Thermo

Scientific

Lab-Line

Imperial 3

General Purpose

Incubators

OPERATION AND REPAIR

MANUAL AND PARTS LIST

Model Numbers

302 311-1

Lab-Line 302-1 3111

3021 305M

302K 305M-1

302R27 305M1

305 306M

305-1 306M-1

3051 306M1

305L 310M

306 310M-1

306-1 311M

3061 311M-1

310 311M1

310-1

3101

311

Additional comments:

057-616-00

Rev K 09/03

9/03

OPERATION MANUAL

MANUAL NO. 057-616-00

REV. K

ECN 18820

LAB-LINE

IMPERIAL III GENERAL PURPOSE

INCUBATORS

MODEL NO. Gravity Convection:

302, 302-1

302K With Key Lock

302R27 With 1-Pen Recorder

305, 305-1 With Outlet

305L With Outlet and Left Hand Door

306, 306-1

310, 310-1 With Outlet

311, 311-1

Mechanical Convection:

305M, 305M-1 With Outlet

306M, 306M-1

310M, 310M-1 With Outlet

311M, 311M-1

1999 North 15th Ave., Melrose Park, IL 60160-1491 USA

PHONE: (563) 556-2241 or (800) 522-5463; FAX: (563) 589-0516

CERTIFICATION OF DECONTAMINATION:

We cannot accept for service or credit a product that has been exposed to or

contaminated with chemically or biologically toxic or infectious substances or subjected

to radioactivity without first being certified as free from said contamination.

Please have your Medical and/or Safety Officer sign this form certifying that

proper decontamination procedures have been followed to render the product safe and

free from hazards.

Any product forwarded to us which is not accompanied by this form and a proper

Return Goods Authorization Number will be returned to the sender. To obtain Return

Goods Authorization Number, contact: Customer Relations Department at 1-800/522-

5463.

We hereby certify that the LAB-LINE INSTRUMENTS, INC. product:

Model No. and Serial No. ,

which is being forwarded has been properly decontaminated and is free from all toxic hazards,

infectious agents, radioactivity and/or other hazards.

Company/Institution Name:

Street Address:

City: State Zip

Name (please print): Title

Signature:

Phone:

DECONTAMINATION PROCEDURE (Be Specific):

Nature of Hazard That Required Decontamination:

TABLE OF CONTENTS

SECTION TITLE

1 Introduction

2 Description

3 Specifications

4 Installation

5 Features

6 Operation

7 Maintenance

8 Troubleshooting

9 Service Guide

10 Replacement Parts

Warranty

SECTION1

INTRODUCTION

THANK YOU

for selecting Lab-Line Instruments for your equipment needs. For maximum value and ease of

start-up,

PLEASE PROCEED AS FOLLOWS:

• Inspect the carton and contents for shipping damage. Notify the carrier immediately if

damage is found.

• Use the Accessory Checklist when unpacking to verify that the complete unit has been

received. Do not discard packing materials until all is accounted for.

• Read this Operation Manual thoroughly before deciding upon an appropriate location for the

unit: you will want to consider the availability of power and other unit requirements, as well

as user convenience.

• Insist that every operator of this unit becomes familiar with the Operation Section of this

manual.

• Be sure to fill out the Warranty Registration Card and mail it in to Lab-Line Instruments

within seven (7) days after receiving the unit.

after reading this manual you should have any difficulties with the installation or operation

instructions, please call:

Lab-Line Customer Relations Department

(563) 556-2241 or (800) 522-5463

The information contained in this manual is the exclusive property of Lab-Line Instruments, Inc., and has been pro- vided solely

to enable the users of the equipment described herein to operate and maintain such equipment. Any other use of this information,

or the reproduction or transmission of all or any portion of this manual without prior written consent of the manufacturer is

SECTION 2

DESCRIPTION

Lab-Line Imperial III General Purpose Incubators are useful in all types of

general incubating and paraffin imbedding.

Cabinets are made of heavy-gauge steel with a powder-coated finish for optimum

appearance and easy cleaning, while the interior walls are stainless steel to spread warm-

wall radiant heat evenly throughout the chamber. Sheathed, low-watt density heaters are

in direct contact with chamber walls to allow close temperature control and quick

recovery after door openings. This arrangement also minimizes temperature gradients

and offers a large working area in the chamber.

A double set of doors, the inner of tempered glass, permits unobstructed viewing

of chamber contents without disturbing the interior environment. Slide-out shelving can

be positioned to meet user requirements.

A PID microprocessor based controller maintains chamber temperature. An over-

temperature safety thermostat controls temperature in the event of primary control failure.

A status lamp above each control is lit when the respective control is maintaining power

to the heaters.

Incubators are available in three sizes. A grounded 3-prong convenience outlet is

supplied in midsize model chambers and 2 outlets are installed in larger models. Models

are built for either 120 VAC or 240 VAC power requirements. Models 305M, 306M,

310M and 311M have the same characteristics as those listed above but, in addition,

provide mechanical convection. These models use a blower and plenum design to

circulates the air within the chamber that allows for rapid temperature and uniformity

recovery after door openings.

