Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comDL-40JANUS manual (d0111) Page 1

• Externaltransmittersorsignalconditionerscanbeeliminated

bydirectconnectionofthesensoroutputtomorethan29Plug-

inInputSignalConditionersthatinclude:

–ACCurrent  –Pressure –Resistance

 –AC/DCVoltage –Process –*Temperature

–LoadCell  –Prototype –4to20mA

*SeemodelsDL-40-RTDandDL-40-RTDforhigheraccuracy

digitallylinearizedthermocoupleandRTD

• Optionalisolated14bitanalogoutput.Userorfactoryscalable

to4to20mA,0to20mAor0to10Vacrossanydesired

 digitalspanfrom±onecounttothefullscalerangeof–1999

to9999(12000counts).

• OptionalIsolatedModbusRTURS-485serialcommunication

withselectablebaudrate(9600,19200),addressandparity.

• Auto-sensingAC/DCpowersupply.Forvoltagesbetween



85-265 VAC / 95-370 VDC (PS1) or15-48VAC/10-72VDC(PS2).

• 24VDCexcitationisavailabletopowerexternaltransmitters

and5or10VDCexcitationisavailableforresistancebridge

typesensorssuchasLoadCellsandPressureTransducers.

• Standardredoroptionalgreenorsuperbrightred4-digitLED

withdisplayrange–1999to9999(12000counts).

• Redorgreen0.8”LEDlargedisplayoption

• FourannunciatorLEDsprovidefrontpanelalarmstatus

indicationforuptofoursetpoints.

• Optionaltwo9AmpFormCandtwo4AmpFormArelays,or

four4AmpFormArelaysareavailable.

• Automaticintelligentaveragingsmoothsnoisysignals,while

providingafastdisplayresponsetorealinputsignalchanges.

• Three-buttonprogrammingfromthefrontpanel

(UP,DOWNandPROGRAMbuttons).

• Frontpanelselectablefour-levelbrightnesscontrolofdigitaldis-

play,andsetpointLEDs.

• Fourprogrammablesetpoints.

• Relayactivationcanbeselectedtooccurabove(HI)orbelow

(LO)eachsetpoint.

• Hysteresissettingforallfoursetpoints.Delayonmakeand

delayonbreakforSP1andSP2.

• PeakandValley.ViewandReset.

AutoCalibrationMode ............5

AutoCalibrationProcedure........5

CaseDimensions ...............16

ConnectorPinouts........... 10-11

ControlsandIndicators...........2

DigitalSpanSelectionforAnalog

RangeOutput...................6

DecimalPoint&BrightnessSelection

..6

GeneralFeatures................1

GlossaryofProgrammingSymbols ..2

InputModuleAnalogCalibration

....15

InputModuleComponentGlossary

14-15

InputModuleCalibration...... 15-16

InputSignalConditioningModules

. 12-14

LensCover&MetalSurroundCase 17

ManualRescaling................4

ManualRescalingProcedure.......4

MeterAssembly ................10

ModbusRTU&RS-485Settings....7

ModbusRTUImplementation......7

ModbusAddressforDL-40Registers8

OrderingInformation............18

Setpoint&RelayConfigurationMode....9

SoftwareFeatures...............1

SoftwareLogicTree ..............3

Specifications...................1

TwoPointAnalogOutputRange

SettingandCalibration............6

0.56" or optional 0.8” large display red or green LED

General Features Input Module Compatibility

Specifications

Software Features

Index

LEOPAR D FAM I LY

LEOPARD

A powerful, smart, programmable panel meter

with optional Modbus RS-485 serial, analog and

relays output for measurement and control

applications in a 1/8 DIN 96x48mm case.

DL-40JANUS

With or without an External Signal

Source for Rescaling

Input Specs:................DependsonInputsignalconditioner

A/D Converter:.............14bitsingleslope

Accuracy:.....................±(0.05%ofreading+2counts)

Temp. Coeff.:...............100ppm/°C(Typical)

Warm up time:.............2minutes

Conversion Rate:.........5conversionspersecond(Typical)

Display:........................4digit0.56"RedLEDdisplay(std),0.56”

or0.8"Red,GreenorSuperBrightRed

(optional)

Range–1999to9999counts.

Polarity:........................Assumedpositive.Displays–negative

Decimal Selection:.......Frontpanelbuttonselectable,X•X•X•X•

Positive Overrange:.....Topsegmentsofdigitaldisplayflash

Negative Overrange:...Bottomsegmentsofdigitaldisplayflash

Relay Output:..............Two4AmpFormArelaysandtwo9

AmpFormC,or4AmpformArelays.

Analog Output:............Isolated14bituserscalablemAorV

AIC(mAout)................4-20mA@0to500Ωmaxloopresis-

tance.

AIV(voltsout)..............0-10VDC@500Ωorhigherresistance

Power Supply:.............AC/DCAutosensingwiderangesupply

PS1 (std).....................85-265 VAC / 95-370 VDC @ 3W max

3.5W. 50-400Hz.

PS2..............................15-48VAC/10-72VDC@2.5Wmax

3.5W.50-400Hz.

Operating Temp.:.........0to60°C

Storage Temp:.............–20°Cto70°C.

