Sunbeam Heated bedding Bedienungsanleitung

heated bedding

USER MANUAL

TRUSTED FOR OVER

100 YEARS

Includes

QUICK

SET-UP

GUIDE

pages 4-5

P.N. 191502 Rev. A

Sunbeam HeatedBedding IB_17ESM1.indd 1 2/3/17 09:09

Control

Flag Tag

Label

Power Cord

Module

Left Side

Right Side

Control Cord

Connector

Left (Secondary)

Control

Flag Tag

Label

Power Cord

Module

Left Side

Right Side Right

(Primary) Control

(Label on back

of control)

Control Cord

Connector

For questions or support, please visit www.sunbeambedding.com.

1 Place the heated blanket/mattress pad on the bed with the label at the foot of the bed facing upward.

2 Connect the cord into the module at the bottom of the heated blanket/ mattress pad until the plastic

hinges click into place.

CAUTION: Cord must be COMPLETELY CONNECTED. A risk of fire could result from a loose connection.

3 Run the control cord on the floor under the bed. Do not sandwich cord between the mattress and box

spring. Avoid any tangling or pinching.

4 Plug power cord into a 110-120 volt wall outlet.

CAUTION: Do not use with generator power or inverter.

Control Placement:

• Dual Control for heated blanket or mattress pad – place primary control (label on back of

control) on the right side of the bed.

Heated Blanket, Mattress Pad and

Comforter Setup

See Control Features on page 8

for your individual control.

If there is a flashing light or your control displays

a flashing “F”, “F1”or “F2”see page 13.

• Single Control for heated blanket or mattress pad –

the control can be placed on either side of the bed.

STEP 1Place on bed with

label at foot of bed

facing out

STEP 2Connect the Control

Cord connector and

module securely

STEP 3Run Control Cord

under the bed

STEP 4Plug Power Cord

into wall

STEP 1Place on bed with

label at foot of bed

facing out

STEP 2Connect the Control

Cord connector and

module securely

STEP 3Run Control Cord

under the bed

STEP 4Plug Power Cord

into wall

Sunbeam HeatedBedding IB_17ESM1.indd 7 2/3/17 09:09

E8 For questions or support, please visit www.sunbeambedding.com.

Control Chart

* S85KQA only

If your controller does not appear on the chart, please visit our website for more information.

Control Features

(for all controllers, see page 9 for detailed features.)

Auto-Off Feature:

The “Auto-Off” feature is designed for conservation of energy by automatically turning your blanket or

mattress pad off after 10 hours of continuous use (3 hours for throws).

For Dual Controls:

Each control operates independently and will turn off 10 hours after the control is turned “On”.

Auto-Off Select* Feature (selected models only):

Some models with the “Auto-Off” feature (see control chart) offer an “Auto-Off Select” button that can

disable the “Auto-Off” feature so the heated product will not automatically turn off.

Controls with the “Auto-Off Select” feature have the “Auto-Off” active as the default so the heated product

will automatically turn off after 10 hours.

To disable the “Auto-Off”, press the “Auto-Off Select” button. The word “StayOn” will appear in the digital

display to indicate the “Auto-Off” feature is deactivated and the heated product will NOT automatically turn

off after 10 hours. The heated product will remain on until the product is manually turned off by pressing the

“On/Off” button.

To activate auto-off, press the “Auto-Off Select” button. The word “AutoOff” will appear in the digital display to

indicate the “Auto-Off” feature is activated and the heated product will automatically turn off after 10 hours.

Note: After a power outage, the “Auto-Off” feature automatically resets the timer.

To restart all heated products after a power failure:

Press the power button and the heated product will begin to warm.

OneSet™Easy Set™ Pro SleekSet™SelectTouch™ Prime Style™ II

AA85

Throw

Elite Style™II

T85B

Throw

Style #

(Single Control) Y85 S85A Z85 P85A

Style #

(Dual Control) Y85KQ S85KQA Z85KQ P85KQA

Backlit

Display b b

Ambient

Temperature

Compensation b

Auto-Off 10 hour 10 hour*

(S85A,

S85KQA)* 10 hour Select 3 hour 3 hour

Warming Settings 5 10 10 20 3 3

Preheat b b

Easy Grip b b b

Sunbeam HeatedBedding IB_17ESM1.indd 8 2/3/17 09:09

For questions or support, please visit www.sunbeambedding.com.

Preheat Feature (selected models only):

The preheat function will heat the bed for a period of 30 minutes and the control will return to its original

setting.

1 To use the preheat feature, simply turn on the warming product by pressing the “On/Off” button and

then press the “Preheat” button. The display will show “PH” while the function is activated.

2 To reset the preheat feature, simply turn off the control by pressing the “On/Off” button and then turn it

back on by pressing the “On/Off” button.