MODEL 302

SECTION 3

SPECIFICATIONS

POWER REQUIREMENTS:

302, 302K: 120 V, 50/60 Hz, 2.1 amps, 250 watts

302-1: 240 V, 50/60 Hz, 0.7 amps, 155 watts

305, 305L: 120 V, 50/60 Hz, 3.3 amps, 400 watts

(1 ELECTRICAL OUTLET, 120 V, 500 W TOTAL LOAD)

305M: 120 V, 60 Hz, 3.3 amps, 400 watts

305-1: 240 V, 50/60 Hz, 1.7 amps, 400 watts

(1 ELECTRICAL OUTLET, 240 V, 500 W TOTAL LOAD)

305M-1: 240 V, 50Hz, 1.7 amps, 400 watts

306: 120 V, 50/60 Hz, 3.3 amps, 400 watts

306M: 120 V, 60 Hz, 3.8 amps, 450 watts

306-1: 240 V, 50/60 Hz, 1.7 amps, 400 watts

306M-1: 240 V, 50 Hz, 1.9 amps, 450 watts

310: 120 V, 50/60 Hz, 5.0 amps, 600 watts

(2 ELECTRICAL OUTLETS, 120 V, 500 W TOTAL LOAD)

310M: 120 V, 60 Hz, 5.0 amps, 600 watts

(2 ELECTRICAL OUTLETS, 120 V, 500 W TOTAL LOAD

(2 ELECTRICAL OUTLETS, 240 V, 500 W TOTAL LOAD)

310-1: 240 V, 50/60 Hz, 2.5 amps, 600 watts

(2 ELECTRICAL OUTLETS, 240 V, 500 W TOTAL LOAD)

310M-1: 240 V, 50 Hz, 2.5 amps, 600 watts

311: 120 V, 50/60 Hz, 5.0 amps, 600 watts

311M: 120 V, 50/60 Hz, 5.8 amps, 700 watts

311-1: 240 V, 50/60 Hz, 2.5 amps, 600 watts

311M-1: 240 V, 50/60 Hz, 2.9 amps, 700 watts

TEMPERATURE RANGE: From slightly above ambient to 65ºC

UNIT DIMENSIONS:

INSIDE OUTSIDE

302 Prefix Models: 13"W x 17"D x 20"H 16"W x 21"D x 29½"H

(33 x 43 x 51 cm) (41 x 53 x 75 cm)

305 Prefix Models: 17"W x 21"D x 25"H 20"W x 25"D x 34½"H

(43 x 53 x 64 cm) (51 x 64 x 88 cm)

306 Prefix Models: 17"W x 21"D x 25"H 20"W x 25"D x 34½"H

(43 x 53 x 64 cm) (51 x 64 x 88 cm)

310 Prefix Models: 37"W x 21"D x 25"H 40½"W x 25"D x 34½"H

(94 x 53 x 64 cm) (103 x 64 x 88 cm)

311 Prefix Models: 37"W x 21"D x 25"H 40½"W x 25"D x 34½"H

(94 x 53 x 64 cm) (103 x 64 x 88 cm)

USABLE VOLUME SHELVES SHELF AREA

302 Prefix Models: 2.6 cu. ft. 2 2.8 sq. ft.

305 Prefix Models: 5.2 cu. ft. 3 6.9 sq. ft.

306 Prefix Models: 5.2 cu. ft. 3 6.9 sq. ft.

310 Prefix Models: 11.2 cu. ft. 6 13.8 sq. ft.

311 Prefix Models: 11.2 cu. ft. 6 13.8 sq. ft.

SPECIFICATIONS: (Con’t)

SHIPPING WEIGHT:

302 Prefix Models 75 lbs. (34 kg)

305, 306 Prefix Models: 120 lbs. (55 kg)

310, 311 Prefix Models: 215 lbs. (98 kg)

UNIT’S ENVIRONMENTAL OPERATING CONDITIONS:

INSTALLATION CATEGORY: II

ALTITUDE: 2000 Meters MSL (Mean Sea Level)

HUMIDITY: 80% maximum, non-condensing

ELECTRICAL SUPPLY: 120VAC or 240VAC

VOLTAGE TOLERANCE: ±10% of normal rated line

TEMPERATURE: 15ºC to 40ºC

PRODUCT USAGE: This product is intended for use indoors only

SECTION 4

INSTALLATION

√SHIPPING CARTON:

This should be inspected upon delivery. When received, carefully examine for

any shipping damage before unpacking. If damage is discovered, the delivering carrier

should both specify and sign for the damage on your copy of the delivery receipt.

Open the carton carefully making certain that all parts are accounted for before

packaging materials are discarded—after unpacking, if damage is found, promptly report

it to the carrier and request a damage inspection promptly.

