Thrustmaster T-x3 Battery Grip Bedienungsanleitung

1/10

For PSP™/ PSP™ Slim & Lite

User Manual

TECHNICAL FEATURES

1. Articulated mounting system via 2 screws

2. DC IN 5V connector (to recharge the Battery Grip)

3. Retractable DC OUT cable (to recharge the PSP™

in the "Closed" position)

4. Enclosed DC OUT cable (to recharge the PSP™ in

the "Open" position)

5. Charging LED

- Red = charging

- Green = charge complete

6. Cable storage compartment cover

WARNING

xBefore using this product, please read this document carefully and hold on to it for later consultation.

xKeep your Battery Grip in a dry place and do not expose it to dust or sunlight.

xMake sure to respect polarities and charging times.

xDo not twist or pull too strongly on the connectors and cables.

xDo not spill liquid on the Battery Grip and its connectors.

xDo not short-circuit the Battery Grip.

xNever recharge the Battery Grip with any accessory other than the 5V power adapter included with

your PSP™.

xNever remove your PSP™ console's internal battery when recharging via the Battery Grip.

xNever dismantle, attempt to burn or expose the Battery Grip to high temperatures.

BEFORE USING YOUR T-X3 BATTERY GRIP FOR THE FIRST TIME:

WE STRONGLY RECOMMEND THAT YOU GIVE YOUR T-X3 BATTERY GRIP

A FULL CHARGE BEFORE USING IT FOR THE FIRST TIME.

2/10

3/10

RECHARGING THE T-X3 BATTERY GRIP

-Connect your PSP™ console's AC ADAPTOR 5V power adapter to the DC IN (2) connector on the

Battery Grip.

The charging LED (5) on the Battery Grip lights up.

-Average length of time for a full charge: 3 hours.

T-X3 BATTERY GRIP CHARGING LED

xRed LED = the battery is recharging.

xGreen LED = the battery is fully charged.

IMPORTANT NOTE: To achieve maximum battery life, you should also recharge your Sony® PSP™

console fully AND separately using the console's power adapter.

INSTALLING THE T-X3 BATTERY GRIP ON YOUR PSP™

1) Turn the articulated mounting system (1) on the Battery Grip 90° in order to access the 2 mounting

screws.

2) If you have a PSP™ 1000 Series model (older generation), position the screen of your PSP™

console on the side marked 1000 - TOP:

4/10

5/10

If you have a PSP™ 2000 Series model (Slim & Lite), position the screen of your PSP™ console on

the side marked 2000 - TOP:

4) Insert the tips of the 2 mounting screws into the 2 corresponding openings on your PSP™.

5) Tighten the 2 screws so that the entire unit is perfectly stable, using a flat head screwdriver if

necessary.

USING THE DC OUT CABLES

The T-X3 Battery Grip features 2 DC OUT cables, allowing you to recharge your PSP™ in 3 different

positions (Open, Stand or Closed).

xRetractable DC OUT cable (3)

(located on the right-hand side of the Battery Grip)

-Remove the connector from its dedicated spot and pull it out gently to bring out the cable.

-Do the reverse after use to store the cable again.

xEnclosed DC OUT cable (4)

(located on the left-hand side of the Battery Grip)

-Open the cable storage compartment cover (the one with OPEN written on it).

-Remove the connector and thread the cable through the corresponding notch.

-Close the cable storage compartment cover.

-Do the reverse after use to store the cable again.

6/10

3 POSITION MECHANICAL SYSTEM TO RECHARGE YOUR PSP™

To switch from one position to another, simply turn your Battery Grip 180°.

xRecharging in the Open (for gaming) or Stand (for watching videos) positions:

-Connect the enclosed DC OUT cable (4) to the DC IN connector on your PSP™.

xRecharging in the Closed position (to protect the screen and for transportation):

-Connect the retractable DC OUT cable (3) to the DC IN connector on your PSP™.