Relative Humidity:.......95%(noncondensing)

Case Dimensions:.......1/8DIN,Bezel:96x48mm(3.78”x1.89”)

Depth behind bezel: 117mm(4.61”)

Plus11.8mm(0.47”)forRight-angled

connectors,orplus20mm(0.79”)for

Straight-thruconnector.

Weight:........................6.5oz.,8.5ozwhenpacked

LEOPARD FAM ILY:Morethan29different

Plug-inI-SeriesInputSignalConditionersare

approvedforTexmate’sLeopardFamilyofmeters.

Someexamplesareshownonpages12-14.

Seewww.texmate.comforanuptodatelisting.

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comPage 2 DL-40JANUS manual (d0111)

Symbol Explanation

This symbol represents the

OPERATIONAL DISPLAY.

This is the PROGRAM button.

This is the UP button.

This is the DOWN button.

When a button is shown, press and

release it to go onto the next step in the

direction indicated by the arrow. When two

or more buttons are shown, each with an

arrow, this indicates that there is a number

of programming choices.

When two buttons are shown side by side

and enclosed by a dotted line, they must

be pressed at the same time then released

to go onto the next programming step.

If the display is shown with XXXX it means

the value displayed will be the previously set

value. When a number is shown it indicates

the initial factory default setting or a specific

“example number”.

When two displays are shown together with

bursts, this indicates that the display is

toggling (flashing) between the name of the

function and the value.

Text or numbers shown between square

brackets in a procedure indicate the pro-

gramming code name of the function or the

value displayed on the meter display.

When the

and

buttons are shown

together, the display value can be increased

by pressing and releasing the

button

or decreased by pressing and releasing the

button.

When the

and

buttons are shown

with two displays, either display can be

selected by pressing and releasing the

buttons.

When there are more than two display selec-

tions they are shown in brackets below the

first display and are also selectable by press-

ing and releasing the

buttons.

A dotted box indicates these functions are

omitted or bypassed when the related hard-

ware is not present

To explain software programming procedures, logic diagrams are

used to visually assist in following the programming steps. The

fol-lowing symbols are used to represent various functions and

associated display elements of the meter:

DOWN ARROW

BUTTON

Setpoint

Annunciator

LEDs

SP4

SP3

SP2

SP1

PROGRAM

BUTTON P

Setpoint Annunciator LEDs

SP1 SP2 SP3 SP4

[LHLH]

[HLHL]

[LLLL]

Front Panel Buttons

Program Button

The

button is used to move from one program step to the next.

When pressed at the same time as the button, it initiates the

calibration mode. When pressed at the same time as the but-

ton, it initiates the setpoint setting mode.

Up Button

When in the operational display, pressing the button alone,

allows you to view and reset the Peak and Valley (Highest and

Lowest Readings.)

When in the calibration mode or the setpoint setting mode the

button is used to increase the value of the displayed parameter.

Down Button

When in the operational display, pressing the button alone,

allows you to view, but not change, the setting of setpoint 1,2,3

& 4.

When in the calibration mode or the setpoint setting mode the

button is used to decrease the value of the displayed parameter.

Glossary of Programming Symbols

Controls and Indicators

[ScAL]

[9999]

UP ARROW

BUTTON

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comDL-40JANUS manual (d0111) Page 3

The DL-40JANUS is an intelligent meter with a hierarchical

software structure designed for easy programming and opera-

tion, as shown below in the software logic tree.

After the meter has been powered up, the four

digits light up for three seconds and then settle to

the operational display indicating the input signal.

15 Second

Program Timeout

The meter has a 15 second

program timeout. If no buttons

are pressed for 15 seconds, at

any stage of the programming

sequence the meter will exit the

programming mode and return

to the operational display. Any

program changes that were

made prior to pressing the

button in the preceding step

will not be saved.

Software Logic Tree

SETPOINT SETTING AND

RELAY CONFIGURATION MODE

See Page 9

Set Setpoint 1

(SP1)

Delay-on-Make

(doM)

Delay-on-Break

(dob)

Setpoint 2

(SP2)

Hysteresis

(HYSt)

Hysteresis

(HYSt)

Hysteresis

(HYSt)

Hysteresis

(HYSt)

Delay-on-Make

(doM)

Delay-on-Break

(dob)

Setpoint 3

(SP3)

NOTE: [dob] [dom] Functions

are only available

for SP1 and SP2

Setpoint 4

(SP4)

Relays Activation [rLYS]

(H) High the relay energizes

when the setpoint is exceeded.