Using Your Control:

1 To turn the control on, press the “On/Off” button.

Note: For SelectTouch™and SleekSet™ controls, the backlit display light will reset itself by flashing “88”

and then will return to the previous setting and will begin to warm.

2 Note: For OneSet™ control, press the button to turn on to the lowest heat setting. Repeat pressing the

button to scroll to desired heat setting (5 total). To turn off, scroll through heat settings until all LED

indicator lights turn off.

3 Adjust the warming setting to your personal comfort by rotating the top knob left or right for

Easy Set™controls.

4 Note: For SelectTouch™controls, press the large left button with the “-” sign to lower the heat setting

and the large right button with the “+” sign to increase your heat setting.

5 Note: For SleekSet™ controls press the upper button with the up arrow to increase your heat setting and

the lower button with the down arrow to lower the heat setting

6 To turn the heated blanket/mattress pad OFF, press the “On/Off” button.

CAUTION: ALWAYS turn the heated blanket/mattress pad “OFF” when not in use.

Sunbeam HeatedBedding IB_17ESM1.indd 9 2/3/17 09:09

E10 For questions or support, please visit www.sunbeambedding.com.

Module

Control

Power

Cord

Flag Tag

Throw Cord

Connector

Throw Cord

Label

Module

Control

Power

Cord

Flag Tag

Throw Cord

Connector

Throw Cord

Label

Heated Throw Setup

When setting up your heated throw, be sure to follow the steps below in order.

1 Locate the heated throw’s information label near the module.

2 Connect the cord into the module at the bottom of the heated throw until

the plastic hinges click into place. CAUTION: Cord must be COMPLETELY CONNECTED. A risk of fire

could result from a loose connection.

3 Plug the [heated throw] power cord into a 110-120 volt wall outlet.

CAUTION: Do not plug main power cord into the wall outlet until you have completely set up your heated

product per the instructions.

• Disconnect power cord from wall before detaching control from heated product.

• Always make sure cords and controls are NOT trapped or pinched between bed slats, mattress,

springs, against wall, foot board or bed frame, or between furniture, walls or chairs.

• Do not wrap control in throw when in use.

• Do not use with generator power.

Using Your Heated throw Control:

1 To turn on the throw press the button in the middle of the control.

The indicator light will glow, depending on which setting the heated

throw is set, and the heated throw will begin to warm.

CAUTION: ALWAYS turn the heated throw “OFF” and disconnect the

power cord from the outlet when not in use.

2 To turn the heated throw OFF press the button through the different

settings until the temperature setting lights are not glowing.

If there is a flashing light

on your control, see page 13.

Sunbeam HeatedBedding IB_17ESM1.indd 10 2/3/17 09:09

E11

For questions or support, please visit www.sunbeambedding.com.

Care and Cleaning OF YOUR HEATED BEDDING PRODUCT

CAUTION: Do not dry clean. Do not use bleach. Do not use wringer. Do

not iron. Do not immerse control or cord in water or other liquids. Do

not use mothballs or sprays of any kind. Do not reconnect the heated

product until it is completely dry.

We recommend washing before initial use.

Before Washing or Storing Your Heated Bedding Product

1 Disconnect power cord from wall BEFORE detaching control cord from the heated product.

2 Ensure that no cords are still connected and none of the wires have worn through the fabric.

3 Carefully follow all washing instructions or your heated product may shrink and possibly cause a fire

hazard.

Washing Instructions

1 Machine wash in cold water, gentle cycle or hand wash.

Caution: Do not use commercial dryers or the dryers at your local laundromat. They get too hot and

would damage the wiring of the heated product.

2 Tumble dry low, delicate cycle.

3 Remove the blanket/mattress pad/throw while still damp and gently stretch to its original size.

4 Drape the heated product over a clothesline or a shower rod. DO NOT use clothespins

5 Heated product must be COMPLETELY dry before reconnecting the power plug or control plug.

Hang to Dry

1 While still damp, gently stretch the blanket/mattress pad/throw back to its original size.

2 Drape the heated product over a clothesline or hang over a shower rod. DO NOT use clothespins.

3 Heated product must be COMPLETELY dry before reconnecting the power plug or control plug.

Sunbeam HeatedBedding IB_17ESM1.indd 11 2/3/17 09:09

E12 For questions or support, please visit www.sunbeambedding.com.

Frequently Asked Questions

ABOUT YOUR HEATED BEDDING PRODUCT

QWho should NOT use the heated blanket, heated mattress pad or heated throw?

AThe following people should NOT use the heated blanket, heated mattress pad

or warming throw:

• An infant

• A child

• An incapacitated or immobile person

• A paraplegic

• A quadriplegic

• A diabetic

• Anyone insensitive to heat such as a person with poor blood circulation

• Anyone who cannot clearly understand the instructions and/or operate the controls

QWhat do I do if my pet chews the cord, I lose my control or the control does not operate

properly?

