Swann DVR Guardian SW244-UDC Bedienungsanleitung

www.swannsecurity.com

Enquiries: [email protected]

Product Code: SW244-UDC

Monitoring Kits & Recording

MONITORING

Warranty

month

DVR Guardian™ Security Kit

USB Digital Video Recorder & 2 Cameras

View & record 2 cameras on your PC from almost anywhere in the world

Digital Video Recorder

• Easiest DVR installation available just ‘plug and play’ into USB port

• View cameras from your mobile cell phone

• Record up to 4 cameras on your hard drive (2 Cameras included)

• Schedule recording or set for motion detection

• Won’t overwrite your existing software or image files

• Easily backup video to CD-R, CD-RW and DVD if fitted

OutdoorCam™ Cameras

• 380 TV Lines for clear image resolution

• 16-26ft (5-8m) infra red night vision

• 60ft (18m) RCA video cables x 2

• Weather resistant sun shield

• Perfect for home & office use

USB

Laptop PC Not Included

Plug & Play

PC Over the Web Cell /Mobile†

Viewing Options

Vista™

Compatible

cable

60ft (18m)

BONUS

4 Security Warning Stickers

Sees in the Dark

16 - 25ft (5 - 8m)

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

MONITORING

DVR Guardian™ Security Kit

USB Digital Video Recorder & 2 Cameras

View & record up to 4 cameras to your PC from almost anywhere in the world

You Have Mail!

Email Notification

USB

Laptop PC Not Included

Plug & Play

Package Contents

Digital Video Recorder

• USB-DVR Guardian

• Software CD

• Quickstart Manual

• Software Manual on CD

Cameras

• OutdoorCam Color Camera x 2

• 60ft/18m video cable with

RCA connectors x 2

• Power Adapter x 2

• Instruction Manual

• Camera stands with screws

System Installation Requirements

Windows Version Supported: Windows® 2000, XP™, Vista™

CPU: Intel Pentium III 800Mhz (or higher)

Memory (RAM): 256MB minimum

VGA card: 64MB or above

HDD: 20GB / or above (7200 RPM Recommended)

Remote Viewing Requirements

Windows 2000 or later PC with IE 6 or later

Windows® Mobile 2003 SE

Windows® Mobile 5.0

Technical Specifications

Digital Video Recorder

Camera Inputs: 4x Composite Video RCA

Audio Inputs: 2x PC Audio RCA

Audio Format: 8bit, one channel

Max Display Rate: 25 fps (PAL), 30fps (NTSC)

Max Recording Rate: 25 fps (PAL), 30fps (NTSC)

Compression Format: MPEG4

Video Resolution: 704x576 (D1), 352x288 (PAL),

640x480 (D1), 320x240 (NTSC)

Record Mode: Motion/Sensor/Schedule/Manual

PTZ: Protocol Configurable, Remote Control Capability

Camera

Camera Sensor: 1/3” / 8.5mm CMOS

TV System: PAL (AU, UK) or NTSC (USA)

- Country Dependant

Definition: 380 TV Lines

Minimum Illumination: 3 Lux (Color) / 0 Lux (B&W)

Power Supply: 8V ~ 12V DC

Infra-red Range: 16-26ft (5-8m)

View Angle: 40°

Construction: Aluminium

Operation Temperature: -40°F - 140°F / -20°C - 60°C

† Depends on your phone’s capabilities