IMPORTANT: Failure to request an inspection of damage within a few days after

receipt of shipment absolves the carrier from any liability for damage: you must call for a

damage inspection promptly.

LOCATION:

Place the unit on a level surface protected from drafts, strong air currents and

large fluctuations in ambient temperature. It must be located near an electrical outlet that

meets the unit nameplate requirements. Allow clearance around the unit for free air

convection, accessory equipment, and user convenience. Do not cover the vent on top of

the incubator.

LEVELING:

It is important that the unit is level before operation. DO NOT REMOVE THE

UNIT’S RUBBER FEET—they assist proper air circulation inside and outside of the

chamber. Removal can result in erratic control and excessive heat build-up beneath the

unit.

SHELF INSTALLATION:

Each shelf bracket has 2 prongs at each end for attachment to the chamber

sidewall. Insert the longer top prongs into slots of equal height on one side of the

chamber, then push the bracket up and insert the lower prongs. Push down on the bracket

to insure proper seating.

Repeat this procedure for the opposing bracket making sure it is on

the same level as the first bracket (count the slots). Install other shelf brackets in the

same way then slide shelves into place.

ELECTRICAL REQUIREMENTS:

120 VAC models require a 120 VAC, 50/60 Hz power source. They are supplied

with a 3-wire line cord. It should be plugged into an outlet designed for 3-prong plugs. If

an extension cord is used, it also should be the 3-wire grounded type. For an outlet

designed to accept 2-prong plugs (ungrounded), it is

required that a qualified electrician replace the outlet with a new grounded type.

240 VAC models require a 240 VAC, 50/60 Hz power source. Because of the variety

of plug configurations in use worldwide for 240 VAC power, the unit is furnished with the

plug removed. The user must install a plug to conform with local code and configuration

requirements. If a plug must be installed, use only the 3-prong grounded type, rated for the

unit load requirements and matching the power outlet. Make sure the green ground wire is

secured to the plug ground terminal. Disconnect unit when not in use.

SECTION 5

FEATURES

CONTROL PANEL:

1 2 3 4 5

1. POWER SWITCH: This 2-position rocker switch controls power to entire

unit. The switch is lit when power is ON.

2. CONTROL STATUS LAMP: This lamp is lit when power is being supplied to

heater and not lit when power to the heater is OFF.

3. PROGRAMMABLE CONTROLLER: Maintains chamber temperature and

provides a display of either chamber or set point temperatures.

4. OVER-TEMPERATURE STATUS LAMP: This lamp is lit when either an

over-temperature condition exists or the over-temperature thermostat is

improperly set too low.

5. OVER-TEMPERATURE THERMOSTAT: This hydraulic thermostat is set by

the operator to back up the control thermostat and safeguard the incubator.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Thermo Scientific Zubehör Handbücher

Thermo Scientific

Thermo Scientific 61-12C Service-Handbuch

Thermo Scientific

Thermo Scientific 3110 Betriebsanleitung

Thermo Scientific

Thermo Scientific 3110 Bedienungsanleitung

Thermo Scientific

Thermo Scientific 61-12N-64P Service-Handbuch

Thermo Scientific

Thermo Scientific Heracell 240i Bedienungsanleitung

Thermo Scientific

Thermo Scientific Unity Lab Services 3307 Bedienungsanleitung

Thermo Scientific

Thermo Scientific Precision 818 Betriebsanleitung

Thermo Scientific

Thermo Scientific AquaSensors AnalogPlus 1.0 Bedienungsanleitung

Thermo Scientific

Thermo Scientific 3403 Bedienungsanleitung

Thermo Scientific

Thermo Scientific Neslab Dimax Bedienungsanleitung

Thermo Scientific

Thermo Scientific RMI300S-9-A Betriebsanleitung

Thermo Scientific

Thermo Scientific 30M Betriebsanleitung

Thermo Scientific

Thermo Scientific Heracell 150i Bedienungsanleitung

Thermo Scientific

Thermo Scientific 3554-35A Montage- und Wartungsanleitung

Thermo Scientific

Thermo Scientific Steri-Cycle i160 CR Bedienungsanleitung

Thermo Scientific

Thermo Scientific 370 Betriebsanleitung

Thermo Scientific

Thermo Scientific Emerald Wireless Remote Sensor Betriebsanleitung

Thermo Scientific

Thermo Scientific 314 Bedienungsanleitung

Thermo Scientific

Thermo Scientific HERACELL VIOS 160i Bedienungsanleitung

Thermo Scientific

Thermo Scientific Smart-Vue Gebrauchs- und Pflegehandbuch

Thermo Scientific

Thermo Scientific 8000DH Series Bedienungsanleitung

Thermo Scientific

Thermo Scientific invitrogen EVOS OSI-2 Bedienungsanleitung

Thermo Scientific

Thermo Scientific Cytomat 2 Bedienungsanleitung

Thermo Scientific

Thermo Scientific Thermo Fisher 3900 Series Betriebsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

Panasonic

Panasonic HG-T Series Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung
