TOPMAQ BJ1513 Bedienungsanleitung
Ash Vacuum Cleaner Operation Manual
BJ1513
The appliance is dry pick-up usage only
Attention: Please read this manual carefully before installing and usage.
The important instruction:
•Check whether or not the local power supply mains matches the appliance
electric rating printed on the label before operation.
•When the appliance is not in operation, please remove plug from supply
mains.
•The plug must be removed from the socket-outlet before cleaning or
maintaining the appliance
•Don't remove the plug by pulling the power cord.
•Do not leave the appliance alone when the appliance is in work.
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision
•Don't press and roll the power cord by heavy objects.
•If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
•Don't vacuum the objects as follows: liquid, inflammable and explosive
dangerous material, corrosive material and burning ash, match, and cigarette.
•Do not use the appliance to vacuum the dust harmful to health.
•Keep the appliance in dry environment.
•Don't touch the live parts in appliance.
•Only to repair the appliance by the manufacturer or its authorized service
agent.
•Do not use appliance for other than intended use.
•Pay more attention when cleaning the stairs.
•Use the accessories and spare parts only supplied by the manufacturer or its
authorized service agent.
•When use the appliance to vacuum fireplace ash, No ashes with a
temperature more than 40°C shall be vacuumed, No ashes and other objects that
the fire is not completely extinguished shall be vacuumed.
•Do not use the appliance if the filter is not installed! Do not use other filters
except the ones (fire prevention filter) attached to the appliance by manufacturer.
•For cold ash only, “Cold Ash” is ash cooled down for a sufficient time without
any pockets of embers inside. This can be confirmed by scouring the ash for pockets
of embers by using metal tools before using the ash vacuum cleaner. Cold ash does
not emit any recognizable heat.
•Substance to be vacuumed - cold ashes from fireplaces, wood/coal stoves,
ashtrays, grill.
•Empty and clean vacuum cleaner before and after vacuuming to avoid the
collection of materials that could pose a fire hazard in the vacuum cleaner.
•Do not use for the separation of health-hazardous dusts (dust classes M)
•Do not vacuum soot
•Vacuum only ashes from admissible fuels
•Do not vacuum any hot, burning or glowing objects
•Do not vacuum any objects that are hotter than > 40 °C
•Do not vacuum any flammable substances
•For ash pre-separators:
max. admissible volume flow:
max . admissible under pressure:
1
The function of the parts:
•Aluminum pipe: Used to vacuum ash in the fireplace (Fig. A2)
•Power switch: Control the appliance to work or stop working
I. 1）Installation of the vacuum cleaner
•Take out the appliance and accessories from the packing box, check the
accessories and whether the appliance enclosure is well-found or not. (Fig. A1)
•Loose the clasp, and take the head part from the container.
•Attach the filter set to the bottom of head part.
Fig. A3
Fig. A2
Fig. A1
9
8
3
6
2
4
5
7
1.Handle
2.Cover
3.Power switch
4.
Air inlet
5.Soft hose
6.Tank
7.Aluminium tube
8.Fire prevention
filter
9.Fire prevention
HEPA filter
•Put the head part on the container and use the clasp to make it fixed.
•Insert the aluminum pipe into the soft tube, and another end of soft tube is
inserted into air inlet. (Fig. A1)
2) Installation of Blowing function uses
• As shown in the picture, put ①into the air outlet④and tighten it to
•the left.Put aluminum tube③into ②
II. Vacuum ash
•Only use the fire prevention filter.
•When the container is full or it feels difficult to vacuum more dust, the filter
needs to be taken out and cleaned.
•While vacuum the fireplace ash, the ash temperature must be below 40°C.
Do not vacuum the ashs that fire is not extingished! (Fig. A2)
III. After the usage (Fig. A3)
•Press the switch to turn off vacuum cleaner.
•Pull out plug.
•Roll up the power cable.
•Disassemble the soft tube from the appliance.
•Take the head part from the appliance.
•Empty the dust container and wash it.
•Use rag to dry the container.
•Take out the filter, clean and wash it carefully, and dry it in air before installed
on vacuum cleaner. (Fig. A3)
IV. Maintenance (Fig. A3)
•The container and outer shell of head part need to be cleaned frequently.
②③
④
①
•The dirty container should wash with the clear water clearly.
•The filter should wash with the clear water clearly.
•If the appliance working unsatisfactory, it is usually resulted from the jam of
soft tube or conjunction of pipes or accessories. In that case, please clean the parts
concerned.
V. Correct Disposal of this product
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe
recycling.
VI. Warranty Information
The manufacturer provides warranty in accordance with the legislation of the
customer's own country of residence, with a minimum of 1 year (Germany: 2 years),
starting from the date on which the appliance is sold to the end user.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service centre.
When making a claim under the warranty, the original bill of purchase (with
purchase date) must be submitted.
The warranty will not apply in cases of:
- Normal wear and tear
- Incorrect use, e.g. overloading of the appliance, use of non-approved accessories
- Use of force, damage caused by external influences
- Damage caused by non-observance of the user manual, e.g. connection to an
unsuitable mains supply or non-compliance with the installation instructions
- Partially or completely dismantled appliances
Tech-date
Model Power Voltage Frequency
BJ131 600W/800W/1000W/1200W AC220V-240V 50/60HZ
