Swann RedAlert SW244-WDW Bedienungsanleitung

Product Code: SW244-WDW

www.swannsecurity.com Monitoring Kits & Recording

• Your personal security recording kit is ideal for home or small business

• Motion triggers still JPEG photos or 10 second AVI video clips at

3 second intervals

• Record up to 250 video clips or 2,000 photos on 128MB SD card or

use built-in 16MB memory

• Includes day/night camera with convenient wireless connection to

RedAlert™

• Built in PIP (Picture-in-Picture) to view 2 cameras simultaneously

• Compact size for discreet storage & operation

MONITORING

Warranty

month

RedAlert™ Security Kit

Movement Video Recorder

& Wireless Camera

Records movement while you are away or distracted

Sees in the Dark

Up to 16ft (5m)

SD Memory Card

Store over

(10 seconds each)

2000 images or 250 AVI Clips

128MB

Video

www.swannsecurity.com

™

MONITORING

Safeguard

Loved Ones

Deter

Shoplifters

Monitor

the Kids

Screen

Visitors

RoHS Compliant

2002/95/EC

RoHS

Front View Rear View

SD Card Slot

Channel Set

Channel Indicator Video In On/Off

AV Out DC Power

RedAlert™Security Kit

Movement Video Recorder

& Wireless Camera

Records movement while you are away or distracted

Wired

Video

Wireless Transmission

Please note that the information contained within this document is subject to change without notification.

DVR Speciﬁcations

Video

Video Format NTSC or PAL

Video Inputs 1 Composite Input

Video Outputs 1 Composite Output

Display Resolution 640 x 480

Display Frame Rate NTSC: 30fps / PAL: 25fps

Recording

Compression Format Video: MPEG / Photo: JPEG

Recording Resolution Video: 320 x 240 / Photo: 640 x 480

Recording Frame Rate NTSC: 15fps / PAL: 15fps

Recording Modes Manual / Motion

Multiplex Operation Simplex

HDD Interface / MemType SD Card

Hard Drive Support Up to 2GB SD

General

Operating Power 5V DC

Dimensions 5.25” x 3.33” x 0.75”

133mm x 85mm x 20mm

Weight 5.25oz / 148g

Back-up Method SD Card

Camera Speciﬁcations

Video

Image Sensor 1/3” CMOS

Image Resolution 330 TV Lines

Electronic Shutter 1/60 - 1/15,000 NTSC

1/50 - 1/15,000 PAL

Signal / Noise Ratio > 48dB

White Balance Automatic

Gain Control Automatic

Backlight CompensationYes

Day/Night Mode Color during day

/ switches to B&W at night

Minimum Illumination 0 Lux (IR on)

Lens 6mm

Viewing Angle 48 degrees

Audio

Microphone Yes

Night Vision

Night Vision Distance Up to 16ft / 5m*

Number of Infra-Red LEDs 10

Infra-Red Wavelength 850nm

Infra-Red LED Life 10,000 hours

General

Operating Power DC 12V

Operating Temperature 0°C ~ 50°C / 32°F ~ 122°F

Body Construction Aluminum

Dimensions - Camera & Stand 5.1” x 2.0” x 2.0”

130mm x 50mm x 50mm

Weight – Camera & Stand 4.8oz / 136g

Dimensions - Receiver 1.0” x 3.1” x 4.3”

25mm x 80mm x 110mm

Weight - Receiver 6.5oz / 185g

Wireless

Digital or Analog Analog

Max. Transmission Range Up to 165ft / 50m*

Typical Range 65ft / 20m

Frequency 2.4 GHz

Transmission Channels 4

Package Contents

• RedAlert™

• Antenna

• Wireless Camera

• Female RCA Video Cable

for Camera 3ft(1m)

• RCA Video Cable 3ft(1m)

• RCA to BNC Adapter

• SD Card (128MB)

• Manual & Easy Setup Guide

• Power Adapters x 2

• Bonus Security Stickers x 4

* Depends on local conditions.