NOTE:

THE CHARGING LED (5) ON THE BATTERY GRIP ONLY LIGHTS UP WHEN THE BATTERY GRIP IS

BEING CHARGED.

7/10

TECHNICAL SUPPORT

If you encounter a problem with your product, please go to http://ts.thrustmaster.com and click Technical

Support. From there you will be able to access various utilities (Frequently Asked Questions (FAQ), the

latest versions of drivers and software) that may help to resolve your problem. If the problem persists, you

can contact the Thrustmaster products technical support service (“Technical Support”):

By email:

In order to take advantage of technical support by email, you must first register online. The information you

provide will help the agents to resolve your problem more quickly. Click Registration on the left-hand side

of the Technical Support page and follow the on-screen instructions. If you have already registered, fill in

the Username and Password fields and then click Login.

By telephone:

United

Kingdom 08450800942

Charges at local rate

Monday to Friday from Noon to 4pm and 5pm to 10pm

Saturday from 9am to Noon and 1pm to 7pm

Sunday from 9am to Noon and 1pm to 4pm

United

States 1-866-889-5036

Free

Monday to Friday from 7am to 11am and from Noon to 5pm

Saturday and Sunday from 7am to Noon

(Eastern Standard Time)

Canada 1-866-889-2181

Gratuit / Free

Monday to Friday from 7am to 11am and from Noon to 5pm

Saturday and Sunday from 7am to Noon

(Eastern Standard Time)

Denmark 80887690

Free

Monday to Friday from 1pm to 5pm and 6pm to 11pm (English)

Saturday from 9am to 1pm and 2pm to 8pm

Sunday from 10am to 1pm and 2pm to 5pm

Sweden 0200884567

Free

Monday to Friday from 1pm to 5pm and 6pm to 11pm (English)

Saturday from 9am to 1pm and 2pm to 8pm

Sunday from 10am to 1pm and 2pm to 5pm

Finland 0800 913060

Free

Monday to Friday from 2pm to 6pm and 7pm to Midnight (English)

Saturday from 10am to 2pm and 3pm to 9pm

Sunday from 11am to 2pm and 3pm to 6pm

8/10

9/10

WARRANTY INFORMATION

Worldwide, Guillemot Corporation S.A. (“Guillemot”) warrants to the consumer that this Thrustmaster product will be free

from material defects and manufacturing flaws for a period of two (2) years from the original date of purchase. Should the

product appear to be defective during the warranty period, immediately contact Technical Support, who will indicate the

procedure to follow. If the defect is confirmed, the product must be returned to its place of purchase (or any other location

indicated by Technical Support).

Within the context of this warranty, the consumer’s defective product will, at Technical Support’s option, be either repaired or

replaced. Where authorized by applicable law, the full liability of Guillemot and its subsidiaries (including for indirect

damages) is limited to the repair or replacement of the Thrustmaster product. The consumer’s legal rights with respect to

legislation applicable to the sale of consumer goods are not affected by this warranty.

This warranty shall not apply: (1) if the product has been modified, opened, altered, or has suffered damage as a result of

inappropriate or abusive use, negligence, an accident, normal wear, or any other cause not related to a material defect or

manufacturing flaw; (2) in the event of failure to comply with the instructions provided by Technical Support; (3) to software

not published by Guillemot, said software being subject to a specific warranty provided by its publisher.

Additional warranty provisions

In the United States of America and in Canada, this warranty is limited to the product’s internal mechanism and external

housing. Any applicable implied warranties, including warranties of merchantability and fitness for a particular purpose, are

hereby limited to two (2) years from the date of purchase and are subject to the conditions set forth in this limited warranty.

In no event shall Guillemot Corporation S.A. or its affiliates be liable for consequential or incidental damage resulting from

the breach of any express or implied warranties. Some States/Provinces do not allow limitation on how long an implied

warranty lasts or exclusion or limitation of incidental/consequential damages, so the above limitation may not apply to you.

This warranty gives you specific legal rights, and you may also have other legal rights which vary from State to State or

Province to Province.