(L) Low the relay energizes below

the setpoint. Setpoint are indicated

from left to right SP1, SP2, SP3, SP4

Peak

Reset

PEAK

Reset

VALY

Setpoint 1

(SP1)

confirm (SP1) confirm

Peak

confirm

Valley

confirm Analog

output values

confirm (SP2)

confirm (SP3)

Setpoint 2

(SP2)

[LHLH]

[HLHL]

[HHHH]

MAIN MENU

Operational Display

SETPOINT

VIEW ONLY MODE

PEAK & VALLEY

VIEW & RESET

Sub-menu

MODE

Calibration

Mode

Calibration

Mode

DECIMAL POINT AND

BRIGHTNESS SELECTION

See Page 6

Setpoint 3

(SP3)

Setpoint 4

(SP4)

Valley

Offset

Scale

Factor

Calibrate

Analog

Output

Calibrate

Analog

Output

[X•XXX]

[XX•XX]

[XXX•X]

[XXXX•]

[XXXX]

[2]

[3]

[4]

Decimal Point

(dp)

Display

Brightness (br)

TWO POINT ANALOG OUTPUT

CALIBRATION

SEE PAGE 6

MANUAL

RESCALING MODE

See Page 4

SELECTION FOR ANALOG

RANGE OUTPUT

See Page 6

confirm (SP4)

confirm

This menu only available

when an analog output

module is installed

When MANUAL

is set to ON

When AUTO

is set to OFF

Span

Zero

Err. Any new setting

canceled and previous

settings are retained

TWO POINT AUTO

CALIBRATION MODE

SEE PAGE 5

This menu only available

when an analog output

module is installed

Modbus RS-485 Settings

See Page 7-8

BAUD: -press Up button for 192(00)

-press Down button for 96(00)

ADDR: -press Up or Down button to change

from 1 to 247.

-value rolls over, e.g. 247 to 1

PRTY: -press Up or Down button to change

-values are 2=Even, 1=Odd, 0=None

Texmate’s Modbus RTU RS-485 module provides

half-duplex, serial communication to PLC, SCADA and

other systems for monitoring and control of the meter’s

functions. The meter functions as a slave.

The RS485 module takes the place of the Analog Output

module, so it is not possible to have both Analog

Output and RS-485 communication. Programming and

operation of the meter are done via a dierent menu

system, or Software Logic Tree, that is accessed through

the front panel push buttons, see below.

14 158 9 10 11

See Leopard Family Input

Signal Conditioning Modules

1 2 3 4 5 6

Relay Outputs

Neutral

– DC

Line

+ DC

(Lock) ON COM Ref A+

29 28 27 26 25 24 23 22

With RS-485 Output Option

MANUAL rescaling- (without external signal) ON

AUTO scaling- (with external signal) OFF

17 1619 18

SP1

SP2

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comPage 4 DL-40JANUS manual (d0111)

When the rear Auto/Manual switch is in the Manual position, the meter can be rescaled without applying an external signal by

changing the oFSt (offset) and SCAL (scale) parameters in the user menu. A pre-calibrated Input Signal Conditioning module must

be used. The meter assumes that this calibration used a true zero input (0V from conditioner to meter) resulting in a display value

of 0 and a maximum input signal span (2V from conditioner to meter) resulting in a display value of the SCAL value set in the user

menu. The linear equation is y = mx + b where m = (SCAL-0)/(2-0) and b = oFSt.

The default value of SCAL is 2000, but it may be set to any value between -1999 and +9999.

The internal Signal Span is limited to 3 V DC between- 1 V DC to+ 2 V DC. Any outputs from an Input Signal Conditioning module

that exceed these limits will cause the meter to indicate overrange regardless of the Digital Display Span scaled. For example,

an ID01 DC Volts Input Signal Conditioner can read +/-2VDC, but in the DL-40 will show under-range for a -1.2V input.

STEP A Enter the Calibration Mode

1) Press the

and buttons at the same time.

Display toggles between [CAL] and [oFF].

2) Press and hold the or button.

Display changes from [oFF] to [on].

3) Press the

button. Display toggles between [CAL] and [out].

STEP B Select Between Calibration of Input or Output

Note: If the analog output option is not present, Step B is skipped and the

program goes directly from Step A to Step C.

1) Press the or button to select the display toggling from [CAL]

to [inPt].

2) Press the

button. Display toggles between [oFSt] and the

previous offset setting.

STEP C Set the Offset on the Digital Display

1) Using the and buttons, adjust the digital display to the

desired offset. This is the reading that the meter will display for a

zero input.

2) Press the

button. Display toggles between [SCAL] and the

previous Scale factor.

STEP D Set the Scale factor on the Digital Display

1) Using the and buttons, adjust the meter display to the

desired Scale factor. The default value is 2000, for which a 2V

input will read 2000. If the scale factor is changed the display will

change proportionately. Therefore if the Scale factor is changed

to 1000 then for the same 2V input the display would read 1000.

2) Press the

button.

The Digital Calibration Procedure Mode is Now Complete.

The menu branches to the DECIMAL POINT AND BRIGHTNESS SE

LECTION,

(see page6) and the display flashes [dP] and the previous

decimal point selection.

Manual Rescaling Mode

Manual Rescaling Procedure

MAIN MENU

Operational Display

Sub-menu

MODE

STEP A Calibration

Mode

STEP B Calibration

Mode

DECIMAL POINT AND

BRIGHTNESS SELECTION

See Page 6

STEP C Offset

STEP D Scale

Factor

DECIMAL POINT AND

BRIGHTNESS SELECTION

See Page 6

Decimal Point

(dp)

TWO POINT ANALOG

OUTPUT RANGE SETTING

AND CALIBRATION

SEE PAGE 6

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comDL-40JANUS manual (d0111) Page 5

When the rear Auto/Manual switch is in the Auto position, the meter can be calibrated with an automatic scale factor calculation,

by applying a low input signal (InLo), entering the desired low display reading for that signal (ZERO), then applying a high input

signal (InHi), and then entering the desired high display reading (SPAN). The meter then automatically calculates and programs in

the requisite scale factor using a true linear (y=mx + b) calculation where m = (SPAN-ZERO)/(InHi-InLo) and b = ZERO, but within

the following parameters.

1. Positive and negative signals may be applied, but the difference between the high and the low signal inputs must be at least 1000

counts or Err will be indicated.

2. Positive and Negative values for the desired reading can be entered, but the scale factor created can not exceed the Digital

Display Span capability of the meter which is 12,000 counts between –1999 to 9999.

3. The internal Signal Span is limited to 3 V DC between – 1 V DC to + 2 V DC. Any outputs from an Input Signal Conditioning

module that exceed these limits will cause the meter to indicate overrange regardless of the Digital Display Span scaled.

Note: Most input signal conditioners have provisions for analog calibration and scaling. If the meter’s digital scale factor is set to

read zero with a zero input (shorted input), and to read 1000 with a 1.000 V input, any pre-calibrated signal conditioner with an

output that does not exceed – 1 V to + 2 V, will read correctly in the meter without any further calibration.

STEP A Enter the Calibration Mode

1) Press the

and buttons at the same time.

Display toggles between [CAL] and [oFF].

2) Press and hold the or button.

Display changes from [oFF] to [on].

3) Press the

button. Display toggles between [ZErO] and the

previous zero setting.

STEP B Select Between Two Point Digital Calibration of Input Signal and

Two Point Analog Output

Note: If the analog output option is not present, Step B is skipped and the

program goes directly from Step A to Step C.

1) Press the or button to select the display toggling from [CAL]

to [inPt] input calibration.

2) Press the

button. Display toggles between [ZErO] and the

previous zero setting.

STEP C Set the Meter’s Low Input Signal Reading on the Digital Display

1) Apply a zero or low signal to the meter.

(Positive or negative values are allowed)

2) Using the and buttons, adjust the meter display to the

desired reading for the applied low input signal.

3) Press the

button. Display toggles between [SPAn] and the

previous span setting.

STEP D Set the Meter’s High Input Signal Reading on the Digital Display

1) Apply a high input signal to the meter.

2) Using the and buttons, adjust the digital display to the

desired reading for the applied high input signal.

3) Press the

button.

The Digital Calibration Procedure Mode is Now Complete.

If the digital calibration was successfully completed, the menu

branches to the DISPLAY FUNCTION CONFIGURATION MODE,

(see page 7) and the display flashes [dP] and the previous setting.

ERROR Indicates Unsuccessful Calibration

If the calibration was unsuccessful, the display indicates [Err],

the new calibration settings just entered will not take effect and

the previously stored setting will remain.

The three most likely causes of an error during calibration are:

1) The full scale and zero signals were too similar. The full scale

signal must be at least 1000 counts greater than the zero or

low input signal (positive and negative values are allowed).

2) The scaling requirement exceeded the capability of the meter

(–1999 to 9999).

3) No input signal present, or incorrect connections.

Auto Calibration Mode

Auto Calibration Procedure

MAIN MENU

Operational Display

Sub-menu

MODE

STEP A Calibration

Mode

STEP B Calibration

Mode

DECIMAL POINT AND

BRIGHTNESS SELECTION

See Page 6

STEP C Zero

STEP D Span

DECIMAL POINT AND

BRIGHTNESS SELECTION

See Page 6

Decimal Point

(dp)

Err. Any new setting

canceled and previous

settings are retained

TWO POINT ANALOG

OUTPUT CALIBRATION

SEE PAGE 6

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comPage 6 DL-40JANUS manual (d0111)

STEP A Enter the Calibration Mode

1) Press the

and buttons at the same time.

Display toggles between [CAL] and [oFF].

2) Press the or button. Display changes from [oFF] to [on].

Press the

button. Display toggles between [CAL] and [out] input calibration.

Note: If at this point the display skips directly to toggle between [oFSt] (Manual) or [ZErO]

(Auto) and the previous setting, the software is detecting that the optional analog output hard-

ware is NOT installed.

STEP B Enter the Analog [oUT] Output Mode

Press the

button. Display toggles between [CLo] and an internal scale factor.

STEP C Set or Calibrate the [CLo] Low Analog Output Range

1) Select the voltage or current loop output header position on the output

module. (See Component Layout on page 9).

2) Connect a multimeter to pins 16 and 17 on the output module. (See Rear

Panel Pinouts on page 8). Using the and buttons, adjust the analog

output to the desired low value as shown on the multimeter display.

cLo may be adjusted to any value from –0.3 mA to 17 mA (mA output

selected) or from –0.6 V to 8 V (volt output selected)

Press the

button. Display toggles between [CHi] and an internal scale factor.

STEP D Set or Calibrate the [CHi] High Analog Output Range

1) Using the and buttons, adjust the analog output to the desired high

value as shown on the multimeter display. CHi may be adjusted to any value

from 17 mA to 21 mA (mA output selected) or from 8 V to 10.3 V (volt out

put selected)

2) Press the

button. The display exits the calibration mode and returns to

the operational display.