APlease stop using the heated product immediately. Call our Consumer Service number

listed under How to Obtain Warranty Service and ask for instructions on how and where to send

the heated product.

QMy control feels warm to the touch. Is this a problem?

ANo. The control will feel warm to the touch when functioning properly.

QMy heated blanket/heated mattress pad/heated throw doesn’t heat properly.

AYour heated product is not a heating pad. It will not feel hot to the touch when laid out flat

in a normal manner. Try the following fold test to see if it is operating

properly:

1 Fold the heated blanket, heated mattress pad or warming throw 3

times over.

2 Make sure the control cord is connected to the module and then plug

the power cord into an outlet.

3 Turn on your heated product, then turn the control to the highest

setting and wait 5 to 7 minutes.

4 Put your hand between the folds and you should feel the blanket/ mattress pad/throw

warming up.

Caution: DO NOT continue the test for more than 7 minutes. DO NOT attempt to make any internal

adjustments to this appliance. If you have tried all of the solutions above and the heated product

still doesn’t work, stop using it immediately, disconnect the power cord and contact Consumer

Care.

Sunbeam HeatedBedding IB_17ESM1.indd 12 2/3/17 09:09

E13

For questions or support, please visit www.sunbeambedding.com.

QWhat does “F1” or “F2” mean on my Electronic Digital Control?

AThe digital controls are designed to notify you in the event that a problem has been discovered

by flashing “F1” or “F2” on the display.

F1 Models: SelectTouch™and SleekSet™

Follow reset instructions below.

F2 Models: SelectTouch™and SleekSet™

Follow reset instructions below.

Reset Instructions

1.) Follow the instructions on the flag tag attached to the control cord to reset control.

2.) Check the blanket/mattress pad for visual damage.

3.) If no visual damage is found, unplug the system from wall outlet.

4.) Check that the control is well-connected to the module.

5.) Plug the power cord into the wall outlet.

6.) Set the control to “On”.

7.) If the system does not operate after 2 or 3 times trying to reset, disconnect the power cord

and contact Consumer Care.

QWhat does a flashing light mean on my OneSet™, Easy Set™, Prime Style™ AO

or Elite Style™ control?

AThese controls are designed to notify you in the event that a problem has been discovered

by flashing the light on the control. Follow instructions on the flag tag to reset control. First,

check the heated product for visual damage. If no visual damage is found, unplug the system

from wall outlet. Check that the control is well-connected to the module. Plug the power cord

into the wall outlet and turn the control On. If the product still does not operate after 2 or 3

times trying to reset, disconnect the power cord and contact Consumer Care.

MODULE

Ensure the Control Cord connector and module are securely

fastened by inserting until hooks are in locked position.

Sunbeam HeatedBedding IB_17ESM1.indd 13 2/3/17 09:09

Andere Handbücher für heated bedding

Inhaltsverzeichnis

Andere Sunbeam Zubehör Handbücher

Sunbeam

Sunbeam SHWL825 Series Bedienungsanleitung

Sunbeam

Sunbeam SLEEP EXPRESS BLB48 Bedienungsanleitung

Sunbeam

Sunbeam Safe & Sound Bedienungsanleitung

Sunbeam

Sunbeam TR6300 Bedienungsanleitung

Sunbeam

Sunbeam Carveasy Master Series Bedienungsanleitung

Sunbeam

Sunbeam Carveasy Pro EK5600 Bedienungsanleitung

Sunbeam

Sunbeam Sleep Perfect BL51 Bedienungsanleitung

Sunbeam

Sunbeam Sleep Express BLE4821 Bedienungsanleitung

Sunbeam

Sunbeam BL49 Bedienungsanleitung

Sunbeam

Sunbeam Sleep warm. Sleep well. Bedienungsanleitung

Sunbeam

Sunbeam BL48 Bedienungsanleitung

Sunbeam

Sunbeam ART0000922835 Bedienungsanleitung

Sunbeam

Sunbeam Service Center Bedienungsanleitung

Sunbeam

Sunbeam Sleep warm. Sleep well. Bedienungsanleitung

Sunbeam

Sunbeam Carveasy EK3800 Bedienungsanleitung

Sunbeam

Sunbeam Sleep Perfect Bedienungsanleitung

Sunbeam

Sunbeam 06081 Bedienungsanleitung

Sunbeam

Sunbeam warming Bedienungsanleitung

Sunbeam

Sunbeam Imperial Court Bedienungsanleitung

Sunbeam

Sunbeam DREAMLAND BLD5021 Bedienungsanleitung

Sunbeam

Sunbeam Sleep warm. Sleep well. Bedienungsanleitung

Sunbeam

Sunbeam SLEEP PERFECT BLF51 Bedienungsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

Panasonic

Panasonic HG-T Series Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung

Sunbeam heated bedding Bedienungsanleitung

Beliebte Zubehör Handbücher anderer Marken
