User’s Guide

USB - PS/2 Scroller

Mini Mouse

Notebook Computer

Mobile Scroller Mini Mouse

INTRODUCTION

Congratulations on your purchase of the Targus USB - PS/2 Scroller Mini

Mouse! It is a state-of-the-art scrolling device, specially designed for the

mobile warrior. The scroller mini mouse is perfect for screen browsing

while on the Internet and when using Windows®applications including

Microsoft®Office 97. Its innovative and ergonomic shape is more

comfortable and gives you better control than a notebook pointing device.

It is compatible with all notebook computers that have either a USB port or

a PS/2 port.

This user’s guide provides descriptions of the scroller mini mouse features,

and gives instructions for connecting the mouse, installing the software,

assigning functions to the mouse buttons, and cleaning the mouse.

Contents

❖One Targus USB - PS/2 Scroller Mini Mouse

❖One PS/2 Adapter

❖This user’s guide

❖One driver diskette (Windows 95, Windows 98 and

Windows NT®4.0 only)

System Requirements: USB

❖Operating system: Windows 98, Windows 2000, or

Macintosh® OS Version 8.6 or greater

❖One USB v. 1.1 Compliant Port

System Requirements: PS/2

❖Operating system: Windows 95, Windows 98,

Windows NT 4.0, or Windows 2000

❖One PS/2 port

CONNECTING THE SCROLLER MINI MOUSE

The scroller mini mouse has the option of connecting through a USB port,

or through a PS/2 port via the PS/2 Adapter. Depending on your

computer’s operating system, it may recognize the mouse and allow Plug

and Play installation. If the operating system does not recognize the mouse,

you need to set it up.

USB Connection with Windows 98 or Windows 2000

Plug the USB connector into the computer’s USB port. The computer

detects the scroller mini mouse immediately. Follow the screen prompts

until installation is complete. Now you are ready to install the software.

Note: USB connection is not supported by Windows 3.1x, Windows 95,

or Windows NT 4.0.

Figure 1. USB-PS/2 Scroller Mini Mouse and PS/2 Adapter

USB Connection with a Macintosh Computer

The Targus USB - PS/2 Scroller Mini Mouse’s use is restricted with a

Macintosh computer. Macintosh supports only a one-button mouse.

PS/2 Connection with Windows 95, 98, NT 4.0, or 2000

Shut down Windows and turn off the computer. Disconnect the existing

mouse, if any. Connect the PS/2 Adapter to the USB connector of the

mouse. Plug the PS/2 Adapter into the computer’s PS/2 port. Turn on the

power. When Windows restarts, its software drivers will enable only the

standard scrolling features.

Warning: Never point the optical sensor toward the face, particularly

the eyes.

Do not use the optical mouse on a surface which is made of glass,

mirror, iron, or black velvet. The optical sensor performs best on

surfaces with detail to track. It may have difficulty tracking on

repetitive patterns, e.g. printed photographs from magazines.

INSTALLING THE SOFTWARE

Note: The USB - PS/2 Scroller Mini Mouse is automatically

detected and enabled with Windows NT and Windows 2000;

therefore software installation is not required.

1Insert the scroller mini mouse software diskette into

drive A or B.

2Open the Start menu (Ctrl plus Esc), and select Run.

3Type A:Setup.exe (or B:Setup.exe) in the command line.

4Click OK.

5Follow the screen prompts until installation is complete.

6Restart the computer.

7Open the Start menu and select Settings.

8Select Control Panel and double-click the mouse icon.

The Mouse Properties window appears. Across the top of

this menu are the categories of features provided. You can

set and reset these features to suit your needs.

USING THE MOUSE

Note: The enhanced features described in the following sections are

not available with Windows NT or Windows 2000. For future

enhancements, visit our Web site at www.targus.com.

You can assign frequently used mouse and keyboard functions to the

mouse buttons with the Button Assignment feature. Microsoft Office 97 is

supported with a new one-step zoom feature.

Factory Settings

Some functions performed by the mouse buttons, scroller wheel, and

scroller button are preassigned at the factory.

Screen scroller Moves the cursor when you roll the wheel

Scroller button No factory setting

Left button Primary button which provides click,

double-click, and drag

Right button Secondary button with no factory setting

Horizontal scrolling Moves the cursor along the horizontal

scroll bar when you press the Shift key

while turning the wheel in the direction

you want it to move

Mouse Properties

The Mouse Properties window has several tabs from which you can choose

options. These options enable you to control cursor movement and make

button assignments that can eliminate as much as 30% of your mouse

movement.