Note: Having established the Low and High range of the analog output, the digital span

can now be selected which will set the two digital points between which the analog out-

put will occur. (See Digital Span Selection below).

STEP A Enter the Decimal Point and Brightness Mode Through the Sub Menu

[CAL] [oFF]

1) Press the

and buttons at the same time.

Display toggles between [CAL] and [oFF].

2) Press the

button. Display shows previous [dP] selection.

STEP E Set the Decimal Point

1) Using the and , adjust the display to the desired decimal point setting.

Press the

button. Display toggles between [br] and the previous [br] setting.

STEP F Set the Display Brightness

1) Using the and buttons, adjust the display to the desired brightness

setting (4 is the brightest setting).

2) Press the

button. Display brightness changes to new setting

and display

toggles between [AnHi] and the previous [AnHi] setting.

STEP G Setting the Digital Span Point for Analog High Output

1) Using the and buttons, adjust the display to the desired digital value

which sets the point at which the selected analog high output range will occur.

Press the

button. Display toggles between [AnLo] and previous [AnLo] setting.

STEP H Setting the Digital Span Point for Analog Low Output

1) Using the and buttons, adjust the display to the desired digital value

which sets the point at which the selected analog low output range will occur.

2) Press the

button.

The display exits the calibration mode and returns to

the operational display.

Note: Any two digital scale points from –1999 to 9999 can be selected. The digital scale

points for analog high and analog low can be reversed for reversed 20-4 mA output. The

span of the digital scale can be as small as two counts however small spans cause the 16

bit D to A to increment in stair case steps.

Two Point Analog Output Range Setting and Calibration

Decimal Point and Brightness Selection

Digital Span Selection for Analog Range Output

MAIN MENU

Operational Display

Sub-menu

MODE

STEP A Calibration Mode

TWO POINT AUTO

CALIBRATION or

MANUAL RESCALING MODE

See page 4 and 5

STEP B Calibration Mode

STEP C Calibrate Analog

Output Lo

STEP D Calibrate Analog

Output Hi

DECIMAL POINT AND

BRIGHTNESS SELECTION

[X•XXX]

[XX•XX]

[XXX•X]

[XXXX•]

[XXXX]

[2]

[3]

[4]

STEP E Decimal

Point (dp)

STEP F Display

Brightness (br)

STEP G Analog

High (Anhi)

STEP H Analog

Low (AnLo)

Confirm

DIGITAL SCALE AND SPAN

SELECTION FOR FULL SCALE

ANALOG RANGE OUTPUT

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comDL-40JANUS manual (d0111) Page 7

The Modbus/RS-485 communication settings sub-menu allows

you to set the following parameters:

a) Baud Rate – this is the baud rate of the RS-485 serial communi-

cation between the meter (slave) and Modbus master. Options are

9600 (default, meter shows “96”) and 19200 (meter shows “192”).

b) Address – this is the meter’s Modbus address on the RS-485

loop. Typically, RS-485 limits the number of devices on the loop to

32, but the DL-40 supports the full Modbus address range of 1-247.

Address 1 is the default value.

c) Parity – this is the parity setting for the RS-485 serial commu-

nication between the meter (slave) and Modbus master. Options

are: None (display shows “0”; Odd (display shows “1”); Even

(default, display shows “2”).

The meter’s response time to a read command from the master is

40-45msec (typically 42msec). The response time for a write com-

mand is 70-75msec (typically 72msec). This is due to the module

having to communicate to the meter’s core firmware to complete

the desired command. Exception responses are handled directly

by the module and typically have a response time of 3msec.

Modbus RTU & RS-485 Communication Settings

The DL-40 Modbus communication module supports the following

Modbus commands:

a) Read Holding Register (0x03)

b) Write Single Register (0x06)

Modbus addresses for DL-40JANUS registers are shown on

the next page

The following are some things to note about particular registers:

a) Modicon address 40001 RELAY has the bit values for Sp3 &

Sp4 and LED3 & LED4 reversed. There is an historical reason

for this, and we have chosen to maintain backward compatibili-

ty in case customer’s want to send their meters in for a Modbus

upgrade (at a nominal fee).

b) Modicon addresses 40002 INP, 40026 PEAK, 40027 VALY,

40029 ZERO, 40029 SPAN return a 2 byte hexadecimal value

of the meter’s display (in counts) and does not include the deci-

mal point. If you need the decimal value with decimal point, you

will need to read the register, convert it to decimal, read 40024

(see below) to determine decimal location, then combine the

two. Display counts are in Two’s Complement notation.

a. Hex values for 0 to 9999 are 0x0000 to 0x270F.

b. Hex values for -1 to -1999 are 0xFFFF to 0xF831.

c. Over-range is indicated by a returned value of 9999

(0x270F).

d. Under-range is indicated by a returned value of -1999

(0xF831).

c) In order for Sp3 and Sp4 set point settings to work, the DL-40

must have the optional Output Carrier Board installed (P/N

SA-DL/OM-CB).

