summit

Summit FF1418DT Bedienungsanleitung

Summit

Summit CT661BI Bedienungsanleitung

Summit

Summit FF1843B Bedienungsanleitung

Summit

Summit SCR1275 Bedienungsanleitung

Summit

Summit SCR600LOS SERIES Bedienungsanleitung

Summit

Summit SPR7OSST Series Bedienungsanleitung

Summit

Summit FF82W Bedienungsanleitung

Summit

Summit FF22B Bedienungsanleitung

Summit

Summit accucold FFAR21LMAN Bedienungsanleitung

Summit

Summit CT661 W Series Bedienungsanleitung

Summit

Summit SPR6-OS Bedienungsanleitung

Summit

Summit FF7BBISSHH Leitfaden

Summit

Summit FFBF171SS Bedienungsanleitung

Summit

Summit CL65ROS Bedienungsanleitung

Summit

Summit FFRF24SS Bedienungsanleitung

Summit

Summit FFAR12W7 Bedienungsanleitung

Summit

Summit FF-6 Series Bedienungsanleitung

Summit

Summit CP97R-1 Bedienungsanleitung

Summit

Summit FF511LBI Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
