FMC00A First Start

Main Page > OBD Trackers > FMC00A > FMC00A First Start

Advanced Plug and Track real-time tracking terminal with GNSS, GSM and Bluetooth

connectivity

Contents

1 How to insert Micro-SIM card and connect battery

2 Pinout

2.1 PC Connection (Windows)

2.2 How to install USB drivers (Windows)

2.3 Configuration (Windows)

2.4 Quick SMS configuration

3 Safety information

3.1 Precautions

How to insert Micro-SIM card and connect battery

Gently remove FMC00A cover using plastic pry tool from both sides.1.

Insert Micro-SIM card as shown with PIN request disabled or read Security info how to2.

enter it later in Configurator. Make sure that Micro-SIM card cut-off corner is pointing

forward to slot.

Connect battery as shown to device. Position the battery in place where it does not obstruct3.

other components.

Attach device cover back.4.

Device is ready to be connected.

Micro-SIM card insertion/removal must be performed when device is powered off –

external voltage and battery are disconnected. Otherwise Micro-SIM card might be

damaged or device will not detect it.

Pinout

NUMBER PIN NAME DESCRIPTION

2PWM_BUS+/VPW

4GND (-) Ground.

5GND (-) Ground.

6CAN_H CAN high.

7K-Line

10 PWM_BUS-

14 CAN_L CAN low.

15 L-Line

16 VCC (10-30)V DC

(+)

Power supply (+10..+30 V DC).

PC Connection (Windows)

Power-up FMC00A with DC voltage 10-30 V power supply using supplied power cable.1.

LED’s should start blinking, see “FMC00A LED status”.

Connect device to computer using Micro-USB cable or Bluetooth connection:2.

Using Micro-USB cable

You will need to install USB drivers, see "How to install USB drivers

(Windows)"

Using Bluetooth

FMC00A Bluetooth is enabled by default. Turn on Bluetooth on your PC, then

select Add Bluetooth or other device > Bluetooth. Choose your device named –

“FMC00A_last_7_imei_digits”, without LE in the end. Enter default password

5555, press Connect and then select Done.

You are now ready to use the device on your computer.3.

How to install USB drivers (Windows)

Please download COM port drivers from Teltonika here.1.

Extract and run TeltonikaCOMDriver.exe.2.

Click Next in driver installation window.3.

In the following window click Install button.4.

Setup will continue installing the driver and eventually the confirmation window will appear.5.

Click Finish to complete the setup.

Configuration (Windows)

At first FMC00A device will have default factory settings set. These settings should be changed

according to the user's needs.

Main configuration can be performed via Teltonika Configurator software. Get the latest FMC00A

Configurator version from here. Configurator operates on Microsoft Windows OS and uses

prerequisite MS .NET Framework. Make sure you have the correct version installed.

MS .NET requirements

Operating

system

MS .NET

Framework

version

Version Link

• Windows

Vista

• Windows

8.1

• Windows

MS .NET

Framework

5.0.17

32 and

64 bit

www.microsoft.com

Downloaded Configurator will be in compressed archive. Extract it and launch Configurator.exe.

After launch software language can be changed by clicking in the right bottom corner:

Configuration process begins by pressing on connected device:

After connection to Configurator Status window will be displayed:

Various Status window tabs display information about GNSS, GSM, I/O, Maintenance and etc.

FMC00A has one user editable profile, which can be loaded and saved to the device. After any

modification of configuration the changes need to be saved to device using Save to device button.

Main buttons offer following functionality:

Load from device – loads configuration from device.1.

Save to device – saves configuration to device.2.

Load from file – loads configuration from file.3.

Save to file – saves configuration to file.4.

Update firmware – updates firmware on device.5.

Read records – read records from device.6.

Reboot device – restarts device.7.

Reset configuration – sets device configuration to default.8.

Most important configurator section is GPRS – where all your server and GPRS settings can be

configured and Data Acquisition – where data acquiring parameters can be configured. More

details about FMC00A configuration using Configurator can be found here.

Quick SMS configuration

Default configuration has optimal parameters present to ensure best performance of track quality

and data usage.

Quickly set up your device by sending this SMS command to it:

" setparam

2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0"

GPRS settings:

2001 – APN

2002 – APN username (if there are no APN username, empty field should be left)

2003 – APN password (if there are no APN password, empty field should be left)

Server settings:

2004 – Domain

2005 – Port

2006 – Data sending protocol (0 – TCP, 1 – UDP)

Note: Before SMS text, two space symbols should be inserted.

Default configuration settings

Movement and ignition detection:

Vehicle movement will be detected

by accelerometer

Ignition will be detected by

vehicle power voltage

between 13,2 – 30 V

Device makes a record On Moving if one of these events happen:

300 seconds passes Vehicle turns 10° degrees

Vehicle drives 100 meters

Speed difference between

last coordinate and current

position is greater than 10

km/h

Device makes a record On Stop if:

1 hour passes while vehicle is

stationary and ignition is off

Records sending to server:

If device has made a record it is

sent to the server every 120

seconds

After successful SMS configuration, FMC00A device will synchronize time and update records to

configured server. Time intervals and default I/O elements can be changed by using Teltonika

Configurator or SMS parameters.

Safety information

This message contains information on how to operate FMC001 safely. By following these

requirements and recommendations, you will avoid dangerous situations. You must read these

instructions carefully and follow them strictly before operating the device!

The device uses SELV limited power source. The nominal voltage is +12 V DC. The allowed

voltage range is +10..+30V DC.

To avoid mechanical damage, it is advised to transport the device in an impact-proof package.

Before usage, the device should be placed so that its LED indicators are visible. They show the

status of device operation.

Before unmounting the device from the vehicle, ignition MUST be OFF.

Precautions

Do not disassemble the device. If the device is damaged, the power supply cables are

not isolated or the isolation is damaged, DO NOT touch the device before unplugging

the power supply.

All wireless data transferring devices produce interference that may affect other

devices which are placed nearby.

Please consult representatives of your vehicle model regarding OBD II location on your

vehicle. In case you are not sure about proper connection, please consult qualified

personnel.

The programming must be performed using a PC with autonomic power supply.

The device is susceptible to water and humidity.

Installation and/or handling during a lightning storm is prohibited.

Teltonika is not responsible for any harm caused by wrong cables used for connection

between PC and FMC00A.

WARNING! Do not use FMC00A device if it distracts driver or causes inconvenience due

to OBD II placement. Device must not interfere with driver.

https://teltonika-gps.com/product/fmc00A/