d) All Delay on Make (DoM), Delay on Break (DoB) and Hysteresis

values are in units of whole seconds.

e) Modicon address 40023 RLYMOD uses the following values

to set the relay activation mode (letter sequence is SP1, SP2,

SP3, SP4):

a. 0 for HHHH

b. 1 for HLHL

c. 2 for LHLH

d. 3 for LLLL

e. H means relay is energized if input is equal to or

exceeds setpoint; L means relay is energized if input

is less than setpoint.

f. Note that the meter will not show the last two letters if

the Output Carrier Board option is not installed.

f) Modicon address 40023 DP uses the following values to set the

display decimal point location:

a. 0 for XXXX (none)

b. 1 for XXXX.

c. 2 for XXX.X

d. 3 for XX.XX

e. 4 for X.XXX

g) Modicon address 40025 BRIGHT must be a value between 1

(most dim) to 4 (most bright).

h) Modicon addresses 40028 and 40029 will have different mean-

ings depending on the Auto calibration or Manual rescaling

operational selection (see Auto Calibration Mode or Manual

Rescaling Mode above). These are explained in the register

table below.

i) Modicon addresses 40030 IZERO and 40031 ISPAN return

hexadecimal values related to the Auto Mode calibration of the

meter. They do not necessarily match expected values due vari-

ations and tolerances in the measurement circuit components,

e.g., calibrating with a value of zero volts for the ZERO value

may return a value of 0xFFFE (-2). These registers have no

meaning in Manual Rescaling Mode).

Modbus RTU Implementation

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comPage 8 DL-40JANUS manual (d0111)

Modbus Addresses for DL-40 Registers

MODICON

ADDRESS

MODICON

ADDRESS

TYPE R/W MIN. MAX. Register DESCRIPTION

40001 0x0000 UINT16 R - - RELAY B_0 SP1 Status

B_1 SP2 Status

B_3 SP4 Status

B_2 SP3 Status

B_4 LED1 Status

B_5 LED2 Status

B_7 LED4 Status

B_6 LED3 Status

40002 0x0001 SINT16 R-1999 9999 INP Hexadecimal value of displayed

value

40003 0x0002 UINT16 R96/192 -BAUD Modbus baud rate stored as 96

for 9600 or 192 for 19200, set

by user via menu interface.

40004 0x0003 UINT16 R 1 247 ADDR Modbus meter address stored as

a value between 1 - 247, set by

user via menu interface.

40005 0x0004 UINT16 R 0 2 PARITY Modbus parity value stored as

a value of 0 (no parity), 1 (odd

parity) or 2 (even parity), set by

user via menu interface.

40 011 0x000A SINT16 R/W -1999 9999 PRES1 Setpoint 1 setting

40012 0x000B UINT16 R/W 09999 P1DOM Setpoint 1 DoM setting

40013 0x000C UINT16 R/W 09999 P1DOB Setpoint 1 DoB setting

40 014 0x000D UINT16 R/W 09999 HYST1 Setpoint 1 Hysteresis setting

40015 0x000E SI NT16 R/W -1999 9999 PRES2 Setpoint 2 setting

40016 0x000F UINT16 R/W 09999 P2DOM Setpoint 2 DoM setting

40 017 0x0010 UINT16 R/W 09999 P2DOB Setpoint 2 DoB setting

40018 0x0011 UINT16 R/W 09999 HYST2 Setpoint 2 Hysteresis setting

40019 0x0012 SINT16 R/W -1999 9999 PRES3 Setpoint 3 setting

40020 0x0013 UINT16 R/W 09999 HYST3 Setpoint 3 Hysteresis setting

40021 0x0014 SINT16 R/W -1999 9999 PRES4 Setpoint 4 setting

40022 0x0015 UINT16 R/W 09999 HYST4 Setpoint 4 Hysteresis setting

40023 0x0 016 UINT16 R/W 0 3 RLY MOD Relay activation polarity (H, L,

disabled, e.g., HHHH)

40024 0x0017 UINT16 R/W 0 4 DP Decimal Point setting

40025 0x0018 UINT16 R/W 1 4 BRIGHT Brightness setting

40026 0x0019 UINT16 R/W - - PEAK Peak (maximum) measured

value, writing any value resets

this register

40027 0x001A UINT16 R/W - - VA LY Valley (minimum) measured

value, writing any value resets

this register

40028 0x001B SINT16 R-1999 9999 ZERO

(Auto Mode

Only)

Displayed value for the min-

imum input signal value that

is applied during Auto Mode

calibration

40029 0x001C SINT16 R-1999 9999 SPAN

(Auto Mode

Only)

Displayed value for the max-

imum input signal value that

is applied during Auto Mode

calibration

40028 0x001B SINT16 R-1999 9999 OFST

(Manual Mode

Only)

Displayed value for the Offset

in Manual Rescaling Mode

40029 0x001C SINT16 R-1999 9999 SCAL

(Manual Mode

Only)

Displayed value for the Scale in

Manual Rescaling Mode

40030 0x001D UINT16 RN/A N/A IZERO Calibrated “zero” measure-

ment for displayed ZERO in

Auto Mode, has no meaning in

Manual mode

40 031 0x001E UINT16 RN/A N/A ISPA N Calibrated “span” measurement

for displayed maximum input

SPAN in Auto Mode, has no

meaning in Manual mode

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comDL-40JANUS manual (d0111) Page 9

The following programming steps are required to enter the setpoint values and configure the relay

functions in a meter with four relays using four setpoints. Generally if less than four relays are

installed the software auto detects missing relays and deletes reference to them from the menu. In

some cases setpoints without relays are operational for display only purposes.

STEP A Enter the Setpoint Mode

1) Press the

and buttons at the same time.

Display toggles between [SP1] and the previous [SP1] setting.

STEP B Set Setpoint 1 (SP1)

1) Using the and buttons, adjust the display to the desired SP1 value.

2) Press the

button. Display toggles between [doM] and the previous [doM] setting.

STEP C Set the SP1 Delay-on-Make (doM) Delay Time Setting

1) Using the and buttons, adjust the display to the desired [doM] value

(0 to 9999 seconds). The reading must continuously remain in an alarm condition

until this delay time has elapsed before the relay will make contact (energize).

2) Press the

button. Display toggles between [dob] and the previous [dob] setting.

STEP D Set the SP1 Delay-on-Break (dob) Delay Time Setting

1) Using the and buttons, adjust the display to the desired [dob] value (0 to 9999

seconds). The reading must continuously remain in an non-alarm condition until this

delay time has elapsed before the relay will break contact (de-energize).

2) Press the

button. Display toggles between [

HYSt]

and the previous

[HYSt]

setting.

STEP E Set the Hysteresis Setting for Setpoint 1

Using the and buttons, adjust the display to the desired hysteresis [hYSt] value.

2) Press the

button. Display toggles between [SP2] and the previous [SP2] setting.

NOTE: Half of the Hysteresis value selected is applied above and below the setpoint.

NOTE: Steps F, G, H and J have functionally the same procedure as steps B, C, D, and E shown above.

STEP F Set Setpoint 2 (SP2)

STEP G Set the SP2 Delay-on-Make (doM) Delay Time Setting

STEP H Set the SP2 Delay-on-Break (dob) Delay Time Setting

STEP I Set the Hysteresis Setting for Setpoint 2

Using the and buttons, adjust the display to the desired hysteresis [HYSt] value.

2) Press the

button. Display toggles between [SP3] and the previous [SP4] setting.

STEP J Set Setpoint 3 (SP3) (No [doM] or [dob])

1) Using the and buttons, adjust the display to the desired SP3 value.

2) Press the

button. Display toggles between

[HYSt]

and the previous

[HYSt]

setting.

STEP K Set the Hysteresis Setting for Setpoint 3

Using the and buttons, adjust the display to the desired hysteresis [HYSt] value.

2) Press the

button. Display toggles between [SP4] and the previous [SP4] setting.

STEP L Set Setpoint 4 (SP4) (No [doM] or [dob])

1) Using the and buttons, adjust the display to the desired SP4 value.

2) Press the

button. Display toggles between [HYSt] and 0.

STEP M Set the Hysteresis Setting for Setpoint 4

Using the and buttons, adjust the display to the desired hysteresis [HYSt] value.

2) Press the

button. Display toggles between [rLYS] and the previous relay setting.

STEP N Set Relay Activation mode [rLYS]

(H) High the relay energizes when the setpoint is exceeded. (L) Low the relay energizes

below the setpoint. The setpoint is indicated from left to right SP1, SP2, SP3, SP4.

1) Using the and buttons, adjust the reading on the display to the desired

relay settings: [LLLL], [LHLH], [HLHL], [HHHH].

If only 2 relays installed [LH--], [HL--], [HH--], [LL--].

2) Press the

button.

The meter exits the setpoint mode and returns to the operational display.

The Setpoint Relay programming mode is now complete.

Setpoint Setting and Relay Configuration Mode

SETPOINT SETTING AND

RELAY CONFIGURATION MODE

See Page 9

STEP B Set

Setpoint 1 (SP1)

STEP C Delay on

Make (doM)

STEP D Delay on

Break (dob)

STEP F Setpoint 2

(SP2)

STEP E Hysteresis

(HYSt)

STEP I Hysteresis

(HYSt)

STEP K Hysteresis

(HYSt)

STEP M Hysteresis

(HYSt)

STEP N Relays

Activation [rLYS]

Confirm

STEP G Delay on

Make (doM)

STEP H Delay on

Break (dob)

STEP J Setpoint 3

(SP3)

NOTE: [dob] [dom]

Functions are

only available for

SP1 and SP2

STEP L Setpoint 4

(SP4)

MAIN MENU

Operational Display

STEP A

[LHLH]

[HLHL]

[HHHH]

Texmate, Inc. Tel. (760) 598-9899 • www.texmate.comPage 10 DL-40JANUS manual (d0111)

Pinout Diagram

The Rear View of the Meter diagram shows the meter with the

relay configuration: dual 9 Amp Form C and dual 4 Amp Form

A relays. An analog output module is also shown as installed.

The DL-40JANUS uses plug-in type screw terminal connectors for

all input and output connections. The power supply connections

(pins 14 and 15) have a unique plug and socket outline to prevent

cross connection. The main board and input signal conditioner

use right-angled connectors as standard. The output module uses

straight-thru connectors as standard.