The settings for these features are divided among seven different tabs

pictured across the top of the Mouse Properties window. They are

described in detail on the following pages.

Magic tab: Browsing speed:adjust the speed at which you surf the

Internet or browse Windows documents.

Browsing direction: move the roller forward to browse

toward the top of the document, or back to browse toward the

end of the document.

Pointers tab:Click this tab to choose the appearance of the mouse pointer.

Cursor tab: Button find: automatically position the cursor on the default

(usually OK) button whenever a dialog box appears on your

screen.

Trails: makes it easier to find the cursor when you are using

an LCD screen. This option can be used only if your screen

supports this.

Loop: when you move the cursor to the bottom (or top) of the

screen, it automatically wraps to the top (or bottom) of the

screen.

Action tab: Mouse speed: adjust the speed at which the cursor moves

across the screen.

Double-click speed: adjust the double-click speed of the

mouse button.

Button Swap: assign the right button to be the primary mouse

button for left-handed use, or revert to the factory setting.

Figure 2. Mouse Properties Window

Settings tab:Button Assignments: You can assign the buttons on the

mouse to perform frequent operations or special functions

such as Auto-panning, EasyJump, and Zoom. To assign a

function to a mouse button, click Button Assignments. An

extensive list of functions appears in a drop-down menu.

There is a drop-down menu for each button: 1, 2, and 3.

EasyJump Options: Click this button to assign a mouse

button to EasyJump. EasyJump provides access to the eight

functions pictured in Figure 3. Click the mouse button

assigned to EasyJump to quickly perform any of the

EasyJump functions:

Close AP Close the application you are using.

Horizontal Move the cursor to the horizontal scroll bar.

Vertical Move the cursor to the vertical scroll bar.

Figure 3. EasyJump Options

Start Menu Activate the Windows Start menu.

Internet Access Open the Browser to access the Internet.

Help Menu Open the Windows Help menu.

Control Panel Open the Mouse Properties window.

Auto-Panning Move the document in the direction

you move the cursor.

Settings Tab (continued):

Office 97 Mode: Support for Microsoft Office 97 features

includes zoom, scrolling, and Auto-scrolling. In this mode, the

mouse functions similarly to Microsoft’s IntelliMouse.

Screen Scroller Mode: Supports all applications that use

scroll bars, with zoom, Auto-panning, and scrolling functions.

About Tab:

Click this tab to display general information about the Targus

USB-PS/2 Scroller Mini Mouse software.

Close AP

Horizontal

Vertical

Start Menu

Auto-Panning

Control Panel

Help Menu

Internet Access

Orientation Tab:

Orientation setup: This feature is specifically designed to

change the position of a portable trackball.

Additional Features

There are additional features provided with the Targus USB - PS/2 Scroller

Mini Mouse. The Switch Applications feature, the Zoom In/Out feature,

and Auto-Panning enable you to perform frequently used functions with

very little mouse movement.

Switch Applications Switch between two open applications

without moving the mouse. After setting

either the secondary button or the screen

scroller button to Switch Applications

from the Mouse Properties window, click

the chosen button to switch back and forth

between the two open applications.

Zoom In/Out For Microsoft Office 97 and Internet

Explorer 4.01 applications, press the

mouse button you assigned to Ctrl and roll

the mini mouse scroller wheel forward to

enlarge the document window. Roll it

backward to decrease the window size.

Auto-Panning Once EasyJump is assigned to a mouse

button, pressing that button presents the

the option of choosing Auto-Panning (or

any of the other EasyJump functions). The

Auto-Panning function enables you to

move the document in the direction you

move the cursor.

Quick Access Double-click the icon in the taskbar

and the Mouse Properties window opens.

To close the scroller mini mouse

software, right-click the icon in the

taskbar and select Close.

Uninstall To remove the software driver from your

hard disk, click the Start menu, select

Programs, select the scroller mini mouse

driver, and click Uninstall.

Figure 4. Removing and cleaning the mouse ball

Mouse Maintenance

The scroller mini mouse may collect dust and dirt that can interfere with its

operation. You can avoid potential problems by keeping your work area

clean and free from dust. Whenever the cursor movement becomes

abnormal, follow the steps that correspond to the type of mouse you have:

To clean the scroller wheel and mouse ball:

1Unplug the USB connector from the computer, or if you are

using the PS/2 Adapter, turn off the computer.

2Turn the mouse upside down and remove the mouse

ball retainer by turning it counter-clockwise until it

becomes loose.

3Remove the retainer and the mouse ball.

4Dampen a lint-free cloth or cotton swab with rubbing

alcohol to clean the surface of the mouse ball.

5Dampen a cotton swab with rubbing alcohol to clean the two

black rollers inside the bottom of the mouse.

6Replace the mouse ball and retainer. Turn the retainer

clockwise until it is tightly in place.

7Use adhesive tape to remove any dust or lint from around

the scroller wheel.

8Dampen a lint-free cloth or cotton swab with rubbing

alcohol. Wipe the surface of wheel clean by wiping across it

from side to side.

9Dampen another lint-free cloth with mild soap and water and

clean the outer surface of the mouse.

10Restart the computer and begin using the mouse.

To clean the optical sensor:

1Turn off the computer if you are using the PS/2 adapter, or

unplug the mouse if you are using the USB port.

2Dampen a cotton swab with mild soap and water.

3Gently wipe the optical sensor clean. Avoid scratching

the surface of the sensor.

4Plug the USB connector into the USB port, or Restart the

computer if you are using the PS/2 adapter, and begin using

the mouse.

Caution: When using a computer mouse or keyboard, you may

experience occasional discomfort in your hands, arms, shoulders,

neck, or other part of your body. If you experience symptoms such as

persistent or recurring discomfort, pain, throbbing, aching, tingling,

numbness, burning sensation, or stiffness, do not ignore these

symptoms. See a qualified health professional promptly. There are

many guidelines available for healthy computing. It is recommended

that you take frequent breaks from continuous computing. If you have

questions about how your computer activities may be related to any of

these discomforts, seek the advice of a qualified health professional.

Targus is not responsible for any disorders or injuries associated with

computing activities.

Andere Handbücher für USB Mobile Mini Hub

Inhaltsverzeichnis

Andere Targus Maus Handbücher

Targus

Targus Optical Notebook Mouse Bedienungsanleitung

Targus

Targus AMU34EU Bedienungsanleitung

Targus

Targus USB mouse Bedienungsanleitung

Targus

Targus Kaleidoscope AMU0503US Bedienungsanleitung

Targus

Targus Wireless laser Stow-N-Go Rechargeable Notebook... Bedienungsanleitung

Targus

Targus Ultralife Bedienungsanleitung

Targus

Targus USB RETRACTABLE OPTICAL LAPTOP MOUSE Bedienungsanleitung

Targus

Targus AMU75EU Bedienungsanleitung

Targus

Targus Stow-N-Go Notebook Mouse Bedienungsanleitung

Targus

Targus AMW07EU Bedienungsanleitung

Targus

Targus AMU0503 Bedienungsanleitung

Targus

Targus AMU0301EU Bedienungsanleitung

Targus

Targus MOBILE Bedienungsanleitung

Targus

Targus AMB582 Bedienungsanleitung

Targus

Targus AMW56AP Bedienungsanleitung

Targus

Targus Stow-N-Go Notebook Mouse Bedienungsanleitung

Targus

Targus AMB581 Bedienungsanleitung

Targus

Targus Wireless RF Mouse Bedienungsanleitung

Targus

Targus Screen Scroller Mouse Bedienungsanleitung

Targus

Targus 400-0086-001A Bedienungsanleitung

Targus

Targus wireless bluetooth notebook mouse Bedienungsanleitung

Targus

Targus U102 Bedienungsanleitung

Targus

Targus AMW43EU Bedienungsanleitung

Targus

Targus AMU47AP Bedienungsanleitung

Beliebte Maus Handbücher anderer Marken

Sven

Sven RX-G720 Bedienungsanleitung

3DConnexion

3DConnexion CadMouse Pro Bedienungsanleitung

Canyon

Canyon Puncher GM-20 Bedienungsanleitung

Sharkoon

Sharkoon Light2 180 Bedienungsanleitung

Cherry

Cherry MW 8C ERGO Bedienungsanleitung

NGS

NGS HIT RB Bedienungsanleitung

Sharkoon

Sharkoon FireGlider Bedienungsanleitung

Lenovo

Lenovo Wireless Mouse N3902 Bedienungsanleitung

BASETech

BASETech BN-S11 Bedienungsanleitung

Dell

Dell WM326 Bedienungsanleitung

Areson

Areson B213 Bedienungsanleitung

HP M17587-371 Bedienungsanleitung

Chatpen

Chatpen CHA-30 Bedienungsanleitung

GAMDIAS

GAMDIAS DEMETER GMS5000 Bedienungsanleitung

HP KJ453AA - Wireless Laser Mouse Bedienungsanleitung

Trust

Trust GRAPHIN GXT 960 Bedienungsanleitung

Lenovo

Lenovo SD-9082 Bedienungsanleitung

Alienware

Alienware AW320M Bedienungsanleitung