Auto-sensing AC/DC power supply. For voltages between

85-265 V AC / 95-370 V DC (PS1) or 18-48 V AC / 10-72 V DC (PS2).

WARNING: AC and DC input signals and power

supply voltages can be hazardous. Do Not connect live

wires to screw terminal plugs, and do not insert, remove

or handle screw terminal plugs with live wires connected.

Standard plug-in screw terminal connectors provided by Texmate:

Connector PinoutsConnector Pinouts

Output

CarrierBoard

Relay

Module

Input Signal

Conditioner

RS-485

or Analog

Output Module

Main

Board

Component LayoutMeter Assembly

COMMON

DIM

ANALOG

OUTPUT –

ANALOG

OUTPUT +

17 16

12 18

With Analog Output Option

14 158 9 10 11

See Leopard Family Input

Signal Conditioning Modules

1 2 3 4 5 6

Relay Outputs

Neutral

– DC

Line

+ DC

(Lock) ON

COM Ref A+

29 28 27 26 25 24 23 22

With RS-485 Output Option

MANUAL rescaling- (without external signal) ON

AUTO scaling- (with external signal) OFF

17 1619

MANUAL rescaling-ON

AUTO scaling- OFF

SP1

SP2

Pins 14 and 15 – AC/DC Power Input

Auto-sensing AC/DC power supply. For voltages between

85-265 V AC/95-370 V DC (PS1) or 18-48 V AC/10-72 V DC (PS2).

Pin 14 AC/DC Neutral. Neutral power supply line.

Pin 15 AC/DC line. Live power supply line.

Analog and RS-485 Output Board Pins

Pins 16 and 17 – Analog Output

Pin 16 Positive (+) analog output.

Pin 17 Negative (–) analog output.

Pins 18 to 21 – Rear Panel Function Pins

Pins 18 to 21 provide functions that can be implemented

with an external switch. Their pin definitions are:

Pin 18 DIM. By connecting the display dim (DIM) pin to

the COMMON pin, the display brightness setting

is halved.

Pin 19 COMMON. To activate the LOCK or DIM

functions from the rear of the meter, the

respective pins have to be connected to the

COMMON pin. This pin is connected to the

internal power supply ground.

Switch 1 AUTO/MANUAL SCALING Mode. When

switch 1 is set to ON position, the Manual

Scaling is selected. When switch 1 is set to OFF,

the Auto Scaling is selected, and this is

the default position.

Switch 2 LOCK. By setting the LOCK pin to the ON

position, the meter's programmed

parameters can be viewed but not changed.

Pins 22 to 29 – Relay Output Module Pins

Input Signal – Pins 1 to 6

Pins 1 to 6 are reserved for the input signal conditioner.

See the data sheet for the selected input signal conditioner.

Pins 8 to 12 – Relay Output Pins

Note: If relays for setpoints 1 & 2 are installed on the

main board, and a relay output module is used that also

has relays in the setpoints 1 & 2 positions, the duplicate

relays will operate in unison.

Pin 8 SP1 NO. Normally Open 5 Amp Form A.

Pin 9 SP1 NO.

Pin 10 SP2 NO. Normally Open 5 Amp Form A.

Pin 11 SP2 NO.

Pin 12 NO CONNECTION.

Dieses Handbuch passt für folgende Modelle

Andere Texmate Messgerät Handbücher

Texmate

Texmate DL-40JANUS-SG Bedienungsanleitung

Texmate

Texmate Tiger 320 Series Konfigurationshandbuch

Texmate

Texmate FL-B101Q-HZ Bedienungsanleitung

Texmate

Texmate CM-35XTL Bedienungsanleitung

Texmate

Texmate CL-B101D40RPM Bedienungsanleitung

Texmate

Texmate BL-40PSF-ACA Bedienungsanleitung

Texmate

Texmate Tiger 320 Series Bedienungsanleitung

Texmate

Texmate Leopard Series Bedienungsanleitung

Texmate

Texmate Leopard Series Bedienungsanleitung

Texmate

Texmate BL-40PSF-PROCESS Bedienungsanleitung

Texmate

Texmate DL-40US-DCA Bedienungsanleitung

Texmate

Texmate UM-35-SG Bedienungsanleitung

Texmate

Texmate Leopard Series Bedienungsanleitung

Texmate

Texmate UM series Bedienungsanleitung

Texmate

Texmate SM-35 Bedienungsanleitung

Texmate

Texmate DL-40PSF-PROCESS Bedienungsanleitung

Texmate

Texmate PM Series Bedienungsanleitung

Texmate

Texmate UM-40-ACV Bedienungsanleitung

Texmate

Texmate DL-40 Bedienungsanleitung

Texmate

Texmate DL-40JANUS-DCA Bedienungsanleitung

Texmate

Texmate Leopard Series Bedienungsanleitung

Texmate

Texmate CL-B101D40-TCRTD Bedienungsanleitung

Texmate

Texmate Leopard Series Bedienungsanleitung

Texmate

Texmate Tiger 320 Series Betriebsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung
